1.attention UNet结构图中AG为attention gate，c为concat拼接，设输入为512×512大小
AG的结构：
from torch import nn
from torch.nn import functional as F
import torch
from torchvision import models
import torchvision
class conv_block(nn.Module):
def __init__(self,ch_in,ch_out):
super(conv_block,self).__init__()
self.conv = nn.Sequential(
nn.Conv2d(ch_in, ch_out, kernel_size=3,stride=1,padding=1,bias=True),
nn.BatchNorm2d(ch_out),
nn.ReLU(inplace=True),
nn.Conv2d(ch_out, ch_out, kernel_size=3,stride=1,padding=1,bias=True),
nn.BatchNorm2d(ch_out),
nn.ReLU(inplace=True)
)
def forward(self,x):
x = self.conv(x)
return x
class up_conv(nn.Module):
def __init__(self,ch_in,ch_out):
super(up_conv,self).__init__()
self.up = nn.Sequential(
nn.Upsample(scale_factor=2),
nn.Conv2d(ch_in,ch_out,kernel_size=3,stride=1,padding=1,bias=True),
nn.BatchNorm2d(ch_out),
nn.ReLU(inplace=True)
)
def forward(self,x):
x = self.up(x)
return x
class Attention_block(nn.Module):
def __init__(self, F_g, F_l, F_int):
super(Attention_block, self).__init__()
self.W_g = nn.Sequential(
nn.Conv2d(F_g, F_int, kernel_size=1, stride=1, padding=0, bias=True),
nn.BatchNorm2d(F_int)
)
self.W_x = nn.Sequential(
nn.Conv2d(F_l, F_int, kernel_size=1, stride=1, padding=0, bias=True),
nn.BatchNorm2d(F_int)
)
self.psi = nn.Sequential(
nn.Conv2d(F_int, 1, kernel_size=1, stride=1, padding=0, bias=True),
nn.BatchNorm2d(1),
nn.Sigmoid()
)
self.relu = nn.ReLU(inplace=True)
def forward(self, g, x):
# 下采样的gating signal 卷积
g1 = self.W_g(g)
# 上采样的 l 卷积
x1 = self.W_x(x)
# concat + relu
psi = self.relu(g1 + x1)
# channel 减为1，并Sigmoid,得到权重矩阵
psi = self.psi(psi)
# 返回加权的 x
return x * psi
class AttU_Net(nn.Module):
def __init__(self, img_ch=3, output_ch=1):
super(AttU_Net, self).__init__()
self.Maxpool = nn.MaxPool2d(kernel_size=2, stride=2)
self.Conv1 = conv_block(ch_in=img_ch, ch_out=64)
self.Conv2 = conv_block(ch_in=64, ch_out=128)
self.Conv3 = conv_block(ch_in=128, ch_out=256)
self.Conv4 = conv_block(ch_in=256, ch_out=512)
self.Conv5 = conv_block(ch_in=512, ch_out=1024)
self.Up5 = up_conv(ch_in=1024, ch_out=512)
self.Att5 = Attention_block(F_g=512, F_l=512, F_int=256)
self.Up_conv5 = conv_block(ch_in=1024, ch_out=512)
self.Up4 = up_conv(ch_in=512, ch_out=256)
self.Att4 = Attention_block(F_g=256, F_l=256, F_int=128)
self.Up_conv4 = conv_block(ch_in=512, ch_out=256)
self.Up3 = up_conv(ch_in=256, ch_out=128)
self.Att3 = Attention_block(F_g=128, F_l=128, F_int=64)
self.Up_conv3 = conv_block(ch_in=256, ch_out=128)
self.Up2 = up_conv(ch_in=128, ch_out=64)
self.Att2 = Attention_block(F_g=64, F_l=64, F_int=32)
self.Up_conv2 = conv_block(ch_in=128, ch_out=64)
self.Conv_1x1 = nn.Conv2d(64, output_ch, kernel_size=1, stride=1, padding=0)
self.sigmoid = nn.Sigmoid()
def forward(self, x):
# encoding path
x1 = self.Conv1(x) # [64,512,512]
x2 = self.Maxpool(x1) # [64,256,256]
x2 = self.Conv2(x2) # [128,256,256]
x3 = self.Maxpool(x2) # [128,128,128]
x3 = self.Conv3(x3) # [256,128,128]
x4 = self.Maxpool(x3) # [256,64,64]
x4 = self.Conv4(x4) # [512,64,64]
x5 = self.Maxpool(x4) # [512,32,32]
x5 = self.Conv5(x5) # [1024,32,32]
# decoding + concat path
d5 = self.Up5(x5) # [512,64,64]
x4 = self.Att5(g=d5, x=x4) # [512,64,64],[512,64,64]
d5 = torch.cat((x4, d5), dim=1) # [1024,64,64]
d5 = self.Up_conv5(d5) # [512,64,64]
d4 = self.Up4(d5) # [256,128,128]
x3 = self.Att4(g=d4, x=x3) # [256,128,128],[256,128,128]
d4 = torch.cat((x3, d4), dim=1) # [512,128,128]
d4 = self.Up_conv4(d4) # [256,128,128]
d3 = self.Up3(d4) # [128,256,256]
x2 = self.Att3(g=d3, x=x2) # [128,256,256],[128,256,256]
d3 = torch.cat((x2, d3), dim=1) # [256,256,256]
d3 = self.Up_conv3(d3) # [128,256,256]
d2 = self.Up2(d3) # [64,512,512]
x1 = self.Att2(g=d2, x=x1) # [64,512,512],[64,512,512]
d2 = torch.cat((x1, d2), dim=1) # [128,512,512]
d2 = self.Up_conv2(d2) # [64,512,512]
d1 = self.Conv_1x1(d2) # [2,512,512]
d1 = self.sigmoid(d1) # [2,512,512]
return d1
