centos/docker下载安装elasticsearch、kibana及ik分词器

• 前言
• 本地安装
• • 安装elasticsearch
  • 安装kibana
• docker安装
• • 安装elasticsearch
  • 安装kibana
• ik分词器安装
• • 下载安装
  • 自定义扩展分词库

环境准备：
系统：centos7.x；
jdk版本：1.8.x；
注意：一定要保证所有软件（ELK、IK）版本一致，否则会报错。

• 下载

官网下载

• 上传解压

tar -zxvf xxx.tar.gz

• 后台启动

sh /usr/local/es/elasticsearch-7.17.3/bin/elasticsearch -d

报错

原因是elasticsearch 默认是不支持用root用户来启动的。正式环境用root运行可能会有安全风险，不建议用root来跑。推荐解决方案：添加专门的用户

• 添加用户

useradd elastic
passwd elastic

• 改变es目录拥有者账号

chown -R elastic /usr/local/es/elasticsearch-7.17.3/

• 配置
  由于我用的虚拟机，所以要对内存做一些限制，开放es外部也能访问，而且要避免一些报错。
  报错如下

  编辑config目录下的编辑config目录下的elasticsearch.yml文件

vim /usr/local/es/elasticsearch-7.17.3/config/elasticsearch.yml

修改了7个地方

# ======================== Elasticsearch Configuration =========================
#
# NOTE: Elasticsearch comes with reasonable defaults for most settings.
#       Before you set out to tweak and tune the configuration, make sure you
#       understand what are you trying to accomplish and the consequences.
#
# The primary way of configuring a node is via this file. This template lists
# the most important settings you may want to configure for a production cluster.
#
# Please consult the documentation for further information on configuration options:
# https://www.elastic.co/guide/en/elasticsearch/reference/index.html
#
# ---------------------------------- Cluster -----------------------------------
#
# Use a descriptive name for your cluster:
#
cluster.name: my-application
#
# ------------------------------------ Node ------------------------------------
#
# Use a descriptive name for the node:
#
node.name: node-1
#
# Add custom attributes to the node:
#
#node.attr.rack: r1
#
# ----------------------------------- Paths ------------------------------------
#
# Path to directory where to store the data (separate multiple locations by comma):
#
path.data: /usr/local/es/elasticsearch-7.17.3/data
#
# Path to log files:
#
path.logs: /usr/local/es/elasticsearch-7.17.3/logs
#
# ----------------------------------- Memory -----------------------------------
#
# Lock the memory on startup:
#
#bootstrap.memory_lock: true
#
# Make sure that the heap size is set to about half the memory available
# on the system and that the owner of the process is allowed to use this
# limit.
#
# Elasticsearch performs poorly when the system is swapping the memory.
#
# ---------------------------------- Network -----------------------------------
#
# By default Elasticsearch is only accessible on localhost. Set a different
# address here to expose this node on the network:
#
network.host: 0.0.0.0
#
# By default Elasticsearch listens for HTTP traffic on the first free port it
# finds starting at 9200. Set a specific HTTP port here:
#
http.port: 9200
#
# For more information, consult the network module documentation.
#
# --------------------------------- Discovery ----------------------------------
#
# Pass an initial list of hosts to perform discovery when this node is started:
# The default list of hosts is ["127.0.0.1", "[::1]"]
#
#discovery.seed_hosts: ["host1", "host2"]
#
# Bootstrap the cluster using an initial set of master-eligible nodes:
#
cluster.initial_master_nodes: ["node-1"]
#
# For more information, consult the discovery and cluster formation module documentation.
#
# ---------------------------------- Various -----------------------------------
#
# Require explicit names when deleting indices:
#
#action.destructive_requires_name: true
#
# ---------------------------------- Security ----------------------------------
#
#                                 *** WARNING ***
#
# Elasticsearch security features are not enabled by default.
# These features are free, but require configuration changes to enable them.
# This means that users don’t have to provide credentials and can get full access
# to the cluster. Network connections are also not encrypted.
#
# To protect your data, we strongly encourage you to enable the Elasticsearch security features.
# Refer to the following documentation for instructions.
#
# https://www.elastic.co/guide/en/elasticsearch/reference/7.16/configuring-stack-security.html

elasticsearch用户拥有的内存权限太小，至少需要262144。切换root用户下，使用vim /etc/sysctl.conf命令编辑sysctl.conf文件

vm.max_map_count=262144

因为 es 不允许使用root用户安装，在使用新建的es用户安装的时候报错如下，

max file descriptors [4096] for elasticsearch process is too low, increase to at least [65535]

将当前用户的软硬限制调大。找到文件 /etc/security/limits.conf，编辑，在文件的最后追加如下配置，注意elastic 改成你自己运行elasticsearch的用户。

elastic hard nofile 65536
elastic soft nofile 65536

• 开放端口

# 开启防火墙
systemctl start firewalld
# 开放指定端口 不加--permanent也是临时开放
firewall-cmd --zone=public --add-port=9200/tcp --permanent
# 重启防火墙
firewall-cmd --reload
# 查看
firewall-cmd --zone=public --query-port=9200/tcp
# 删除
firewall-cmd --zone=public --remove-port=9200/tcp --permanent

• 切换账号，重新启动

su elastic

• 访问测试：http://192.168.25.131:9200

  成功！！！

• 下载压缩包

官网下载

• 安装
  上传并解压

tar -zxvf xxx.tar.z

• 配置
  编辑kibana.yml文件，开放访问和切换中文

#取消server.port端口、server.host网络和elasticsearch地址ip注释,并修改
server.port: 5601

server:host:"0.0.0.0"

elasticsearch.hosts: ["http://localhost:9200"]

#修改中文
i18n.locale: "zh-CN"

注意root用户无法启动Kibana，需要对其他用户进行授权

#root账户下操作

#改变es目录拥有者账号
chown -R estest /usr/local/kibana/kibana-7.17.3-linux-x86_64/

#还需要设置访问权限
chmod -R 777 /usr/local/kibana/kibana-7.17.3-linux-x86_64/

切换账号登录

su elastic
# 后台启动
nohup ./bin/kibana &

连接测试：http://192.168.25.131:5601
注意，这个版本安装完成之后，用chrome浏览器打不开，换了其他浏览器才能连接上

镜像地址

• 拉取镜像

docker pull elasticsearch:7.17.3

• 配置挂载数据文件夹

# 创建配置文件目录
mkdir -p /mydata/elasticsearch/config

# 创建数据目录
mkdir -p /mydata/elasticsearch/data

# 将/mydata/elasticsearch/文件夹中文件都可读可写
chmod -R 777 /mydata/elasticsearch/

# 配置任意机器可以访问 elasticsearch
echo "http.host: 0.0.0.0" >/mydata/elasticsearch/config/elasticsearch.yml

• 启动容器

docker run --name elasticsearch -p 9200:9200 -p 9300:9300
-e  "discovery.type=single-node"
-e ES_JAVA_OPTS="-Xms64m -Xmx512m"
-v /mydata/elasticsearch/config/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml
-v /mydata/elasticsearch/data:/usr/share/elasticsearch/data
-v  /mydata/elasticsearch/plugins:/usr/share/elasticsearch/plugins
-d elasticsearch:7.17.3

# 自动启动也设置一下
docker update elasticsearch --restart=always

访问测试
浏览器输入：192.168.25.131:9200

• 拉取镜像

docker pull kibana:7.17.3

• 启动容器

docker run --name kibana
-e ELASTICSEARCH_HOSTS=http://192.168.25.131:9200
-p 5601:5601
-d kibana:7.17.3

docker update kibana --restart=always

-e ELASTICSEARCH_HOSTS=http://192.168.25.131:9200: 这里要设置成自己的虚拟机IP地址

• 访问测试
  浏览器输入：192.168.25.131:5601


• 下载

下载地址

• 上传
  上传到外部挂载目录plugins，解压之后删除压缩包即可，如果是直接安装，那就直接上传到es对用的插件文件夹plugins中。
• 重启es
  这里我遇到一个问题，restart es之后总是提示内存不足，导致无法启动，解决办法：停止es容器并删除，按照上边的docker run命令再启动一下es，可能是因为装了ik插件，导致重启变成默认占用内存了，我用的虚拟机，内存只有2g。

vim /mydata/elasticsearch/plugins/ik/config/IKAnalyzer.cfg.xml

建一个文件 fenci.txt，放在nginx的html路径下，即可实现远程扩展字典，当然也可以放在本地，远程会方便修改

        IK Analyzer 扩展配置






        http://192.168.25.131/fenci.txt



重启

docker restart elasticsearch
