用pygame编写单人RPG小游戏（二）

• 介绍
• 二、绘制地图并移动
• • 在地图上的移动

在 上一讲 中介绍了如何构建游戏地图界面，并实现鼠标移动到消息框上时高亮显示该信息框，在这一讲中将介绍绘制地图、加载英雄头像图片，并用鼠标控制英雄移动。

地图为网格状，宽高为40 x 40像素，英雄头像为一个jpg图片，宽和高均为40像素，如下图所示。

这个界面实现的原理是用双重for循环，在屏幕不断地画出网格。为此在Game.py的display_map()方法中添加以下代码：

	# 会遇到怪的区域
	for i in range(0, GameConst.MapBlock_X):
			position = 0, GameConst.MapBlockSize*i, GameConst.MapBlockSize, GameConst.MapBlockSize
			pygame.draw.rect(self.DISPLAYSURF, RGB.Red2, position, 0)
			position = GameConst.MapBox[2]-GameConst.MapBlockSize, GameConst.MapBlockSize*i, GameConst.MapBlockSize, GameConst.MapBlockSize
			pygame.draw.rect(self.DISPLAYSURF, RGB.Red2, position, 0)
			position = GameConst.MapBlockSize*i, GameConst.MapBox[3]-GameConst.MapBlockSize, GameConst.MapBlockSize, GameConst.MapBlockSize
			pygame.draw.rect(self.DISPLAYSURF, RGB.Red2, position, 0)

		# 画出网格
		for i in range(0, GameConst.MapBlock_X):
			width = 1
			# 横
			start = 0, (i+1)*GameConst.MapBlockSize
			end = GameConst.MapBox[2], (i+1)*GameConst.MapBlockSize
			pygame.draw.line(self.DISPLAYSURF, RGB.SlateGrey, start, end, width)

			# 竖
			start = (i+1)*GameConst.MapBlockSize, 0
			end = (i+1)*GameConst.MapBlockSize, GameConst.MapBox[2]
			pygame.draw.line(self.DISPLAYSURF, RGB.SlateGrey, start, end, width)

然后加载英雄头像，英雄一开始的XY坐标设置为(0, 0)。
为此，在Player类的__init__()方法中添加记录头像图片左上角坐标的变量，并把它们设置为player对象的X和Y属性，并添加一个相关的draw_player_image()方法，根据player对象的X和Y属性绘制头像图片。

		# 载入英雄头像
		self.master_image = pygame.image.load(GameConst.player_image).convert_alpha()
		# 记录头像左上角的坐标
		self.image_x = 0
		self.image_y = 0

	def _getx(self): return self.image_x
	def _setx(self, value): self.image_x= value
	X = property(_getx, _setx)

	def _gety(self): return self.image_y
	def _sety(self, value): self.image_y= value
	Y = property(_gety, _sety)

	def draw_player_image(self, game):
		game.DISPLAYSURF.blit(self.master_image, (self.X, self.Y))

然后在Game类的display_map()方法中添加调用绘制英雄头像方法的语句。

def display_map(self, player, game):
	...
		# 绘制英雄头像
			player.draw_player_image(game)

程序运行结果如图所示。

现在想要让英雄头像随着鼠标的点击移动起来，即，鼠标在地图上英雄的上、下、左、右侧点击时，英雄会向上、下、左、右方向移动一格。为此，首先实现鼠标移动到地图上英雄的上、下、左、右侧时，高亮可点击的区域；在Game类的respond_to_mouse_motion()方法中添加如下代码：

				leftrect = pygame.Rect(0, player.Y, player.X, GameConst.MapBlockSize)
				if leftrect.collidepoint(x, y):
					left, top, width, height = leftrect
					pygame.draw.rect(self.DISPLAYSURF, RGB.GhostWhite, (left, top, width+5, height+5), 4)
				rightrect = pygame.Rect(player.X + GameConst.MapBlockSize, player.Y, GameConst.MapBox[2] - player.X - GameConst.MapBlockSize, GameConst.MapBlockSize)
				if rightrect.collidepoint(x, y):
					left, top, width, height = rightrect
					pygame.draw.rect(self.DISPLAYSURF, RGB.GhostWhite, (left, top, width+5, height+5), 4)
				uprect = pygame.Rect(player.X, 0, GameConst.MapBlockSize, player.Y)
				if uprect.collidepoint(x, y):
					left, top, width, height = uprect
					pygame.draw.rect(self.DISPLAYSURF, RGB.GhostWhite, (left, top, width+5, height+5), 4)
				downrect = pygame.Rect(player.X, player.Y + GameConst.MapBlockSize, GameConst.MapBlockSize, GameConst.MapBox[3] - player.Y - GameConst.MapBlockSize)

这段代码的意思就是根据英雄头像所处的位置，在其上、下、左、右生成四个矩形，当鼠标移动到其中时就高亮该矩形，如图所示。

接着实现英雄在地图上的移动，在Player类中添加move()方法，然后在Game类的respond_to_click()方法中调用该方法。

	def move(self, direction, hero, game):
		''' 英雄头像在地图上的移动。'''
		if self.game_process == GameConst.WALKING_ON_THE_MAP:
			game.clear_message()
			if direction == 'down':
				if self.Y <= 320:
					self.Y += 40
					hero.y_coordinate += 1
					self.is_moved = 1
				else:
					self.is_moved = 2
			elif direction == 'up':
				if self.Y >= 40:
					self.Y -= 40
					hero.y_coordinate -= 1
					self.is_moved = 1
				else:
					self.is_moved = 2
			elif direction == 'left':
				if self.X >= 40:
					self.X -= 40
					hero.x_coordinate -= 1
					self.is_moved = 1
				else:
					self.is_moved = 2
			elif direction == 'right':
				if self.X <= 320:
					self.X += 40
					hero.x_coordinate += 1
					self.is_moved = 1
				else:
					self.is_moved = 2
			else:
				self.is_moved = 0

在Game类的respond_to_click()方法中调用Player.move()方法。

				MapBox = pygame.Rect(GameConst.MapBox)
				if MapBox.collidepoint(x, y):
					leftrect = pygame.Rect(0, player.Y, player.X, GameConst.MapBlockSize)
					rightrect = pygame.Rect(player.X + GameConst.MapBlockSize, player.Y, GameConst.MapBox[2] - player.X - GameConst.MapBlockSize, GameConst.MapBlockSize)
					uprect = pygame.Rect(player.X, 0, GameConst.MapBlockSize, player.Y)
					downrect = pygame.Rect(player.X, player.Y + GameConst.MapBlockSize, GameConst.MapBlockSize, GameConst.MapBox[3] - player.Y - GameConst.MapBlockSize)
					if leftrect.collidepoint(x, y):
						player.move('left', hero, game)
					elif rightrect.collidepoint(x, y):
						player.move('right', hero, game)
					elif uprect.collidepoint(x, y):
						player.move('up', hero, game)
					elif downrect.collidepoint(x, y):
						player.move('down', hero, game)

运行结果如图所示：

完整的代码已经上传到GitCode：class2 · master · 下唐人 / magic_tower_chapter_0 · GitCode
