SpringBoot整合RocketMQ搭建集群详细步骤

文章目录

• RocketMQ
• • 1、重试策略
  • • 1.1 producer端重试
• 1.2 consumer端重试
• • • 1.2.1 exception
  • 2、RocketMQ的集群
  • • 2.1 集群模式
  • 2.2 搭建2m2s集群
  • • 搭建集群：
  • 3、SprinBoot整合RocketMQ
  • • 3.1、导入依赖
    • 3.2、编写application.properties配置文件
    • 3.3、生产者发送消息
    • 3.4、消费消息
    • 3.5、编写启动类
    • 3.6、编写测试用例
    • 3.7、测试
    • 3.8、事务消息
    • • 3.8.1、定义TransactionListenerImpl
      • 3.8.2、定义生产者
      • 3.8.3、消费者（没有变化）
      • 3.8.4、编写测试用例
      • 3.8.5、测试

---

RocketMQ 1、重试策略

在消息的发送和消费过程中，都有可能出现错误，如网络异常等，出现了错误就需要进行错误重试，这种消息的重
试需要分2种，分别是producer端重试和consumer端重试。

1.1 producer端重试

生产者端的消息失败，也就是Producer往MQ上发消息没有发送成功，比如网络抖动导致生产者发送消息到MQ失
败。

package cn.itcast.rocketmq;
import org.apache.rocketmq.client.producer.DefaultMQProducer;
import org.apache.rocketmq.client.producer.SendResult;
import org.apache.rocketmq.common.message.Message;
import org.apache.rocketmq.remoting.common.RemotingHelper;

public class SyncProducer {
	public static void main(String[] args) throws Exception {
		DefaultMQProducer producer = new DefaultMQProducer("HAOKE_IM");
		producer.setNamesrvAddr("172.16.55.185:9876");
		//消息发送失败时，重试3次
		producer.setRetryTimesWhenSendFailed(3);
		producer.start();
		String msgStr = "用户A发送消息给用户B";
		Message msg = new Message("haoke_im_topic","SEND_MSG",
		msgStr.getBytes(RemotingHelper.DEFAULT_CHARSET));
		// 发送消息,并且指定超时时间
		SendResult sendResult = producer.send(msg, 1000);
		System.out.println("消息状态：" + sendResult.getSendStatus());
		System.out.println("消息id：" + sendResult.getMsgId());
		System.out.println("消息queue：" + sendResult.getMessageQueue());
		System.out.println("消息offset：" + sendResult.getQueueOffset());
		System.out.println(sendResult);
		producer.shutdown();
	}
}

1.2 consumer端重试

消费者端的失败，分为2种情况，一个是exception，一个是timeout。

1.2.1 exception

消息正常的到了消费者，结果消费者发生异常，处理失败了。例如反序列化失败，消息数据本身无法处理（例如话
费充值，当前消息的手机号被注销，无法充值）等。
消息的状态：

package org.apache.rocketmq.client.consumer.listener;
public enum ConsumeConcurrentlyStatus {

	CONSUME_SUCCESS,

	RECONSUME_LATER;
}

可以看到，消息的状态分为成功或者失败。如果返回的状态为失败会怎么样呢？
在启动broker的日志中可以看到这样的信息：

INFO main - messageDelayLevel=1s 5s 10s 30s 1m 2m 3m 4m 5m 6m 7m 8m 9m 10m 20m 30m 1h
2h

这个表示了，如果消息消费失败，那么消息将会在1s、5s、10s后重试，一直到2h后不再重试。
其实，有些时候并不需要重试这么多次，一般重试3~5次即可。这个时候就可以通过msg.getReconsumeTimes()获
取重试次数进行控制。

package cn.itcast.rocketmq;
import org.apache.rocketmq.client.consumer.DefaultMQPushConsumer;
import org.apache.rocketmq.client.consumer.listener.ConsumeConcurrentlyContext;
import org.apache.rocketmq.client.consumer.listener.ConsumeConcurrentlyStatus;
import org.apache.rocketmq.client.consumer.listener.MessageListenerConcurrently;
import org.apache.rocketmq.client.exception.MQClientException;
import org.apache.rocketmq.common.message.MessageExt;
import org.apache.rocketmq.common.protocol.heartbeat.MessageModel;
import java.io.UnsupportedEncodingException;
import java.util.List;
public class ConsumerDemo {
	public static void main(String[] args) throws Exception {
		DefaultMQPushConsumer consumer = new DefaultMQPushConsumer("HAOKE_IM");
		consumer.setNamesrvAddr("172.16.55.185:9876");
		// 订阅topic，接收此Topic下的所有消息
		consumer.subscribe("my-test-topic", "*");
		consumer.registerMessageListener(new MessageListenerConcurrently() {
		@Override
		public ConsumeConcurrentlyStatus consumeMessage(List msgs,
		ConsumeConcurrentlyContext context) {
			for (MessageExt msg : msgs) {
			try {
				System.out.println(new String(msg.getBody(), "UTF-8"));
			} catch (UnsupportedEncodingException e) {
				e.printStackTrace();
			}
			}
			System.out.println("收到消息->" + msgs);
			if(msgs.get(0).getReconsumeTimes() >= 3){
				// 重试3次后，不再进行重试
				return ConsumeConcurrentlyStatus.CONSUME_SUCCESS;
			}
				return ConsumeConcurrentlyStatus.RECONSUME_LATER;
			}
		});
		consumer.start();
	}
}

1.2.2、timeout
比如由于网络原因导致消息压根就没有从MQ到消费者上，那么在RocketMQ内部会不断的尝试发送这条消息，直
至发送成功为止！
也就是说，服务端没有接收到消息的反馈，既不是成功也不是失败，这个时候定义为超时。

2、RocketMQ的集群 2.1 集群模式

在RocketMQ中，集群的部署模式是比较多的，有以下几种：

• 单个Master

  这种方式风险较大，一旦Broker重启或者宕机时，会导致整个服务不可用，不建议线上环境使用。

• 多Master模式

  一个集群无Slave，全是Master，例如2个Master或者3个Master
  单台机器宕机期间，这台机器上未被消费的消息在机器恢复之前不可订阅，消息实时性会受到影响。

• 多Master多Slave模式，异步复制

  每个Master配置一个Slave，有多对Master-Slave，HA采用异步复制方式，主备有短暂消息延迟，毫秒级。
  优点：即使磁盘损坏，消息丢失的非常少，且消息实时性不会受影响，因为Master宕机后，消费者仍然可以从Slave消费，此过程对应用透明，不需要人工干预。性能同多Master模式几乎一样。
  缺点：Master宕机，磁盘损坏情况，会丢失少量消息。

• 多Master多Slave模式，同步双写

  每个Master配置一个Slave，有多对Master-Slave，HA采用同步双写方式，主备都写成功，向应用返回成功。
  优点：数据与服务都无单点，Master宕机情况下，消息无延迟，服务可用性与数据可用性都非常高。
  缺点：性能比异步复制模式略低，大约低10%左右。

  2.2 搭建2m2s集群

  下面通过docker搭建2master+2slave的集群。
  克隆新的镜像，配置如下：

  vi /etc/hostname

  vi /etc/sysconfig/network-scripts/ifcfg-ens32（修改IPADDR为192.168.208.131）

  vi /etc/hosts

  reboot # 重启linux服务器

搭建集群：

出现错误：

Error response from daemon: Get “https://registry-1.docker.io/v2/”: dial tcp: lookup registry-1.docker.io on 192.168.208.2:53: read udp 192.168.208.131:44902->192.168.208.2:53: i/o timeout

解决方法：

vi /etc/resolv.conf
添加 nameserver 8.8.8.8

#	创建2个master
#	nameserver1
docker create -p 9876:9876 --name rmqserver01
-e "JAVA_OPT_EXT=-server -Xms128m -Xmx128m -Xmn128m"
-e "JAVA_OPTS=-Duser.home=/opt"
-v /usr/local/develop/rmq/rmqserver01/logs:/opt/logs
-v /usr/local/develop/rmq/rmqserver01/store:/opt/store
foxiswho/rocketmq:server-4.3.2
#	nameserver2
docker create -p 9877:9876 --name rmqserver02
-e "JAVA_OPT_EXT=-server -Xms128m -Xmx128m -Xmn128m"
-e "JAVA_OPTS=-Duser.home=/opt"
-v /usr/local/develop/rmq/rmqserver02/logs:/opt/logs
-v /usr/local/develop/rmq/rmqserver02/store:/opt/store
foxiswho/rocketmq:server-4.3.2

#	创建第1个master broker
#	master broker01
docker create --net host --name rmqbroker01
-e "JAVA_OPTS=-Duser.home=/opt"
-e "JAVA_OPT_EXT=-server -Xms128m -Xmx128m -Xmn128m"
-e "autoCreateTopicEnable=true"
-v /usr/local/develop/rmq/rmqbroker01/conf/broker.conf:/etc/rocketmq/broker.conf
-v /usr/local/develop/rmq/rmqbroker01/logs:/opt/logs
-v /usr/local/develop/rmq/rmqbroker01/store:/opt/store
foxiswho/rocketmq:broker-4.3.2
#	配置broker.conf文件内容如下（需要先在linux主机上创建）
namesrvAddr=192.168.208.131:9876;192.168.208.131:9877
brokerClusterName=ItcastCluster
brokerName=broker01
brokerId=0
deleteWhen=04
fileReservedTime=48
brokerRole=SYNC_MASTER
flushDiskType=ASYNC_FLUSH
brokerIP1=192.168.208.131
brokerIp2=192.168.208.131
listenPort=10911

#	创建第2个master broker
#	master broker02
docker create --net host --name rmqbroker02
-e "JAVA_OPTS=-Duser.home=/opt"
-e "JAVA_OPT_EXT=-server -Xms128m -Xmx128m -Xmn128m"
-e "autoCreateTopicEnable=true"
-v /usr/local/develop/rmq/rmqbroker02/conf/broker.conf:/etc/rocketmq/broker.conf
-v /usr/local/develop/rmq/rmqbroker02/logs:/opt/logs
-v /usr/local/develop/rmq/rmqbroker02/store:/opt/store
foxiswho/rocketmq:broker-4.3.2
#	master broker02（broker.conf文件需要先创建好）
namesrvAddr=192.168.208.131:9876;192.168.208.131:9877
brokerClusterName=ItcastCluster
brokerName=broker02
brokerId=0
deleteWhen=04
fileReservedTime=48
brokerRole=SYNC_MASTER
flushDiskType=ASYNC_FLUSH
brokerIP1=192.168.208.131
brokerIp2=192.168.208.131
listenPort=10811

#	创建第1个slave broker
#	slave broker01
docker create --net host --name rmqbroker03
-e "JAVA_OPTS=-Duser.home=/opt"
-e "JAVA_OPT_EXT=-server -Xms128m -Xmx128m -Xmn128m"
-e "autoCreateTopicEnable=true"
-v /usr/local/develop/rmq/rmqbroker03/conf/broker.conf:/etc/rocketmq/broker.conf
-v /usr/local/develop/rmq/rmqbroker03/logs:/opt/logs
-v /usr/local/develop/rmq/rmqbroker03/store:/opt/store
foxiswho/rocketmq:broker-4.3.2
#	slave broker01
namesrvAddr=192.168.208.131:9876;192.168.208.131:9877
brokerClusterName=ItcastCluster
brokerName=broker01
brokerId=1
deleteWhen=04
fileReservedTime=48
brokerRole=SLAVE
flushDiskType=ASYNC_FLUSH
brokerIP1=192.168.208.131
brokerIp2=192.168.208.131
listenPort=10711

#创建第2个slave broker
#slave broker01
docker create --net host --name rmqbroker04
-e "JAVA_OPTS=-Duser.home=/opt"
-e "JAVA_OPT_EXT=-server -Xms128m -Xmx128m -Xmn128m"
-e "autoCreateTopicEnable=true"
-v /usr/local/develop/rmq/rmqbroker04/conf/broker.conf:/etc/rocketmq/broker.conf
-v /usr/local/develop/rmq/rmqbroker04/logs:/opt/logs
-v /usr/local/develop/rmq/rmqbroker04/store:/opt/store
foxiswho/rocketmq:broker-4.3.2
#slave broker02
namesrvAddr=192.168.208.131:9876;192.168.208.131:9877
brokerClusterName=ItcastCluster
brokerName=broker02
brokerId=1
deleteWhen=04
fileReservedTime=48
brokerRole=SLAVE
flushDiskType=ASYNC_FLUSH
brokerIP1=192.168.208.131
brokerIp2=192.168.208.131
listenPort=10611

部署RocketMQ的管理工具：

#	拉取镜像
docker pull styletang/rocketmq-console-ng:1.0.0
#	创建并启动容器
docker run -e "JAVA_OPTS=-Drocketmq.namesrv.addr=192.168.208.131:9876;192.168.208.131:9877 -Dcom.rocketmq.sendMessageWithVIPChannel=false" -p 8082:8080 -t -d styletang/rocketmq-console-ng:1.0.0

#	启动容器
docker start rmqserver01 rmqserver02
docker start rmqbroker01 rmqbroker02 rmqbroker03 rmqbroker04

3、SprinBoot整合RocketMQ 3.1、导入依赖

4.0.0

	org.springframework.boot
	spring-boot-starter-parent
	2.1.0.RELEASE

com.zrj.rocketmq
rocketmq-test
1.0-SNAPSHOT


		org.springframework.boot
		spring-boot-starter


		org.springframework.boot
		spring-boot-starter-test
		test


		org.apache.rocketmq
		rocketmq-spring-boot-starter
		2.0.1


		org.apache.rocketmq
		rocketmq-client
		4.3.2






			org.apache.maven.plugins
			maven-compiler-plugin
			3.2

				1.8
				1.8
				UTF-8




说明：rocketmq-spring-boot-starter的依赖包是不能直接从中央仓库下载的，需要自己通过源码install到本
地仓库的。

#源码地址（或者使用资料中的源码）
  https://github.com/apache/rocketmq-spring
#进入源码目录，执行如下命令
  mvn clean install

3.2、编写application.properties配置文件

# Spring boot application
spring.application.name = itcast-rocketmq
spring.rocketmq.nameServer=172.16.55.185:9876
spring.rocketmq.producer.group=my-group

3.3、生产者发送消息

@Component
public class SpringProducer {
	@Autowired
	private RocketMQTemplate rocketMQTemplate;

	public void sendMsg(String topic, String msg){
		this.rocketMQTemplate.convertAndSend(topic, msg);
	}
}

3.4、消费消息

@Component
@RocketMQMessageListener(topic = "my-topic",
consumerGroup = "haoke-consumer",
selectorExpression = "*")
public class SpringConsumer implements RocketMQListener {
	@Override
	public void onMessage(String msg) {
		System.out.println("接收到消息 -> " + msg);
	}
}

3.5、编写启动类

@SpringBootApplication
public class MyApplication {
	public static void main(String[] args) {
		SpringApplication.run(MyApplication.class, args);
	}
}

3.6、编写测试用例

@RunWith(SpringRunner.class)
@SpringBootTest
public class TestSpringRocketMQ {

	@Autowired
	private SpringProducer springProducer;

	@Test
	public void testSendMsg(){
		this.springProducer.sendMsg("my-topic", "第一个Spring消息");
	}
}

3.7、测试

    先启动springboot，再运行测试用例，即可看到消费者接收到生产者发送的消息。

3.8、事务消息 3.8.1、定义TransactionListenerImpl

@RocketMQTransactionListener(txProducerGroup = "myTransactionGroup")
public class TransactionListenerImpl implements RocketMQLocalTransactionListener {
	private static Map STATE_MAP = new
	HashMap<>();
	@Override
	public RocketMQLocalTransactionState executeLocalTransaction(Message message,
	Object o) {
		String transId =(String)message.getHeaders().get(RocketMQHeaders.TRANSACTION_ID);
		try {
			System.out.println("执行操作1");
			Thread.sleep(500);
			System.out.println("执行操作2");
			Thread.sleep(800);
			STATE_MAP.put(transId, RocketMQLocalTransactionState.COMMIT);
			return RocketMQLocalTransactionState.COMMIT;
		} catch (Exception e) {
			e.printStackTrace();
		}
			STATE_MAP.put(transId, RocketMQLocalTransactionState.ROLLBACK);
			return RocketMQLocalTransactionState.ROLLBACK;
	}
	@Override
	public RocketMQLocalTransactionState checkLocalTransaction(Message message) {
		String transId = (String)message.getHeaders().get(RocketMQHeaders.TRANSACTION_ID);
		System.out.println("回查消息 -> transId = " + transId + ", state = " + STATE_MAP.get(transId));
		return STATE_MAP.get(transId);
	}
}

3.8.2、定义生产者

@Component
public class SpringTransactionProducer {

	@Autowired
	private RocketMQTemplate rocketMQTemplate;


	public void sendMsg(String topic, String msg) {
		Message message = MessageBuilder.withPayload(msg).build();
		// myTransactionGroup要和 @RocketMQTransactionListener(txProducerGroup = "myTransactionGroup")定义的一致
		this.rocketMQTemplate.sendMessageInTransaction("myTransactionGroup", topic, message, null);
		System.out.println("发送消息成功");
	}
}

3.8.3、消费者（没有变化）

@Component
@RocketMQMessageListener(topic = "my-topic",
consumerGroup = "haoke-consumer",
selectorExpression = "*")
public class SpringConsumer implements RocketMQListener {
	@Override
	public void onMessage(String msg) {
		System.out.println("接收到消息 -> " + msg);
	}
}

3.8.4、编写测试用例

@RunWith(SpringRunner.class)
@SpringBootTest
public class TestSpringRocketMQ {

	@Autowired
	private SpringProducer springProducer;

	@Autowired
	private SpringTransactionProducer springTransactionProducer;

	@Test
	public void testSendMsg(){
		this.springProducer.sendMsg("my-topic", "第2个Spring消息");
	}
	@Test
	public void testSendMsg2(){
		this.springTransactionProducer.sendMsg("my-topic", "第3个Spring消息");
	}
}

3.8.5、测试

测试结果与非Spring使用，结果一致。
