消息队列 RabbitMQ[三] RabbitMQ的HelloWorld工作模式(SpringBoot方式与amqp-client方式)

HelloWorld工作模式架构图:

1. 引入依赖：

     com.rabbitmq
     amqp-client
     4.8.0


2. 通过可视化管理界面添加用户并分配虚拟机
消息队列 RabbitMQ[二] RabbitMQ可视化管控台创建用户并为用户分配虚拟机

3. 生产者代码：

import com.rabbitmq.client.Channel;
import com.rabbitmq.client.Connection;
import com.rabbitmq.client.ConnectionFactory;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Producer_HelloWorld {
    public static void main(String[] args) throws IOException, TimeoutException {
        // 1. 创建连接工厂
        ConnectionFactory connectionFactory = new ConnectionFactory();
        // 2. 设置参数
        connectionFactory.setHost("127.0.0.1"); // IP地址 默认地址localhost
        connectionFactory.setPort(5672); // 端口号 默认5672
        connectionFactory.setVirtualHost("/demo_virtual"); // 虚拟机名称 默认/
        connectionFactory.setUsername("zdy"); // 用户名 默认guest
        connectionFactory.setPassword("zdy"); // 密码 默认guest
        // 3. 创建连接 Connection
        Connection connection = connectionFactory.newConnection();
        // 4. 创建频道 Channel
        Channel channel = connection.createChannel();
        // 5. 创建队列

        channel.queueDeclare("hello_world", true, false, false, null);
        // 6. 发送消息

        String body = "hello rabbitmq";
        channel.basicPublish("", "hello_world", null, body.getBytes());
        channel.close();
        connection.close();
    }
}

4. 消费者代码：

import com.rabbitmq.client.*;

import java.io.IOException;
import java.util.concurrent.TimeoutException;

public class Consumer_HelloWorld {
    public static void main(String[] args) throws IOException, TimeoutException {
        // 1. 创建连接工厂
        ConnectionFactory connectionFactory = new ConnectionFactory();
        // 2. 设置参数
        connectionFactory.setHost("127.0.0.1"); // IP地址 默认地址localhost
        connectionFactory.setPort(5672); // 端口号 默认5672
        connectionFactory.setVirtualHost("/demo_virtual"); // 虚拟机名称 默认/
        connectionFactory.setUsername("zdy"); // 用户名 默认guest
        connectionFactory.setPassword("zdy"); // 密码 默认guest
        // 3. 创建连接 Connection
        Connection connection = connectionFactory.newConnection();
        // 4. 创建频道 Channel
        Channel channel = connection.createChannel();

        Consumer consumer = new Consumer() {
            public void handleConsumeOk(java.lang.String s) {

            }

            public void handleCancelOk(java.lang.String s) {

            }

            public void handleCancel(java.lang.String s) throws IOException {

            }

            public void handleShutdownSignal(java.lang.String s, ShutdownSignalException e) {

            }

            public void handleRecoverOk(java.lang.String s) {

            }

            public void handleDelivery(java.lang.String s, Envelope envelope, AMQP.BasicProperties basicProperties, byte[] bytes) throws IOException {
                System.out.println(new String(bytes));
            }
        };
        // 5. 接收消息

        channel.basicConsume("hello_world", true, consumer);
    }
}

1. 引入依赖：

    org.springframework.boot
     spring-boot
     2.3.12.RELEASE


     org.springframework.boot
     spring-boot-starter-amqp
     2.3.12.RELEASE


     org.springframework.boot
     spring-boot-starter-test
     2.3.12.RELEASE


2. 编写生产者代码（创建新的SpringBoot项目）
2.1 编写配置文件application.yml

spring:
  rabbitmq:
    host: 127.0.0.1
    port: 5672
    username: zdy
    password: zdy
    virtual-host: /demo_virtual

2.2. 编写RabbitMQ配置文件

import org.springframework.amqp.core.*;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

@Configuration
public class RabbitMQConfig {

	public static final String QUEUE_NAME = "hello_world_queue";

    // 2. 创建Queue队列
    @Bean("hello_world_queue")
    public Queue createQueue(){
        return QueueBuilder.durable(QUEUE_NAME).build();
    }
}

2.3. 编写测试类

import com.zdy.config.RabbitMQConfig;
import org.junit.Test;
import org.junit.runner.RunWith;
import org.springframework.amqp.rabbit.core.RabbitTemplate;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.test.context.SpringBootTest;
import org.springframework.test.context.junit4.SpringRunner;

@SpringBootTest
@RunWith(SpringRunner.class)
public class ProducerTest {

    @Autowired
    private RabbitTemplate rabbitTemplate;

    @Test
    public void testHelloWorldSend(){
    	// 生产者生产消息
        rabbitTemplate.convertAndSend(RabbitMQConfig.QUEUE_NAME, "hello rabbitmq");
    }
}

3. 编写消费者代码（创建新的SpringBoot项目）
3.1. 编写配置文件application.yml（与生产者的一样）
3.2. 编写消息监听类

import org.springframework.amqp.core.Message;
import org.springframework.amqp.rabbit.annotation.RabbitListener;
import org.springframework.stereotype.Component;

@Component
public class RabbitMQListener {

    @RabbitListener(queues = "hello_world_queue")
    public void listenQueue(Message message){
        System.out.println(new String(message.getBody()));
    }
}

3.3. 运行项目
