大数据之Superset

文章目录

大数据之Superset第1章 Superset入门

1.1 Superset概述1.2 环境说明第2章 Superset安装

2.1 安装Python环境

2.1.1 安装Miniconda2.1.2 创建Python3.7环境 2.2 Superset部署

2.2.1 安装依赖2.2.2 安装Superset2.2.3 启动Supterset2.2.4 superset启停脚本第3章 Superset使用

3.1准备MySQL数据源3.2 对接MySQL数据源

3.2.1 安装依赖3.2.2 重启Superset3.2.3 数据源配置 3.3 制作仪表盘

3.3.1 创建空白仪表盘3.3.2 创建图表3.3.3 编辑仪表盘第4章 Superset实战

4.1 制作地图4.2 制作饼状图

第1章 Superset入门 1.1 Superset概述

Apache Superset是一个现代的数据探索和可视化平台。它功能强大且十分易用，可对接各种数据源，包括很多现代的大数据分析引擎，拥有丰富的图表展示形式，并且支持自定义仪表盘。

1.2 环境说明

本课程使用的服务器操作系统为CentOS 7，Superset对接的数据源为MySQL数据库。

第2章 Superset安装

Superset官网地址：http://superset.apache.org/

2.1 安装Python环境

Superset是由Python语言编写的Web应用，要求Python3.7的环境。

2.1.1 安装Miniconda

conda是一个开源的包、环境管理器，可以用于在同一个机器上安装不同Python版本的软件包及其依赖，并能够在不同的Python环境之间切换，Anaconda包括Conda、Python以及一大堆安装好的工具包，比如：numpy、pandas等，Miniconda包括Conda、Python。

此处，我们不需要如此多的工具包，故选择MiniConda。

1）下载Miniconda（Python3版本）

下载地址：https://repo.anaconda.com/miniconda/Miniconda3-latest-Linux-x86_64.sh

2）安装Miniconda

（1）执行以下命令进行安装，并按照提示操作，直到安装完成。

[liumingze@hadoop102 lib]$ bash Miniconda3-latest-Linux-x86_64.sh

（2）在安装过程中，出现以下提示时，可以指定安装路径

（3）出现以下字样，即为安装完成

3）加载环境变量配置文件，使之生效

[liumingze@hadoop102 lib]$ source ~/.bashrc

4）取消激活base环境

Miniconda安装完成后，每次打开终端都会激活其默认的base环境，我们可通过以下命令，禁止激活默认base环境。

[liumingze@hadoop102 lib]$ conda config --set auto_activate_base false

2.1.2 创建Python3.7环境

1）配置conda国内镜像

(base) [liumingze@hadoop102 ~]$ conda config --add channels https://mirrors.tuna.tsinghua.edu.cn/anaconda/pkgs/free

(base) [liumingze@hadoop102 ~]$ conda config --add channels https://mirrors.tuna.tsinghua.edu.cn/anaconda/pkgs/main

(base) [liumingze@hadoop102 ~]$ conda config --set show_channel_urls yes

2）创建Python3.7环境

(base) [liumingze@hadoop102 ~]$ conda create --name superset python=3.7

说明：conda环境管理常用命令

创建环境：conda create -n env_name

查看所有环境：conda info --envs

删除一个环境：conda remove -n env_name --all

3）激活superset环境

(base) [liumingze@hadoop102 ~]$ conda activate superset

激活后效果如下图所示

说明：退出当前环境

(superset) [liumingze@hadoop102 ~]$ conda deactivate

4）执行python命令查看python版本

2.2 Superset部署 2.2.1 安装依赖

安装Superset之前，需安装以下所需依赖

(superset) [liumingze@hadoop102 ~]$ sudo yum install -y gcc gcc-c++ libffi-devel python-devel python-pip python-wheel python-setuptools openssl-devel cyrus-sasl-devel openldap-devel

2.2.2 安装Superset

1）安装（更新）setuptools和pip

(superset) [liumingze@hadoop102 ~]$ pip install --upgrade setuptools pip -i https://pypi.douban.com/simple/

**说明：**pip是python的包管理工具，可以和centos中的yum类比

2）安装Supetset

(superset) [liumingze@hadoop102 ~]$ pip install apache-superset -i https://pypi.douban.com/simple/

说明：-i的作用是指定镜像，这里选择国内镜像

注：如果遇到网络错误导致不能下载，可尝试更换镜像

(superset) [liumingze@hadoop102 ~]$ pip install apache-superset --trusted-host https://repo.huaweicloud.com -i https://repo.huaweicloud.com/repository/pypi/simple

3）初始化Supetset数据库

(superset) [liumingze@hadoop102 ~]$ superset db upgrade

4）创建管理员用户

(superset) [liumingze@hadoop102 ~]$ export FLASK_APP=superset

(superset) [liumingze@hadoop102 ~]$ superset fab create-admin

说明：flask是一个python web框架，Superset使用的就是flask

5）Superset初始化

(superset) [liumingze@hadoop102 ~]$ superset init

2.2.3 启动Supterset

1）安装gunicorn

(superset) [liumingze@hadoop102 ~]$ pip install gunicorn -i https://pypi.douban.com/simple/

**说明：**gunicorn是一个Python Web Server，可以和java中的TomCat类比

2）启动Superset

（1）确保当前conda环境为superset，及下图所示

（2）启动

(superset) [liumingze@hadoop102 ~]$ gunicorn --workers 5 --timeout 120 --bind hadoop102:8787 "superset.app:create_app()" --daemon

说明：

–workers：指定进程个数

–timeout：worker进程超时时间，超时会自动重启

–bind：绑定本机地址，即为Superset访问地址

–daemon：后台运行

（3）登录Superset

访问http://hadoop102:8787，并使用2.2.2节中第4步创建的管理员账号进行登录。

3）停止superset

停掉gunicorn进程

(superset) [liumingze@hadoop102 ~]$ ps -ef | awk '/superset/ && !/awk/{print $2}' | xargs kill -9

退出superset环境

(superset) [liumingze@hadoop102 ~]$ conda deactivate

2.2.4 superset启停脚本

1）创建superset.sh文件

[liumingze@hadoop102 bin]$ vim superset.sh

内容如下

#!/bin/bash

superset_status(){
    result=`ps -ef | awk '/gunicorn/ && !/awk/{print $2}' | wc -l`
    if [[ $result -eq 0 ]]; then
        return 0
    else
        return 1
    fi
}
superset_start(){
        source ~/.bashrc
        superset_status >/dev/null 2>&1
        if [[ $? -eq 0 ]]; then
            conda activate superset ; gunicorn --workers 5 --timeout 120 --bind hadoop102:8787 --daemon 'superset.app:create_app()'
        else
            echo "superset正在运行"
        fi

}

superset_stop(){
    superset_status >/dev/null 2>&1
    if [[ $? -eq 0 ]]; then
        echo "superset未在运行"
    else
        ps -ef | awk '/gunicorn/ && !/awk/{print $2}' | xargs kill -9
    fi
}


case $1 in
    start )
        echo "启动Superset"
        superset_start
    ;;
    stop )
        echo "停止Superset"
        superset_stop
    ;;
    restart )
        echo "重启Superset"
        superset_stop
        superset_start
    ;;
    status )
        superset_status >/dev/null 2>&1
        if [[ $? -eq 0 ]]; then
            echo "superset未在运行"
        else
            echo "superset正在运行"
        fi
esac

2）加执行权限

[liumingze@hadoop102 bin]$ chmod +x superset.sh

3）测试

启动superset

[liumingze@hadoop102 bin]$ superset.sh start

停止superset

[liumingze@hadoop102 bin]$ superset.sh stop

第3章 Superset使用 3.1准备MySQL数据源

1）创建MySQL数据库

2）导入表结构和模拟数据

按将以下步骤将gmall_report.sql脚本导入到刚刚创建的gamll_report数据库中。


SET NAMES utf8mb4;
SET FOREIGN_KEY_CHECKS = 0;

-- ----------------------------
-- Table structure for ads_order_by_province
-- ----------------------------
DROP TABLE IF EXISTS `ads_order_by_province`;
CREATE TABLE `ads_order_by_province`  (
  `dt` date NOT NULL,
  `province_id` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NOT NULL COMMENT '统计日期',
  `province_name` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NULL DEFAULT NULL COMMENT '省份名称',
  `area_code` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NULL DEFAULT NULL COMMENT '地区编码',
  `iso_code` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NULL DEFAULT NULL COMMENT '国际标准地区编码',
  `order_count` bigint(20) NULL DEFAULT NULL COMMENT '订单数',
  `order_amount` decimal(16, 2) NULL DEFAULT NULL COMMENT '订单金额',
  PRIMARY KEY (`dt`, `province_id`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8mb4 COLLATE = utf8mb4_unicode_ci ROW_FORMAT = Dynamic;

-- ----------------------------
-- Records of ads_order_by_province
-- ----------------------------
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '1', '北京', '110000', 'CN-11', 13, 402232.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '10', '福建', '350000', 'CN-35', 7, 315645.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '11', '江西', '360000', 'CN-36', 4, 114391.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '12', '山东', '370000', 'CN-37', 5, 291400.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '13', '重庆', '500000', 'CN-50', 6, 153022.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '14', '台湾', '710000', 'CN-71', 6, 184981.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '15', '黑龙江', '230000', 'CN-23', 2, 80049.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '16', '吉林', '220000', 'CN-22', 8, 144899.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '17', '辽宁', '210000', 'CN-21', 2, 20976.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '18', '陕西', '610000', 'CN-61', 3, 100557.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '19', '甘肃', '620000', 'CN-62', 9, 422565.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '2', '天津', '120000', 'CN-12', 11, 283788.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '20', '青海', '630000', 'CN-63', 12, 289611.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '21', '宁夏', '640000', 'CN-64', 5, 184526.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '22', '新疆', '650000', 'CN-65', 9, 262549.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '23', '河南', '410000', 'CN-41', 5, 197189.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '24', '湖北', '420000', 'CN-42', 4, 25823.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '25', '湖南', '430000', 'CN-43', 7, 187572.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '26', '广东', '440000', 'CN-44', 9, 357141.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '27', '广西', '450000', 'CN-45', 4, 130352.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '28', '海南', '460000', 'CN-46', 6, 104162.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '29', '香港', '810000', 'CN-91', 6, 203598.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '3', '山西', '140000', 'CN-14', 2, 65986.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '30', '澳门', '820000', 'CN-92', 7, 268936.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '31', '四川', '510000', 'CN-51', 1, 18893.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '32', '贵州', '520000', 'CN-52', 6, 236319.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '33', '云南', '530000', 'CN-53', 8, 381042.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '34', '西藏', '540000', 'CN-54', 5, 187908.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '4', '内蒙古', '150000', 'CN-15', 6, 178156.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '5', '河北', '130000', 'CN-13', 5, 267768.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '6', '上海', '310000', 'CN-31', 9, 333872.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '7', '江苏', '320000', 'CN-32', 5, 165192.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '8', '浙江', '330000', 'CN-33', 8, 232229.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-14', '9', '安徽', '340000', 'CN-34', 6, 158620.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '1', '北京', '110000', 'CN-11', 13, 402232.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '10', '福建', '350000', 'CN-35', 7, 315645.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '11', '江西', '360000', 'CN-36', 4, 114391.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '12', '山东', '370000', 'CN-37', 5, 291400.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '13', '重庆', '500000', 'CN-50', 6, 153022.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '14', '台湾', '710000', 'CN-71', 6, 184981.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '15', '黑龙江', '230000', 'CN-23', 2, 80049.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '16', '吉林', '220000', 'CN-22', 8, 144899.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '17', '辽宁', '210000', 'CN-21', 2, 20976.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '18', '陕西', '610000', 'CN-61', 3, 100557.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '19', '甘肃', '620000', 'CN-62', 9, 422565.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '2', '天津', '120000', 'CN-12', 11, 283788.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '20', '青海', '630000', 'CN-63', 12, 289611.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '21', '宁夏', '640000', 'CN-64', 5, 184526.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '22', '新疆', '650000', 'CN-65', 9, 262549.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '23', '河南', '410000', 'CN-41', 5, 197189.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '24', '湖北', '420000', 'CN-42', 4, 25823.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '25', '湖南', '430000', 'CN-43', 7, 187572.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '26', '广东', '440000', 'CN-44', 9, 357141.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '27', '广西', '450000', 'CN-45', 4, 130352.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '28', '海南', '460000', 'CN-46', 6, 104162.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '29', '香港', '810000', 'CN-91', 6, 203598.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '3', '山西', '140000', 'CN-14', 2, 65986.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '30', '澳门', '820000', 'CN-92', 7, 268936.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '31', '四川', '510000', 'CN-51', 1, 18893.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '32', '贵州', '520000', 'CN-52', 6, 236319.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '33', '云南', '530000', 'CN-53', 8, 381042.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '34', '西藏', '540000', 'CN-54', 5, 187908.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '4', '内蒙古', '150000', 'CN-15', 6, 178156.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '5', '河北', '130000', 'CN-13', 5, 267768.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '6', '上海', '310000', 'CN-31', 9, 333872.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '7', '江苏', '320000', 'CN-32', 5, 165192.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '8', '浙江', '330000', 'CN-33', 8, 232229.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-15', '9', '安徽', '340000', 'CN-34', 6, 158620.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '1', '北京', '110000', 'CN-11', 13, 402232.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '10', '福建', '350000', 'CN-35', 7, 315645.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '11', '江西', '360000', 'CN-36', 4, 114391.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '12', '山东', '370000', 'CN-37', 5, 291400.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '13', '重庆', '500000', 'CN-50', 6, 153022.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '14', '台湾', '710000', 'CN-71', 6, 184981.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '15', '黑龙江', '230000', 'CN-23', 2, 80049.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '16', '吉林', '220000', 'CN-22', 8, 144899.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '17', '辽宁', '210000', 'CN-21', 2, 20976.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '18', '陕西', '610000', 'CN-61', 3, 100557.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '19', '甘肃', '620000', 'CN-62', 9, 422565.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '2', '天津', '120000', 'CN-12', 11, 283788.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '20', '青海', '630000', 'CN-63', 12, 289611.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '21', '宁夏', '640000', 'CN-64', 5, 184526.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '22', '新疆', '650000', 'CN-65', 9, 262549.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '23', '河南', '410000', 'CN-41', 5, 197189.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '24', '湖北', '420000', 'CN-42', 4, 25823.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '25', '湖南', '430000', 'CN-43', 7, 187572.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '26', '广东', '440000', 'CN-44', 9, 357141.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '27', '广西', '450000', 'CN-45', 4, 130352.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '28', '海南', '460000', 'CN-46', 6, 104162.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '29', '香港', '810000', 'CN-91', 6, 203598.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '3', '山西', '140000', 'CN-14', 2, 65986.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '30', '澳门', '820000', 'CN-92', 7, 268936.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '31', '四川', '510000', 'CN-51', 1, 18893.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '32', '贵州', '520000', 'CN-52', 6, 236319.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '33', '云南', '530000', 'CN-53', 8, 381042.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '34', '西藏', '540000', 'CN-54', 5, 187908.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '4', '内蒙古', '150000', 'CN-15', 6, 178156.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '5', '河北', '130000', 'CN-13', 5, 267768.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '6', '上海', '310000', 'CN-31', 9, 333872.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '7', '江苏', '320000', 'CN-32', 5, 165192.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '8', '浙江', '330000', 'CN-33', 8, 232229.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-16', '9', '安徽', '340000', 'CN-34', 6, 158620.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '1', '北京', '110000', 'CN-11', 13, 402232.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '10', '福建', '350000', 'CN-35', 7, 315645.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '11', '江西', '360000', 'CN-36', 4, 114391.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '12', '山东', '370000', 'CN-37', 5, 291400.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '13', '重庆', '500000', 'CN-50', 6, 153022.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '14', '台湾', '710000', 'CN-71', 6, 184981.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '15', '黑龙江', '230000', 'CN-23', 2, 80049.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '16', '吉林', '220000', 'CN-22', 8, 144899.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '17', '辽宁', '210000', 'CN-21', 2, 20976.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '18', '陕西', '610000', 'CN-61', 3, 100557.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '19', '甘肃', '620000', 'CN-62', 9, 422565.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '2', '天津', '120000', 'CN-12', 11, 283788.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '20', '青海', '630000', 'CN-63', 12, 289611.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '21', '宁夏', '640000', 'CN-64', 5, 184526.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '22', '新疆', '650000', 'CN-65', 9, 262549.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '23', '河南', '410000', 'CN-41', 5, 197189.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '24', '湖北', '420000', 'CN-42', 4, 25823.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '25', '湖南', '430000', 'CN-43', 7, 187572.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '26', '广东', '440000', 'CN-44', 9, 357141.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '27', '广西', '450000', 'CN-45', 4, 130352.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '28', '海南', '460000', 'CN-46', 6, 104162.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '29', '香港', '810000', 'CN-91', 6, 203598.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '3', '山西', '140000', 'CN-14', 2, 65986.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '30', '澳门', '820000', 'CN-92', 7, 268936.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '31', '四川', '510000', 'CN-51', 1, 18893.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '32', '贵州', '520000', 'CN-52', 6, 236319.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '33', '云南', '530000', 'CN-53', 8, 381042.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '34', '西藏', '540000', 'CN-54', 5, 187908.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '4', '内蒙古', '150000', 'CN-15', 6, 178156.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '5', '河北', '130000', 'CN-13', 5, 267768.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '6', '上海', '310000', 'CN-31', 9, 333872.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '7', '江苏', '320000', 'CN-32', 5, 165192.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '8', '浙江', '330000', 'CN-33', 8, 232229.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-17', '9', '安徽', '340000', 'CN-34', 6, 158620.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '1', '北京', '110000', 'CN-11', 13, 402232.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '10', '福建', '350000', 'CN-35', 7, 315645.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '11', '江西', '360000', 'CN-36', 4, 114391.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '12', '山东', '370000', 'CN-37', 5, 291400.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '13', '重庆', '500000', 'CN-50', 6, 153022.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '14', '台湾', '710000', 'CN-71', 6, 184981.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '15', '黑龙江', '230000', 'CN-23', 2, 80049.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '16', '吉林', '220000', 'CN-22', 8, 144899.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '17', '辽宁', '210000', 'CN-21', 2, 20976.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '18', '陕西', '610000', 'CN-61', 3, 100557.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '19', '甘肃', '620000', 'CN-62', 9, 422565.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '2', '天津', '120000', 'CN-12', 11, 283788.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '20', '青海', '630000', 'CN-63', 12, 289611.65);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '21', '宁夏', '640000', 'CN-64', 5, 184526.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '22', '新疆', '650000', 'CN-65', 9, 262549.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '23', '河南', '410000', 'CN-41', 5, 197189.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '24', '湖北', '420000', 'CN-42', 4, 25823.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '25', '湖南', '430000', 'CN-43', 7, 187572.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '26', '广东', '440000', 'CN-44', 9, 357141.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '27', '广西', '450000', 'CN-45', 4, 130352.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '28', '海南', '460000', 'CN-46', 6, 104162.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '29', '香港', '810000', 'CN-91', 6, 203598.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '3', '山西', '140000', 'CN-14', 2, 65986.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '30', '澳门', '820000', 'CN-92', 7, 268936.30);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '31', '四川', '510000', 'CN-51', 1, 18893.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '32', '贵州', '520000', 'CN-52', 6, 236319.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '33', '云南', '530000', 'CN-53', 8, 381042.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '34', '西藏', '540000', 'CN-54', 5, 187908.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '4', '内蒙古', '150000', 'CN-15', 6, 178156.35);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '5', '河北', '130000', 'CN-13', 5, 267768.05);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '6', '上海', '310000', 'CN-31', 9, 333872.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '7', '江苏', '320000', 'CN-32', 5, 165192.70);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '8', '浙江', '330000', 'CN-33', 8, 232229.00);
INSERT INTO `ads_order_by_province` VALUES ('2020-06-18', '9', '安徽', '340000', 'CN-34', 6, 158620.05);

-- ----------------------------
-- Table structure for ads_order_spu_stats
-- ----------------------------
DROP TABLE IF EXISTS `ads_order_spu_stats`;
CREATE TABLE `ads_order_spu_stats`  (
  `dt` date NOT NULL COMMENT '统计日期',
  `spu_id` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NOT NULL COMMENT '商品ID',
  `spu_name` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NULL DEFAULT NULL COMMENT '商品名称',
  `tm_id` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NOT NULL COMMENT '品牌ID',
  `tm_name` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NULL DEFAULT NULL COMMENT '品牌名称',
  `category3_id` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NOT NULL COMMENT '三级品类ID',
  `category3_name` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NULL DEFAULT NULL COMMENT '三级品类名称',
  `category2_id` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NOT NULL COMMENT '二级品类ID',
  `category2_name` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NULL DEFAULT NULL COMMENT '二级品类名称',
  `category1_id` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NOT NULL COMMENT '一级品类ID',
  `category1_name` varchar(255) CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci NOT NULL COMMENT '一级品类名称',
  `order_count` bigint(20) NULL DEFAULT NULL COMMENT '订单数',
  `order_amount` decimal(16, 2) NULL DEFAULT NULL COMMENT '订单金额',
  PRIMARY KEY (`dt`, `spu_id`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8mb4 COLLATE = utf8mb4_unicode_ci ROW_FORMAT = Dynamic;

-- ----------------------------
-- Records of ads_order_spu_stats
-- ----------------------------
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '1', '小米10', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 75, 999840.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '10', 'CAREMiLLE珂曼奶油小方口红 雾面滋润保湿持久丝缎唇膏', '9', 'CAREMiLLE', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 194, 27410.64);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '11', '香奈儿（Chanel）女士香水5号香水 粉邂逅柔情淡香水EDT ', '11', '香奈儿', '473', '香水', '54', '香水彩妆', '8', '个护化妆', 51, 37520.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '12', '华为智慧屏 4K全面屏智能电视机', '3', '华为', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 54, 505065.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '2', 'Redmi 10X', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 113, 299439.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '3', 'Apple iPhone 12', '2', '苹果', '61', '手机', '13', '手机通讯', '2', '手机', 137, 2428867.29);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '4', 'HUAWEI P40', '3', '华为', '61', '手机', '13', '手机通讯', '2', '手机', 97, 858353.71);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '5', 'TCL巨幕私人影院电视 4K超高清 AI智慧屏  液晶平板电视机', '4', 'TCL', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 72, 1478239.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '6', '小米电视 内置小爱 智能网络液晶平板教育电视', '5', '小米', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 50, 326894.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '7', '十月稻田 长粒香大米 东北大米 东北香米 5kg', '6', '长粒香', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 52, 4816.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '8', '金沙河面条 原味银丝挂面 龙须面 方便速食拉面 清汤面 900g', '7', '金沙河', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 40, 1118.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-14', '9', '索芙特i-Softto 口红不掉色唇膏保湿滋润 璀璨金钻哑光唇膏 ', '8', '索芙特', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 180, 50819.76);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '1', '小米10', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 75, 999840.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '10', 'CAREMiLLE珂曼奶油小方口红 雾面滋润保湿持久丝缎唇膏', '9', 'CAREMiLLE', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 194, 27410.64);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '11', '香奈儿（Chanel）女士香水5号香水 粉邂逅柔情淡香水EDT ', '11', '香奈儿', '473', '香水', '54', '香水彩妆', '8', '个护化妆', 51, 37520.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '12', '华为智慧屏 4K全面屏智能电视机', '3', '华为', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 54, 505065.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '2', 'Redmi 10X', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 113, 299439.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '3', 'Apple iPhone 12', '2', '苹果', '61', '手机', '13', '手机通讯', '2', '手机', 137, 2428867.29);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '4', 'HUAWEI P40', '3', '华为', '61', '手机', '13', '手机通讯', '2', '手机', 97, 858353.71);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '5', 'TCL巨幕私人影院电视 4K超高清 AI智慧屏  液晶平板电视机', '4', 'TCL', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 72, 1478239.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '6', '小米电视 内置小爱 智能网络液晶平板教育电视', '5', '小米', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 50, 326894.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '7', '十月稻田 长粒香大米 东北大米 东北香米 5kg', '6', '长粒香', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 52, 4816.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '8', '金沙河面条 原味银丝挂面 龙须面 方便速食拉面 清汤面 900g', '7', '金沙河', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 40, 1118.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-15', '9', '索芙特i-Softto 口红不掉色唇膏保湿滋润 璀璨金钻哑光唇膏 ', '8', '索芙特', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 180, 50819.76);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '1', '小米10', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 75, 999840.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '10', 'CAREMiLLE珂曼奶油小方口红 雾面滋润保湿持久丝缎唇膏', '9', 'CAREMiLLE', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 194, 27410.64);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '11', '香奈儿（Chanel）女士香水5号香水 粉邂逅柔情淡香水EDT ', '11', '香奈儿', '473', '香水', '54', '香水彩妆', '8', '个护化妆', 51, 37520.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '12', '华为智慧屏 4K全面屏智能电视机', '3', '华为', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 54, 505065.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '2', 'Redmi 10X', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 113, 299439.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '3', 'Apple iPhone 12', '2', '苹果', '61', '手机', '13', '手机通讯', '2', '手机', 137, 2428867.29);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '4', 'HUAWEI P40', '3', '华为', '61', '手机', '13', '手机通讯', '2', '手机', 97, 858353.71);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '5', 'TCL巨幕私人影院电视 4K超高清 AI智慧屏  液晶平板电视机', '4', 'TCL', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 72, 1478239.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '6', '小米电视 内置小爱 智能网络液晶平板教育电视', '5', '小米', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 50, 326894.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '7', '十月稻田 长粒香大米 东北大米 东北香米 5kg', '6', '长粒香', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 52, 4816.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '8', '金沙河面条 原味银丝挂面 龙须面 方便速食拉面 清汤面 900g', '7', '金沙河', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 40, 1118.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-16', '9', '索芙特i-Softto 口红不掉色唇膏保湿滋润 璀璨金钻哑光唇膏 ', '8', '索芙特', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 180, 50819.76);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '1', '小米10', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 75, 999840.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '10', 'CAREMiLLE珂曼奶油小方口红 雾面滋润保湿持久丝缎唇膏', '9', 'CAREMiLLE', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 194, 27410.64);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '11', '香奈儿（Chanel）女士香水5号香水 粉邂逅柔情淡香水EDT ', '11', '香奈儿', '473', '香水', '54', '香水彩妆', '8', '个护化妆', 51, 37520.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '12', '华为智慧屏 4K全面屏智能电视机', '3', '华为', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 54, 505065.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '2', 'Redmi 10X', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 113, 299439.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '3', 'Apple iPhone 12', '2', '苹果', '61', '手机', '13', '手机通讯', '2', '手机', 137, 2428867.29);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '4', 'HUAWEI P40', '3', '华为', '61', '手机', '13', '手机通讯', '2', '手机', 97, 858353.71);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '5', 'TCL巨幕私人影院电视 4K超高清 AI智慧屏  液晶平板电视机', '4', 'TCL', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 72, 1478239.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '6', '小米电视 内置小爱 智能网络液晶平板教育电视', '5', '小米', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 50, 326894.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '7', '十月稻田 长粒香大米 东北大米 东北香米 5kg', '6', '长粒香', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 52, 4816.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '8', '金沙河面条 原味银丝挂面 龙须面 方便速食拉面 清汤面 900g', '7', '金沙河', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 40, 1118.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-17', '9', '索芙特i-Softto 口红不掉色唇膏保湿滋润 璀璨金钻哑光唇膏 ', '8', '索芙特', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 180, 50819.76);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '1', '小米10', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 75, 999840.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '10', 'CAREMiLLE珂曼奶油小方口红 雾面滋润保湿持久丝缎唇膏', '9', 'CAREMiLLE', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 194, 27410.64);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '11', '香奈儿（Chanel）女士香水5号香水 粉邂逅柔情淡香水EDT ', '11', '香奈儿', '473', '香水', '54', '香水彩妆', '8', '个护化妆', 51, 37520.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '12', '华为智慧屏 4K全面屏智能电视机', '3', '华为', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 54, 505065.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '2', 'Redmi 10X', '1', '三星', '61', '手机', '13', '手机通讯', '2', '手机', 113, 299439.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '3', 'Apple iPhone 12', '2', '苹果', '61', '手机', '13', '手机通讯', '2', '手机', 137, 2428867.29);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '4', 'HUAWEI P40', '3', '华为', '61', '手机', '13', '手机通讯', '2', '手机', 97, 858353.71);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '5', 'TCL巨幕私人影院电视 4K超高清 AI智慧屏  液晶平板电视机', '4', 'TCL', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 72, 1478239.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '6', '小米电视 内置小爱 智能网络液晶平板教育电视', '5', '小米', '86', '平板电视', '16', '大 家 电', '3', '家用电器', 50, 326894.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '7', '十月稻田 长粒香大米 东北大米 东北香米 5kg', '6', '长粒香', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 52, 4816.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '8', '金沙河面条 原味银丝挂面 龙须面 方便速食拉面 清汤面 900g', '7', '金沙河', '803', '米面杂粮', '82', '粮油调味', '14', '食品饮料、保健食品', 40, 1118.00);
INSERT INTO `ads_order_spu_stats` VALUES ('2020-06-18', '9', '索芙特i-Softto 口红不掉色唇膏保湿滋润 璀璨金钻哑光唇膏 ', '8', '索芙特', '477', '唇部', '54', '香水彩妆', '8', '个护化妆', 180, 50819.76);

-- ----------------------------
-- Table structure for ads_order_total
-- ----------------------------
DROP TABLE IF EXISTS `ads_order_total`;
CREATE TABLE `ads_order_total`  (
  `dt` date NOT NULL COMMENT '统计日期',
  `order_count` bigint(255) NULL DEFAULT NULL COMMENT '订单数',
  `order_amount` decimal(16, 2) NULL DEFAULT NULL COMMENT '订单金额',
  `order_user_count` bigint(255) NULL DEFAULT NULL COMMENT '下单人数',
  PRIMARY KEY (`dt`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8mb4 COLLATE = utf8mb4_unicode_ci ROW_FORMAT = Dynamic;

-- ----------------------------
-- Records of ads_order_total
-- ----------------------------
INSERT INTO `ads_order_total` VALUES ('2020-06-14', 211, 6951956.90, 211);
INSERT INTO `ads_order_total` VALUES ('2020-06-15', 263, 5265165.23, 259);
INSERT INTO `ads_order_total` VALUES ('2020-06-16', 226, 7521463.46, 220);
INSERT INTO `ads_order_total` VALUES ('2020-06-17', 237, 5625751.35, 223);
INSERT INTO `ads_order_total` VALUES ('2020-06-18', 280, 8651362.82, 275);

-- ----------------------------
-- Table structure for ads_user_total
-- ----------------------------
DROP TABLE IF EXISTS `ads_user_total`;
CREATE TABLE `ads_user_total`  (
  `dt` date NOT NULL COMMENT '统计日期',
  `new_user_count` bigint(20) NULL DEFAULT NULL COMMENT '新注册用户数',
  `new_order_user_count` bigint(20) NULL DEFAULT NULL COMMENT '新增下单用户数',
  `order_user_count` bigint(20) NULL DEFAULT NULL COMMENT '下单用户数',
  `no_order_user_count` bigint(20) NULL DEFAULT NULL COMMENT '未下单用户数(具体指活跃用户中未下单用户)',
  PRIMARY KEY (`dt`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8mb4 COLLATE = utf8mb4_unicode_ci ROW_FORMAT = Dynamic;

-- ----------------------------
-- Records of ads_user_total
-- ----------------------------
INSERT INTO `ads_user_total` VALUES ('2020-06-14', 100, 73, 211, 343);
INSERT INTO `ads_user_total` VALUES ('2020-06-15', 123, 65, 190, 231);
INSERT INTO `ads_user_total` VALUES ('2020-06-16', 125, 55, 234, 421);
INSERT INTO `ads_user_total` VALUES ('2020-06-17', 92, 84, 124, 425);
INSERT INTO `ads_user_total` VALUES ('2020-06-18', 153, 120, 343, 357);

SET FOREIGN_KEY_CHECKS = 1;

3）查看导入结果

3.2 对接MySQL数据源 3.2.1 安装依赖

(superset) [liumingze@hadoop102 ~]$ conda install mysqlclient

说明：对接不同的数据源，需安装不同的依赖，以下地址为官网说明

https://superset.apache.org/docs/databases/installing-database-drivers

3.2.2 重启Superset

(superset) [liumingze@hadoop102 ~]$ superset.sh restart

3.2.3 数据源配置

1）Database配置

Step1：点击Data/Databases

Step2：点击＋DATAbase

**Step3：**点击填写Database及SQL Alchemy URI

注：SQL Alchemy URI编写规范：mysql://用户名:密码@主机名:端口号/数据库名称

此处填写：

mysql://root:000000@hadoop102:3306/gmall_report?charset=utf8

**Step4：**点击Test Connection，出现“Connection looks good!”提示即表示连接成功

**Step5：**点击ADD

2）Table配置

Step1：点击Data/Datasets

Step2：点击Data/ Datasets

Step3：配置Table

3.3 制作仪表盘 3.3.1 创建空白仪表盘

1）点击Dashboards/+DASHBOARDS

2）命名并保存

3.3.2 创建图表

1）点击Charts/+CHART

2）选则数据源及图表类型

3）选择何使的图表类型

4）创建图表

5）按照说明配置图表

6）点击“Run Query”

7）如配置无误，可出现以下图标

8）命名该图表，并保存至仪表盘

3.3.3 编辑仪表盘

1）打开仪表盘，点击编辑按钮

2）调整图表大小以及图表盘布局

3）点击下图中箭头，可调整仪表盘自动刷新时间

第4章 Superset实战 4.1 制作地图

4.1.1 配置Table

4.1.2 配置Chart

4.2 制作饼状图

4.2.1 配置Table

4.2.2 配置Chart

大数据之大并非只是数量之大,实质上(大数据之路:阿里巴巴大数据实践)

大数据系统相关栏目本月热门文章
