Hue创建Oozie工作流、Oozie的java客户端api

1、Hue创建Oozie工作流（1）local 模式

登录Hue，创建Oozie工作流，点击【Workspace】按钮，新页面打开，上传jar包至lib目录中.

进入WorkSpace，上传JAR包至lib目录：

添加Spark2任务：

选择jar包所在目录和jar包名称：

填写MainClass及添加JAR包文件：

设置使用Spark2，否则默认使用的Spark1：

保存Oozie，然后点击提交：

成功

（2）yarn client 模式

进入 Workspace，进入 lib 目录，并上传 jar 包，拖拽 Spark Program，填写业务主类名称和
配置参数：

点击小齿轮，查看其他参数：
保存配置，提交运行：

其中Hue自动生成的workflow配置文件内容如下：




        Action failed, error message[${wf:errorMessage(wf:lastErrorNode())}]



            ${jobTracker}
            ${nameNode}


                    oozie.action.sharelib.for.spark
                    spark2


                    mapred.job.queue.name
                    default


            yarn
            client
            YarnSparkPi
              org.apache.spark.examples.SparkPi
            spark-examples_2.11-2.2.0.jar
              --driver-memory 512m --executor-memory 512m --num-executors 1 --executor-cores 1 --conf spark.yarn.historyServer.address=http://bigdata-cdh01:18080 -- conf spark.eventLog.enabled=true --conf spark.eventLog.dir=hdfs://bigdata-cdh01:8020/spark/eventLogs --conf spark.yarn.jars=hdfs://bigdata-cdh01:8020/spark/jars/*
            /user/root/oozie_works/examples/apps/hue-oozie-1646279075.31/lib/spark-examples_2.11-2.2.0.jar#spark-examples_2.11-2.2.0.jar

（3）yarn cluster 模式

按照上述yarn client模式使用hue构建workflow，设置应用运行为yarn-cluster模式，提交运
行。

运行成功截图：

（4）Schedule 调度

选择进入Scheduler页面，基于Workflow构建调度任务，可以设置时间调度。

设置名称和描述，选择Workflow及定时执行表达式（注意时区选择）：

2、Oozie Java Client API

Apache Oozie是一个工作流调度系统，具有如下特性优势：

1）、工作流的调度是DAG（有向无环图）-Directed Acyclical Graphs

2）、Coordinator job可以通过时间和数据集的可用性触发

3）、集成了Hadoop生态系统的其它任务，如mr,pig,hive,sqoop,distcp

4）、可扩展：一个Oozie就是一个mr程序，但是仅仅是map，没有reduce

5）、可靠性：任务失败后的重试

(1) Workflow Submit

将SparkPi圆周率程序提交到YARN上以cluster DeployMode运行，相关配置文件内容如下：

package com.yyds.tags.oozie;

public class OozieConstant {
    static String HDFSROOTPATH = "hdfs://192.168.42.7:8020";
    static String OOZIE_URL = "http://192.168.42.7:11000/oozie/";
    static String jobTracker = "192.168.42.7:8032";
}

package com.yyds.tags.oozie;

import org.apache.oozie.client.OozieClient;
import org.apache.oozie.client.OozieClientException;
import org.apache.oozie.client.WorkflowJob;

import java.util.Properties;

public class OozieWorkflowSubmit {
    public static void main(String[] args) throws OozieClientException, InterruptedException {
        String OOZIE_URL = OozieConstant.OOZIE_URL;
        // TODO: 1. 构建OozieClient 客户端实例对象
        OozieClient oozieClient = new OozieClient(OOZIE_URL);
        // TODO: 2. 设置Workflow相关配置参数值
        Properties jobConf = oozieClient.createConfiguration();
        // 2.1. 系统参数设置
        jobConf.setProperty("oozie.use.system.libpath", "true");
        jobConf.setProperty("user.name", "root");
        jobConf.setProperty("oozie.libpath", OozieConstant.HDFSROOTPATH + "/user/root/share/lib/lib_20190723215106/spark2");
        // 2.2. 必要参数信息
        jobConf.setProperty("nameNode", OozieConstant.HDFSROOTPATH);
        jobConf.setProperty("jobTracker", OozieConstant.jobTracker);
        jobConf.setProperty("queueName", "default");
        // 2.3. 应用提交运行yarn参数
        jobConf.setProperty("master", "yarn");
        jobConf.setProperty("mode", "client");
        jobConf.setProperty("sparkOptions", " --driver-memory 512m " + "--executor-memory 512m " + "--num-executors 1 " + "--executor-cores 1 " + "--conf spark.yarn.historyServer.address=http://192.168.42.7:18080 " + "--conf spark.eventLog.enabled=true " + "--conf spark.eventLog.dir=hdfs://192.168.42.7:8020/spark/eventLogs " + "--conf spark.yarn.jars=hdfs://192.168.42.7:8020/spark/jars/*");
        jobConf.setProperty("mainClass", "org.apache.spark.examples.SparkPi");
        jobConf.setProperty("appName", "SparkExamplePi");
        jobConf.setProperty("jarPath", OozieConstant.HDFSROOTPATH + "/user/root/oozie_works/cron-yarn_pi/lib/spark-examples_2.11-2.2.0.jar");
        jobConf.setProperty("appParam", "10");
        // 2.4. Oozie Workflow 参数
        jobConf.setProperty(OozieClient.APP_PATH, OozieConstant.HDFSROOTPATH + "/user/root/oozie_works/cron_yarn_pi/workflow.xml");
        // TODO: 3. 提交执行Oozie Workflow，返回应用提交JobID
        String jobId = oozieClient.run(jobConf);
        System.out.println("JobId = " + jobId);
        // TODO: 4. 依据JobID获取转态信息
        while (oozieClient.getJobInfo(jobId).getStatus() == WorkflowJob.Status.RUNNING) {
            System.out.println("Workflow job running ...");
            Thread.sleep(10 * 1000);
        }
        System.out.println("Workflow job completed ...");
    }
}

注意，将Spark Application程序依赖包及workflow.xml文件上传到HDFS目录中

其中workflow文件内容为:




        Action failed, error message[${wf:errorMessage(wf:lastErrorNode())}]



            ${jobTracker}
            ${nameNode}


                    oozie.action.sharelib.for.spark
                    spark2


                    mapred.job.queue.name
                    default


            yarn
            client
            YarnSparkPi
              org.apache.spark.examples.SparkPi
            spark-examples_2.11-2.2.0.jar
              --driver-memory 512m --executor-memory 512m --num-executors 1 --executor-cores 1 --conf spark.yarn.historyServer.address=http://bigdata-cdh01:18080 -- conf spark.eventLog.enabled=true --conf spark.eventLog.dir=hdfs://bigdata-cdh01:8020/spark/eventLogs --conf spark.yarn.jars=hdfs://bigdata-cdh01:8020/spark/jars/*
            /user/root/oozie_works/examples/apps/hue-oozie-1646279075.31/lib/spark-examples_2.11-2.2.0.jar#spark-examples_2.11-2.2.0.jar

(2) Coordinator Submit

修改上述代码，添加定时调度时间设置及执行Coordinator配置文件，提交执行即可，具体
如下：

package com.yyds.tags.oozie;

import org.apache.oozie.client.OozieClient;
import org.apache.oozie.client.OozieClientException;
import org.apache.oozie.client.WorkflowJob;

import java.util.Properties;

public class OozieCoordinatorSubmit {
    public static void main(String[] args) throws OozieClientException, InterruptedException {
        String OOZIE_URL = OozieConstant.OOZIE_URL;
        // TODO: 1. 构建OozieClient 客户端实例对象
        OozieClient oozieClient = new OozieClient(OOZIE_URL);
        // TODO: 2. 设置Workflow相关配置参数值
        Properties jobConf = oozieClient.createConfiguration();
        // 2.1. 系统参数设置
        jobConf.setProperty("oozie.use.system.libpath", "true");
        jobConf.setProperty("user.name", "root");
        jobConf.setProperty("oozie.libpath", OozieConstant.HDFSROOTPATH + "/user/root/share/lib/lib_20190723215106/spark2");
        // 2.2. 必要参数信息
        jobConf.setProperty("nameNode", OozieConstant.HDFSROOTPATH);
        jobConf.setProperty("jobTracker", "192.168.42.7:8032");
        jobConf.setProperty("queueName", "default");
        // 2.3. 应用提交运行yarn参数
        jobConf.setProperty("master", "yarn");
        jobConf.setProperty("mode", "client");
        jobConf.setProperty("sparkOptions", " --driver-memory 512m " + "--executor-memory 512m " + "--num-executors 1 " + "--executor-cores 1 " + "--conf spark.yarn.historyServer.address=http://192.168.42.7:18080 " + "--conf spark.eventLog.enabled=true " + "--conf spark.eventLog.dir=hdfs://192.168.42.7:8020/spark/eventLogs " + "--conf spark.yarn.jars=hdfs://192.168.42.7:8020/spark/jars/*");
        jobConf.setProperty("mainClass", "org.apache.spark.examples.SparkPi");
        jobConf.setProperty("appName", "SparkExamplePi");
        jobConf.setProperty("jarPath", OozieConstant.HDFSROOTPATH + "/user/root/oozie_works/cron-yarn_pi/lib/spark-examples_2.11-2.2.0.jar");
        jobConf.setProperty("appParam", "10");

        // 2.4. 定时任务设置
        jobConf.setProperty("start", "2022-03-05T17:42Z");
        jobConf.setProperty("freq", "0/3 * * * *");
        jobConf.setProperty("end", "2022-06-01T17:50Z");
        // 2.5. Oozie Workflow 参数
        jobConf.setProperty("appPath", OozieConstant.HDFSROOTPATH + "/user/root/oozie_works/cron_yarn_pi");
        jobConf.setProperty(OozieClient.COORDINATOR_APP_PATH, OozieConstant.HDFSROOTPATH + "/user/root/oozie_works/cron_yarn_pi/coordinator.xml");
        // TODO: 3. 提交执行Oozie Workflow，返回应用提交JobID
        String jobId = oozieClient.run(jobConf);
        System.out.println("JobId = " + jobId);
        // TODO: 4. 依据JobID获取转态信息
        while (oozieClient.getJobInfo(jobId).getStatus() == WorkflowJob.Status.RUNNING) {
            System.out.println("Workflow job running ...");
            Thread.sleep(10 * 1000);
        }
        System.out.println("Workflow job completed ...");
    }
}

Coordinator配置文件：



    FIFO



      ${wf_application_path}


            oozie.use.system.libpath
            True


            start_date
            ${start_date}


            end_date
            ${end_date}
