生产环境kubeadm部署k8s（1.23）高可用集群

kubeadm部署k8s高可用集群

1、设备清单2、各节点下载docker源3、各节点安装docker服务并加入开机启动4、各节点配置docker加速器并修改成k8s驱动5、各节点重启docker服务6、各节点配置hosts文件7、更改各节点主机名8、关闭各个节点防火墙9、关闭各节点SElinux10、关闭各节点swap分区11、各节点重启服务器12、各节点同步的时间13、各节点内核调整,将桥接的IPv4流量传递到iptables的链14、配置各节点k8s的yum源15、各节点安装ipset服务16、各节点开启ipvs模块17、所有master节点安装haproxy和keepalived服务18、修改master1节点keepalived配置文件19、修改master2节点keepalived配置文件20、修改master3节点keepalived配置文件21、三台master节点haproxy配置都一样22、每台master节点编写健康监测脚本23、master节点给脚本增加执行权限24、master节点启动keepalived和haproxy服务并加入开机启动25、查看vip IP地址26、每个节点安装kubeadm,kubelet和kubectl # 安装的kubeadm、kubectl和kubelet要和kubernetes版本一致，kubelet加入开机启动之后不手动启动，要不然会报错，初始化集群之后集群会自动启动kubelet服务！！！27、获取默认配置文件28、修改初始化配置文件29、下载相关镜像30、初始化集群31、在其它两个master节点创建以下目录32、把主master节点证书分别复制到其他master节点33、把 master 主节点的 admin.conf 复制到其他 node 节点34、master节点加入集群执行以下命令35、node节点加入集群执行以下命令36、所有master节点执行以下命令，node节点随意37、查看所有节点状态38、安装网络插件39、查看节点状态40、下载etcdctl客户端命令行工具41、解压并加入环境变量42、验证etcdctl是否能用，出现以下结果代表已经成功了43、查看etcd高可用集群健康状态44、查看etcd高可用集群列表45、查看etcd高可用集群leader46、部署k8s的dashboard

1.1、下载recommended.yaml文件1.2、修改recommended.yaml文件1.3、创建证书1.4、安装dashboard （如果报错：Error from server (AlreadyExists): error when creating "./recommended.yaml": namespaces "kubernetes-dashboard" already exists这个忽略不计，不影响。）1.5、查看安装结果1.6、创建dashboard管理员1.7、部署dashboard-admin.yaml文件1.8、为用户分配权限1.9、查看并复制用户Token2.0、复制token并访问dashboard ip:30000

1、设备清单

设备	IP
master1	10.10.220.10
master2	10.10.220.11
master3	10.10.220.12
slave1	10.10.220.20
slave2	10.10.220.21
vip	10.10.220.29

2、各节点下载docker源

[root@k8s-master01 ~]# yum install -y yum-utils device-mapper-persistent-data lvm2
[root@k8s-master01 ~]# yum-config-manager --add-repo https://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo
[root@k8s-master01 ~]# yum makecache fast

3、各节点安装docker服务并加入开机启动

yum -y install docker-ce && systemctl start docker && systemctl enable docker

4、各节点配置docker加速器并修改成k8s驱动

vi /etc/docker/daemon.json
{
  "exec-opts": ["native.cgroupdriver=systemd"],
  "log-driver": "json-file",
  "log-opts": {
    "max-size": "100m"
  },
  "storage-driver": "overlay2",
  "storage-opts": [
    "overlay2.override_kernel_check=true"
  ]
}

5、各节点重启docker服务

systemctl restart docker &&  systemctl status docker

6、各节点配置hosts文件

vi /etc/hosts
127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4
::1         localhost localhost.localdomain localhost6 localhost6.localdomain6
10.10.220.10 master1
10.10.220.11 master2
10.10.220.12 master3
10.10.220.20 slave1
10.10.220.21 slave2

7、更改各节点主机名

hostnamectl set-hostname 主机名

8、关闭各个节点防火墙

systemctl stop firewalld && systemctl disable firewalld

9、关闭各节点SElinux

[root@master1 ~]# cat /etc/selinux/config

# This file controls the state of SELinux on the system.
# SELINUX= can take one of these three values:
#     enforcing - SELinux security policy is enforced.
#     permissive - SELinux prints warnings instead of enforcing.
#     disabled - No SELinux policy is loaded.
SELINUX=disabled        # 改成disabled
# SELINUXTYPE= can take one of three two values:
#     targeted - Targeted processes are protected,
#     minimum - Modification of targeted policy. only selected processes are protected.
#     mls - Multi Level Security protection.
SELINUXTYPE=targeted

10、关闭各节点swap分区

[root@master1 ~]# vi /etc/fstab

#
# /etc/fstab
# Created by anaconda on Wed Dec 30 15:01:07 2020
#
# Accessible filesystems, by reference, are maintained under '/dev/disk'
# See man pages fstab(5), findfs(8), mount(8) and/or blkid(8) for more info
#
/dev/mapper/centos-root /                       xfs     defaults        0 0
UUID=7321cb15-9220-4cc2-be0c-a4875f6d8bbc /boot                   xfs     defaults        0 0
#/dev/mapper/centos-swap swap                    swap    defaults        0 0         # 注释这行

11、各节点重启服务器

reboot

12、各节点同步的时间

timedatectl set-timezone Asia/Shanghai && chronyc -a makestep

13、各节点内核调整,将桥接的IPv4流量传递到iptables的链

cat > /etc/sysctl.d/k8s.conf << EOF
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
net.ipv4.ip_nonlocal_bind = 1
net.ipv4.ip_forward = 1

sysctl -p /etc/sysctl.d/k8s.conf

14、配置各节点k8s的yum源

cat > /etc/yum.repos.d/kubernetes.repo << EOF
[kubernetes]
name=Kubernetes
baseurl=https://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64/
enabled=1
gpgcheck=1
repo_gpgcheck=1
gpgkey=https://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg https://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg

15、各节点安装ipset服务

yum -y install ipvsadm ipset sysstat conntrack libseccomp

16、各节点开启ipvs模块

cat > /etc/sysconfig/modules/ipvs.modules <
 chmod 755 /etc/sysconfig/modules/ipvs.modules && bash /etc/sysconfig/modules/ipvs.modules && lsmod | grep -e ip_vs -e nf_conntrack_ipv4

17、所有master节点安装haproxy和keepalived服务
yum -y install haproxy keepalived

18、修改master1节点keepalived配置文件
vi /etc/keepalived/keepalived.conf
! Configuration File for keepalived

global_defs {
   router_id LVS_DEVEL

# 添加如下内容
   script_user root
   enable_script_security
}



vrrp_script check_haproxy {
    script "/etc/keepalived/check_haproxy.sh"         # 检测脚本路径
    interval 3
    weight -2
    fall 10
    rise 2
}



vrrp_instance VI_1 {
    state MASTER            # MASTER
    interface eth0         # 本机网卡名
    virtual_router_id 51
    priority 100             # 权重100
    advert_int 1
    authentication {
        auth_type PASS
        auth_pass 1111
    }
    virtual_ipaddress {
        10.10.220.29      # 虚拟IP
    }
    track_script {
        check_haproxy       # 模块
    }
}

19、修改master2节点keepalived配置文件
vi  /etc/keepalived/keepalived.conf
! Configuration File for keepalived

global_defs {
   router_id LVS_DEVEL

# 添加如下内容
   script_user root
   enable_script_security
}



vrrp_script check_haproxy {
    script "/etc/keepalived/check_haproxy.sh"         # 检测脚本路径
    interval 3
    weight -2
    fall 10
    rise 2
}



vrrp_instance VI_1 {
    state BACKUP            # BACKUP
    interface eth0        # 本机网卡名
    virtual_router_id 51
    priority 99             # 权重99
    advert_int 1
    authentication {
        auth_type PASS
        auth_pass 1111
    }
    virtual_ipaddress {
        10.10.220.29     # 虚拟IP
    }
    track_script {
        check_haproxy       # 模块
    }
}

20、修改master3节点keepalived配置文件
vi  /etc/keepalived/keepalived.conf
! Configuration File for keepalived

global_defs {
   router_id LVS_DEVEL

# 添加如下内容
   script_user root
   enable_script_security
}



vrrp_script check_haproxy {
    script "/etc/keepalived/check_haproxy.sh"         # 检测脚本路径
    interval 3
    weight -2
    fall 10
    rise 2
}



vrrp_instance VI_1 {
    state BACKUP            # BACKUP
    interface eth0        # 本机网卡名
    virtual_router_id 51
    priority 99             # 权重99
    advert_int 1
    authentication {
        auth_type PASS
        auth_pass 1111
    }
    virtual_ipaddress {
        10.10.220.29     # 虚拟IP
    }
    track_script {
        check_haproxy       # 模块
    }
}

21、三台master节点haproxy配置都一样
#---------------------------------------------------------------------
# Example configuration for a possible web application.  See the
# full configuration options online.
#
#   http://haproxy.1wt.eu/download/1.4/doc/configuration.txt
#
#---------------------------------------------------------------------

#---------------------------------------------------------------------
# Global settings
#---------------------------------------------------------------------
global
    # to have these messages end up in /var/log/haproxy.log you will
    # need to:
    #
    # 1) configure syslog to accept network log events.  This is done
    #    by adding the '-r' option to the SYSLOGD_OPTIONS in
    #    /etc/sysconfig/syslog
    #
    # 2) configure local2 events to go to the /var/log/haproxy.log
    #   file. A line like the following can be added to
    #   /etc/sysconfig/syslog
    #
    #    local2.*                       /var/log/haproxy.log
    #
    log         127.0.0.1 local2

    chroot      /var/lib/haproxy
    pidfile     /var/run/haproxy.pid
    maxconn     4000
    user        haproxy
    group       haproxy
    daemon

    # turn on stats unix socket
    stats socket /var/lib/haproxy/stats

#---------------------------------------------------------------------
# common defaults that all the 'listen' and 'backend' sections will
# use if not designated in their block
#---------------------------------------------------------------------
defaults
    mode                    http
    log                     global
    option                  httplog
    option                  dontlognull
    option http-server-close
    option forwardfor       except 127.0.0.0/8
    option                  redispatch
    retries                 3
    timeout http-request    10s
    timeout queue           1m
    timeout connect         10s
    timeout client          1m
    timeout server          1m
    timeout http-keep-alive 10s
    timeout check           10s
    maxconn                 3000

#---------------------------------------------------------------------
# main frontend which proxys to the backends
#---------------------------------------------------------------------
frontend  kubernetes-apiserver
    mode                        tcp
    bind                        *:16443
    option                      tcplog
    default_backend             kubernetes-apiserver

#---------------------------------------------------------------------
# static backend for serving up images, stylesheets and such
#---------------------------------------------------------------------
listen stats
    bind            *:1080
    stats auth      admin:admin
    stats refresh   5s
    stats realm     HAProxy Statistics
    stats uri       /admin?stats

#---------------------------------------------------------------------
# round robin balancing between the various backends
#---------------------------------------------------------------------
backend kubernetes-apiserver
    mode        tcp
    balance     roundrobin
    server  master1 10.10.220.10:6443 check
    server  master2 10.10.220.11:6443 check
    server  master3 10.10.220.12:6443 check

22、每台master节点编写健康监测脚本
vi /etc/keepalived/check_haproxy.sh
#!/bin/sh
# HAPROXY down
A=`ps -C haproxy --no-header | wc -l`
if [ $A -eq 0 ]
then
systmectl start haproxy
if [ ps -C haproxy --no-header | wc -l -eq 0 ]
then
killall -9 haproxy
echo "HAPROXY down" | mail -s "haproxy"
sleep 3600
fi

fi

23、master节点给脚本增加执行权限
chmod +x /etc/keepalived/check_haproxy.sh

24、master节点启动keepalived和haproxy服务并加入开机启动
systemctl start keepalived && systemctl enable keepalived
systemctl start haproxy && systemctl enable haproxy

25、查看vip IP地址
[root@master1 ~]# ip a
1: lo:  mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: eth0:  mtu 1500 qdisc pfifo_fast state UP group default qlen 1000
    link/ether 0c:da:41:1d:2a:17 brd ff:ff:ff:ff:ff:ff
    inet 10.10.220.10/24 brd 10.10.220.255 scope global eth0
       valid_lft forever preferred_lft forever
    inet 10.10.220.29/32 scope global eth0
       valid_lft forever preferred_lft forever
    inet6 fe80::eda:41ff:fe1d:2a17/64 scope link
       valid_lft forever preferred_lft forever
3: docker0:  mtu 1500 qdisc noqueue state DOWN group default
    link/ether 02:42:08:75:6c:9a brd ff:ff:ff:ff:ff:ff
    inet 172.17.0.1/16 brd 172.17.255.255 scope global docker0
       valid_lft forever preferred_lft forever

26、每个节点安装kubeadm,kubelet和kubectl # 安装的kubeadm、kubectl和kubelet要和kubernetes版本一致，kubelet加入开机启动之后不手动启动，要不然会报错，初始化集群之后集群会自动启动kubelet服务！！！
yum -y install kubeadm-1.23.4 kubelet-1.23.4 kubectl-1.23.4
systemctl enable kubelet && systemctl daemon-reload

27、获取默认配置文件
kubeadm config print init-defaults > kubeadm-config.yaml

28、修改初始化配置文件
piVersion: kubeadm.k8s.io/v1beta2
bootstrapTokens:
- groups:
  - system:bootstrappers:kubeadm:default-node-token
  token: abcdef.0123456789abcdef
  ttl: 24h0m0s
  usages:
  - signing
  - authentication
kind: InitConfiguration
localAPIEndpoint:
  advertiseAddress: 10.10.220.10     # 本机IP
  bindPort: 6443
nodeRegistration:
  criSocket: /var/run/dockershim.sock
  name: master1        # 本主机名
  taints:
  - effect: NoSchedule
    key: node-role.kubernetes.io/master
---
apiServer:
  timeoutForControlPlane: 4m0s
apiVersion: kubeadm.k8s.io/v1beta2
certificatesDir: /etc/kubernetes/pki
clusterName: kubernetes
controlPlaneEndpoint: "10.10.220.29:16443"    # 虚拟IP和haproxy端口
controllerManager: {}
dns:
  type: CoreDNS
etcd:
  local:
    dataDir: /var/lib/etcd
imageRepository: registry.aliyuncs.com/google_containers    # 镜像仓库源要根据自己实际情况修改
kind: ClusterConfiguration
kubernetesVersion: v1.23.4     # k8s版本
networking:
  dnsDomain: cluster.local
  podSubnet: "10.244.0.0/16"
  serviceSubnet: 10.96.0.0/12
scheduler: {}

---
apiVersion: kubeproxy.config.k8s.io/v1alpha1
kind: KubeProxyConfiguration
featureGates:
  SupportIPVSProxyMode: true

29、下载相关镜像
[root@master1 ~]# kubeadm config images pull --config kubeadm-config.yaml
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-apiserver:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-controller-manager:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-scheduler:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-proxy:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/pause:3.6
[config/images] Pulled registry.aliyuncs.com/google_containers/etcd:3.5.1-0
[config/images] Pulled registry.aliyuncs.com/google_containers/coredns:v1.8.6

30、初始化集群
[root@master1 ~]# kubeadm config images pull --config kubeadm-config.yaml
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-apiserver:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-controller-manager:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-scheduler:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/kube-proxy:v1.23.4
[config/images] Pulled registry.aliyuncs.com/google_containers/pause:3.6
[config/images] Pulled registry.aliyuncs.com/google_containers/etcd:3.5.1-0
[config/images] Pulled registry.aliyuncs.com/google_containers/coredns:v1.8.6
[root@master1 ~]# kubeadm init --config kubeadm-config.yaml
[init] Using Kubernetes version: v1.23.4
[preflight] Running pre-flight checks
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "ca" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local master1] and IPs [10.96.0.1 10.10.220.10 10.10.220.29]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-ca" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/ca" certificate and key
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [localhost master1] and IPs [10.10.220.10 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [localhost master1] and IPs [10.10.220.10 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "sa" key and public key
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[kubeconfig] Writing "admin.conf" kubeconfig file
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[kubeconfig] Writing "kubelet.conf" kubeconfig file
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Starting the kubelet
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
[control-plane] Creating static Pod manifest for "kube-scheduler"
[etcd] Creating static Pod manifest for local etcd in "/etc/kubernetes/manifests"
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[apiclient] All control plane components are healthy after 7.019473 seconds
[upload-config] Storing the configuration used in ConfigMap "kubeadm-config" in the "kube-system" Namespace
[kubelet] Creating a ConfigMap "kubelet-config-1.23" in namespace kube-system with the configuration for the kubelets in the cluster
NOTE: The "kubelet-config-1.23" naming of the kubelet ConfigMap is deprecated. once the UnversionedKubeletConfigMap feature gate graduates to Beta the default name will become just "kubelet-config". Kubeadm upgrade will handle this transition transparently.
[upload-certs] Skipping phase. Please see --upload-certs
[mark-control-plane] Marking the node master1 as control-plane by adding the labels: [node-role.kubernetes.io/master(deprecated) node-role.kubernetes.io/control-plane node.kubernetes.io/exclude-from-external-load-balancers]
[mark-control-plane] Marking the node master1 as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]
[bootstrap-token] Using token: abcdef.0123456789abcdef
[bootstrap-token] Configuring bootstrap tokens, cluster-info ConfigMap, RBAC Roles
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to get nodes
[bootstrap-token] configured RBAC rules to allow Node Bootstrap tokens to post CSRs in order for nodes to get long term certificate credentials
[bootstrap-token] configured RBAC rules to allow the csrapprover controller automatically approve CSRs from a Node Bootstrap Token
[bootstrap-token] configured RBAC rules to allow certificate rotation for all node client certificates in the cluster
[bootstrap-token] Creating the "cluster-info" ConfigMap in the "kube-public" namespace
[kubelet-finalize] Updating "/etc/kubernetes/kubelet.conf" to point to a rotatable kubelet client certificate and key
[addons] Applied essential addon: CoreDNS
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[addons] Applied essential addon: kube-proxy

Your Kubernetes control-plane has initialized successfully!

To start using your cluster, you need to run the following as a regular user:

  mkdir -p $HOME/.kube
  sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
  sudo chown $(id -u):$(id -g) $HOME/.kube/config

Alternatively, if you are the root user, you can run:

  export KUBECONFIG=/etc/kubernetes/admin.conf

You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
  https://kubernetes.io/docs/concepts/cluster-administration/addons/

You can now join any number of control-plane nodes by copying certificate authorities
and service account keys on each node and then running the following as root:

  kubeadm join 10.10.220.29:16443 --token abcdef.0123456789abcdef
        --discovery-token-ca-cert-hash sha256:22ade41b08d214f20b37e0612612ff3a3a3b6927928679f776488bb0ec25d427
        --control-plane

Then you can join any number of worker nodes by running the following on each as root:

kubeadm join 10.10.220.29:16443 --token abcdef.0123456789abcdef
        --discovery-token-ca-cert-hash sha256:22ade41b08d214f20b37e0612612ff3a3a3b6927928679f776488bb0ec25d427

31、在其它两个master节点创建以下目录
mkdir -p /etc/kubernetes/pki/etcd

32、把主master节点证书分别复制到其他master节点
scp /etc/kubernetes/pki/ca.* root@10.10.220.11:/etc/kubernetes/pki/
scp /etc/kubernetes/pki/sa.* root@10.10.220.11:/etc/kubernetes/pki/
scp /etc/kubernetes/pki/front-proxy-ca.* root@10.10.220.11:/etc/kubernetes/pki/
scp /etc/kubernetes/pki/etcd/ca.* root@10.10.220.11:/etc/kubernetes/pki/etcd/
scp /etc/kubernetes/admin.conf root@10.10.220.11:/etc/kubernetes/
scp /etc/kubernetes/pki/ca.* root@10.10.220.12:/etc/kubernetes/pki/
scp /etc/kubernetes/pki/sa.* root@10.10.220.12:/etc/kubernetes/pki/
scp /etc/kubernetes/pki/front-proxy-ca.* root@10.10.220.12:/etc/kubernetes/pki/
scp /etc/kubernetes/pki/etcd/ca.* root@10.10.220.12:/etc/kubernetes/pki/etcd/
scp /etc/kubernetes/admin.conf root@10.10.220.12:/etc/kubernetes/

33、把 master 主节点的 admin.conf 复制到其他 node 节点
scp /etc/kubernetes/admin.conf root@10.10.220.20:/etc/kubernetes/
scp /etc/kubernetes/admin.conf root@10.10.220.21:/etc/kubernetes/

34、master节点加入集群执行以下命令
kubeadm join 10.10.220.29:16443 --token abcdef.0123456789abcdef
    --discovery-token-ca-cert-hash sha256:22ade41b08d214f20b37e0612612ff3a3a3b6927928679f776488bb0ec25d427
    --control-plane

加完后
[root@master3 ~]# kubeadm join 10.10.220.29:16443 --token abcdef.0123456789abcdef
>     --discovery-token-ca-cert-hash sha256:22ade41b08d214f20b37e0612612ff3a3a3b6927928679f776488bb0ec25d427
>     --control-plane
[preflight] Running pre-flight checks
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[preflight] Running pre-flight checks before initializing the new control plane instance
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [localhost master3] and IPs [10.10.220.12 127.0.0.1 ::1]
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [localhost master3] and IPs [10.10.220.12 127.0.0.1 ::1]
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local master3] and IPs [10.96.0.1 10.10.220.12 10.10.220.29]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Valid certificates and keys now exist in "/etc/kubernetes/pki"
[certs] Using the existing "sa" key
[kubeconfig] Generating kubeconfig files
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[kubeconfig] Using existing kubeconfig file: "/etc/kubernetes/admin.conf"
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[endpoint] WARNING: port specified in controlPlaneEndpoint overrides bindPort in the controlplane address
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
[control-plane] Creating static Pod manifest for "kube-scheduler"
[check-etcd] Checking that the etcd cluster is healthy
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...
[etcd] Announced new etcd member joining to the existing etcd cluster
[etcd] Creating static Pod manifest for "etcd"
[etcd] Waiting for the new etcd member to join the cluster. This can take up to 40s
The 'update-status' phase is deprecated and will be removed in a future release. Currently it performs no operation
[mark-control-plane] Marking the node master3 as control-plane by adding the labels: [node-role.kubernetes.io/master(deprecated) node-role.kubernetes.io/control-plane node.kubernetes.io/exclude-from-external-load-balancers]
[mark-control-plane] Marking the node master3 as control-plane by adding the taints [node-role.kubernetes.io/master:NoSchedule]

This node has joined the cluster and a new control plane instance was created:

* Certificate signing request was sent to apiserver and approval was received.
* The Kubelet was informed of the new secure connection details.
* Control plane (master) label and taint were applied to the new node.
* The Kubernetes control plane instances scaled up.
* A new etcd member was added to the local/stacked etcd cluster.

To start administering your cluster from this node, you need to run the following as a regular user:

        mkdir -p $HOME/.kube
        sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
        sudo chown $(id -u):$(id -g) $HOME/.kube/config

Run 'kubectl get nodes' to see this node join the cluster.

35、node节点加入集群执行以下命令
[root@slave2 ~]# kubeadm join 10.10.220.29:16443 --token abcdef.0123456789abcdef
>     --discovery-token-ca-cert-hash sha256:22ade41b08d214f20b37e0612612ff3a3a3b6927928679f776488bb0ec25d427
[preflight] Running pre-flight checks
[preflight] Reading configuration from the cluster...
[preflight] FYI: You can look at this config file with 'kubectl -n kube-system get cm kubeadm-config -o yaml'
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Starting the kubelet
[kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap...

This node has joined the cluster:
* Certificate signing request was sent to apiserver and a response was received.
* The Kubelet was informed of the new secure connection details.

Run 'kubectl get nodes' on the control-plane to see this node join the cluster.

36、所有master节点执行以下命令，node节点随意
root用户执行以下命令
echo "export KUBEConFIG=/etc/kubernetes/admin.conf" >> ~/.bash_profile
source .bash_profile

非root用户执行以下命令
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config


37、查看所有节点状态
[root@master1 ~]# kubectl get nodes
NAME      STATUS     ROLES    AGE     VERSION
master1   NotReady   master   4m54s   v1.18.2
master2   NotReady   master   2m27s   v1.18.2
master3   NotReady   master   93s     v1.18.2
node1     NotReady      76s     v1.18.2


38、安装网络插件
kubectl apply -f https://raw.githubusercontent.com/coreos/flannel/master/documentation/kube-flannel.yml

39、查看节点状态
[root@master1 ~]# kubectl get nodes
NAME      STATUS   ROLES                  AGE     VERSION
master1   Ready    control-plane,master   41m     v1.23.4
master2   Ready    control-plane,master   12m     v1.23.4
master3   Ready    control-plane,master   10m     v1.23.4
slave1    Ready                     8m41s   v1.23.4
slave2    Ready                     7m46s   v1.23.4


40、下载etcdctl客户端命令行工具
wget https://github.com/etcd-io/etcd/releases/download/v3.4.14/etcd-v3.4.14-linux-amd64.tar.gz

41、解压并加入环境变量
tar -zxf etcd-v3.4.14-linux-amd64.tar.gz
mv etcd-v3.4.14-linux-amd64/etcdctl /usr/local/bin
chmod +x /usr/local/bin/

42、验证etcdctl是否能用，出现以下结果代表已经成功了
[root@master1 ~]# etcdctl
NAME:
	etcdctl - A simple command line client for etcd3.

USAGE:
	etcdctl [flags]

VERSION:
	3.4.14

API VERSION:
	3.4


COMMANDS:
	alarm disarm		Disarms all alarms
	alarm list		Lists all alarms
	auth disable		Disables authentication
	auth enable		Enables authentication
	check datascale		Check the memory usage of holding data for different workloads on a given server endpoint.
	check perf		Check the performance of the etcd cluster
	compaction		Compacts the event history in etcd
	defrag			Defragments the storage of the etcd members with given endpoints
	del			Removes the specified key or range of keys [key, range_end)
	elect			Observes and participates in leader election
	endpoint hashkv		Prints the KV history hash for each endpoint in --endpoints
	endpoint health		Checks the healthiness of endpoints specified in `--endpoints` flag
	endpoint status		Prints out the status of endpoints specified in `--endpoints` flag
	get			Gets the key or a range of keys
	help			Help about any command
	lease grant		Creates leases
	lease keep-alive	Keeps leases alive (renew)
	lease list		List all active leases
	lease revoke		Revokes leases
	lease timetolive	Get lease information
	lock			Acquires a named lock
	make-mirror		Makes a mirror at the destination etcd cluster
	member add		Adds a member into the cluster
	member list		Lists all members in the cluster
	member promote		Promotes a non-voting member in the cluster
	member remove		Removes a member from the cluster
	member update		Updates a member in the cluster
	migrate			Migrates keys in a v2 store to a mvcc store
	move-leader		Transfers leadership to another etcd cluster member.
	put			Puts the given key into the store
	role add		Adds a new role
	role delete		Deletes a role
	role get		Gets detailed information of a role
	role grant-permission	Grants a key to a role
	role list		Lists all roles
	role revoke-permission	Revokes a key from a role
	snapshot restore	Restores an etcd member snapshot to an etcd directory
	snapshot save		Stores an etcd node backend snapshot to a given file
	snapshot status		Gets backend snapshot status of a given file
	txn			Txn processes all the requests in one transaction
	user add		Adds a new user
	user delete		Deletes a user
	user get		Gets detailed information of a user
	user grant-role		Grants a role to a user
	user list		Lists all users
	user passwd		Changes password of user
	user revoke-role	Revokes a role from a user
	version			Prints the version of etcdctl
	watch			Watches events stream on keys or prefixes

OPTIONS:
      --cacert=""				verify certificates of TLS-enabled secure servers using this CA bundle
      --cert=""					identify secure client using this TLS certificate file
      --command-timeout=5s			timeout for short running command (excluding dial timeout)
      --debug[=false]				enable client-side debug logging
      --dial-timeout=2s				dial timeout for client connections
  -d, --discovery-srv=""			domain name to query for SRV records describing cluster endpoints
      --discovery-srv-name=""			service name to query when using DNS discovery
      --endpoints=[127.0.0.1:2379]		gRPC endpoints
  -h, --help[=false]				help for etcdctl
      --hex[=false]				print byte strings as hex encoded strings
      --insecure-discovery[=true]		accept insecure SRV records describing cluster endpoints
      --insecure-skip-tls-verify[=false]	skip server certificate verification (CAUTION: this option should be enabled only for testing purposes)
      --insecure-transport[=true]		disable transport security for client connections
      --keepalive-time=2s			keepalive time for client connections
      --keepalive-timeout=6s			keepalive timeout for client connections
      --key=""					identify secure client using this TLS key file
      --password=""				password for authentication (if this option is used, --user option shouldn't include password)
      --user=""					username[:password] for authentication (prompt if password is not supplied)
  -w, --write-out="simple"			set the output format (fields, json, protobuf, simple, table)


43、查看etcd高可用集群健康状态
[root@master1 ~]# ETCDCTL_API=3 etcdctl --cacert=/etc/kubernetes/pki/etcd/ca.crt --cert=/etc/kubernetes/pki/etcd/peer.crt --key=/etc/kubernetes/pki/etcd/peer.key --write-out=table --endpoints=192.168.200.3:2379,192.168.200.4:2379,192.168.200.5:2379 endpoint health
+--------------------+--------+-------------+-------+
|      ENDPOINT      | HEALTH |    TOOK     | ERROR |
+--------------------+--------+-------------+-------+
| 192.168.200.3:2379 |   true | 60.655523ms |       |
| 192.168.200.4:2379 |   true |  60.79081ms |       |
| 192.168.200.5:2379 |   true | 63.585221ms |       |
+--------------------+--------+-------------+-------+

44、查看etcd高可用集群列表
[root@master1 ~]# ETCDCTL_API=3 etcdctl --cacert=/etc/kubernetes/pki/etcd/ca.crt --cert=/etc/kubernetes/pki/etcd/peer.crt --key=/etc/kubernetes/pki/etcd/peer.key --write-out=table --endpoints=192.168.200.3:2379,192.168.200.4:2379,192.168.200.5:2379 member list
+------------------+---------+---------+----------------------------+----------------------------+------------+
|        ID        | STATUS  |  NAME   |         PEER ADDRS         |        CLIENT ADDRS        | IS LEARNER |
+------------------+---------+---------+----------------------------+----------------------------+------------+
| 4a8537d90d14a19b | started | master1 | https://192.168.200.3:2380 | https://192.168.200.3:2379 |      false |
| 4f48f36de1949337 | started | master2 | https://192.168.200.4:2380 | https://192.168.200.4:2379 |      false |
| 88fb5c8676da6ea1 | started | master3 | https://192.168.200.5:2380 | https://192.168.200.5:2379 |      false |
+------------------+---------+---------+----------------------------+----------------------------+------------+

45、查看etcd高可用集群leader
[root@master1 ~]# ETCDCTL_API=3 etcdctl --cacert=/etc/kubernetes/pki/etcd/ca.crt --cert=/etc/kubernetes/pki/etcd/peer.crt --key=/etc/kubernetes/pki/etcd/peer.key --write-out=table --endpoints=192.168.200.3:2379,192.168.200.4:2379,192.168.200.5:2379 endpoint status
+--------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|      ENDPOINT      |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+--------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 192.168.200.3:2379 | 4a8537d90d14a19b |   3.4.3 |  2.8 MB |      true |      false |         7 |       2833 |               2833 |        |
| 192.168.200.4:2379 | 4f48f36de1949337 |   3.4.3 |  2.7 MB |     false |      false |         7 |       2833 |               2833 |        |
| 192.168.200.5:2379 | 88fb5c8676da6ea1 |   3.4.3 |  2.7 MB |     false |      false |         7 |       2833 |               2833 |        |
+--------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

46、部署k8s的dashboard
1.1、下载recommended.yaml文件
wget https://raw.githubusercontent.com/kubernetes/dashboard/v2.0.0/aio/deploy/recommended.yaml

1.2、修改recommended.yaml文件
---
kind: Service
apiVersion: v1
metadata:
  labels:
    k8s-app: kubernetes-dashboard
  name: kubernetes-dashboard
  namespace: kubernetes-dashboard
spec:
  type: NodePort #增加
  ports:
    - port: 443
      targetPort: 8443
      nodePort: 30000 #增加
  selector:
    k8s-app: kubernetes-dashboard
---

1.3、创建证书
mkdir dashboard-certs

cd dashboard-certs/

#创建命名空间
kubectl create namespace kubernetes-dashboard

# 创建key文件
openssl genrsa -out dashboard.key 2048

#证书请求
openssl req -days 36000 -new -out dashboard.csr -key dashboard.key -subj '/CN=dashboard-cert'

#自签证书
openssl x509 -req -in dashboard.csr -signkey dashboard.key -out dashboard.crt


1.4、安装dashboard （如果报错：Error from server (AlreadyExists): error when creating “./recommended.yaml”: namespaces “kubernetes-dashboard” already exists这个忽略不计，不影响。）
kubectl apply -f recommended.yaml

1.5、查看安装结果
NAMESPACE              NAME                                         READY   STATUS    RESTARTS      AGE     IP             NODE      NOMINATED NODE   READINESS GATES
kube-system            coredns-6d8c4cb4d-hx88z                      1/1     Running   0             50m     10.244.4.3     slave2
kube-system            coredns-6d8c4cb4d-zngd4                      1/1     Running   0             71m     10.244.4.2     slave2
kube-system            etcd-master1                                 1/1     Running   1 (30h ago)   2d22h   10.10.220.10   master1
kube-system            etcd-master2                                 1/1     Running   1 (30h ago)   2d22h   10.10.220.11   master2
kube-system            etcd-master3                                 1/1     Running   1 (30h ago)   2d22h   10.10.220.12   master3
kube-system            kube-apiserver-master1                       1/1     Running   1 (30h ago)   2d22h   10.10.220.10   master1
kube-system            kube-apiserver-master2                       1/1     Running   1 (30h ago)   2d22h   10.10.220.11   master2
kube-system            kube-apiserver-master3                       1/1     Running   1 (30h ago)   2d22h   10.10.220.12   master3
kube-system            kube-controller-manager-master1              1/1     Running   4 (30h ago)   2d22h   10.10.220.10   master1
kube-system            kube-controller-manager-master2              1/1     Running   2 (20h ago)   2d22h   10.10.220.11   master2
kube-system            kube-controller-manager-master3              1/1     Running   2 (30h ago)   2d22h   10.10.220.12   master3
kube-system            kube-flannel-ds-2l7f5                        1/1     Running   0             44m     10.10.220.11   master2
kube-system            kube-flannel-ds-6ljmp                        1/1     Running   0             44m     10.10.220.20   slave1
kube-system            kube-flannel-ds-6vdgh                        1/1     Running   0             44m     10.10.220.12   master3
kube-system            kube-flannel-ds-7jbwh                        1/1     Running   0             44m     10.10.220.10   master1
kube-system            kube-flannel-ds-krg2b                        1/1     Running   0             44m     10.10.220.21   slave2
kube-system            kube-proxy-6zggm                             1/1     Running   0             74m     10.10.220.21   slave2
kube-system            kube-proxy-bzgwm                             1/1     Running   0             75m     10.10.220.20   slave1
kube-system            kube-proxy-g6rqq                             1/1     Running   0             75m     10.10.220.12   master3
kube-system            kube-proxy-gpts8                             1/1     Running   0             74m     10.10.220.11   master2
kube-system            kube-proxy-hk9xh                             1/1     Running   0             75m     10.10.220.10   master1
kube-system            kube-scheduler-master1                       1/1     Running   3 (30h ago)   2d22h   10.10.220.10   master1
kube-system            kube-scheduler-master2                       1/1     Running   1 (30h ago)   2d22h   10.10.220.11   master2
kube-system            kube-scheduler-master3                       1/1     Running   3             2d22h   10.10.220.12   master3
kubernetes-dashboard   dashboard-metrics-scraper-799d786dbf-rl9v7   1/1     Running   0             71s     10.244.3.3     slave1
kubernetes-dashboard   kubernetes-dashboard-7577b7545-vbslg         1/1     Running   0             71s     10.244.3.2     slave1

1.6、创建dashboard管理员
vim dashboard-admin.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
  labels:
    k8s-app: kubernetes-dashboard
  name: dashboard-admin
  namespace: kubernetes-dashboard

1.7、部署dashboard-admin.yaml文件
kubectl apply -f dashboard-admin.yaml

1.8、为用户分配权限
vim dashboard-admin-bind-cluster-role.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: dashboard-admin-bind-cluster-role
  labels:
    k8s-app: kubernetes-dashboard
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
- kind: ServiceAccount
  name: dashboard-admin
  namespace: kubernetes-dashboard

kubectl apply -f dashboard-admin-bind-cluster-role.yaml

1.9、查看并复制用户Token
[root@master1 ~]# kubectl -n kubernetes-dashboard describe secret $(kubectl -n kubernetes-dashboard get secret | grep dashboard-admin | awk '{print $1}')
Name:         dashboard-admin-token-f5ljr
Namespace:    kubernetes-dashboard
Labels:
Annotations:  kubernetes.io/service-account.name: dashboard-admin
              kubernetes.io/service-account.uid: 95741919-e296-498e-8e10-233c4a34b07a

Type:  kubernetes.io/service-account-token

Data
====
ca.crt:     1025 bytes
namespace:  20 bytes
token:      eyJhbGciOiJSUzI1NiIsImtpZCI6Iko5TVI0VVQ2TndBSlBLc2Rxby1CWGxSNHlxYXREWGdVOENUTFVKUmFGakEifQ.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.tP3EFBeOIJg7_cgJ-M9SDqTtPcfmoJU0nTTGyb8Sxag6Zq4K-g1lCiDqIFbVgrd-4nM7cOTMBfMwyKgdf_Xz573omNNrPDIJCTYkNx2qFN0qfj5qp8Txia3JV8FKRdrmqsap11ItbGD9a7uniIrauc6JKPgksK_WvoXZbKglEUla98ZU9PDm5YXXq8STyUQ6egi35vn5EYCPa-qkUdecE-0N06ZbTFetIYsHEnpswSu8LZZP_Zw7LEfnX9IVdl1147i4OpF4ET9zBDfcJTSr-YE7ILuv1FDYvvo1KAtKawUbGu9dJxsObLeTh5fHx_JWyqg9cX0LB3Gd1ZFm5z5s4g

2.0、复制token并访问dashboard ip:30000
问题：
namespaces is forbidden: User "system:serviceaccount:kubernetes-dashboard:kubernetes-dashboard" cannot list resource "namespaces" in API group "" at the cluster scope"

生产环境kubeadm部署k8s（1.23）高可用集群

Linux相关栏目本月热门文章
