1. 环境

K8s nodes:

       master-node(192.168.2.51)

       slave-node(192.168.2.52)

2. 部署

2.1 部署contour+envoy

kubectl apply -f https://projectcontour.io/quickstart/contour.yaml

有2个envoy pod，查看其中1个:

kubectl describe pod -n projectcontour envoy-g4gk9

每个envoy pod里有2个container：shutdown-manager和envoy：

​2.2 部署不同版本的业务pod

为测试envoy功能，部署2个不同业务pod；按照不同的规则，流量引到某个pod上。

2.1.1 create

kubectl create deployment demoappv11 --image='ikubernetes/demoapp:v1.1' -n dev
kubectl create deployment demoappv12 --image='ikubernetes/demoapp:v1.2' -n dev

2.1.2 创造与之对应的SVC

kubectl create service clusterip demoappv11 --tcp=80 -n dev
kubectl create service clusterip demoappv12 --tcp=80 -n dev

kubectl get svc -n dev

查看每个pod的ClusterIP及对应的service ip:

2.1.3 pods部署结果：

master-node与worker-node 各1个envoy pod;

2个demoapp pod都在worker-node上.

2.1.4 访问测试：

在master上curl demoapp的ip:

2.3 部署dev namespace的httpproxy

sudo vim httpproxy-headers-routing.yaml

apiVersion: projectcontour.io/v1
kind: HTTPProxy
metadata:
  name: httpproxy-headers-routing
  namespace: dev
spec:
  virtualhost:
    fqdn: www.ilinux.io
  routes:  #路由
  - conditions:
    - header:
        name: X-Canary  #header中包含X-Canary:true
        present: true
    - header:
        name: User-Agent #header中包含curl
        contains: curl
    services:  #满足以上两个条件路由到demoappv11
    - name: demoappv11
      port: 80
  - services:  #其他不满足条件路由到demoapp12
    - name: demoappv12
      port: 80

kubectl apply -f httpproxy-headers-routing.yaml

3 数据流转与流量流转

参见 云原生 -- contour+envoy流量转发

4 测试Envoy

4.1 基本测试

4.1.1 配置

在其他主机上配置 /etc/hosts： 让 www.ilinux.io 选worker node 192.168.2.52

sudo vim /etc/hosts   #添加hosts
192.168.2.52  www.ilinux.io  #设置成worker-node

4.1.2 打开log监测

envoy的log:

Master:

kubectl logs envoy-rlrng envoy -n projectcontour -f

Worker:

kubectl logs envoy-g4gk9 envoy -n projectcontour -f

业务pod的log:

worker上的demoappv11和demoappv12的log:

kubectl logs demoappv11-c94b75cdb-2l4js -n dev -f
kubectl logs demoappv12-5565b67f86-8fcwf -n dev -f

4.2 在主机上curl

4.2.1 默认为1.2版本

curl http://www.ilinux.io

iKubernetes demoapp v1.2 !! ClientIP: 10.244.0.6, ServerName: demoappv12-5565b67f86-8fcwf, ServerIP: 10.244.1.4!

先在worker-node的demoapp1.2上可以看到log:

10.244.0.6 - - [17/Feb/2022 03:16:41] "GET / HTTP/1.1" 200 -

再envoy worker-node上可以看到log:

[2022-02-17T03:16:41.160Z] "GET / HTTP/1.1" 200 - 0 113 4 3 "192.168.2.52" "curl/7.68.0" "1741571e-087e-46cd-994d-98527496fc88" "www.ilinux.io" "10.244.1.4:80"

4.2.2 带 X-Canary:true选 1.1版本：

curl -H "X-Canary:true" http://www.ilinux.io

iKubernetes demoapp v1.1 !! ClientIP: 10.244.0.6, ServerName: demoappv11-c94b75cdb-2l4js, ServerIP: 10.244.1.3!

先在worker-node的demoapp1.1上可以看到log:

10.244.0.6 - - [17/Feb/2022 03:15:42] "GET / HTTP/1.1" 200 -

再envoy worker-node上可以看到log:
[2022-02-17T03:15:42.897Z] "GET / HTTP/1.1" 200 - 0 112 4 3 "192.168.2.52" "curl/7.68.0" "e80b8dfe-8a51-4a80-9eb0-cdbab4a9cff3" "www.ilinux.io" "10.244.1.3:80"
