import cv2
import numpy as np
import os
im = cv2.imread("lamp1.jpg")
sp = im.shape
sz1 = sp[0]#height(rows) of image
sz2 = sp[1]#width(colums) of image
sz3 = sp[2]#the pixels value is made up of three primary colors
if(sz2>4000 and sz2<6000):
Wth = sz2/2
Ht = sz1/2
elif(sz2>6000 and sz2<9000):
Wth = sz2/3
Ht = sz1/3
else:
Wth = sz2
Ht = sz1
image = cv2.resize(im,(Wth,Ht),interpolation=cv2.INTER_CUBIC) #resize 1500,1000
gray = cv2.cvtColor(image, cv2.COLOR_BGR2GRAY)
#cv2.imshow("Image", image)
gradX = cv2.Sobel(gray, ddepth=cv2.cv.CV_32F, dx=1, dy=0, ksize=-1)
gradY = cv2.Sobel(gray, ddepth=cv2.cv.CV_32F, dx=0, dy=1, ksize=-1)
# subtract the y-gradient from the x-gradient
gradient = cv2.subtract(gradX, gradY)
gradient = cv2.convertScaleAbs(gradient)
# blur and threshold the image
blurred = cv2.blur(gradient, (9, 9))
(_, thresh) = cv2.threshold(blurred, 80, 255, cv2.THRESH_BINARY) #ret 90
kernel = cv2.getStructuringElement(cv2.MORPH_RECT, (25, 25))
closed = cv2.morphologyEx(thresh, cv2.MORPH_CLOSE, kernel)
# perform a series of erosions and dilations
closed = cv2.erode(closed, None, iterations=4)
closed = cv2.dilate(closed, None, iterations=4)
(cnts, _) = cv2.findContours(closed.copy(), cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE)
'''
def Crop_Img(i):
c = sorted(cnts, key=cv2.contourArea, reverse=True)[i]
print c
'''
if (os.path.exists('sbphW')==False):
os.mkdir('sbphW')
for n in range(0, len(cnts)):
c = sorted(cnts, key=cv2.contourArea, reverse=True)[n]
# compute the rotated bounding box of the largest contour
rect = cv2.minAreaRect(c)
box = np.int0(cv2.cv.BoxPoints(rect))
# draw a bounding box arounded the detected barcode and display the image
# cv2.drawContours(image, [box], -1, (0, 255, 0), 3)
Xs = [i[0] for i in box]
Ys = [i[1] for i in box]
# x1 = min(Xs)
# x2 = max(Xs)
# y1 = min(Ys)
# y2 = max(Ys)
x1 = min(Xs)*2
x2 = max(Xs)*2
y1 = min(Ys)*2
y2 = max(Ys)*2
hight = y2 - y1
width = x2 - x1
# cropImg = image[y1:y1+hight, x1:x1+width]
cropImg = im[y1:y1+hight, x1:x1+width] #origin image for cut
# cv2.imshow("Image", image)
if (hight > 30 and width > 30):
cv2.imwrite("sbphWcImg7_" + str(n)+ ".jpg", cropImg)
cv2.waitKey(0)
'''
# draw a bounding box arounded the detected barcode and display the image
cv2.drawContours(image, [box], -1, (0, 255, 0), 3)
Xs = [i[0] for i in box]
Ys = [i[1] for i in box]
x1 = min(Xs)
x2 = max(Xs)
y1 = min(Ys)
y2 = max(Ys)
hight = y2 - y1
width = x2 - x1
cropImg = image[y1:y1+hight, x1:x1+width]
cv2.imshow("Image", image)
cv2.imwrite("cImg.jpg", cropImg)
cv2.waitKey(0)
'''
