TDEngine 集群安装 (K8S)

#!/bin/bash

set +e
ulimit -c unlimited
sysctl -w kernel.core_pattern=/corefile/core-%e-%p

if [ "x$TZ" != "x" ]; then
    ln -sf /usr/share/zoneinfo/$TZ /etc/localtime
fi

if [ "$TAOS_FQDN" = "" ]; then
    echo "TAOS_FQDN not set"
    exit 1
fi

sed -i "s#.*fqdn.*#fqdn    ${TAOS_FQDN}#" /etc/taos/taos.cfg
if [ $? -ne 0 ]; then
    echo "refreshing fqdn failed"
    exit 1
fi

if [ "x$TAOS_FIRST_EP" != "x" ]; then
    sed -i "s#.*firstEp.*#firstEp     ${TAOS_FIRST_EP}#" /etc/taos/taos.cfg
    if [ $? -ne 0 ]; then
        echo "refreshing firstEp failed"
        exit 1
    fi
fi

if [ "x$TAOS_SERVER_PORT" != "x" ]; then
    sed -i "s#.*serverPort.*#serverPort     ${TAOS_SERVER_PORT}#" /etc/taos/taos.cfg
    if [ $? -ne 0 ]; then
        echo "refreshing serverPort failed"
        exit 1
    fi
fi


CLUSTER=${CLUSTER:=}
FIRST_EP_HOST=${TAOS_FIRST_EP%:*}
SERVER_PORT=${TAOS_SERVER_PORT:-6030}


if [ "$CLUSTER" = "" ]; then
    # single node
    $@
elif [ "$TAOS_FQDN" = "$FIRST_EP_HOST" ] ; then
    # master node
    $@
else
    # follower, wait for master node ready
    while true
    do
        taos -h $FIRST_EP_HOST -n startup > /dev/null
        if [ $? -eq 0 ]; then
            taos -h $FIRST_EP_HOST -s "create dnode "$TAOS_FQDN:$SERVER_PORT";"
            break
        fi
        sleep 1s
    done

    $@
fi

通过源码方式构建镜像，同时支持 AMD64 & ARM64 系统

FROM ubuntu:18.04 as builder
RUN apt-get update
    && apt-get install -y gcc cmake build-essential git wget
    && apt-get clean
    && cd /usr/local/src
    && wget https://github.com/taosdata/TDengine/archive/refs/tags/ver-2.4.0.0.tar.gz
    && tar zxvf ver-2.4.0.0.tar.gz && cd TDengine-ver-2.4.0.0
    && mkdir debug && cd debug
    && cmake .. && cmake --build . && make install
WORKDIR /root


FROM ubuntu:18.04
LABEL MAINTAINER="eli.he@outlook.com>"

COPY ./entrypoint.sh /usr/bin/
COPY --from=0 /usr/local/taos /usr/local/taos
COPY --from=0 /etc/taos /etc/taos

ENV DEBIAN_FRonTEND=noninteractive
RUN apt-get update
    && apt-get install -y apt-utils locales tzdata curl wget net-tools iproute2 iputils-ping sysstat binutils
    && locale-gen en_US.UTF-8
    && apt-get clean
    && chmod +x /usr/bin/entrypoint.sh
    && ln -s /usr/local/taos/bin/taos /usr/bin/taos
    && ln -s /usr/local/taos/bin/taosd       /usr/bin/taosd
    && ln -s /usr/local/taos/bin/taosdump    /usr/bin/taosdump
    && ln -s /usr/local/taos/bin/taosdemo    /usr/bin/taosdemo
    && ln -s /usr/local/taos/bin/remove.sh   /usr/bin/rmtaos
    && ln -s /usr/local/taos/include/taoserror.h  /usr/include/taoserror.h
    && ln -s /usr/local/taos/include/taos.h  /usr/include/taos.h
    && ln -s /usr/local/taos/driver/libtaos.so.2.4.0.0  /usr/lib/libtaos.so.1
    && ln -s /usr/lib/libtaos.so.1 /usr/lib/libtaos.so
    && mkdir -p /var/lib/taos
    && mkdir -p /var/log/taos
    && chmod 777 /var/log/taos

ENV LC_ALL=en_US.UTF-8
ENV LANG=en_US.UTF-8
ENV LANGUAGE=en_US.UTF-8

WORKDIR /etc/taos
EXPOSE 6030 6031 6032 6033 6034 6035 6036 6037 6038 6039 6040 6041 6042
CMD ["taosd"]
VOLUME [ "/var/lib/taos", "/var/log/taos", "/corefile" ]
ENTRYPOINT [ "/usr/bin/entrypoint.sh" ]

docker build -t tdengine:2.4.0.0 .

$ mkdir ~/taos && cd $_

$ cat > taos-namespace.yml <
2.2 创建 ConfigMap
$ cat > taos-configmap.yml <
2.3 创建 PV
暂时使用本地文件系统，可换成 Ceph 等

# 1. 所有节点上，挂载相应的存储盘或路径
$ mkdir -p /data/tdengine

# 2. 创建PV
$ cat > taos-pv.yml <
2.4 创建 PVC
$ cat > taos-pvc.yml <
2.5 创建 Service (无头服务)
$ cat > taos-headless.yml <
2.6 创建 StatefulSet
$ cat > taos-app.yml <
2.7 创建 Service (外部访问)
cat > taos-external-svc.yml <
3. 验证
3.1 kubectl
登录到容器中，执行命令检查集群状态

$ kubectl exec -it tdengine-0 -n taos-cluster -- taos -s "show dnodes;"

Welcome to the TDengine shell from Linux, Client Version:2.2.2.0
Copyright (c) 2020 by TAOS Data, Inc. All rights reserved.

taos> show dnodes;
   id   |           end_point            | vnodes | cores  |   status   | role  |       create_time       |      offline reason      |
======================================================================================================================================
      1 | tdengine-0.taosd.taos-clust... |      0 |      2 | ready      | any   | 2021-11-26 02:42:25.932 |                          |
      2 | tdengine-1.taosd.taos-clust... |      1 |      2 | ready      | any   | 2021-11-26 02:42:35.633 |                          |
      3 | tdengine-2.taosd.taos-clust... |      1 |      2 | ready      | any   | 2021-11-26 02:42:48.004 |                          |
Query OK, 3 row(s) in set (0.001099s)

3.2 restful
容器外部，使用restful接口访问，注意：容器外，无法之间使用taos客户端连接

$ curl -H 'Authorization: Basic cm9vdDp0YW9zZGF0YQ==' -d 'show databases;' 192.168.80.240:36041/rest/sql
{"status":"succ","head":["name","created_time","ntables","vgroups","replica","quorum","days","keep","cache(MB)","blocks","minrows","maxrows","wallevel","fsync","comp","cachelast","precision","update","status"],"column_meta":[["name",8,32],["created_time",9,8],["ntables",4,4],["vgroups",4,4],["replica",3,2],["quorum",3,2],["days",3,2],["keep",8,24],["cache(MB)",4,4],["blocks",4,4],["minrows",4,4],["maxrows",4,4],["wallevel",2,1],["fsync",4,4],["comp",2,1],["cachelast",2,1],["precision",8,3],["update",2,1],["status",8,10]],"data":[["log","2021-11-26 02:42:26.936",6,1,1,1,10,"30",1,3,100,4096,1,3000,2,0,"us",0,"ready"],["iec61850","2021-12-01 01:13:56.176",59,1,1,1,10,"365",16,6,100,4096,1,3000,2,0,"ms",0,"ready"]],"rows":2}

$ curl -u root:taosdata -d 'show databases;' 192.168.80.240:36041/rest/sql

参考资料：

https://github.com/taosdata/TDengine-Operator 【官方 kubernetes 安装tdengine 方案】
