Springboot使用fabric8调用Kubernetes Api(token方式)

fabric8官方Github地址

其中kubernetes-examples模块中有大量示例代码可以参考

一、引入依赖


    io.fabric8
    kubernetes-client
    5.0.0

二、获取token

要调用kubernetes的api需要认证,认证方式有多种,这里介绍token方式

1、创建一个具有管理员权限的账户

创建账户咱们还是通过kubectl运行yml文件方式,k8s-admin.yml

---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: dashboard-admin
  namespace: kube-system
---
kind: ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1beta1
metadata:
  name: dashboard-admin
subjects:
  - kind: ServiceAccount
    name: dashboard-admin
    namespace: kube-system
roleRef:
  kind: ClusterRole
  name: cluster-admin
  apiGroup: rbac.authorization.k8s.io

执行命令即可创建: kubectl apply -f k8s-admin.yaml

2、获取新建账户的token

第一步: kubectl -n kube-system get sa dashboard-admin -o yaml

第二步: kubectl describe secret dashboard-admin-token-8h9j8 -n kube-system

三、调用测试

package com.imysh.zmy.k8s.api.service;

import io.fabric8.kubernetes.api.model.NamespaceList;
import io.fabric8.kubernetes.client.Config;
import io.fabric8.kubernetes.client.ConfigBuilder;
import io.fabric8.kubernetes.client.DefaultKubernetesClient;
import io.fabric8.kubernetes.client.KubernetesClient;


public class ApiService {

    public static void main(String[] args) {
        String base64Token = "eyJhbGciOiJSUzI1NiIsImtpZCI6ImNlQU44STJjX0c3bjhpYTY0NjBJYlpkSmc2dHExUUR5Vk8wblNSdkRjRFEifQ" +
                ".eyJpc3MiOiJrdWJlcm5ldGVzL3NlcnZpY2VhY2NvdW50Iiwia3ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9uYW1lc3BhY2UiOiJ" +
                "rdWJlLXN5c3RlbSIsImt1YmVybmV0ZXMuaW8vc2VydmljZWFjY291bnQvc2VjcmV0Lm5hbWUiOiJkYXNoYm9hcmQtYWRtaW4tdG9rZW4t" +
                "OGg5ajgiLCJrdWJlcm5ldGVzLmlvL3NlcnZpY2VhY2NvdW50L3NlcnZpY2UtYWNjb3VudC5uYW1lIjoiZGFzaGJvYXJkLWFkbWluIiwia3" +
                "ViZXJuZXRlcy5pby9zZXJ2aWNlYWNjb3VudC9zZXJ2aWNlLWFjY291bnQudWlkIjoiMDQ2NTU2ZmEtNWZmZC00MjkxLWJjMzgtNTk1NWZhMG" +
                "U0NjExIiwic3ViIjoic3lzdGVtOnNlcnZpY2VhY2NvdW50Omt1YmUtc3lzdGVtOmRhc2hib2FyZC1hZG1pbiJ9.pPh5dXVocHUB-x72B3lFhU" +
                "AcjGFFaEyPaD6CWmCCaVV_O-bURt9SmBY6T1GezIZTKGHOBxOGH9FS39x9fa_yCS5XMndW9pC8KGRoAKf0pATKalurYpym_9Z3r0yreO4-eUOl5" +
                "MBQClh1YuwQDmWzj2omgW86uoZE-YdJ-qEpivruQXxlX2IoD027tYquy93dbczrFCFF8sRzJdGUGZDOAVGRAIBhsKXfdXirwAiM9jAry0KjtfO0G" +
                "4seU5wUFqtHPAmw4_4xQEAaPfKHJ9Dyy7bGxHSa0mIxLtCuHjaxJ473Z5h_0Zflw0YvALmALJDCBrhJYjiKLAmXLRriImvkHg";
        String masterUrl = "https://192.168.0.110:6443";
        Config config = new ConfigBuilder()
                .withTrustCerts(true)
                .withMasterUrl(masterUrl)
                .withOauthToken(base64Token)
                .build();
        KubernetesClient client = new DefaultKubernetesClient(config);
        // 查看命名空间
        NamespaceList namespaceList = client.namespaces().list();
        namespaceList.getItems()
                .forEach(namespace ->
                        System.out.println(namespace.getmetadata().getName() + ":" + namespace.getStatus().getPhase()));
    }

}

运行效果:

可以通过Kuboard管理界面看到所有的命名空间

其他的调用参考官方示例
