ELK 搭建

版本选择7.10.2，可配置中文版。

logstash-7.10.2、elasticsearch-7.10.2、kibana-7.10.2

下载完，解压，例如：tar  -zxvf  logstash-7.10.2-linux-x86_64.tar.gz

cd logstash-7.10.2/config

vim logstash-yjg.conf

#读
input {
    # file 从项目文件读取
    file {
        path => ["/data/myProject/logs/*.log"]
        #排除不想监听的文件
        #exclude => "exclude.log"

        #设置多长时间扫描目录，发现新文件
        discover_interval => 1

        #自定义日志区分类型
        type => "ThisIsMyProjectType"

        # beginning 从文件开始处读写
        # end 文件结尾处读写
        start_position => end
    }

    # nginx 日志收集
    file {
        path => ["/tmp/logs/*.log"]
        discover_interval => 1
        type => "nginx"
        start_position => end
    }

    # http 方式收集，用于客户端上送消息
    http{
        id => "http_request"
        port => 9062
        codec => json
        type => "http"
    }
}


#过滤
filter {
    if [type] == "http" {
        # 把东八区时间赋值给新建的logdate 字段,logstash 不允许自建的特殊字段如带@标识的字段
        ruby{
           code => "event.set('logdate', (event.get('@timestamp').time.localtime).strftime('%Y-%m-%d %H:%M:%S'))"
        }
    } else if [type] == "nginx" {
        grok {
            match => ["message", "%{IPORHOST:host} - - [%{HTTPDATE:logdate}]"]
            overwrite => [ "host"]
        }
    } else {
        grok {
            match => ["message", "%{TIMESTAMP_ISO8601:logdate}"]
        }
    }

    date {
            match => ["logdate", "YYYY-MM-dd HH:mm:ss.SSS"]
            # 赋值给 @timestamp
            target => "@timestamp"
    }

    mutate {
        # 删除不需要的字段
        remove_field => ["@version","tags","headers"]
    }
}

#输出
output{
    #输出到ES
    elasticsearch{
        # es地址
        hosts=>["127.0.0.1:9200"]
        # es的index名字，默认就是这个，可以更改
        index => "yjg-logstash-%{+YYYY.MM.dd}"
    }

    #输出到控制台
    stdout{
        codec => rubydebug
    }

    # 输出到kafka
    #kafka {}

    # 输出到数据库
    # jdbc {
    #   driver_jar_path => "/mysql-connector-java-5.1.48.jar"
    #   driver_class => "com.mysql.jdbc.Driver"
    #   connection_string => "jdbc:mysql://127.0.0.1:3306/test?useUnicode=true&characterEncoding=UTF-8&useSSL=false&serverTimezone=Asia/Shanghai&useAffectedRows=true"
    #   username => "root"
    #   password => "123456"
    #   statement => ["INSERT INTO logstash_log_temp(level, ip, content, logdate) VALUES( ?, INET_ATON(?), ? ,?)", "[level]","[host]", "[message]", "[logdate]"]
    #
    #}
}

启动

# 启动logstash，并加载指定配置文件
./bin/logstash -f config/logstash-yjg.conf

注意：如果out 到数据库的话，因为插件不是默认安装，所以需要手动安装

# 官方拉取插件
./bin/logstash-plugin install logstash-output-jdbc

cd elasticsearch-7.10.2/config

vim elasticsearch.yml

path.data: /data/elasticsearch-7.10.2/data
path.logs: /data/elasticsearch-7.10.2/logs
network.host: 127.0.0.1
http.port: 9200
http.cors.enabled: true
http.cors.allow-origin: "*"

 注意：elaticsearch默认不能用root用户启动，否则会提示 java.lang.RuntimeException: can not run elasticsearch as root

# 为elaticsearch创建用户
groupadd elsearch
useradd elsearch -g elsearch -p elasticsearch

# 分配权限
chown -R elsearch:elsearch elasticsearch-7.10.2

# 切换用户到elsearch
su elsearch

启动

# 后台启动
./bin/elasticsearch &

# 验证启动是否成功
http://127.0.0.1::9200

{
  "name" : "my-name",
  "cluster_name" : "elasticsearch",
  "cluster_uuid" : "Px7djFasdfasdfa4eGTSbQ",
  "version" : {
    "number" : "7.10.2",
    "build_flavor" : "default",
    "build_type" : "tar",
    "build_hash" : "747e1cc71def077253878a123123123123",
    "build_date" : "2021-01-13T00:42:12.435326Z",
    "build_snapshot" : false,
    "lucene_version" : "8.7.0",
    "minimum_wire_compatibility_version" : "6.8.0",
    "minimum_index_compatibility_version" : "6.0.0-beta1"
  },
  "tagline" : "You Know, for Search"
}

cd kibana-7.10.2-linux-x86_64/config

vim kibana.yml

server.port: 5601
server.host: "127.0.0.1"
server.name: "my-kibana"
elasticsearch.hosts: ["http://127.0.0.1:9200"]
kibana.index: ".kibana"
# 设置中文（注意，如果是kibana-6*版本的话，需要下载python的服务，手动翻译，替换原文件，比较麻烦，故使用7版本）
i18n.locale: "zh-CN"

启动

# 启动kibana
./bin/kibana

注意：kibana 不支持root用户启动，否则提示：Kibana should not be run as root.  Use --allow-root to continue。如果硬是要用root用户启动  就在后面加   --allow-root

# kibana 强制使用root用户启动
./bin/kibana --allow-root

注意：@timestamp 默认为UTC时间,比北京时间采集时间少8个小时。可以在kibana高级设置中更改

至此搭建全部结束，下期分享logstash采集和kibana查询规则
