kafka-0.11版API kafka与flume连接

生产者API-producer

普通API

package bigdata.producer;

import org.apache.kafka.clients.producer.KafkaProducer;
import org.apache.kafka.clients.producer.ProducerConfig;
import org.apache.kafka.clients.producer.ProducerRecord;

import java.util.Properties;

public class CustomProducer {

    public static void main(String[] args) {

        //kafka集群的配置信息
        Properties props = new Properties();

        //连接的虚拟机
        props.put(ProducerConfig.BOOTSTRAP_SERVERS_CONFIG,"hadoop001:9092");

        //配置ack机制
        props.put(ProducerConfig.ACKS_CONFIG,"all");

        //重试次数
        props.put(ProducerConfig.RETRIES_CONFIG,1);

        //批次大小
        props.put(ProducerConfig.BATCH_SIZE_CONFIG, 16384);

        //等待时间
        props.put(ProducerConfig.LINGER_MS_CONFIG, 1);

        //缓冲区大小
        props.put(ProducerConfig.BUFFER_MEMORY_CONFIG,33554432);

        //序列化
        props.put(ProducerConfig.KEY_SERIALIZER_CLASS_CONFIG,"org.apache.kafka.common.serialization.StringSerializer");
        props.put(ProducerConfig.VALUE_SERIALIZER_CLASS_CONFIG,"org.apache.kafka.common.serialization.StringSerializer");

        KafkaProducer kafkaProducer = new KafkaProducer(props);

        for (int i = 0; i < 100; i++) {
            kafkaProducer.send(new ProducerRecord("test","test-" + Integer.toString(i),"test-"+ Integer.toString(i)));
        }

        kafkaProducer.close();
    }
}

package bigdata.producer;

import bigdata.patitioner.MyPatitioner;
import org.apache.kafka.clients.producer.*;

import java.util.Properties;

public class CallBackProducer {

    public static void main(String[] args) {
        //kafka集群的配置信息
        Properties props = new Properties();

        //连接的虚拟机
        props.put(ProducerConfig.BOOTSTRAP_SERVERS_CONFIG,"hadoop001:9092");

        //配置ack机制
        props.put(ProducerConfig.ACKS_CONFIG,"all");

        //重试次数
        props.put(ProducerConfig.RETRIES_CONFIG,1);

        //批次大小
        props.put(ProducerConfig.BATCH_SIZE_CONFIG, 16384);

        //等待时间
        props.put(ProducerConfig.LINGER_MS_CONFIG, 1);

        //缓冲区大小
        props.put(ProducerConfig.BUFFER_MEMORY_CONFIG,33554432);

        //序列化
        props.put(ProducerConfig.KEY_SERIALIZER_CLASS_CONFIG,"org.apache.kafka.common.serialization.StringSerializer");
        props.put(ProducerConfig.VALUE_SERIALIZER_CLASS_CONFIG,"org.apache.kafka.common.serialization.StringSerializer");



        KafkaProducer kafkaProducer = new KafkaProducer<>(props);

        for (int i = 0; i < 10; i++) {
            kafkaProducer.send(new ProducerRecord<>("first", "test-" + i, "test-" + i+"-kafka"), new Callback() {
                @Override
                public void onCompletion(Recordmetadata recordmetadata, Exception e) {
                    if (e ==null) {
                        System.out.println(recordmetadata.partition()+ "----"+recordmetadata.offset());
                    }else {
                        e.printStackTrace();
                    }
                }
            });
        }

        kafkaProducer.close();
    }
}

package bigdata.patitioner;

import org.apache.kafka.clients.producer.Partitioner;
import org.apache.kafka.common.Cluster;

import java.util.Map;

public class MyPatitioner implements Partitioner {
    @Override
    public int partition(String s, Object o, byte[] bytes, Object o1, byte[] bytes1, Cluster cluster) {
        return 1;
    }

    @Override
    public void close() {

    }

    @Override
    public void configure(Map map) {

    }
}

需要在生产者的配置信息中配置自定义的分区器

//自定义分区器
props.put(ProducerConfig.PARTITIONER_CLASS_CONFIG, MyPatitioner.class);

生产者的发送数据有两条线程，为sender线程和main线程

同步发送的意思就是，一条消息发送之后，会阻塞当前main线程， 直至返回 ack。

由于 send 方法返回的是一个 Future 对象，根据 Futrue 对象的特点，我们也可以实现同步发送的效果，只需在调用 Future 对象的 get 方发即可

for (int i = 0; i < 10; i++) {
    kafkaProducer.send(new ProducerRecord<>("first", "test-" + i, "test-" + i+"-kafka"), new Callback() {
        @Override
        public void onCompletion(Recordmetadata recordmetadata, Exception e) {
            if (e ==null) {
                System.out.println(recordmetadata.partition()+ "----"+recordmetadata.offset());
            }else {
                e.printStackTrace();
            }
        }
    }).get();
}

消费者API -Consumer

简单的消费者API

package bigdata.consumer;

import org.apache.kafka.clients.consumer.ConsumerConfig;
import org.apache.kafka.clients.consumer.ConsumerRecord;
import org.apache.kafka.clients.consumer.ConsumerRecords;
import org.apache.kafka.clients.consumer.KafkaConsumer;

import java.util.Arrays;
import java.util.Collections;
import java.util.Properties;

public class CustomConsumer {

    public static void main(String[] args) {

        //配置文件
        Properties props = new Properties();

        //配置主机
        props.put(ConsumerConfig.BOOTSTRAP_SERVERS_CONFIG, "hadoop001:9092");

        //配置消费者组id
        props.put(ConsumerConfig.GROUP_ID_CONFIG,"123");

        //配置是否允许提交
        props.put(ConsumerConfig.ENABLE_AUTO_COMMIT_CONFIG, true);

        //配置一次的提交时间
        props.put(ConsumerConfig.AUTO_COMMIT_INTERVAL_MS_CONFIG, 1000);

        //配置反序列化
        props.put(ConsumerConfig.KEY_DESERIALIZER_CLASS_CONFIG,"org.apache.kafka.common.serialization.StringDeserializer");
        props.put(ConsumerConfig.VALUE_DESERIALIZER_CLASS_CONFIG,"org.apache.kafka.common.serialization.StringDeserializer");

        KafkaConsumer kafkaConsumer = new KafkaConsumer<>(props);

        kafkaConsumer.subscribe(Collections.singletonList("first"));

        while (true) {
            ConsumerRecords records = kafkaConsumer.poll(100);

            for (ConsumerRecord record : records) {
                System.out.printf("offset = %d, key = %s, value = %s%n", record.offset(), record.key(), record.value());
            }
        }
    }

}

Consumer 消费数据时的可靠性是很容易保证的，因为数据在 Kafka 中是持久化的，故不用担心数据丢失问题。

由于 consumer 在消费过程中可能会出现断电宕机等故障， consumer 恢复后，需要从故障前的位置的继续消费，所以consumer 需要实时记录自己消费到了哪个 offset，以便故障恢复后继续消费。

若是需要重置offset，即类似命令行运行消费者时的参数–from-beginning，需要在消费者配置中加入下列参数

props.put(ConsumerConfig.AUTO_OFFSET_RESET_CONFIG, “earliest”);

对于消费者来说，读取数据后提交offset有两种方法，

commitSync（同步提交）

会阻塞当前进程，直至提交成功才继续，但如果写入之后，在提交过程中宕机，会使得数据重复

commitAsync（异步提交）

不会阻塞当前进程，提交并且继续读取数据，但如果还未完全写完该数据，offset就已经提交成功，则会使得数据丢失。

因此，一般将offset提交和数据写入放入事务中，使得两者保持一致性

拦截器API-Interceptor

时间拦截器

package bigdata.interceptor;

import org.apache.kafka.clients.producer.ProducerInterceptor;
import org.apache.kafka.clients.producer.ProducerRecord;
import org.apache.kafka.clients.producer.Recordmetadata;

import java.util.Map;

public class TimeInterceptor implements ProducerInterceptor {

    //配置文件
    @Override
    public void configure(Map map) {

    }

    //逻辑处理，得到数据后哪些数据需要拦截
    @Override
    public ProducerRecord onSend(ProducerRecord producerRecord) {
        return new ProducerRecord(producerRecord.topic(),producerRecord.partition(),producerRecord.timestamp(),producerRecord.key(),
                "TimeInterceptor: " + System.currentTimeMillis() + "," + producerRecord.value().toString());
    }

    @Override
    public void onAcknowledgement(Recordmetadata recordmetadata, Exception e) {

    }

    @Override
    public void close() {

    }


}

记录发送成功和失败数量的拦截器

package bigdata.interceptor;

import org.apache.kafka.clients.producer.ProducerInterceptor;
import org.apache.kafka.clients.producer.ProducerRecord;
import org.apache.kafka.clients.producer.Recordmetadata;

import java.util.Map;

public class CounterInterceptor implements ProducerInterceptor {

    private Long successCounter=0L;
    private Long errorCounter=0L;

    @Override
    public void configure(Map map) {

    }

    @Override
    public ProducerRecord onSend(ProducerRecord producerRecord) {
        return producerRecord;
    }

    @Override
    public void onAcknowledgement(Recordmetadata recordmetadata, Exception e) {
        //统计成功和失败的次数
        if (e == null){
            successCounter++;
        }else {
            errorCounter++;
        }
    }

    @Override
    public void close() {
        System.out.println("Successful set : " + successCounter);
        System.out.println("Failed set : " + errorCounter);
    }

}

//自定义拦截器
ArrayList interceptors = new ArrayList<>();
interceptors.add("bigdata.interceptor.TimeInterceptor");
interceptors.add("bigdata.interceptor.CounterInterceptor");

Flume配置kafka

flume配置kafka只需要在定义sink为kafka，同时配置拦截器

要注意的是，拦截器中添加头信息的位置添加的key-value值需要变为“topic”-“tipic_name”，此时flume会根据topic的值来添加进不同的主题中，如：

请添加图片描述

flume的配置文件如下：

# define
a1.sources = r1
a1.sinks = k1
a1.channels = c1

# source
a1.sources.r1.type = exec
a1.sources.r1.command = tail -F -c +0 /opt/app/datas/flume.log
a1.sources.r1.shell = /bin/bash -c

# sink
a1.sinks.k1.type = org.apache.flume.sink.kafka.KafkaSink
a1.sinks.k1.kafka.bootstrap.servers = hadoop001:9092,hadoop002:9092,hadoop003:9092
a1.sinks.k1.kafka.topic = first
a1.sinks.k1.kafka.flumeBatchSize = 20
a1.sinks.k1.kafka.producer.acks = 1
a1.sinks.k1.kafka.producer.linger.ms = 1

# channel
a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

# bind
a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1
