文章优先发布在Github，其它平台会晚一段时间，文章纠错与更新内容只在Github：https://github.com/youthlql/JavaYouth转载须知：转载请注明GitHub出处，让我们一起维护一个良好的技术创作环境。如果你要提交 issue 或者 pr 的话建议到 Github 提交。笔者会陆续更新，如果对你有所帮助，不妨Github点个Star~。你的Star是我创作的动力。


     

第5章-容器刷新流程 流程图-容器刷新 容器创建

public class AnnotationMainTest {

   public static void main(String[] args) {

      ApplicationContext applicationContext =
            new AnnotationConfigApplicationContext(MainConfig.class);
   }

AnnotationConfigApplicationContext有参构造

    public AnnotationConfigApplicationContext(Class... componentClasses) {
       this();
       register(componentClasses);
       refresh(); //容器完整刷新（创建出所有组件，组织好所有功能）
    }

AnnotationConfigApplicationContext#this()无参构造

    // 上面的this()就是调用的这里
    public AnnotationConfigApplicationContext() {
        StartupStep createAnnotatedBeanDefReader = this.getApplicationStartup().start("spring.context.annotated-bean-reader.create");
        this.reader = new AnnotatedBeanDefinitionReader(this);
        createAnnotatedBeanDefReader.end();
        this.scanner = new ClassPathBeanDefinitionScanner(this);
    }

AnnotatedBeanDefinitionReader有参构造

    public AnnotatedBeanDefinitionReader(BeanDefinitionRegistry registry) {
       this(registry, getOrCreateEnvironment(registry));
    }

	public AnnotatedBeanDefinitionReader(BeanDefinitionRegistry registry, Environment environment) {
		Assert.notNull(registry, "BeanDefinitionRegistry must not be null");
		Assert.notNull(environment, "Environment must not be null");
		this.registry = registry;
		this.conditionevaluator = new Conditionevaluator(registry, environment, null);
		AnnotationConfigUtils.registerAnnotationConfigProcessors(this.registry);
	}

AnnotationConfigUtils#registerAnnotationConfigProcessors()注册Spring内部几个核心组件


	public static final String CONFIGURATION_ANNOTATION_PROCESSOR_BEAN_NAME =
			"org.springframework.context.annotation.internalConfigurationAnnotationProcessor";


	public static final String CONFIGURATION_BEAN_NAME_GENERATOR =
			"org.springframework.context.annotation.internalConfigurationBeanNameGenerator";


	public static final String AUTOWIRED_ANNOTATION_PROCESSOR_BEAN_NAME =
			"org.springframework.context.annotation.internalAutowiredAnnotationProcessor";


	@Deprecated
	public static final String REQUIRED_ANNOTATION_PROCESSOR_BEAN_NAME =
			"org.springframework.context.annotation.internalRequiredAnnotationProcessor";


	public static final String COMMON_ANNOTATION_PROCESSOR_BEAN_NAME =
			"org.springframework.context.annotation.internalCommonAnnotationProcessor";


	public static final String PERSISTENCE_ANNOTATION_PROCESSOR_BEAN_NAME =
			"org.springframework.context.annotation.internalPersistenceAnnotationProcessor";

	private static final String PERSISTENCE_ANNOTATION_PROCESSOR_CLASS_NAME =
			"org.springframework.orm.jpa.support.PersistenceAnnotationBeanPostProcessor";


	public static final String EVENT_LISTENER_PROCESSOR_BEAN_NAME =
			"org.springframework.context.event.internalEventListenerProcessor";


	public static final String EVENT_LISTENER_FACTORY_BEAN_NAME =
			"org.springframework.context.event.internalEventListenerFactory";


	public static void registerAnnotationConfigProcessors(BeanDefinitionRegistry registry) {
       registerAnnotationConfigProcessors(registry, null);
    }



	public static Set registerAnnotationConfigProcessors(
			BeanDefinitionRegistry registry, @Nullable Object source) {

		DefaultListableBeanFactory beanFactory = unwrapDefaultListableBeanFactory(registry);
		if (beanFactory != null) {
			if (!(beanFactory.getDependencyComparator() instanceof AnnotationAwareOrderComparator)) {
				beanFactory.setDependencyComparator(AnnotationAwareOrderComparator.INSTANCE);
			}
			if (!(beanFactory.getAutowireCandidateResolver() instanceof ContextAnnotationAutowireCandidateResolver)) {
				beanFactory.setAutowireCandidateResolver(new ContextAnnotationAutowireCandidateResolver());
			}
		}

        //下面是注册Spring底层的核心组件，主要是就是Spring自己的BeanPostproPostProcessor或者BeanFactoryPostProcessor
		Set beanDefs = new linkedHashSet<>(8);
		//注册底层的  配置文件处理器
		if (!registry.containsBeanDefinition(CONFIGURATION_ANNOTATION_PROCESSOR_BEAN_NAME)) {
			RootBeanDefinition def = new RootBeanDefinition(ConfigurationClassPostProcessor.class);
			def.setSource(source);
			beanDefs.add(registerPostProcessor(registry, def, CONFIGURATION_ANNOTATION_PROCESSOR_BEAN_NAME));
		}
        //注册底层的自动装配处理器
		if (!registry.containsBeanDefinition(AUTOWIRED_ANNOTATION_PROCESSOR_BEAN_NAME)) {
			RootBeanDefinition def = new RootBeanDefinition(AutowiredAnnotationBeanPostProcessor.class);
			def.setSource(source);
			beanDefs.add(registerPostProcessor(registry, def, AUTOWIRED_ANNOTATION_PROCESSOR_BEAN_NAME));
		}
        //注册支持JSR-250的处理
		// Check for JSR-250 support, and if present add the CommonAnnotationBeanPostProcessor.
		if (jsr250Present && !registry.containsBeanDefinition(COMMON_ANNOTATION_PROCESSOR_BEAN_NAME)) {
			RootBeanDefinition def = new RootBeanDefinition(CommonAnnotationBeanPostProcessor.class);
			def.setSource(source);
			beanDefs.add(registerPostProcessor(registry, def, COMMON_ANNOTATION_PROCESSOR_BEAN_NAME));
		}

		// Check for JPA support, and if present add the PersistenceAnnotationBeanPostProcessor.
		if (jpaPresent && !registry.containsBeanDefinition(PERSISTENCE_ANNOTATION_PROCESSOR_BEAN_NAME)) {
			RootBeanDefinition def = new RootBeanDefinition();
			try {
				def.setBeanClass(ClassUtils.forName(PERSISTENCE_ANNOTATION_PROCESSOR_CLASS_NAME,
						AnnotationConfigUtils.class.getClassLoader()));
			}
			catch (ClassNotFoundException ex) {
				throw new IllegalStateException(
						"Cannot load optional framework class: " + PERSISTENCE_ANNOTATION_PROCESSOR_CLASS_NAME, ex);
			}
			def.setSource(source);
			beanDefs.add(registerPostProcessor(registry, def, PERSISTENCE_ANNOTATION_PROCESSOR_BEAN_NAME));
		}

		if (!registry.containsBeanDefinition(EVENT_LISTENER_PROCESSOR_BEAN_NAME)) {
			RootBeanDefinition def = new RootBeanDefinition(EventListenerMethodProcessor.class);
			def.setSource(source);
			beanDefs.add(registerPostProcessor(registry, def, EVENT_LISTENER_PROCESSOR_BEAN_NAME));
		}

		if (!registry.containsBeanDefinition(EVENT_LISTENER_FACTORY_BEAN_NAME)) {
			RootBeanDefinition def = new RootBeanDefinition(DefaultEventListenerFactory.class);
			def.setSource(source);
			beanDefs.add(registerPostProcessor(registry, def, EVENT_LISTENER_FACTORY_BEAN_NAME));
		}

		return beanDefs;
	}

上面的方法走完，我们可以看看到主要是下面4个后置处理器

RootBeanDefinition

    public RootBeanDefinition(@Nullable Class beanClass) {
       super();
       setBeanClass(beanClass);
    }

AbstractBeanDefinition

    protected AbstractBeanDefinition() {
       this(null, null);
    }

ClassPathBeanDefinitionScanner

    public ClassPathBeanDefinitionScanner(BeanDefinitionRegistry registry, boolean useDefaultFilters,
          Environment environment, @Nullable ResourceLoader resourceLoader) {

       Assert.notNull(registry, "BeanDefinitionRegistry must not be null");
       this.registry = registry;

       if (useDefaultFilters) {
          registerDefaultFilters();
       }
       setEnvironment(environment); //准备环境
       setResourceLoader(resourceLoader);//准备资源加载器
    }

AnnotationConfigApplicationContext#register()

    public void register(Class... componentClasses) {
       //componentClasses就是咱们的配置类
       Assert.notEmpty(componentClasses, "At least one component class must be specified");
       StartupStep registerComponentClass = this.getApplicationStartup().start("spring.context.component-classes.register")
             .tag("classes", () -> Arrays.toString(componentClasses));
       this.reader.register(componentClasses);
       registerComponentClass.end();
    }

AnnotatedBeanDefinitionReader#register()注册主配置类BeanDefinition

    public void register(Class... componentClasses) {
       for (Class componentClass : componentClasses) {
          registerBean(componentClass);
       }
    }

	public void registerBean(Class beanClass) {
		doRegisterBean(beanClass, null, null, null, null);
	}


	private  void doRegisterBean(Class beanClass, @Nullable String name,
			@Nullable Class[] qualifiers, @Nullable Supplier supplier,
			@Nullable BeanDefinitionCustomizer[] customizers) {

        // 主配置类也被封装成一个Bean定义信息了
		AnnotatedGenericBeanDefinition abd = new AnnotatedGenericBeanDefinition(beanClass);
		if (this.conditionevaluator.shouldSkip(abd.getmetadata())) {
			return;
		}

		abd.setInstanceSupplier(supplier);
		Scopemetadata scopemetadata = this.scopemetadataResolver.resolveScopemetadata(abd);
		abd.setScope(scopemetadata.getScopeName());
		String beanName = (name != null ? name : this.beanNameGenerator.generateBeanName(abd, this.registry));
		//完善主配置类的BeanDefinition
		AnnotationConfigUtils.processCommonDefinitionAnnotations(abd);
		if (qualifiers != null) {
			for (Class qualifier : qualifiers) {
				if (Primary.class == qualifier) {
					abd.setPrimary(true);
				}
				else if (Lazy.class == qualifier) {
					abd.setLazyInit(true);
				}
				else {
					abd.addQualifier(new AutowireCandidateQualifier(qualifier));
				}
			}
		}
		if (customizers != null) {
			for (BeanDefinitionCustomizer customizer : customizers) {
				customizer.customize(abd);
			}
		}

		BeanDefinitionHolder definitionHolder = new BeanDefinitionHolder(abd, beanName);
		definitionHolder = AnnotationConfigUtils.applyScopedProxyMode(scopemetadata, definitionHolder, this.registry);
		BeanDefinitionReaderUtils.registerBeanDefinition(definitionHolder, this.registry);
	}

AnnotationConfigUtils#processCommonDefinitionAnnotations()感知@Lazy，@Primary等注解

这里传进来的是主配置类，解析的就是主配置类的注解，其它的Bean这里还没有解析@Lazy，@Primary这些注解

    public static void processCommonDefinitionAnnotations(AnnotatedBeanDefinition abd) {
       processCommonDefinitionAnnotations(abd, abd.getmetadata());
    }
    //解读所有Bean定义信息需要感知的注解
    static void processCommonDefinitionAnnotations(AnnotatedBeanDefinition abd, AnnotatedTypemetadata metadata) {
       AnnotationAttributes lazy = attributesFor(metadata, Lazy.class);
       if (lazy != null) {
          abd.setLazyInit(lazy.getBoolean("value"));
       }
       else if (abd.getmetadata() != metadata) {
          lazy = attributesFor(abd.getmetadata(), Lazy.class);
          if (lazy != null) {
             abd.setLazyInit(lazy.getBoolean("value"));
          }
       }

       if (metadata.isAnnotated(Primary.class.getName())) {
          abd.setPrimary(true);
       }
       AnnotationAttributes dependsOn = attributesFor(metadata, DependsOn.class);
       if (dependsOn != null) {
          abd.setDependsOn(dependsOn.getStringArray("value"));
       }

       AnnotationAttributes role = attributesFor(metadata, Role.class);
       if (role != null) {
          abd.setRole(role.getNumber("value").intValue());
       }
       AnnotationAttributes description = attributesFor(metadata, Description.class);
       if (description != null) {
          abd.setDescription(description.getString("value"));
       }
    }

走完之后，注册中心肯定多了咱们的配置类

接下来就是想办法让主配置类里的配置生效目前Spring就靠上面的4个后置处理器和一个主配置类白手起家了，开始我们后面最重要的refresh()容器刷新流程了

AbstractApplicationContext#refresh()开始容器刷新

    @Override  //容器刷新的十二大步。模板模式
    public void refresh() throws BeansException, IllegalStateException {
       synchronized (this.startupShutdownMonitor) {
           //容器启动过程状态的封装类
          StartupStep contextRefresh = this.applicationStartup.start("spring.context.refresh");

          //准备上下文环境 Prepare this context for refreshing.
          prepareRefresh();

          // Tell the subclass to refresh the internal bean factory.
          // 工厂创建：BeanFactory第一次开始创建的时候,有xml解析逻辑。注解版这一步什么都没做，直接返回this()环节早就new好的工厂
          ConfigurableListableBeanFactory beanFactory = obtainFreshBeanFactory();

          //给容器中注册了环境信息作为单实例Bean方便后续自动装配；放了一些后置处理器处理（监听、xxAware功能） Prepare thebean factory for use in this context.
          prepareBeanFactory(beanFactory);

          try {
             //留给子类的模板方法，允许子类继续对工厂执行一些处理； Allows post-processing of the bean factory in context subclasses.
             postProcessBeanFactory(beanFactory);

             StartupStep beanPostProcess = this.applicationStartup.start("spring.context.beans.post-process");
             //【核心】工厂增强：执行所有的BeanFactory后置增强器；利用BeanFactory后置增强器对工厂进行修改或者增强,配置类会在这里进行解析。 Invoke factory processors registered as beans in the context.
             invokeBeanFactoryPostProcessors(beanFactory);

             //【核心】注册所有的Bean的后置处理器 Register bean processors that intercept bean creation.
             registerBeanPostProcessors(beanFactory);
             beanPostProcess.end();

             //初始化国际化功能 Initialize message source for this context.
             initMessageSource();

             //初始化事件多播功能（事件派发） Initialize event multicaster for this context.
             initApplicationEventMulticaster();

             // Initialize other special beans in specific context subclasses.
             onRefresh();

             //注册监听器，从容器中获取所有的ApplicationListener； Check for listener beans and register them.
             registerListeners();

             // Instantiate all remaining (non-lazy-init) singletons.
             //【大核心】bean创建；完成 BeanFactory 初始化。（工厂里面所有的组件都好了）
             finishBeanFactoryInitialization(beanFactory);

             //发布事件 Last step: publish corresponding event.
             finishRefresh();
          }

          catch (BeansException ex) {
             if (logger.isWarnEnabled()) {
                logger.warn("Exception encountered during context initialization - " +
                      "cancelling refresh attempt: " + ex);
             }

             // Destroy already created singletons to avoid dangling resources.
             destroyBeans();

             // Reset 'active' flag.
             cancelRefresh(ex);

             // Propagate exception to caller.
             throw ex;
          }

          finally {
             // Reset common introspection caches in Spring's core, since we
             // might not ever need metadata for singleton beans anymore...
             resetCommonCaches();
             contextRefresh.end();
          }
       }
    }

prepareRefresh()准备上下文环境

    protected void prepareRefresh() {
       // Switch to active.
       this.startupDate = System.currentTimeMillis();
       this.closed.set(false);
       this.active.set(true);

       if (logger.isDebugEnabled()) {
          if (logger.isTraceEnabled()) {
             logger.trace("Refreshing " + this);
          }
          else {
             logger.debug("Refreshing " + getDisplayName());
          }
       }

       //其他子容器自行实现（比如：WebApplicationContext） Initialize any placeholder property sources in the context environment.
       initPropertySources();

       //准备环境变量信息 Validate that all properties marked as required are resolvable:
       // see ConfigurablePropertyResolver#setRequiredProperties
       getEnvironment().validateRequiredProperties();

       // 存储子容器早期运行的一些监听器； Store pre-refresh ApplicationListeners...
       if (this.earlyApplicationListeners == null) {
          this.earlyApplicationListeners = new linkedHashSet<>(this.applicationListeners);
       }
       else {
          // Reset local application listeners to pre-refresh state.
          this.applicationListeners.clear();
          this.applicationListeners.addAll(this.earlyApplicationListeners);
       }

       //早期的一些事件存储到这里 Allow for the collection of early ApplicationEvents,
       // to be published once the multicaster is available...
       this.earlyApplicationEvents = new linkedHashSet<>();
    }

initPropertySources()

protected void initPropertySources() {
   // For subclasses: do nothing by default. 自行在此处加载一些自己感兴趣的信息。【WebApplicationContextUtils.initServletPropertySources】
    // web-ioc容器启动的时候一般在此加载当前应用的上下文信息（ApplicationContext）
}

prepareBeanFactory()给BeanFactory准备一些核心组件

    protected void prepareBeanFactory(ConfigurableListableBeanFactory beanFactory) {
       // Tell the internal bean factory to use the context's class loader etc.
       beanFactory.setBeanClassLoader(getClassLoader());
       if (!shouldIgnoreSpel) { //解释器模式  ，解析el表达式
          beanFactory.setBeanexpressionResolver(new StandardBeanexpressionResolver(beanFactory.getBeanClassLoader()));
       }
       beanFactory.addPropertyEditorRegistrar(new ResourceEditorRegistrar(this, getEnvironment()));

       // Configure the bean factory with context callbacks.
       beanFactory.addBeanPostProcessor(new ApplicationContextAwareProcessor(this)); //准备一个处理Aware接口功能的后置处理器
       beanFactory.ignoreDependencyInterface(EnvironmentAware.class); //告诉Spring先别管这些接口
       beanFactory.ignoreDependencyInterface(EmbeddedValueResolverAware.class);
       beanFactory.ignoreDependencyInterface(ResourceLoaderAware.class);
       beanFactory.ignoreDependencyInterface(ApplicationEventPublisherAware.class);
       beanFactory.ignoreDependencyInterface(MessageSourceAware.class);
       beanFactory.ignoreDependencyInterface(ApplicationContextAware.class);
       beanFactory.ignoreDependencyInterface(ApplicationStartupAware.class);


       beanFactory.registerResolvableDependency(BeanFactory.class, beanFactory);
       beanFactory.registerResolvableDependency(ResourceLoader.class, this);
       beanFactory.registerResolvableDependency(ApplicationEventPublisher.class, this);
       beanFactory.registerResolvableDependency(ApplicationContext.class, this);

       // 注册应用监听器的探测器，用来探测应用中有哪些监听器。这也是一个后置处理器
       beanFactory.addBeanPostProcessor(new ApplicationListenerDetector(this));

       // Detect a LoadTimeWeaver and prepare for weaving, if found.
       if (!NativeDetector.inNativeImage() && beanFactory.containsBean(LOAD_TIME_WEAVER_BEAN_NAME)) {
          beanFactory.addBeanPostProcessor(new LoadTimeWeaverAwareProcessor(beanFactory));
          // Set a temporary ClassLoader for type matching.
          beanFactory.setTempClassLoader(new ContextTypeMatchClassLoader(beanFactory.getBeanClassLoader()));
       }

       //注册默认组件： Register default environment beans.
       if (!beanFactory.containsLocalBean(ENVIRONMENT_BEAN_NAME)) {
          beanFactory.registerSingleton(ENVIRONMENT_BEAN_NAME, getEnvironment());
       }
       if (!beanFactory.containsLocalBean(SYSTEM_PROPERTIES_BEAN_NAME)) {
          beanFactory.registerSingleton(SYSTEM_PROPERTIES_BEAN_NAME, getEnvironment().getSystemProperties());
       }
       if (!beanFactory.containsLocalBean(SYSTEM_ENVIRONMENT_BEAN_NAME)) {
          beanFactory.registerSingleton(SYSTEM_ENVIRONMENT_BEAN_NAME, getEnvironment().getSystemEnvironment());
       }
       if (!beanFactory.containsLocalBean(APPLICATION_STARTUP_BEAN_NAME)) {
          beanFactory.registerSingleton(APPLICATION_STARTUP_BEAN_NAME, getApplicationStartup());
       }
    }

	String ENVIRONMENT_BEAN_NAME = "environment";

	String SYSTEM_PROPERTIES_BEAN_NAME = "systemProperties";

	String SYSTEM_ENVIRONMENT_BEAN_NAME = "systemEnvironment";


	String APPLICATION_STARTUP_BEAN_NAME = "applicationStartup";

postProcessBeanFactory()留给子类的模板方法

这里是一个空方法，主要是留给子类实现，比如Web里的

    protected void postProcessBeanFactory(ConfigurableListableBeanFactory beanFactory) {
    }

invokeBeanFactoryPostProcessors()工厂增强【核心】

    protected void invokeBeanFactoryPostProcessors(ConfigurableListableBeanFactory beanFactory) {
       PostProcessorRegistrationDelegate.invokeBeanFactoryPostProcessors(beanFactory, getBeanFactoryPostProcessors()); //执行所有的工厂增强器
       //上面的类叫：后置处理器的注册代理（门面模式-装饰模式）
       // Detect a LoadTimeWeaver and prepare for weaving, if found in the meantime
       // (e.g. through an @Bean method registered by ConfigurationClassPostProcessor)
       if (!NativeDetector.inNativeImage() && beanFactory.getTempClassLoader() == null && beanFactory.containsBean(LOAD_TIME_WEAVER_BEAN_NAME)) {
          beanFactory.addBeanPostProcessor(new LoadTimeWeaverAwareProcessor(beanFactory));
          beanFactory.setTempClassLoader(new ContextTypeMatchClassLoader(beanFactory.getBeanClassLoader()));
       }
    }

这一步有个很关键的后置处理器

ConfigurationClassPostProcessor#postProcessBeanDefinitionRegistry()开始解析@Configuration标注的所有配置类相关信息，并生成Bean

AnnotationConfigApplicationContext#register()这里解析的是主配置类

    @Override //把配置类中所有bean的定义信息导入进来。
    public void postProcessBeanDefinitionRegistry(BeanDefinitionRegistry registry) {
       int registryId = System.identityHashCode(registry);
       if (this.registriesPostProcessed.contains(registryId)) {
          throw new IllegalStateException(
                "postProcessBeanDefinitionRegistry already called on this post-processor against " + registry);
       }
       if (this.factoriesPostProcessed.contains(registryId)) {
          throw new IllegalStateException(
                "postProcessBeanFactory already called on this post-processor against " + registry);
       }
       this.registriesPostProcessed.add(registryId);

       processConfigBeanDefinitions(registry); //处理配置的BeanDefinition信息
    }



	public void processConfigBeanDefinitions(BeanDefinitionRegistry registry) {
		List configCandidates = new ArrayList<>();
		String[] candidateNames = registry.getBeanDefinitionNames(); //拿到工厂所有的bean定义信息

		for (String beanName : candidateNames) {
			BeanDefinition beanDef = registry.getBeanDefinition(beanName);
			if (beanDef.getAttribute(ConfigurationClassUtils.CONFIGURATION_CLASS_ATTRIBUTE) != null) {
				if (logger.isDebugEnabled()) {
					logger.debug("Bean definition has already been processed as a configuration class: " + beanDef);
				}
			}
			else if (ConfigurationClassUtils.checkConfigurationClassCandidate(beanDef, this.metadataReaderFactory)) {
				configCandidates.add(new BeanDefinitionHolder(beanDef, beanName)); //将配置类加到候选集合里面，等待处理
			}
		}

		// Return immediately if no @Configuration classes were found
		if (configCandidates.isEmpty()) {
			return;
		}

		// 对所有的配置类进行排序，Sort by previously determined @Order value, if applicable
		configCandidates.sort((bd1, bd2) -> {
			int i1 = ConfigurationClassUtils.getOrder(bd1.getBeanDefinition());
			int i2 = ConfigurationClassUtils.getOrder(bd2.getBeanDefinition());
			return Integer.compare(i1, i2);
		});

		// Detect any custom bean name generation strategy supplied through the enclosing application context
		SingletonBeanRegistry sbr = null;
		if (registry instanceof SingletonBeanRegistry) {
			sbr = (SingletonBeanRegistry) registry;
			if (!this.localBeanNameGeneratorSet) {
				BeanNameGenerator generator = (BeanNameGenerator) sbr.getSingleton(
						AnnotationConfigUtils.CONFIGURATION_BEAN_NAME_GENERATOR); //getBean--getSingleton，获取创建一个internalConfigurationBeanNameGenerator来用来生成配置类的名字
				if (generator != null) {
					this.componentScanBeanNameGenerator = generator;
					this.importBeanNameGenerator = generator;
				}
			}
		}

		if (this.environment == null) {
			this.environment = new StandardEnvironment();
		}

		//由ConfigurationClassParser解析每一个配置类 Parse each @Configuration class
		ConfigurationClassParser parser = new ConfigurationClassParser(
				this.metadataReaderFactory, this.problemReporter, this.environment,
				this.resourceLoader, this.componentScanBeanNameGenerator, registry);

		Set candidates = new linkedHashSet<>(configCandidates);
		Set alreadyParsed = new HashSet<>(configCandidates.size());
		do {
			StartupStep processConfig = this.applicationStartup.start("spring.context.config-classes.parse");
			parser.parse(candidates); //解析配置类;所有需要扫描进来的组件的BeanDefinition信息都已经完成
			parser.validate();

			Set configClasses = new linkedHashSet<>(parser.getConfigurationClasses());
			configClasses.removeAll(alreadyParsed);
			//每一个组件都可以当配置类，@import之类的都能进行处理
			// Read the model and create bean definitions based on its content
			if (this.reader == null) {
				this.reader = new ConfigurationClassBeanDefinitionReader(
						registry, this.sourceExtractor, this.resourceLoader, this.environment,
						this.importBeanNameGenerator, parser.getimportRegistry());
			}
			this.reader.loadBeanDefinitions(configClasses);
			alreadyParsed.addAll(configClasses);
			processConfig.tag("classCount", () -> String.valueOf(configClasses.size())).end();

			candidates.clear();
			if (registry.getBeanDefinitionCount() > candidateNames.length) {
				String[] newCandidateNames = registry.getBeanDefinitionNames();
				Set oldCandidateNames = new HashSet<>(Arrays.asList(candidateNames));
				Set alreadyParsedClasses = new HashSet<>();
				for (ConfigurationClass configurationClass : alreadyParsed) {
					alreadyParsedClasses.add(configurationClass.getmetadata().getClassName());
				}
				for (String candidateName : newCandidateNames) {
					if (!oldCandidateNames.contains(candidateName)) {
						BeanDefinition bd = registry.getBeanDefinition(candidateName);
						if (ConfigurationClassUtils.checkConfigurationClassCandidate(bd, this.metadataReaderFactory) &&
								!alreadyParsedClasses.contains(bd.getBeanClassName())) {
							candidates.add(new BeanDefinitionHolder(bd, candidateName));
						}
					}
				}
				candidateNames = newCandidateNames;
			}
		}
		while (!candidates.isEmpty());

		// Register the importRegistry as a bean in order to support importAware @Configuration classes
		if (sbr != null && !sbr.containsSingleton(import_REGISTRY_BEAN_NAME)) {
			sbr.registerSingleton(import_REGISTRY_BEAN_NAME, parser.getimportRegistry());
		}

		if (this.metadataReaderFactory instanceof CachingmetadataReaderFactory) {
			// Clear cache in externally provided metadataReaderFactory; this is a no-op
			// for a shared cache since it'll be cleared by the ApplicationContext.
			((CachingmetadataReaderFactory) this.metadataReaderFactory).clearCache();
		}
	}

ConfigurationClassParser#parse()

    public void parse(Set configCandidates) {
       for (BeanDefinitionHolder holder : configCandidates) {
          BeanDefinition bd = holder.getBeanDefinition();
          try {
             if (bd instanceof AnnotatedBeanDefinition) {
                parse(((AnnotatedBeanDefinition) bd).getmetadata(), holder.getBeanName());
             }
             else if (bd instanceof AbstractBeanDefinition && ((AbstractBeanDefinition) bd).hasBeanClass()) {
                parse(((AbstractBeanDefinition) bd).getBeanClass(), holder.getBeanName());
             }
             else {
                parse(bd.getBeanClassName(), holder.getBeanName());
             }
          }
          catch (BeanDefinitionStoreException ex) {
             throw ex;
          }
          catch (Throwable ex) {
             throw new BeanDefinitionStoreException(
                   "Failed to parse configuration class [" + bd.getBeanClassName() + "]", ex);
          }
       }

       this.deferredimportSelectorHandler.process();
    }


	//解析配置类
	protected final void parse(Annotationmetadata metadata, String beanName) throws IOException {
		processConfigurationClass(new ConfigurationClass(metadata, beanName), DEFAULT_EXCLUSION_FILTER);
	}



	protected void processConfigurationClass(ConfigurationClass configClass, Predicate filter) throws IOException {
		if (this.conditionevaluator.shouldSkip(configClass.getmetadata(), ConfigurationPhase.PARSE_CONFIGURATION)) {
			return;
		}
		//Spring底层大量使用缓存来保证框架速度
		ConfigurationClass existingClass = this.configurationClasses.get(configClass);
		if (existingClass != null) {
			if (configClass.isimported()) {
				if (existingClass.isimported()) {
					existingClass.mergeimportedBy(configClass);
				}
				// Otherwise ignore new imported config class; existing non-imported class overrides it.
				return;
			}
			else {
				// Explicit bean definition found, probably replacing an import.
				// Let's remove the old one and go with the new one.
				this.configurationClasses.remove(configClass);
				this.knownSuperclasses.values().removeIf(configClass::equals);
			}
		}

		// Recursively process the configuration class and its superclass hierarchy.
		SourceClass sourceClass = asSourceClass(configClass, filter);
		do { //解析配置类里面的所有注解，
			sourceClass = doProcessConfigurationClass(configClass, sourceClass, filter);
		}
		while (sourceClass != null);
		//只要这个配置类解析过，就放在已经解析好的集合中防止重复解析
		this.configurationClasses.put(configClass, configClass);
	}

ConfigurationClassParser#doProcessConfigurationClass()解析配置类中诸如@ComponentScan，@import，@Bean等注解

	private final Environment environment;

	private final BeanDefinitionRegistry registry;

	private final ComponentScanAnnotationParser componentScanParser;

	private final Map configurationClasses = new linkedHashMap<>();

	private final Map knownSuperclasses = new HashMap<>();

	protected final SourceClass doProcessConfigurationClass(
			ConfigurationClass configClass, SourceClass sourceClass, Predicate filter)
			throws IOException {

		if (configClass.getmetadata().isAnnotated(Component.class.getName())) {
			// Recursively process any member (nested) classes first
			processMemberClasses(configClass, sourceClass, filter);
		}

		// Process any @PropertySource annotations
		for (AnnotationAttributes propertySource : AnnotationConfigUtils.attributesForRepeatable(
				sourceClass.getmetadata(), PropertySources.class,
				org.springframework.context.annotation.PropertySource.class)) {
			if (this.environment instanceof ConfigurableEnvironment) {
				processPropertySource(propertySource);
			}
			else {
				logger.info("Ignoring @PropertySource annotation on [" + sourceClass.getmetadata().getClassName() +
						"]. Reason: Environment must implement ConfigurableEnvironment");
			}
		}

		// Process any @ComponentScan annotations
		Set componentScans = AnnotationConfigUtils.attributesForRepeatable(
				sourceClass.getmetadata(), ComponentScans.class, ComponentScan.class);
		if (!componentScans.isEmpty() &&
				!this.conditionevaluator.shouldSkip(sourceClass.getmetadata(), ConfigurationPhase.REGISTER_BEAN)) {
			for (AnnotationAttributes componentScan : componentScans) {
				//使用Scanner把ComponentScan指定的包下的所有组件都扫描进来 The config class is annotated with @ComponentScan -> perform the scan immediately
				Set scannedBeanDefinitions =
						this.componentScanParser.parse(componentScan, sourceClass.getmetadata().getClassName());
				// Check the set of scanned definitions for any further config classes and parse recursively if needed
				for (BeanDefinitionHolder holder : scannedBeanDefinitions) {
					BeanDefinition bdCand = holder.getBeanDefinition().getOriginatingBeanDefinition();
					if (bdCand == null) {
						bdCand = holder.getBeanDefinition();
					}
					if (ConfigurationClassUtils.checkConfigurationClassCandidate(bdCand, this.metadataReaderFactory)) {
						parse(bdCand.getBeanClassName(), holder.getBeanName());
					}
				}
			}
		}

		//处理@import注解的地方【AOP就是利用这个地方导入一个后置处理器的】 Process any @import annotations
		processimports(configClass, sourceClass, getimports(sourceClass), filter, true);

		//处理@importResource  Process any @importResource annotations
		AnnotationAttributes importResource =
				AnnotationConfigUtils.attributesFor(sourceClass.getmetadata(), importResource.class);
		if (importResource != null) {
			String[] resources = importResource.getStringArray("locations");
			Class readerClass = importResource.getClass("reader");
			for (String resource : resources) {
				String resolvedResource = this.environment.resolveRequiredPlaceholders(resource);
				configClass.addimportedResource(resolvedResource, readerClass);
			}
		}

		//处理@Bean Process individual @Bean methods
		Set beanMethods = retrieveBeanMethodmetadata(sourceClass);
		for (Methodmetadata methodmetadata : beanMethods) {
			configClass.addBeanMethod(new BeanMethod(methodmetadata, configClass));
		}

		// Process default methods on interfaces
		processInterfaces(configClass, sourceClass);

		// Process superclass, if any
		if (sourceClass.getmetadata().hasSuperClass()) {
			String superclass = sourceClass.getmetadata().getSuperClassName();
			if (superclass != null && !superclass.startsWith("java") &&
					!this.knownSuperclasses.containsKey(superclass)) {
				this.knownSuperclasses.put(superclass, configClass);
				// Superclass found, return its annotation metadata and recurse
				return sourceClass.getSuperClass();
			}
		}

		// No superclass -> processing is complete
		return null;
	}

ComponentScanAnnotationParser#parse()具体如何解析@ComponentScan注解。这里也是@Component注解生效的地方

    public Set parse(AnnotationAttributes componentScan, final String declaringClass) {
       ClassPathBeanDefinitionScanner scanner = new ClassPathBeanDefinitionScanner(this.registry,
				componentScan.getBoolean("useDefaultFilters"), this.environment, this.resourceLoader);
       // ...省略不重要
       return scanner.doScan(StringUtils.toStringArray(basePackages)); //扫描器进行扫描
    }

ClassPathBeanDefinitionScanner#doScan()

public class ClassPathBeanDefinitionScanner extends ClassPathScanningCandidateComponentProvider{

    //...

	protected Set doScan(String... basePackages) {
       Assert.notEmpty(basePackages, "At least one base package must be specified");
       Set beanDefinitions = new linkedHashSet<>();
       for (String basePackage : basePackages) {
          Set candidates = findCandidateComponents(basePackage); //找到候选组件（我们需要扫描进来的组件），这里是调用父类的方法
          for (BeanDefinition candidate : candidates) {
             Scopemetadata scopemetadata = this.scopemetadataResolver.resolveScopemetadata(candidate);
             candidate.setScope(scopemetadata.getScopeName());
             String beanName = this.beanNameGenerator.generateBeanName(candidate, this.registry);
             if (candidate instanceof AbstractBeanDefinition) {
                postProcessBeanDefinition((AbstractBeanDefinition) candidate, beanName);
             }
             if (candidate instanceof AnnotatedBeanDefinition) {
                AnnotationConfigUtils.processCommonDefinitionAnnotations((AnnotatedBeanDefinition) candidate);
             }
             if (checkCandidate(beanName, candidate)) {
                BeanDefinitionHolder definitionHolder = new BeanDefinitionHolder(candidate, beanName);
                definitionHolder =
                      AnnotationConfigUtils.applyScopedProxyMode(scopemetadata, definitionHolder, this.registry);
                beanDefinitions.add(definitionHolder);
                registerBeanDefinition(definitionHolder, this.registry);
             }
          }
       }
       return beanDefinitions;
    }


    // ...
}

ClassPathScanningCandidateComponentProvider#findCandidateComponents()

    public Set findCandidateComponents(String basePackage) {
       if (this.componentsIndex != null && indexSupportsIncludeFilters()) {
          return addCandidateComponentsFromIndex(this.componentsIndex, basePackage);
       }
       else {
          return scanCandidateComponents(basePackage); //扫描所有组件
       }
    }


	private Set scanCandidateComponents(String basePackage) {
		Set candidates = new linkedHashSet<>();
		try {
			String packageSearchPath = ResourcePatternResolver.CLASSPATH_ALL_URL_PREFIX +
					resolvebasePackage(basePackage) + '/' + this.resourcePattern;
			Resource[] resources = getResourcePatternResolver().getResources(packageSearchPath);
			boolean traceEnabled = logger.isTraceEnabled();
			boolean debugEnabled = logger.isDebugEnabled();
			for (Resource resource : resources) {
				if (traceEnabled) {
					logger.trace("Scanning " + resource);
				}
				if (resource.isReadable()) {
					try { //生成每一个资源的元数据信息
						metadataReader metadataReader = getmetadataReaderFactory().getmetadataReader(resource);
						if (isCandidateComponent(metadataReader)) { //如果当前类在扫描范围
							ScannedGenericBeanDefinition sbd = new ScannedGenericBeanDefinition(metadataReader);
							sbd.setSource(resource);
							if (isCandidateComponent(sbd)) {
								if (debugEnabled) {
									logger.debug("Identified candidate component class: " + resource);
								}
								candidates.add(sbd);
							}
							else {
								if (debugEnabled) {
									logger.debug("Ignored because not a concrete top-level class: " + resource);
								}
							}
						}
						else {
							if (traceEnabled) {
								logger.trace("Ignored because not matching any filter: " + resource);
							}
						}
					}
					catch (Throwable ex) {
						throw new BeanDefinitionStoreException(
								"Failed to read candidate component class: " + resource, ex);
					}
				}
				else {
					if (traceEnabled) {
						logger.trace("Ignored because not readable: " + resource);
					}
				}
			}
		}
		catch (IOException ex) {
			throw new BeanDefinitionStoreException("I/O failure during classpath scanning", ex);
		}
		return candidates;
	}

拿到所有类(资源),不管你有没有标@Component注解。然后挨个遍历每一个资源是不是候选的组件(根据前面准备的一些条件，在这里进行判断)

最后我们看一下执行完之后的BeanDefinition信息

registerBeanPostProcessors()注册所有的Bean后置处理器

前面讲过

    protected void registerBeanPostProcessors(ConfigurableListableBeanFactory beanFactory) {
       PostProcessorRegistrationDelegate.registerBeanPostProcessors(beanFactory, this);
    }

PostProcessorRegistrationDelegate#registerBeanPostProcessors()

    public static void registerBeanPostProcessors(
          ConfigurableListableBeanFactory beanFactory, AbstractApplicationContext applicationContext) {

       // WARNING: Although it may appear that the body of this method can be easily
       // refactored to avoid the use of multiple loops and multiple lists, the use
       // of multiple lists and multiple passes over the names of processors is
       // intentional. We must ensure that we honor the contracts for PriorityOrdered
       // and Ordered processors. Specifically, we must NOT cause processors to be
       // instantiated (via getBean() invocations) or registered in the ApplicationContext
       // in the wrong order.
       //
       // Before submitting a pull request (PR) to change this method, please review the
       // list of all declined PRs involving changes to PostProcessorRegistrationDelegate
       // to ensure that your proposal does not result in a breaking change:
       // https://github.com/spring-projects/spring-framework/issues?q=PostProcessorRegistrationDelegate+is%3Aclosed+label%3A%22status%3A+declined%22
       //获取到容器中所有的 BeanPostProcessor； Bean的后置处理器
       String[] postProcessorNames = beanFactory.getBeanNamesForType(BeanPostProcessor.class, true, false);

       // Register BeanPostProcessorChecker that logs an info message when
       // a bean is created during BeanPostProcessor instantiation, i.e. when
       // a bean is not eligible for getting processed by all BeanPostProcessors.
       int beanProcessorTargetCount = beanFactory.getBeanPostProcessorCount() + 1 + postProcessorNames.length;
       beanFactory.addBeanPostProcessor(new BeanPostProcessorChecker(beanFactory, beanProcessorTargetCount));

       // Separate between BeanPostProcessors that implement PriorityOrdered,
       // Ordered, and the rest.
       List priorityOrderedPostProcessors = new ArrayList<>();
       List internalPostProcessors = new ArrayList<>();
       List orderedPostProcessorNames = new ArrayList<>();
       List nonOrderedPostProcessorNames = new ArrayList<>();
       for (String ppName : postProcessorNames) {
          if (beanFactory.isTypeMatch(ppName, PriorityOrdered.class)) {  //获取所有实现了 PriorityOrdered 的 BeanPostProcessor
             BeanPostProcessor pp = beanFactory.getBean(ppName, BeanPostProcessor.class);
             priorityOrderedPostProcessors.add(pp);
             if (pp instanceof MergedBeanDefinitionPostProcessor) {
                internalPostProcessors.add(pp);
             }
          }
          else if (beanFactory.isTypeMatch(ppName, Ordered.class)) {
             orderedPostProcessorNames.add(ppName);
          }
          else {
             nonOrderedPostProcessorNames.add(ppName);
          }
       }

       //首先，注册所有的实现了 PriorityOrdered 的 BeanPostProcessor ；  First, register the BeanPostProcessors that implement PriorityOrdered.
       sortPostProcessors(priorityOrderedPostProcessors, beanFactory);
       registerBeanPostProcessors(beanFactory, priorityOrderedPostProcessors);

       //接下来，注册所有的实现了 Ordered 的 BeanPostProcessor  Next, register the BeanPostProcessors that implement Ordered.
       List orderedPostProcessors = new ArrayList<>(orderedPostProcessorNames.size());
       for (String ppName : orderedPostProcessorNames) {
          BeanPostProcessor pp = beanFactory.getBean(ppName, BeanPostProcessor.class);
          orderedPostProcessors.add(pp);
          if (pp instanceof MergedBeanDefinitionPostProcessor) {
             internalPostProcessors.add(pp);
          }
       }
       sortPostProcessors(orderedPostProcessors, beanFactory);
       registerBeanPostProcessors(beanFactory, orderedPostProcessors);

       // 最后，注册所有普通的 BeanPostProcessor ；Now, register all regular BeanPostProcessors.
       List nonOrderedPostProcessors = new ArrayList<>(nonOrderedPostProcessorNames.size());
       for (String ppName : nonOrderedPostProcessorNames) {
          BeanPostProcessor pp = beanFactory.getBean(ppName, BeanPostProcessor.class); //从容器中获取这个组件
          nonOrderedPostProcessors.add(pp);
          if (pp instanceof MergedBeanDefinitionPostProcessor) {
             internalPostProcessors.add(pp);
          }
       }
       registerBeanPostProcessors(beanFactory, nonOrderedPostProcessors);

       //最后，重新注册所有internal的BeanPostProcessors  Finally, re-register all internal BeanPostProcessors.
       sortPostProcessors(internalPostProcessors, beanFactory);
       registerBeanPostProcessors(beanFactory, internalPostProcessors);

       // 重新注册一下这个后置处理器 Re-register post-processor for detecting inner beans as ApplicationListeners,
       // 把他放到后置处理器的最后一位； moving it to the end of the processor chain (for picking up proxies etc).
       beanFactory.addBeanPostProcessor(new ApplicationListenerDetector(applicationContext));
    }

initMessageSource()

初始化国际化功能

看容器中是否有MessageSource的定义信息如果没有就注册一个默认的把国际化组件(MessageSource) 放到单例池中

initApplicationEventMulticaster()

初始化事件多播功能（事件派发）

看容器中是否有applicationEventMulticaster的定义信息，按照id找如果没有就注册一个默认的把事件多播器组件(ApplicationEventMulticaster) 放到单例池中

onRefresh()模板方法留给子类继续增强处理

留给子类继续增强处理，模板模式。

registerListeners()

注册监听器，从容器中获取所有的ApplicationListener


    protected void registerListeners() {
       //把所有监听器保存到多播器的集合中 Register statically specified listeners first.
       for (ApplicationListener listener : getApplicationListeners()) {
          getApplicationEventMulticaster().addApplicationListener(listener);
       }

       // Do not initialize FactoryBeans here: We need to leave all regular beans
       // uninitialized to let post-processors apply to them! 获取ApplicationListener在ioc容器中注册的bean的名字
       String[] listenerBeanNames = getBeanNamesForType(ApplicationListener.class, true, false);
       for (String listenerBeanName : listenerBeanNames) {
          getApplicationEventMulticaster().addApplicationListenerBean(listenerBeanName); //获取所有的容器中的监听器，并保存他们的名字
       }

       //派发之前攒的一些早期事件 Publish early application events now that we finally have a multicaster...
       Set earlyEventsToProcess = this.earlyApplicationEvents;
       this.earlyApplicationEvents = null;
       if (!CollectionUtils.isEmpty(earlyEventsToProcess)) {
          for (ApplicationEvent earlyEvent : earlyEventsToProcess) {
             getApplicationEventMulticaster().multicastEvent(earlyEvent);
          }
       }
    }

监听器也是一个重点，后面细讲

finishBeanFactoryInitialization()正式创建所有普通Bean

前面Bean的初始化流程讲的很仔细了

主要就是遍历循环所有BeanDefinition里的BeanName，挨个创建Bean对象。注意BeanPostProcessor这些不算普通Bean，在registerBeanPostProcessors()，invokeBeanFactoryPostProcessors()已经创建完了，因为在普通Bean创建的过程中，后置处理器可能需要参与进来，所以需要比普通Bean提前创建好最后执行SmartInitializingSingleton.afterSingletonsInstantiated后初始化

finishRefresh()主要是发送容器刷新完成的事件

最后进行一些清理和事件发送等

    protected void finishRefresh() {
       // Clear context-level resource caches (such as ASM metadata from scanning).
       clearResourceCaches();

       // Initialize lifecycle processor for this context.
       initLifecycleProcessor();

       //告诉LifecycleProcessor容器onRefresh Propagate refresh to lifecycle processor first.
       getLifecycleProcessor().onRefresh();

       //发布事件 Publish the final event.
       publishEvent(new ContextRefreshedEvent(this));

       //jconsole（暴露MBean端点信息） Participate in LiveBeansView MBean, if active.
       if (!NativeDetector.inNativeImage()) {
          LiveBeansView.registerApplicationContext(this);
       }
    }

自此over

补充：循环引用解决方案

单开一节，讲一下之前一直忽略的这个。其实很简单的一个东西，被网上搞的很难一样。

测试类 A

@Component
public class A {
    private B b;

    public A() {
        System.out.println("A...构造....");
    }

    @Autowired
    public void setB(B b) {
        this.b = b;
    }
}

B

@Component
public class B {

   private A a;

   public B() {
      System.out.println("B...构造....");
   }

   @Autowired
   public void setA(A a) {
      this.a = a;
   }
}

这就是循环引用的场景，这种写法由于Spring内部获取Bean都是通过getBean方法来获取，就造成了下面的死循环。我们来看看Spring是怎么解决的。

核心代码 AbstractBeanFactory

    protected  T doGetBean(
          String name, @Nullable Class requiredType, @Nullable Object[] args, boolean typeCheckOnly)
          throws BeansException {

       String beanName = transformedBeanName(name); //转换Bean名字
       Object beanInstance;

       // 先检查单实例bean的缓存 Eagerly check singleton cache for manually registered singletons.
       // ☆☆☆ pos_1
       Object sharedInstance = getSingleton(beanName); //检查缓存中有没有，如果是第一次获取肯定是没有的
       if (sharedInstance != null && args == null) {
          if (logger.isTraceEnabled()) {
             if (isSingletonCurrentlyInCreation(beanName)) {
				// ...
             }
             else {
                // ..
             }
          }
          beanInstance = getObjectForBeanInstance(sharedInstance, name, beanName, null);
       }

       else { //默认第一次获取组件都会进入else环节
			// ...

             // 创建bean的实例；Create bean instance.
             if (mbd.isSingleton()) {
                // ☆☆☆ pos_2
                sharedInstance = getSingleton(beanName, () -> {
                   try {
                      return createBean(beanName, mbd, args);  //创建bean对象的实例
                   }
                   catch (BeansException ex) {
                      destroySingleton(beanName);
                      throw ex;
                   }
                }); //看当前bean是否是FactoryBean
                beanInstance = getObjectForBeanInstance(sharedInstance, name, beanName, mbd);
             }

 		// ...
    }

DefaultSingletonBeanRegistry

    public Object getSingleton(String beanName) {
       // ☆☆☆ pos_3
       return getSingleton(beanName, true);
    }


   //☆☆☆ pos_4
    @Nullable  //双检查锁
    protected Object getSingleton(String beanName, boolean allowEarlyReference) {
       //先检查单例缓存池，获取当前对象  Quick check for existing instance without full singleton lock
       Object singletonObject = this.singletonObjects.get(beanName); //一级缓存
       if (singletonObject == null && isSingletonCurrentlyInCreation(beanName)) { //如果当前bean正在创建过程中，而且缓存中没有则继续
          singletonObject = this.earlySingletonObjects.get(beanName); //二级
          if (singletonObject == null && allowEarlyReference) {
             synchronized (this.singletonObjects) {
                // Consistent creation of early reference within full singleton lock
                singletonObject = this.singletonObjects.get(beanName);
                if (singletonObject == null) {
                   singletonObject = this.earlySingletonObjects.get(beanName);
                   if (singletonObject == null) {
                      ObjectFactory singletonFactory = this.singletonFactories.get(beanName); //三级
                      if (singletonFactory != null) {
                         singletonObject = singletonFactory.getObject();
                         this.earlySingletonObjects.put(beanName, singletonObject);
                         this.singletonFactories.remove(beanName);
                      }
                   }
                }
             }
          }
       }
       return singletonObject;
    }


	// ☆☆☆ pos_5
	public Object getSingleton(String beanName, ObjectFactory singletonFactory) {
		Assert.notNull(beanName, "Bean name must not be null");
		synchronized (this.singletonObjects) {
			Object singletonObject = this.singletonObjects.get(beanName);//再检查一次单例池
			if (singletonObject == null) { //单实例池子里面没有当前对象（说明没有创建完成）
				if (this.singletonsCurrentlyInDestruction) {
					throw new BeanCreationNotAllowedException(beanName,
							"Singleton bean creation not allowed while singletons of this factory are in destruction " +
							"(Do not request a bean from a BeanFactory in a destroy method implementation!)");
				}
				if (logger.isDebugEnabled()) {
					logger.debug("Creating shared instance of singleton bean '" + beanName + "'");
				}
                 // ☆☆☆ pos_6
				beforeSingletonCreation(beanName); //单实例创建之前，这个就是加到
				boolean newSingleton = false;
				boolean recordSuppressedExceptions = (this.suppressedExceptions == null);
				if (recordSuppressedExceptions) {
					this.suppressedExceptions = new linkedHashSet<>();
				}
				try {
					singletonObject = singletonFactory.getObject();//会调用lamda表达式的内容，真正创建对象
					newSingleton = true;
				}
				catch (IllegalStateException ex) {
					// Has the singleton object implicitly appeared in the meantime ->
					// if yes, proceed with it since the exception indicates that state.
                    // ☆☆☆ pos_7
					singletonObject = this.singletonObjects.get(beanName);
					if (singletonObject == null) {
						throw ex;
					}
				}
				catch (BeanCreationException ex) {
					// ...
				}
				finally {
					if (recordSuppressedExceptions) {
						this.suppressedExceptions = null;
					}
					afterSingletonCreation(beanName);
				}
				if (newSingleton) {
					addSingleton(beanName, singletonObject);
				}
			}
			return singletonObject;
		}
	}

	// 加到singletonsCurrentlyInCreation
	protected void beforeSingletonCreation(String beanName) {
		if (!this.inCreationCheckExclusions.contains(beanName) && !this.singletonsCurrentlyInCreation.add(beanName)) {
			throw new BeanCurrentlyInCreationException(beanName);
		}
	}

AbstractAutowireCapableBeanFactory

    protected Object doCreateBean(String beanName, RootBeanDefinition mbd, @Nullable Object[] args)
          throws BeanCreationException {

       // Instantiate the bean.
       BeanWrapper instanceWrapper = null;
       if (mbd.isSingleton()) { //是否单例的
          instanceWrapper = this.factoryBeanInstanceCache.remove(beanName);
       }
       if (instanceWrapper == null) {
          //创建Bean的实例,默认使用无参构造器创建的对象，组件的原始对象就创建了 ☆☆☆ pos_8
          instanceWrapper = createBeanInstance(beanName, mbd, args);
       }
       Object bean = instanceWrapper.getWrappedInstance();
       Class beanType = instanceWrapper.getWrappedClass();
       if (beanType != NullBean.class) {
          mbd.resolvedTargetType = beanType;
       }

	  // ...

       // 提前暴露单实例。专门来解决循环引用问题；Eagerly cache singletons to be able to resolve circular references
       // even when triggered by lifecycle interfaces like BeanFactoryAware.
       // ☆☆☆ pos_9
       boolean earlySingletonExposure = (mbd.isSingleton() && this.allowCircularReferences &&
             isSingletonCurrentlyInCreation(beanName));
       if (earlySingletonExposure) {
          if (logger.isTraceEnabled()) {
             logger.trace("Eagerly caching bean '" + beanName +
                   "' to allow for resolving potential circular references");
          }
          addSingletonFactory(beanName, () -> getEarlyBeanReference(beanName, mbd, bean)); //三级缓存中的Bean也会被后置处理来增强，
       }

       // Initialize the bean instance.
       Object exposedObject = bean;
       try {
          // ☆☆☆ pos_10
          populateBean(beanName, mbd, instanceWrapper); //给创建好的对象每个属性进行赋值，@Autowired发生在这里
          exposedObject = initializeBean(beanName, exposedObject, mbd);//初始化bean
       }
       catch (Throwable ex) {
          if (ex instanceof BeanCreationException && beanName.equals(((BeanCreationException) ex).getBeanName())) {
             throw (BeanCreationException) ex;
          }
          else {
             throw new BeanCreationException(
                   mbd.getResourceDescription(), beanName, "Initialization of bean failed", ex);
          }
       }
       //早期单实例暴露
       if (earlySingletonExposure) {
          Object earlySingletonReference = getSingleton(beanName, false); //检查早期缓存中是否存在这个组件
          if (earlySingletonReference != null) {
             if (exposedObject == bean) {
                exposedObject = earlySingletonReference;
             }
             else if (!this.allowRawInjectionDespiteWrapping && hasDependentBean(beanName)) {
                String[] dependentBeans = getDependentBeans(beanName);
                Set actualDependentBeans = new linkedHashSet<>(dependentBeans.length);
                for (String dependentBean : dependentBeans) {
                   if (!removeSingletonIfCreatedForTypeCheckOnly(dependentBean)) {
                      actualDependentBeans.add(dependentBean);
                   }
                }
                if (!actualDependentBeans.isEmpty()) {
                   throw new BeanCurrentlyInCreationException(beanName,
                         "Bean with name '" + beanName + "' has been injected into other beans [" +
                         StringUtils.collectionToCommaDelimitedString(actualDependentBeans) +
                         "] in its raw version as part of a circular reference, but has eventually been " +
                         "wrapped. This means that said other beans do not use the final version of the " +
                         "bean. This is often the result of over-eager type matching - consider using " +
                         "'getBeanNamesForType' with the 'allowEagerInit' flag turned off, for example.");
                }
             }
          }
       }

       // Register bean as disposable.
       try {
          registerDisposableBeanIfNecessary(beanName, bean, mbd);
       }
       catch (BeanDefinitionValidationException ex) {
          throw new BeanCreationException(
                mbd.getResourceDescription(), beanName, "Invalid destruction signature", ex);
       }

       return exposedObject;
    }

流程

pos_1位置先进入pos_3位置的getSingleton(beanName, true)，查看缓存中有没有A组件

然后走到pos_2调用pos_5的getSingleton()开始创建A的流程在pos_5的getSingleton()中走到pos_6的beforeSingletonCreation()，就变成下面这样

接着pos_7的会调用pos_2的lamda表达式里的createbean()，里面再调用doCreateBean()。前面讲过不多说，最终调用A的无参构造(pos_8)，创建完之后发现A的B属性是null。

5.在pos_9处的addSingletonFactory()来准备解决循环引用

    protected void addSingletonFactory(String beanName, ObjectFactory singletonFactory) {
       Assert.notNull(singletonFactory, "Singleton factory must not be null");
       synchronized (this.singletonObjects) {
          if (!this.singletonObjects.containsKey(beanName)) { //当前对象如果没有在单例池中
             this.singletonFactories.put(beanName, singletonFactory);
             this.earlySingletonObjects.remove(beanName);
             this.registeredSingletons.add(beanName);
          }
       }
    }

接着在pos_10处的populateBean()开始给属性赋值，这一步就是要把B b自动装配进来。主要是

    protected void populateBean(String beanName, RootBeanDefinition mbd, @Nullable BeanWrapper bw) {
       if (bw == null) {
          if (mbd.hasPropertyValues()) {
             throw new BeanCreationException(
                   mbd.getResourceDescription(), beanName, "Cannot apply property values to null instance");
          }
          else {
             // Skip property population phase for null instance.
             return;
          }
       }

       // @Autowired赋值也在这里(但是没做事)。可以中断初始化行为； 在属性赋值之前，后置处理器可以提前准备些东西 Give any InstantiationAwareBeanPostProcessors the opportunity to modify the

       if (!mbd.isSynthetic() && hasInstantiationAwareBeanPostProcessors()) {
          for (InstantiationAwareBeanPostProcessor bp : getBeanPostProcessorCache().instantiationAware) {
             if (!bp.postProcessAfterInstantiation(bw.getWrappedInstance(), beanName)) {
                return;
             }
          }
       } //以上的后置处理器可以中断以下的行为

       PropertyValues pvs = (mbd.hasPropertyValues() ? mbd.getPropertyValues() : null);

       int resolvedAutowireMode = mbd.getResolvedAutowireMode();
       if (resolvedAutowireMode == AUTOWIRE_BY_NAME || resolvedAutowireMode == AUTOWIRE_BY_TYPE) {
          // ...
       }

       boolean hasInstAwareBpps = hasInstantiationAwareBeanPostProcessors();
       boolean needsDepCheck = (mbd.getDependencyCheck() != AbstractBeanDefinition.DEPENDENCY_CHECK_NONE);

       PropertyDescriptor[] filteredPds = null;
       if (hasInstAwareBpps) {
          if (pvs == null) {
             pvs = mbd.getPropertyValues(); //xml中property标签指定的
          } //使用后置处理器处理属性
          for (InstantiationAwareBeanPostProcessor bp : getBeanPostProcessorCache().instantiationAware) {
             PropertyValues pvsToUse = bp.postProcessProperties(pvs, bw.getWrappedInstance(), beanName);
             if (pvsToUse == null) {
                if (filteredPds == null) {
                   filteredPds = filterPropertyDescriptorsForDependencyCheck(bw, mbd.allowCaching);
                }
                pvsToUse = bp.postProcessPropertyValues(pvs, filteredPds, bw.getWrappedInstance(), beanName);
                if (pvsToUse == null) {
                   return;
                }
             }
             pvs = pvsToUse; //封装了当前bean的所有属性名和值，可以由后置处理器处理得到
          }
       }
       // ...

       if (pvs != null) { //把以前处理好的PropertyValues给bean里面设置一下。主要是上面步骤没有给bean里面设置的属性
          applyPropertyValues(beanName, mbd, bw, pvs); //xml版的所有配置会来到这里给属性赋值
       }
    }

通过前面讲过的AutowiredAnnotationBeanPostProcessor来注入B，最后发现要调用setB方法给B赋值

继续走，发现要想获得B还是要调用getBean

    public Object resolveCandidate(String beanName, Class requiredType, BeanFactory beanFactory)
          throws BeansException {

       return beanFactory.getBean(beanName); //所有自动注入的属性都是beanFactory.getBean(beanName);的结果
    }

然后图就是这样子

B也是走这一套

B为了获取A，还要再走一次getBean()流程，最终还是走到

   //☆☆☆ pos_4
    @Nullable  //双检查锁
    protected Object getSingleton(String beanName, boolean allowEarlyReference) {
       //先检查单例缓存池，获取当前对象  Quick check for existing instance without full singleton lock
       Object singletonObject = this.singletonObjects.get(beanName); //一级缓存
       if (singletonObject == null && isSingletonCurrentlyInCreation(beanName)) { //如果当前bean正在创建过程中，而且缓存中没有则继续
          singletonObject = this.earlySingletonObjects.get(beanName); //二级
          if (singletonObject == null && allowEarlyReference) {
             synchronized (this.singletonObjects) {
                // Consistent creation of early reference within full singleton lock
                singletonObject = this.singletonObjects.get(beanName);
                if (singletonObject == null) {
                   singletonObject = this.earlySingletonObjects.get(beanName);
                   if (singletonObject == null) {
                      ObjectFactory singletonFactory = this.singletonFactories.get(beanName); //三级
                      if (singletonFactory != null) {
                         singletonObject = singletonFactory.getObject();// 用那个lamda表达式拿对象
                         this.earlySingletonObjects.put(beanName, singletonObject);
                         this.singletonFactories.remove(beanName);
                      }
                   }
                }
             }
          }
       }
       return singletonObject;
    }

得到A之后，B赋值结束。B进入初始化

populateBean(beanName, mbd, instanceWrapper); //给创建好的对象每个属性进行赋值，@Autowired发生在这里
exposedObject = initializeBean(beanName, exposedObject, mbd);//初始化bean

B初始化完之后，回到getSingleton，把自己放到单例池里

protected void addSingleton(String beanName, Object singletonObject) {
   synchronized (this.singletonObjects) {
      this.singletonObjects.put(beanName, singletonObject);
      this.singletonFactories.remove(beanName);
      this.earlySingletonObjects.remove(beanName);
      this.registeredSingletons.add(beanName);
   }
}

B全部结束之后回到A的流程，A赋值工作结束了，然后就开始A的初始化。初始化的过程中

protected void addSingleton(String beanName, Object singletonObject) {
   synchronized (this.singletonObjects) {
      this.singletonObjects.put(beanName, singletonObject); //加到一级
      this.singletonFactories.remove(beanName); //移除三级
      this.earlySingletonObjects.remove(beanName); //移除二级
      this.registeredSingletons.add(beanName);
   }
}

全部的流程图
