链路追踪zipkin

zipkin工作流程

application.properties

server:
 port: 8080
spring:
  application:
    name: zipkinTest
  zipkin:
   base-url: http://localhost:9411
   sender:
     type: web

pom.xml


            org.springframework.cloud
            spring-cloud-starter-zipkin





                org.springframework.cloud
                spring-cloud-dependencies
                Hoxton.SR6
                pom
                import




logback-spring.xml













            DEBUG


            ${CONSOLE_LOG_PATTERN}
            utf8





        ${LOG_FILE}

            ${LOG_FILE}.%d{yyyy-MM-dd}.gz
            7


            ${CONSOLE_LOG_PATTERN}
            utf8







zipkin 官网地址
https://zipkin.io/pages/quickstart.html

官网的server相关的配置
https://github.com/openzipkin/zipkin/tree/master/zipkin-server

mysql的建表脚本如下
https://github.com/openzipkin/zipkin/blob/master/zipkin-storage/mysql-v1/src/main/resources/mysql.sql

使用下面的命令启动zipkin server

java -jar zipkin-server-2.23.16-exec.jar --STORAGE_TYPE=mysql --MYSQL_HOST=localhost --MYSQL_TCP_PORT=3306 --MYSQL_USER=root --MYSQL_PASS=root --MYSQL_DB=zipkinDB

服务端启动命令

java -jar zipkin-server-2.23.16-exec.jar --STORAGE_TYPE=mysql --MYSQL_HOST=localhost --MYSQL_TCP_PORT=3306 --MYSQL_USER=root --MYSQL_PASS=root --MYSQL_DB=zipkinDB --RABBIT_ADDRESSES=localhost:5672 --RABBIT_USER=guest --RABBIT_PASSWORD=guest --RABBIT_VIRTUAL_HOST=/ --RABBIT_QUEUE=zipkin

修改程序的yml文件

server:
 port: 8080
spring:
  application:
    name: zipkinTest
  zipkin:
   base-url: http://localhost:9411
   sender:
     type: rabbit
   rabbitmq:
     queue: zipkin
  rabbitmq:
    host: 127.0.0.1
    port: 5672
    username: guest
    password: guest
    virtual-host: /

pom文件中添加mq的依赖


            org.springframework.amqp
            spring-rabbit


在MQ中创建消息zipkin

java -jar zipkin-server-2.23.16-exec.jar --STORAGE_TYPE=elasticsearch --ES_HOSTS=http://localhost:9200/ --RABBIT_ADDRESSES=localhost:5672 --RABBIT_USER=guest --RABBIT_PASSWORD=guest --RABBIT_VIRTUAL_HOST=/ --RABBIT_QUEUE=zipkin

会自动简历一个zipkin开头的索引
