[数据处理记录]little

数据一：[13098, 11129, 11105, 11157, 11021, 11018, 11028, 11157]网状数据二：[11194, 15090, 11018, 11028, 11009, 15076, 11147, 11105]星状数据三：[11106, 15018, 11020, 11012, 11018, 11212, 11016, 11014]网状数据四：[11131, 11194, 11106, 11012, 15018, 11228, 11013, 11014]网状数据五：[11012, 15018, 15148, 11011, 11013, 11028, 11018, 11014]网状
以数据二为例 二、代码 1. 导入库

import pandas as pd
import numpy as np
import collections
import pickle
import networkx as nx
import scipy.sparse as sparse
import torch
import collections
import matplotlib.pyplot as plt
import random
## 先实例化预定义函数
## 预定义函数放入附录

# 通用数据读入
allnodes=np.load("../data/allnodes.npy").tolist()
ifo = pd.read_csv("../data/info1.csv")
bikes7=pd.read_csv("../data/bikefor7days.csv")
ridetime=pd.read_csv("../data/ridetime.csv",header=None)
ridetime.columns=["index","station1","station2","time"]

nodeset=[11194, 15090, 11018, 11028, 11009, 15076, 11147, 11105] # 星状

## ridetime的修改
ridetime["choose"]=ridetime.apply(lambda row: get_inner(row['station1'],row['station2'],nodeset),axis=1)
new_rt=ridetime[ridetime["choose"]][["station1","station2","time"]]
new_rt.reset_index(drop=True,inplace=True)
new_rt.to_csv("../data"+str(nodeset[0])+"/ridetime.csv",header=None)

# 对上述node完成 ifo_new
## 1.筛选含nodeset的数据集
bikes7["choose"]=bikes7.apply(lambda row: get(row['借车站点'],row['还车站点'],nodeset),axis=1)
data=bikes7[bikes7["choose"]] [["借车站点",'还车站点']]
## 2. 内部数据进行标签化，利用get_inner函数
data["inner"]=data.apply(lambda row: get_inner(row['借车站点'],row['还车站点'],nodeset),axis=1)
## 3.计算总流量和内部流量（流量包括起点和终点）
inner=collections.defaultdict(lambda: 0)
total = collections.defaultdict(lambda:0)
for column in ["借车站点","还车站点"]:
    dfi=data.groupby(column)[["inner"]].sum()
    dft=data.groupby(column).count()
    for node in nodeset:
        inner[node] = dfi.loc[node]["inner"]
        total[node] = dft.loc[node]["inner"]
## 4. 计算比值,并获得ifo_new
ifo_new=pd.Dataframe(columns=ifo.columns) # 建立一个跟ifo表格头相同的df
for i in range(len(nodeset)):
    node = nodeset[i]
    idx=allnodes.index(node) # 获取ifo的对应索引
    ifo_new.loc[i]= ifo.loc[idx]
    p = inner[node]/total[node]
    ifo_new.loc[i,"size"]=int(ifo.loc[idx,"size"] *p )+3
ifo_new=ifo_new[['station', 'jing', 'wei', 'name', 'distict','types', 'size']]
ifo_new.to_csv("../data"+str(nodeset[0])+"/ifo_"+str(nodeset[0])+".csv",header=None)

# 对上述nodeset进行数据记录
## 1. 晒选内部数据
bikes7["inner_choose"]=bikes7.apply(lambda row: get_inner(row['借车站点'],row['还车站点'],nodeset),axis=1)
colu=[["借车站点","j_d",'j_h','j_m'],['还车站点','h_d','h_h','h_m']]

## 2. 分dayhour，分别对借和还 的数据进行筛选，添加标签，修改列明，数据合并
for day in range(20,27):
    for hour in range(24):
# day = 20
# hour =8
        DF = pd.Dataframe(columns=["station","M","mode"])
        for i in range(2):
            data=bikes7[bikes7["inner_choose"]] [colu[i]]
            data.columns=["station","D","H","M"]
            df = data[(data["D"]==day)&(data['H']==hour)][["station","M"]]
            df ["mode"]=[i]*(len(df))
            DF=pd.concat([df,DF],axis=0) # 数据合并
        ##  3.对DF进行数据排序,并修改索引
        DF.sort_values( by="M", axis=0, ascending=True, inplace=True)# 对列“M”排序，升序,在原表修改
        DF.reset_index(inplace=True,drop=True)
        ### 保存数据
        DF.to_csv("../data"+str(nodeset[0])+"/"+str(day)+str(hour)+".npy")

# 对上述nodeset获得流量矩阵
## 1. 选择日期、筛选内部数据
bikes7["inner_choose"]=bikes7.apply(lambda row: get_inner(row['借车站点'],row['还车站点'],nodeset),axis=1)
#day = 20
for day in range(20,27):
    data = bikes7[(bikes7["inner_choose"])&(bikes7["j_d"]==day)]
    ## 2. 筛选阶段数据，并用groupby进行分组，获得流量
    for i in range(3):
        periods = [[5,6,7,8,9],[10,11,12,13,14],[13,15,16,17,18]]
        data1 = data[(data["j_h"]>=periods[i][0])&(data['j_h']<=periods[i][-1])]
        data2=data1.groupby(["借车站点","还车站点"]).count().reset_index()#数据分组后，重置索引
        #print(data2)
        ## 3. 建立 节点与索引的对应关系
        nodes=np.array(nodeset)
        np.save("../data"+str(nodeset[0])+"/nodes.npy",nodes)
        ## 4. 建立流量矩阵
        adj = np.zeros(shape=(len(nodeset),len(nodeset)))
        for j in range(len(data2)):
            row = data2.loc[j]
            id1 = nodeset.index(row[0])
            #print(id1)
            id2 = nodeset.index(row[1])
            #print(id2)
            val = row[2]
            adj[id1,id2]= val
        #print(adj)
        np.save("../data"+str(nodeset[0])+"/adjflow"+str(day)+str(periods[i][0])+".npy",adj)

# 对上述nodeset获得demand和supply属性
## 1.筛选含nodeset的数据集,利用get_inner函数
bikes7["inner"]=bikes7.apply(lambda row: get_inner(row['借车站点'],row['还车站点'],nodeset),axis=1)
b = bikes7[bikes7["inner"]]
## 2. 对时间【day,hour】进行循环
for day in range(20,27):
    for hour in range(0,24):
        ## 统计数据
        data = b[(b["j_d"]==day)&(b["j_h"]==hour)][['借车站点','还车站点']]
#         print(len(data))
        demand,supply=[],[]
        df1 = data.groupby(["借车站点"]).count().reset_index()#数据分组后，重置索引
        df2 = data.groupby(["还车站点"]).count().reset_index()
        ## 按照列表排序
        for node in nodeset:
            if node in df1["借车站点"].tolist():
                demand.append(df1.loc[df1["借车站点"]==node,"还车站点"].values[0]) #将node出流量的计数放入demand中
            else:
                demand.append(0)
            if node in df2["还车站点"].tolist():
                supply.append(df2.loc[df2["还车站点"]==node,"借车站点"].values[0]) #将node入流量的计数放入supply中
            else:
                supply.append(0)
        ## 存档
        f1 = open("../data"+str(nodeset[0])+"/demand.txt","a")
        f1.write(str([day,hour]))
        f1.write(str(demand))
        f1.write("n")
        f1.close()
        f2 = open("../data"+str(nodeset[0])+"/supply.txt","a")
        f2.write(str([day,hour]))
        f2.write(str(supply))
        f2.write("n")
        f2.close()

注意到：open(".txt",“a”),中“a"是可继续填写的属性，因此，如果中间报错的话，需要将txt文件删除后再执行代码，防止有错误累计。

——————————————————————————————————

def get(x,y,vertexes):
    if (x in vertexes) or (y in vertexes):
        return True
    else:
        return False

def get_inner(x,y,neib):
    if (x in neib) and (y in neib):
        return True
    else:
        return False

def modify_name(x):
    if x=="第一类边缘量小型":
        #return "Small-margin stations"
        return "pink"
    elif x=="第二类调度需求型":
        return "blue"
        #return "Dynamically balanced stations"
    elif x=="第三类动态均衡型":
        #return "Scheduling demand stations"
        return "orange"
    else:
        #return "Key guarantee stations"
        return "red"
def get_matrix(adj_file):
    ## 读取稀疏矩阵
    wname = adj_file
    co_w = sparse.load_npz(wname)
    values = co_w.data
    indices = np.vstack((co_w.row, co_w.col))
    i = torch.LongTensor(indices)
    v = torch.FloatTensor(values)
    shape = co_w.shape
    adjacency = torch.sparse.FloatTensor(i, v, torch.Size(shape))
    adj = adjacency.to_dense()
    return adj


def get_MX(g,state):
    ## 获得重叠性数据
    MG = collections.defaultdict(dict) # 用来记录重叠矩阵
    if state=="morning":
        T =range(5,10)
    elif state=="noon":
        T =range(10,15)
    else:
        T = range(15,20)
    for v in vertexes:
        for t in T:
            if t in g[v].keys(): # 判断节点v在t是否有记录
                for w in g[v][t]:
                    if w in MG[v].keys(): # node w是否记录过，没有记录设为1，有记录则加1
                        MG[v][w] += 1
                    else:
                        MG[v][w] = 1
    ## 删除值为1的键值对
    for v in MG.keys():
        for w in list(MG[v].keys()):
            if MG[v][w]==1:
                del MG[v][w]
    return MG
def get_Counter(g,state,mode="jie"):
    MG = collections.Counter() # 计数器
    if state=="morning":
        T =range(5,10)
    elif state=="noon":
        T =range(10,15)
    else:
        T = range(15,20)
    for v in vertexes:
        for t in T:
            if t in g[v].keys(): # 判断节点v在t是否有记录
                if mode == "jie":
                    cl = [(v,w) for w in g[v][t]] # 将借车OD对变为列表
                else:
                    cl = [(w,v) for w in g[v][t]] # 将还车OD对变为列表
                MG.update(cl) # 放入计数器中
    ## 删除计数值为1的键
    for k in list(MG.keys()):
        if MG[k] == 1:
            del MG[k]
    return MG
