网络地址转换（二）

[Huawei]acl 2000
[Huawei-acl-basic-2000]rule 5 permit source 192.168.1.0 0.0.0.255
[Huawei-acl-basic-2000]
[Huawei-acl-basic-2000]rule 10 permit source 192.168.2.0 0.0.0.255
[Huawei-acl-basic-2000]
[Huawei-acl-basic-2000]rule 15 permit source 192.168.3.0 0.0.0.255
[Huawei-acl-basic-2000]
[Huawei-acl-basic-2000]quit
[Huawei]
[Huawei]int g2/0/0
[Huawei-GigabitEthernet2/0/0]nat outbound 2000

        3、测试

        ​​​​​​​

二、NAT Server转换实验

        1、拓扑图



        2、NAT Server配置命令

[Huawei]int g2/0/0

[Huawei-GigabitEthernet2/0/0]

[Huawei-GigabitEthernet2/0/0]

[Huawei-GigabitEthernet2/0/0]nat server protocol tcp global 100.100.100.3 www inside 192.168.4.1 www

        3、测试结果

        ​​​​​​​
