Flink 窗口触发器

• 决定何时触发窗口后续的逻辑执行。每个窗口都有一个默认的触发器,时间窗口默认watermark超过EndTime就触发计算

• Flink中定义了Trigger抽象类，任何trigger必须继承Trigger类，Flink官方提供了几种常用的trigger实现，同时，用户可以根据需求自定义trigger。

public abstract class Trigger implements Serializable {

	private static final long serialVersionUID = -4104633972991191369L;


	public abstract TriggerResult onElement(T element, long timestamp, W window, TriggerContext ctx) throws Exception;


	public abstract TriggerResult onProcessingTime(long time, W window, TriggerContext ctx) throws Exception;


	public abstract TriggerResult onEventTime(long time, W window, TriggerContext ctx) throws Exception;


	public boolean canMerge() {
		return false;
	}


	public void onMerge(W window, OnMergeContext ctx) throws Exception {
		throw new UnsupportedOperationException("This trigger does not support merging.");
	}


	public abstract void clear(W window, TriggerContext ctx) throws Exception;

}

• 前三方法决定着如何通过返回一个TriggerResult枚举类来操作输入事件

CONTINUE:什么都不做
FIRE:触发计算
PURE:清除窗口的元素
FIRE_AND_PURE:触发计算和清除窗口元素

public class ProcessingTimeTrigger extends Trigger {
	private static final long serialVersionUID = 1L;

	private ProcessingTimeTrigger() {}



	@Override
	public TriggerResult onElement(Object element, long timestamp, TimeWindow window, TriggerContext ctx) {
		ctx.registerProcessingTimeTimer(window.maxTimestamp());
		return TriggerResult.CONTINUE;
	}


	@Override
	public TriggerResult onEventTime(long time, TimeWindow window, TriggerContext ctx) throws Exception {
		return TriggerResult.CONTINUE;
	}


	@Override
	public TriggerResult onProcessingTime(long time, TimeWindow window, TriggerContext ctx) {
		return TriggerResult.FIRE;
	}

	@Override
	public void clear(TimeWindow window, TriggerContext ctx) throws Exception {
		ctx.deleteProcessingTimeTimer(window.maxTimestamp());
	}

	@Override
	public boolean canMerge() {
		return true;
	}

	@Override
	public void onMerge(TimeWindow window,
			OnMergeContext ctx) {
		// only register a timer if the time is not yet past the end of the merged window
		// this is in line with the logic in onElement(). If the time is past the end of
		// the window onElement() will fire and setting a timer here would fire the window twice.
		long windowMaxTimestamp = window.maxTimestamp();
		if (windowMaxTimestamp > ctx.getCurrentProcessingTime()) {
			ctx.registerProcessingTimeTimer(windowMaxTimestamp);
		}
	}

	@Override
	public String toString() {
		return "ProcessingTimeTrigger()";
	}


	public static ProcessingTimeTrigger create() {
		return new ProcessingTimeTrigger();
	}
}

• 需要注意的是ProcessingTimeTrigger类只会在窗口的最终时间到达的时候触发窗口函数的计算，计算完成后并不会清除窗口中的数据，这些数据存储在内存中，除非调用PURGE或FIRE_AND_PURGE,否则数据将一直存在内存中。实际上，Flink中提供的Trigger类，除了PurgingTrigger类，其他的都不会对窗口中的数据进行清除。
