Swagger2笔记

    io.springfox
    springfox-swagger2
    2.8.0


    io.springfox
    springfox-swagger-ui
    2.8.0

@Configuration
@EnableSwagger2
public class Swagger2Configuration {

    @Bean
    public Docket createRestAPI(){
        return new Docket(documentationType.SWAGGER_2)
                .apiInfo(apiInfo())
                .select()
                .apis(RequestHandlerSelectors.basePackage("com.dou"))//扫描的包
                .paths(PathSelectors.any())
                .build();
    }

    private ApiInfo apiInfo(){
        return new ApiInfoBuilder()
                .title("豆豆接口服务")//设置文档的标题
                .description("豆豆几口服务，API接口文档")//设置文档的描述
                .version("1.0")//设置文档的版本
                .termsOfServiceUrl("http://www.doudou.com")//设置文档License信息
                .build();
    }
}

@Configuration：让Spring加载该配置类

@EnableSwagger2：启动Swagger2

@RestController
public class StudentController {

    @Resource
    private StudentService studentService;

    @ApiOperation(value = "获取用户列表",notes = "")
    @RequestMapping(value = "/getStudents", method = RequestMethod.GET)
    public List getStudents(){

        return studentService.getStudents();
    }

    @ApiOperation(value = "增加学生信息", notes = "根据student添加学生信息")
    @ApiImplicitParam(name = "student", value = "添加学生信息", required = true, dataType = "Student", dataTypeClass = Student.class)
    @RequestMapping(value = "/postStudent", method = RequestMethod.POST)
    public String postStudent(@RequestBody Student student){

        studentService.postStudent(student);

        return "success";
    }

    @ApiOperation(value = "更新学生信息", notes = "根据id来取出更新学生信息，把用户更信息后修改数据库")
    @ApiImplicitParams({
            @ApiImplicitParam(name = "id", value = "学生id", required = true, dataType = "String", dataTypeClass = String.class),
            @ApiImplicitParam(name = "student", value = "学生信息", required = true, dataType = "Student", dataTypeClass = Student.class)
    })
    @RequestMapping(value = "/putStudent", method = RequestMethod.PUT)
    public String putStudent(@RequestParam String id, @RequestBody Student student){

        Student stu = studentService.getStudent(id);
        stu.setName(student.getName());
        stu.setAge(student.getAge());
        studentService.putStudent(stu);

        return "success";
    }

    @ApiOperation(value = "删除学生", notes = "根据id删除学生信息")
    @ApiImplicitParam(name = "id", value = "学生id", required = true, dataType = "String", dataTypeClass = String.class)
    @RequestMapping(value = "/deleteStudent", method = RequestMethod.DELETE)
    public String deleteStudent(@RequestParam String id){
        studentService.deleteStudent(id);

        return "success";
    }
}

@ApiOperation：描述接口

• value：该接口的简单描述
• notes：操作的详细描述

@ApiImplicitParam：描述一个参数

• name：参数名称
• value：参数的简单描述
• required：是否需要该参数
• dataType：参数的数据类型
• dataTypeClass：参数的类

@ApiImplicitParams：描述多个参数

@Apilgnore：使用该注解忽略这个API

代码完成后启动项目，访问：http://ip:端口号/swagger-ui.html

1. 版本问题

   • Unable to interpret the implicit parameter configuration with dataType: String, dataTypeClass: class java.lang.Void

     一般对于integer、long、string这样的类型，会遇到此报错，

     **解决方法：**降低swagger版本，我原先版本3.0.0，降低为2.8.0，不在出现此报错

   • Parameter 0 of method linkDiscoverers in org.springframework.hateoas.config.HateoasConfiguration required a single bean, but 15 were found:

     **解决方法：**spring boot项目整合swagger需要注意两者的版本，spring boot项目的版本低，相应的swagger版本不能太高，反之亦然，将swagger版本更改到与spring boot版本相近即可。

2. 配置问题

   • Failed to start bean ‘documentationPluginsBootstrapper’; nested exception is java.lang.NullPointerException

     原因：Springfox使用的路径匹配是基于AntPathMatcher的，而Spring Boot 2.6.x使用的是PathPatternMatcher

     **解决方法：**使用yaml，添加如下配置

     spring:
       mvc:
         pathmatch:
           matching-strategy: ANT_PATH_MATCHER


     使用properties配置，添加如下配置

     spring.mvc.pathmatch.matching-strategy= ANT_PATH_MATCHER


https://gitee.com/shen_doudou/practice-code.git
