实现(2, 1, 7)卷积码编码
信息序列1001 1010 1111 1100
生成序列g1 = 1011011;g2 = 1111001
初始状态全0.
以上参数可自行在main中修改。
复制代码 代码如下:
#include
#define LEN(array, len){len=sizeof(array)/sizeof(array[0]);}//Size of array
int encoder(int **gen, int n, int L, int reg[], int m, int inf[], int inf_len, int output[])
{
int inf_ex[inf_len + m];
int i,j;//Index
for (i=0;i < inf_len + m;i++)//Extend the information sequence to include the last m bits
{
if(i < inf_len)
inf_ex[i] = inf[i];
else
inf_ex[i] = 0;
}
for (i=0;i < inf_len + m;i++)//Foreach bit in extend information
{
for (j=0;j < n;j++)//Output n bits at each clock cycle
{
int out_tem=0;//Temp number
if (*(gen + L*j) == 1)//Judge whether the next information bit should paticipate in the Mod op
out_tem += inf_ex[i];
int k;
for (k=0;k < m;k++)//Foreach registers
{
if (*(gen + L*j + k + 1) == 1)
out_tem += reg[k];//Mod op according to the generation sequence
}
out_tem %= 2;//Mod 2
output[i*n + j] = out_tem;
}
for (j=m - 1;j > 0;j--)//Register shift
{
reg[j] = reg[j - 1];
}
reg[0] = inf_ex[i];//Input information bits into register
}
return 1;
}
main()
{
int inf[]={1, 0, 0, 1, 1, 0, 1, 0, 1, 1, 1, 1, 1, 1, 0, 0};//Information sequence
int inf_len;//Information length
LEN(inf, inf_len);
int gen[2][7]={{1, 0, 1, 1, 0, 1, 1}, {1, 1, 1, 1, 0, 0, 1}};//Generation sequence
int n;//The number of bits out the encoder at each clock cycle
int L;//Constraight length
LEN(gen, n);
LEN(gen[0], L);
int m=L - 1;//The number of shift registers
int init_s[]={0, 0, 0, 0, 0, 0}; //Initial states are all zero
int reg[m];//Register
int i;//Index
for (i=0;i < m;i++)
{
reg[i] = init_s[i];
}
int output_len=(inf_len + m)*n;//Output length, every bit of input can generate n bits of output sequence
int output[(inf_len + m)*n];//Output sequence
encoder(gen, n, L, reg, m, inf, inf_len, output);//Encoder
for (i=0;i < output_len;i++)
{
printf("%d", output[i]);
}
system("pause");
}
