BLINK-DataStream开发

1、pom.xml

注意：
            com.alibaba.flink
            datahub-connector
            0.1-SNAPSHOT
            jar-with-dependencies


此依赖需要手动加载到maven仓库，具体方式参见：读取DataHub数据示例 - 实时计算Flink版 - 阿里云

也可以参考本人小记：

Blink-DataHub connector Maven依赖转化_大数据00的博客-CSDN博客

    4.0.0

    com.alibaba.blink
    blink-udx-3.x
    1.0-SNAPSHOT


        2.11.12
        2.11
        blink-3.3.0
        1.8
        1.8
        1.8




            com.alibaba.blink
            flink-core
            ${blink.version}
            provided



            com.alibaba.blink
            flink-streaming-java_${scala.binary.version}
            ${blink.version}
            provided



            com.alibaba.blink
            flink-table_2.11
            ${blink.version}
            provided



            junit
            junit
            4.12
            test


            org.scala-lang
            scala-library
            2.11.12
            provided








            com.aliyun.datahub
            aliyun-sdk-datahub
            2.12.2-public
            provided


                    org.slf4j
                    slf4j-api


                    org.slf4j
                    slf4j-log4j12


                    org.slf4j
                    jcl-over-slf4j


                    org.slf4j
                    jul-slf4j


                    log4j
                    log4j













            com.alibaba.flink
            datahub-connector
            0.1-SNAPSHOT
            jar-with-dependencies


            org.postgresql
            postgresql
            42.1.1





                org.apache.maven.plugins
                maven-assembly-plugin
                3.1.1



                            com.alibaba.blink.demo.stream_demo



                        jar-with-dependencies




                        make-assembly
                        package

                            single







2、开发入口类

package com.alibaba.blink.demo;

import com.alibaba.blink.mojo.Record;
import com.alibaba.blink.sink.HoloSink;
import com.alibaba.flink.connectors.datahub.datastream.source.DatahubSourceFunction;
import com.aliyun.datahub.client.model.RecordEntry;
import org.apache.flink.api.common.functions.FlatMapFunction;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.util.Collector;

import java.util.List;

public class stream_demo {

    private static String endPoint = "your endpoint";//内网访问。
    //private static String endPoint ="public endpoint";//公网访问（填写内网Endpoint，就不用填写公网Endpoint）。
    private static String projectName = "your projectName ";
    private static String topicSourceName = "your topicSourceName";
    private static String accessId = "your accessId ";
    private static String accessKey = "your accessKey";
    private static Long datahubStartInMs = 0L;//设置消费的启动位点对应的时间。
    private static Long datahubEndInMs=Long.MAX_VALUE;

    public static void main(String[] args) throws Exception {
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setParallelism(1);

        DataStreamSource> listDataStreamSource = env.addSource(
                new DatahubSourceFunction(endPoint,
                        projectName,
                        topicSourceName,
                        accessId,
                        accessKey,
                        datahubStartInMs,
                        datahubEndInMs,
                        20L,
                        1000L,
                        1000));

        SingleOutputStreamOperator result = listDataStreamSource
                .flatMap((FlatMapFunction, Record>) (ls, collector) -> {
                    for (RecordEntry recordEntry : ls) {
                        Record record = new Record(recordEntry);
                        collector.collect(record);
                    }
                }).returns(Record.class)
                .filter(s -> (s.getoneid() != null))
                .filter(s -> (s.getEvent() != null))
                ;

//        result.print();
//                .addSink((SinkFunction)new HoloSink())
//                .setParallelism(2);
        result.addSink(new HoloSink()).setParallelism(10);

        env.execute();

    }
}

3、开发自定义HoloSink

package com.alibaba.blink.sink;

import com.alibaba.blink.mojo.Record;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.streaming.api.functions.sink.RichSinkFunction;

import java.sql.Connection;
import java.sql.DriverManager;
import java.sql.PreparedStatement;
import java.sql.ResultSet;
import java.util.UUID;

public class HoloSink extends RichSinkFunction {
    private static String url="jdbc:postgresql://ip:port/database?tcpKeepAlive=true";
    private static String username = "username ";
    private static String password = "password ";
    private static String postgresdriver = "org.postgresql.Driver";
    private Connection connection;
    private ThreadLocal pstmt;
    private ThreadLocal querymt;
    private ThreadLocal updatemt;

    private Connection getConnection() {
        Connection conn = null;
        try {
            Class.forName(postgresdriver);
            conn = DriverManager.getConnection(url, username, password);
        } catch (Exception e) {
            e.printStackTrace();
        }
        return conn;
    }
    @Override
    public void open(Configuration parameters) throws Exception {
        super.open(parameters);
        this.connection = getConnection();
        this.pstmt = new ThreadLocal<>();
        this.querymt = new ThreadLocal<>();
        this.updatemt = new ThreadLocal<>();
    }

    @Override
    public void invoke(Record record, Context context) throws Exception {
        if ( null == record || record.getoneid() == null) {
            System.out.println("record is null!!!");
            return;
        }
        //哪个线程空着呢 用哪个线程
        if (this.querymt.get() == null)
            this.querymt.set(this.connection.prepareStatement("select oneid,event from holo_sink where oneid=?"));
        if (this.updatemt.get() == null)
            this.updatemt.set(this.connection.prepareStatement("update holo_sink set event=? where oneid=?"));
        if (this.pstmt.get() == null)
            this.pstmt.set(this.connection.prepareStatement("insert into holo_sink(oneid,event) values (?,?)"));

        ((PreparedStatement)this.querymt.get()).setString(1, record.getoneid());
        ResultSet resultSet = ((PreparedStatement)this.querymt.get()).executeQuery();
//        System.out.println(resultSet.getFetchSize());
        //如果oneid存在 即更新
        if ( resultSet.next() ) {
            ((PreparedStatement)this.updatemt.get()).setString(1, record.getEvent());
            ((PreparedStatement)this.updatemt.get()).setString(2, record.getoneid());
            ((PreparedStatement)this.updatemt.get()).executeUpdate();
            System.out.println("update " + record.toString() + ",threadId:" + Thread.currentThread().getId());
         // oneid不存在就插入 并赋值新的oneid
        }
        else {
            ((PreparedStatement)this.pstmt.get()).setString(1, UUID.randomUUID().toString());
            ((PreparedStatement)this.pstmt.get()).setString(2, record.getEvent());
            ((PreparedStatement)this.pstmt.get()).executeUpdate();
            System.out.println("insert " + record.toString() + ",threadId:" + Thread.currentThread().getId());
        }
    }

    @Override
    public void close() throws Exception {
        super.close();
        if (this.pstmt.get() != null)
            ((PreparedStatement)this.pstmt.get()).close();
        if (this.querymt.get() != null)
            ((PreparedStatement)this.querymt.get()).close();
        if (this.updatemt.get() != null)
            ((PreparedStatement)this.updatemt.get()).close();
        if (this.connection != null)
            this.connection.close();
    }
}

4、自定义mojo类

package com.alibaba.blink.mojo;

import com.aliyun.datahub.client.model.RecordEntry;
import com.aliyun.datahub.client.model.TupleRecordData;

public class Record {
    private String oneid;
    private String event;

    public Record(RecordEntry recordEntry) {
        this.oneid = getString(recordEntry, "oneid");
        this.event = getString(recordEntry, "event");

    }
    private String getString(RecordEntry recordEntry, String field) {
        Object o = ((TupleRecordData)recordEntry.getRecordData()).getField(field);
        if (o == null)
            return "null";
        return o.toString();
    }

    public String getoneid() {
        return oneid;
    }

    public void setoneid(String oneid) {
        this.oneid = oneid;
    }

    public String getEvent() {
        return event;
    }

    public void setEvent(String event) {
        this.event = event;
    }

    public Record(String oneid, String event) {
        this.oneid = oneid;
        this.event = event;
    }

    public Record() {
    }

    @Override
    public String toString() {
        return "Record{" +
                "oneid='" + oneid + ''' +
                ", event='" + event + ''' +
                '}';
    }
}

5、辅助类 DataHub Writer

package com.alibaba.blink.datahub;


import com.alibaba.blink.utils.producer_with_random;
import com.aliyun.datahub.client.DatahubClient;
import com.aliyun.datahub.client.DatahubClientBuilder;
import com.aliyun.datahub.client.auth.AliyunAccount;
import com.aliyun.datahub.client.common.DatahubConfig;
import com.aliyun.datahub.client.exception.DatahubClientException;
import com.aliyun.datahub.client.http.HttpConfig;
import com.aliyun.datahub.client.model.PutRecordsResult;
import com.aliyun.datahub.client.model.RecordEntry;
import com.aliyun.datahub.client.model.RecordSchema;
import com.aliyun.datahub.client.model.TupleRecordData;


import java.util.ArrayList;
import java.util.List;

public class datahubwriter {

    public static void main(String[] args) throws InterruptedException {
        // Endpoint以Region: 华东1为例，其他Region请按实际情况填写
        String endpoint = "endpoint ";
        String accessId = "accessId ";
        String accessKey = "accessKey ";
// 创建DataHubClient实例
        DatahubClient datahubClient = DatahubClientBuilder.newBuilder()
                .setDatahubConfig(
                        new DatahubConfig(endpoint,
                                // 是否开启二进制传输，服务端2.12版本开始支持
                                new AliyunAccount(accessId, accessKey), true))
                //专有云使用出错尝试将参数设置为           false
                // HttpConfig可不设置，不设置时采用默认值
                .setHttpConfig(new HttpConfig()
                        .setCompressType(HttpConfig.CompressType.LZ4) // 读写数据推荐打开网络传输 LZ4压缩
                        .setConnTimeout(10000))
                .build();
        String project = "projectName";
        String topic = "topic ";
        int retryTimes = 10;

        tupleExample(datahubClient,project,topic,retryTimes);

    }
    // 写入Tuple型数据
    public static void tupleExample(DatahubClient datahubClient,String project,String topic,int retryTimes) throws InterruptedException {
        // 获取schema
        RecordSchema recordSchema = datahubClient.getTopic(project,topic ).getRecordSchema();
        // 生成100条数据
        List recordEntries = new ArrayList<>();
        for (int i = 0; i < 100; ++i) {
            RecordEntry recordEntry = new RecordEntry();
            // 对每条数据设置额外属性，例如ip 机器名等。可以不设置额外属性，不影响数据写入
            recordEntry.addAttribute("key2", "value2");

            if(i%10==0) {
                Thread.sleep(1000);
            }
            String records = producer_with_random.get_records();
            String v = "" +Math.random() * 100 + 1+ System.currentTimeMillis() ;
            System.out.println(records +"=>"+ v);
            TupleRecordData data = new TupleRecordData(recordSchema);
            data.setField("oneid", records);
            data.setField("event", v);
            recordEntry.setRecordData(data);
            boolean add = recordEntries.add(recordEntry);
            if (add==true){
                System.out.println("数据生成成功！！！！");
            }
        }
        try {
            PutRecordsResult result = datahubClient.putRecords(project, topic, recordEntries);
            int i = result.getFailedRecordCount();
            if (i > 0) {
                retry(datahubClient, result.getFailedRecords(), retryTimes, project, topic);
            }
        }  catch (DatahubClientException e) {
            System.out.println("requestId:" + e.getRequestId() + "tmessage:" + e.getErrorMessage());
        }
    }
    //重试机制
    public static void retry(DatahubClient client, List records, int retryTimes, String project, String topic) {
        boolean suc = false;
        while (retryTimes != 0) {
            retryTimes = retryTimes - 1;
            PutRecordsResult recordsResult = client.putRecords(project, topic, records);
            if (recordsResult.getFailedRecordCount() > 0) {
                retry(client,recordsResult.getFailedRecords(),retryTimes,project,topic);
            }
            suc = true;
            break;
        }
        if (!suc) {
            System.out.println("retryFailure");
        }
    }
}

6、方法类

package com.alibaba.blink.utils;

import java.util.HashMap;
import java.util.Map;
import java.util.UUID;

public class producer_with_random {
    static Map map = new HashMap(){
        { put(1,"0000048e-fb42-4898-ad1c-4b2aca517165");
         put(2,"00000842-448e-415b-808a-1f3682c64b1b");
         put(3,"00000d2d-7c7b-46b7-bd99-2e224cd194f9");
         put(4,"0000110b-efb9-4d03-9438-f4e58dbd6f11");
         put(5,"00001245-aa6c-4ddc-94be-b99ee7b51deb");
         put(6,"00001406-c496-4bdf-9fbc-76bbbc053423");
         put(7,"00001755-c010-49ef-b063-313bf0833fc1");
         put(8,"00001a92-8c10-4a73-9480-13941e2483db");
         put(9,"00001b17-8fff-440f-b9eb-5c9a5477d533");
         put(10,"00001d09-66ad-4ad7-a042-c8bdc578676d");
         put(11,"00001d67-d753-43d9-a087-2556548ca7c3");
         put(12,"00001da8-0290-4bed-8872-8a014543e91d");
         put(13,"00001f8d-6aa6-4483-9c75-b4c98c2d05cb");
        put(14,"000022b8-623d-404b-9a56-4f9243adc32c");
        put(15,"000023f4-c9e5-43fd-aa33-56551d6aebee");
        put(16,"00002651-df13-4cb1-a107-93623e18734c");
        put(17,"000033a1-6a4f-4b95-ae5a-40b7f8616498");
        put(18,"00003d5f-6360-4344-94c1-d67bedbd1709");
        put(19,"00003dcc-5b4c-4519-af41-484704079680");
        put(20, String.valueOf(UUID.randomUUID()));

        }
    };


    public static String get_records(){
        int random = (int)(Math.random()*21+1);
        System.out.println(random);
        return (String) map.get(random);
    }

    public static void main(String[] args) {

        System.out.println(get_records());
    }
}

7、打包上传

8、创建DataStream任务

 9、任务详情

--完整主类名，必填，例如com.alibaba.realtimecompute.DatastreamExample
blink.main.class=com.alibaba.blink.demo.stream_demo

--包含完整主类名的JAR包资源名称，多个JAR包时必填，例如blink_datastream.jar
--blink.main.jar=${完整主类名jar包的资源名称}

--默认state backend配置，当作业代码没有显式声明时生效
state.backend.type=niagara
state.backend.niagara.ttl.ms=129600000

--默认Checkpoint配置，当作业代码没有显式声明时生效
blink.checkpoint.interval.ms=180000

--默认启用项目参数
--disable.project.config=false

--设置自定义参数，代码中获取自定义参数的方法请参考如下链接：
--https://help.aliyun.com/document_detail/127758.html?spm=a2c4g.11174283.6.677.61fb1e49NJoWTR

 其他可选择设置项

3.2及以上版本开启window miniBatch方法（3.2及以上版本默认不开启window miniBatch）。
sql.exec.mini-batch.window.enabled=true
-- excatly-once语义。
blink.checkpoint.mode=EXACTLY_onCE
-- checkpoint间隔时间，单位毫秒。
blink.checkpoint.interval.ms=180000
blink.checkpoint.timeout.ms=600000
-- 实时计算Flink版2.0及以上版本使用niagara作为statebackend，以及设定state数据生命周期，单位毫秒。
state.backend.type=niagara
state.backend.niagara.ttl.ms=129600000
-- 实时计算Flink版2.0及以上版本开启5秒的microbatch（窗口函数不需要设置该参数）。
blink.microBatch.allowLatencyMs=5000
-- 表示整个Job允许的延迟。
blink.miniBatch.allowLatencyMs=5000
-- 双流join节点优化参数。
blink.miniBatch.join.enabled=true
-- 单个Batch的size。
blink.miniBatch.size=20000
-- local优化，实时计算Flink版2.0及以上版本默认已经开启，1.6.4版本需要手动开启。
blink.localAgg.enabled=true
-- 实时计算Flink版2.0及以上版本开启partial优化，解决count distinct效率低问题。
blink.partialAgg.enabled=true
-- union all优化。
blink.forbid.unionall.as.breakpoint.in.subsection.optimization=true
-- GC优化（源表为SLS时，不能设置该参数）。
blink.job.option=-yD heartbeat.timeout=180000 -yD env.java.opts='-verbose:gc -XX:NewRatio=3 -XX:+PrintGCDetails -XX:+PrintGCDateStamps -XX:ParallelGCThreads=4'
-- 时区设置。
blink.job.timeZone=Asia/Shanghai

10、提交发布 启动

11、资源文件

alibaba-flink-connectors-flink-1.5.2-compatible.zip-flink文档类资源-CSDN下载

blink_udx_3x-master.zip-flink文档类资源-CSDN下载

datahub-demo-master.zip-flink文档类资源-CSDN下载
