spark conf 配置优化

spark conf 配置优化

一、背景

spark版本:2.3.1
scala版本:2.11.8

二、conf配置说明
选项说明组合
spark.sql.crossJoin.enabledtrue值为true时,sql进行迪卡尔积join运算1
spark.dynamicAllocation.enabledture值为true时,spark就会启动ExecutorAllocationManager,动态管理执行器;2
spark.shuffle.service.enabledture值为true时,spark动态管理shuffle服务,与 ExecutorAllocationManager配合使用2
spark.dynamicAllocation.initialExecutors数值初始化执行器数量2
spark.dynamicAllocation.maxExecutors数值最多执行器数量2
spark.dynamicAllocation.minExecutors数值最少执行器数量2
spark.default.parallelism数值task的并行度,num-executors * executor-cores的2~3倍较为合适;该参数比较重要3
spark.sql.adaptive.enabledtrue默认为false,自适应执行框架的开关4
spark.sql.adaptive.skewedJoin.enabledtrue默认为 false ,倾斜处理开关4
spark.driver.extraJavaOptions-Dlog4j.configuration=file:log4j.properties / -Xss30Mdriver 的jvm参数5
spark.hadoop.ipc.client.fallback-to-simple-auth-allowedtruehdfs跨集群数据迁移6
spark.shuffle.memoryFraction0.3该参数代表了Executor内存中,分配给shuffle read task进行聚合操作的内存比例,默认是20%7
spark.storage.memoryFraction0.5用于设置RDD持久化数据在Executor内存中能占的比例,默认是0.6,,默认Executor 60%的内存,可以用来保存持久化的RDD数据8
hive.metastore.client.factory.classcom.amazonaws.glue.catalog.metastore.AWSGlueDataCatalogHiveClientFactoryaws Glue 数据单元管理9
hive.exec.dynamici.partitiontruehive写操作,动态分区10
hive.exec.dynamic.partition.modenonstricthive写操作,动态分区10
spark.sql.sources.partitionOverwriteModedynamichive覆盖分区:动态分区10
三、conf设置方式 3.1、代码配置

scala 两种设置如下

import org.apache.spark.sql.SparkSession


val spark: SparkSession = SparkSession.builder()
  .config(
    "hive.metastore.client.factory.class",
    "com.amazonaws.glue.catalog.metastore.AWSGlueDataCatalogHiveClientFactory"
  ) // aws Glue 数据单元管理
  .enableHiveSupport()
  .config("hive.exec.dynamici.partition", true)
  .config("hive.exec.dynamic.partition.mode", "nonstrict")
  .getOrCreate()

spark.conf.set("spark.sql.sources.partitionOverwriteMode", "dynamic")

3.2、提交形式
spark-submit
--name conf_example
--master yarn
--deploy-mode cluster
--num-executors 1
--executor-cores 1
--executor-memory 1G
--driver-memory 1G
--class xxx.xxxx.xxxxx.xxx.xxxx
--files conf.properties,log4j.properties,log4j2.xml
--conf spark.hadoop.ipc.client.fallback-to-simple-auth-allowed=true
--conf spark.driver.extraJavaOptions=-Dlog4j.configuration=file:log4j.properties
--jars sss.jar,wwqq.jar
main.jar
3.3、submit
./bin/spark-submit

  //主类入口
  --class

  // 指定appname
  --name

  //pom依赖所需要的resource目录下的资源文件
  --files

  //需要的jar包
  --jar

  //运行内存
  --executor-memory 1G

  //运行内核数
  --num-executors 1

 //运行模式指定
  --master

  //指定client模式或者cluster模式,默认是client
  --deploy-mode

  //设置参数
  --conf =

  //jar包路径


  //main方法的参数
  [application-arguments]



# Run application locally on 8 cores
./bin/spark-submit
  --class org.apache.spark.examples.SparkPi
  --master local[8]
  /path/to/examples.jar
  100

# Run on a Spark standalone cluster in client deploy mode
./bin/spark-submit
  --class org.apache.spark.examples.SparkPi
  --master spark://207.184.161.138:7077
  --executor-memory 20G
  --total-executor-cores 100
  /path/to/examples.jar
  1000

# Run on a Spark standalone cluster in cluster deploy mode with supervise
./bin/spark-submit
  --class org.apache.spark.examples.SparkPi
  --master spark://207.184.161.138:7077
  --deploy-mode cluster
  --supervise
  --executor-memory 20G
  --total-executor-cores 100
  /path/to/examples.jar
  1000

# Run on a YARN cluster
export HADOOP_CONF_DIR=XXX
./bin/spark-submit
  --class org.apache.spark.examples.SparkPi
  --master yarn
  --deploy-mode cluster   # can be client for client mode
  --executor-memory 20G
  --num-executors 50
  /path/to/examples.jar
  1000
