saltstack zabbix部署状态文件编写

用saltstack搭建lamp架构

查看整体文件结构：

[root@master prod]# tree
.
├── modules
│   ├── application
│   │   └── php
│   │       ├── files
│   │       │   ├── init.d.php-fpm
│   │       │   ├── install.sh
│   │       │   ├── oniguruma-devel-6.8.2-2.el8.x86_64.rpm
│   │       │   ├── php-7.4.25.tar.gz
│   │       │   ├── php-fpm.conf.default
│   │       │   ├── php-fpm.service
│   │       │   ├── php.ini-production
│   │       │   └── www.conf.default
│   │       └── install.sls
│   ├── database
│   │   └── mysql
│   │       ├── files
│   │       │   ├── my.cnf
│   │       │   ├── mysql-5.7.35-linux-glibc2.12-x86_64.tar.gz
│   │       │   ├── mysqld.service
│   │       │   ├── mysqld.sh
│   │       │   └── mysql.server
│   │       └── install.sls
│   └── web
│       └── apache
│           ├── files
│           │   ├── apr-1.7.0.tar.gz
│           │   ├── apr-util-1.6.1.tar.gz
│           │   ├── httpd-2.4.48.tar.gz
│           │   ├── httpd.conf
│           │   ├── httpd.service
│           │   └── install.sh
│           └── install.sls
└── zabbix
    ├── apache.sls
    ├── files
    │   ├── index.php
    │   ├── my.cnf
    │   ├── mysql.conf
    │   └── vhosts.conf
    ├── main.sls
    └── mysql.sls

编写 apache

[root@master apache]# pwd
/srv/salt/prod/modules/web/apache
[root@master apache]# vim install.sls
[root@master modules]# cat install.sls
"Development Tools":
  pkg.group_installed

httpd-dep-pakcgae:
  pkg.installed:
    - pkgs:
      - openssl-devel
      - pcre-devel
      - expat-devel
      - libtool
      - gcc
      - gcc-c++
      - make

create-user-apache:
  user.present:
    - name: apache
    - createhome: false
    - system: true
    - shell: /sbin/nologin

copy-software-apache-pkg:
  file.managed:
    - names:
      - /usr/src/apr-1.7.0.tar.gz:
        - source: salt://modules/web/apache/files/apr-1.7.0.tar.gz
      - /usr/src/apr-util-1.6.1.tar.gz:
        - source: salt://modules/web/apache/files/apr-util-1.6.1.tar.gz
      - /usr/src/httpd-2.4.48.tar.gz:
        - source: salt://modules/web/apache/files/httpd-2.4.48.tar.gz

salt://modules/web/apache/files/install.sh:
  cmd.script

/usr/local/apache/conf/httpd.conf:
  file.managed:
    - source: salt://modules/web/apache/files/httpd.conf
    - user: root
    - group: root
    - mode: '0644'

/usr/lib/systemd/system/httpd.service:
  file.managed:
    - source: salt://modules/web/apache/files/httpd.service
    - user: root
    - group: root
    - mode: '0644'

[root@master zabbix]# pwd
/srv/salt/prod/zabbix
[root@master zabbix]# vim apache.sls
[root@master zabbix]# cat apache.sls
include:
  - modules.web.apache.install

/usr/include/httpd:
  file.symlink:
    - target: .usr/local/apache/include

/usr/local/apache/htdocs/zabbix:
  file.directory:
    - user: root
    - group: root
    - mode: '0755'
    - makedirs: true

/usr/local/apache/conf/extra/vhosts.conf:
  file.managed:
    - source: salt://zabbix/files/vhosts.conf
    - user: root
    - group: root
    - mode: '0644'

/usr/local/apache/htdocs/zabbix/index.php:
  file.managed:
    - source: salt://zabbix/files/index.php
    - user: root
    - group: root
    - mode: '0644'

httpd.service:
  service.running:
    - enable: true

编写 mysql

[root@master mysql]# vim install.sls
[root@master mysql]# cat install.sls
ncurses-compat-libs:
  pkg.installed

mysql:
  user.present:
    - system: true
    - createhome: false
    - shell: /sbin/nologin

/usr/local:
  archive.extracted:
    - source: salt://modules/database/mysql/files/mysql-5.7.35-linux-glibc2.12-x86_64.tar.gz
  file.symlink:
    - name: /usr/local/mysql
    - target: /usr/local/mysql-5.7.35-linux-glibc2.12-x86_64

/usr/local/mysql:
  file.directory:
    - user: mysql
    - group: mysql
    - mode: '0755'
    - recurse:
      - user
      - group

/opt/data:
  file.directory:
    - user: mysql
    - group: mysql
    - mode: '0755'
    - makedirs: true
    - recurse:
      - user
      - group

/etc/profile.d/mysqld.sh:
  file.managed:
    - source: salt://modules/database/mysql/files/mysqld.sh
    - user: root
    - group: root
    - mode: '0755'

/usr/local/mysql/support-files/mysql.server:
  file.managed:
    - source: salt://modules/database/mysql/files/mysql.server
    - user: mysql
    - group: mysql
    - mode: '0755'

/usr/lib/systemd/system/mysqld.service:
  file.managed:
    - source: salt://modules/database/mysql/files/mysqld.service
    - user: root
    - group: root
    - mode: '0644'

mysql-initialize:
  cmd.run:
    - name: '/usr/local/mysql/bin/mysqld --initialize-insecure --user=mysql --datadir=/opt/data/'
[root@master mysql]# vim install.sls
[root@master mysql]# cat install.sls
ncurses-compat-libs:
  pkg.installed

mysql:
  user.present:
    - system: true
    - createhome: false
    - shell: /sbin/nologin

/usr/local:
  archive.extracted:
    - source: salt://modules/database/mysql/files/mysql-5.7.35-linux-glibc2.12-x86_64.tar.gz
  file.symlink:
    - name: /usr/local/mysql
    - target: /usr/local/mysql-5.7.35-linux-glibc2.12-x86_64

/usr/local/mysql:
  file.directory:
    - user: mysql
    - group: mysql
    - mode: '0755'
    - recurse:
      - user
      - group

/opt/data:
  file.directory:
    - user: mysql
    - group: mysql
    - mode: '0755'
    - makedirs: true
    - recurse:
      - user
      - group

/etc/profile.d/mysqld.sh:
  file.managed:
    - source: salt://modules/database/mysql/files/mysqld.sh
    - user: root
    - group: root
    - mode: '0755'

/usr/local/mysql/support-files/mysql.server:
  file.managed:
    - source: salt://modules/database/mysql/files/mysql.server
    - user: mysql
    - group: mysql
    - mode: '0755'

/usr/lib/systemd/system/mysqld.service:
  file.managed:
    - source: salt://modules/database/mysql/files/mysqld.service
    - user: root
    - group: root
    - mode: '0644'

mysql-initialize:
  cmd.run:
    - name: '/usr/local/mysql/bin/mysqld --initialize-insecure --user=mysql --datadir=/opt/data/'

[root@master zabbix]# pwd
/srv/salt/prod/zabbix
[root@master zabbix]# vim mysql.sls
[root@master zabbix]# cat mysql.sls
include:
  - modules.database.mysql.install

lamp-dep-package:
  pkg.installed:
    - pkgs:
      - ncurses-devel
      - openssl-devel
      - openssl
      - cmake
      - mariadb-devel

/usr/local/include/mysql:
  file.symlink:
    - target: /usr/local/mysql/include

/etc/ld.so.conf.d/mysql.conf:
  file.managed:
    - source: salt://zabbix/files/mysql.conf
    - user: root
    - group: root
    - mode: '0644'

/etc/my.cnf:
  file.managed:
    - source: salt://zabbix/files/my.cnf
    - user: root
    - group: root
    - mode: '0644'

mysqld.service:
  service.running:
    - enable: true

set-password-mysql:
  cmd.run:
    - name: /usr/local/mysql/bin/mysql -e "set password = password('147258');"

编写 php

[root@master php]# pwd
/srv/salt/prod/modules/application/php
[root@master php]# vim install.sls
[root@master php]# cat install.sls
/tmp/oniguruma-devel-6.8.2-2.el8.x86_64.rpm:
  file.managed:
    - source: salt://modules/application/php/files/oniguruma-devel-6.8.2-2.el8.x86_64.rpm
    - user: root
    - group: root
    - mode: '0644'
  cmd.run:
    - name: yum -y install /tmp/oniguruma-devel-6.8.2-2.el8.x86_64.rpm

php-dep-package:
  pkg.installed:
    - pkgs:
      - libzip
      - libzip-devel
      - libxml2
      - libxml2-devel
      - libsqlite3x-devel
      - openssl
      - openssl-devel
      - bzip2
      - bzip2-devel
      - libcurl
      - libcurl-devel
      - libicu-devel
      - libjpeg-turbo
      - libjpeg-turbo-devel
      - libpng
      - libpng-devel
      - openldap-devel
      - pcre-devel
      - freetype
      - freetype-devel
      - gmp
      - gmp-devel
      - libmcrypt
      - libmcrypt-devel
      - readline
      - readline-devel
      - libxslt
      - libxslt-devel
      - mhash
      - mhash-devel
      - php-mysqlnd

/usr/src:
  archive.extracted:
    - source: salt://modules/application/php/files/php-7.4.25.tar.gz

salt://modules/application/php/files/install.sh:
  cmd.script

copy-file-php:
  file.managed:
    - names:
      - /usr/local/php7/etc/php-fpm.conf:
        - source: salt://modules/application/php/files/php-fpm.conf.default
      - /usr/local/php7/etc/php-fpm.d/www.conf:
        - source: salt://modules/application/php/files/www.conf.default
      - /etc/php.ini:
        - source: salt://modules/application/php/files/php.ini-production
      - /etc/init.d/php-fpm:
        - source: salt://modules/application/php/files/init.d.php-fpm
        - user: root
        - group: root
        - mode: '0755'
      - /usr/lib/systemd/system/php-fpm.service:
        - source: salt://modules/application/php/files/php-fpm.service

php-fpm.service:
  service.running:
    - enable: true

编写总执行文件：

[root@master zabbix]# pwd
/srv/salt/prod/zabbix
[root@master zabbix]# vim main.sls
[root@master zabbix]# cat main.sls
include:
  - zabbix.apache
  - zabbix.mysql
  - modules.application.php.install

最后执行：

[root@master zabbix]# salt 'node1' state.sls zabbix.main saltenv=prod

//node1上查看端口
[root@node1 ~]# ss -anlt
State     Recv-Q    Send-Q         Local Address:Port         Peer Address:Port
LISTEN    0         128                127.0.0.1:9000              0.0.0.0:*
LISTEN    0         128                  0.0.0.0:22                0.0.0.0:*
LISTEN    0         80                         *:3306                    *:*
LISTEN    0         128                        *:80                      *:*
LISTEN    0         128                     [::]:22                   [::]:*

编写zabbix项目配置

[root@master ~]# tree /srv/salt/prod/zabbix/
/srv/salt/prod/zabbix/
├── apache.sls
├── files
│   ├── index.php
│   ├── my.cnf
│   ├── mysql.conf
│   └── vhosts.conf
├── main.sls
└── mysql.sls

1 directory, 7 files

[root@master ~]# cat /srv/salt/prod/zabbix/apache.sls
include:
  - modules.web.httpd.install

/usr/include/httpd:
  file.symlink:
    - target: /usr/local/apache/include

/usr/local/apache/htdocs/zabbix:
  file.directory:
    - user: root
    - group: root
    - mode: '0755'
    - makedirs: true

/usr/local/apache/conf/extra/vhosts.conf:
  file.managed:
    - source: salt://zabbix/files/vhosts.conf
    - user: root
    - group: root
    - mode: '0664'
    - require:
      - cmd: httpd-install

/usr/local/apache/htdocs/zabbix/index.php:
  file.managed:
    - source: salt://zabbix/files/index.php
    - user: root
    - group: root
    - mode: '0664'

httpd.service:
  service.running:
    - enable: true
    - reload: true
    - require:
      - cmd: httpd-install
      - file: /usr/lib/systemd/system/httpd.service
    - watch:
      - file: /usr/local/apache/conf/httpd.conf
      - file: /usr/local/apache/conf/extra/vhosts.conf
[root@master ~]# cat /srv/salt/prod/zabbix/mysql.sls
include:
  - modules.database.mysql.install

lamp-dep-package:
  pkg.installed:
    - pkgs:
      - ncurses-devel
      - openssl-devel
      - openssl
      - cmake
      - mariadb-devel
      - glibc
      - glibc-gconv-extra
      - libgcc
      - libstdc++

/usr/local/include/mysql:
  file.symlink:
    - target: /usr/local/mysql/include

/etc/ld.so.conf.d/mysql.conf:
  file.managed:
    - source: salt://zabbix/files/mysql.conf
    - user: root
    - group: root
    - mode: '0644'

/etc/my.cnf:
  file.managed:
    - source: salt://zabbix/files/my.cnf
    - user: root
    - group: root
    - mode: '0644'
    - watch_in:
      - service: mysqld.service

mysqld.service:
  service.running:
    - enable: true
    - reload: true
    - require:
      - archive: /usr/local
      - file: /usr/lib/systemd/system/mysqld.service
      - file: /etc/my.cnf

set-password-mysql:
  cmd.run:
    - name: /usr/local/mysql/bin/mysql -e "set password = password('1');"
    - require:
      - service: mysqld.service
    - unless: /usr/local/mysql/bin/mysql -uroot -p1 -e 'exit'
[root@master ~]# cat /srv/salt/prod/zabbix/files/index.php

[root@master ~]# cat /srv/salt/prod/zabbix/files/my.cnf
[mysqld]
basedir = /usr/local/mysql
datadir = /opt/data
socket = /tmp/mysql.sock
port = 3306
pid-file = /opt/data/mysql.pid
user = mysql
skip-name-resolve
[root@master ~]# cat /srv/salt/prod/zabbix/files/mysql.conf
/usr/local/mysql/lib
[root@master ~]# cat /srv/salt/prod/zabbix/files/vhosts.conf

    documentRoot "/usr/local/apache/htdocs/zabbix"
    ServerName zabbix.example.com
    ProxyRequests Off
    ProxyPassMatch ^/(.*.php)$ fcgi://127.0.0.1:9000/usr/local/apache/htdocs/zabbix/$1

        Options none
        AllowOverride none
        Require all granted


[root@master ~]# cat /srv/salt/prod/zabbix/main.sls
include:
  - zabbix.apache
  - zabbix.mysql
  - modules.application.php.install

## 执行状态文件，部署lamp

[root@master prod]# salt ‘minion’ state.sls zabbix.main saltenv=prod

## minion上查看服务

[root@minion ~]# ss -antl
State Recv-Q Send-Q Local Address:Port Peer Address:Port Process
LISTEN 0 128 0.0.0.0:22 0.0.0.0:*
LISTEN 0 128 0.0.0.0:9000 0.0.0.0:*
LISTEN 0 80 *:3306 :
LISTEN 0 128 :80 :
LISTEN 0 128 [::]:22 [::]:

## 网页测试
![在这里插入图片描述](https://img-blog.csdnimg.cn/f3dc85c6649c4f9083b7189637aa7305.png?x-oss-process=image/watermark,type_ZHJvaWRzYW5zZmFsbGJhY2s,shadow_50,text_Q1NETiBAa29yZXlvc2hpaWlpaQ==,size_20,color_FFFFFF,t_70,g_se,x_16)

saltstack zabbix部署状态文件编写

Linux相关栏目本月热门文章
