前言

1. MyBatis-Plus 是一个 Mybatis 增强版工具，在 MyBatis 上扩充了其他功能没有改变其基本功能，为了简化开发提交效率而存在。

2. MyBatis-Plus 的代码生成器可以生成 Entity、Mapper、Mapper XML、Service、Controller 模块代码。

3.MyBatis-Plus 的代码生成器基于Spring boot帮助代码生成(Spring boot在这里我就不做过多介绍了)

---

一、导入相应的代码生成器依赖

    org.apache.velocity
    velocity
    1.7

提示:MyBatis-Plus 从 3.0.3 之后移除了代码生成器与模板引擎的默认依赖，需要手动添加相关依赖，才能实现代码生成器功能。

---

二、使用步骤

1.在Spring boot test/java中添加

CodeGenerator类

import com.baomidou.mybatisplus.annotation.FieldFill;
import com.baomidou.mybatisplus.annotation.IdType;
import com.baomidou.mybatisplus.core.toolkit.StringPool;
import com.baomidou.mybatisplus.generator.AutoGenerator;
import com.baomidou.mybatisplus.generator.InjectionConfig;
import com.baomidou.mybatisplus.generator.config.*;
import com.baomidou.mybatisplus.generator.config.po.TableFill;
import com.baomidou.mybatisplus.generator.config.po.TableInfo;
import com.baomidou.mybatisplus.generator.config.rules.DateType;
import com.baomidou.mybatisplus.generator.config.rules.NamingStrategy;
import lombok.Data;
import lombok.experimental.Accessors;
import org.apache.commons.lang3.StringUtils;

import java.util.ArrayList;
import java.util.HashMap;
import java.util.List;
import java.util.Map;


@Data
@Accessors(chain = true)
public class CodeGenerator {


    private String userName;

    private String password;

    private String driverName;

    private String driverUrl;


    private String projectPackagePath;


    private String parentPackage;


    private String packageController = "controller";

    // ############################ 自定义配置部分 start ############################

    private String moduleName;


    private String projectName ="";

    private String author;

    private String tableName;

    private String pkIdColumnName = "id";

    private GeneratorStrategy generatorStrategy = GeneratorStrategy.ALL;



    public enum GeneratorStrategy {
        SIMPLE, NORMAL, ALL
    }


    private boolean pageListOrder = false;

    private boolean paramValidation = true;


    private boolean generatorEntity;

    private boolean generatorController;

    private boolean generatorService;

    private boolean generatorServiceImpl;

    private boolean generatorMapper;

    private boolean generatorMapperXml;

    private boolean generatiorEvent;

    private boolean generatorListHtml;

    private boolean generatorEditHtml;

    private boolean generatorActivitiTable;

    private boolean generatorQueryParam;

    private boolean generatorQueryVo;

    private boolean requiresPermissions;
    // ############################ 自定义配置部分 end ############################


    private String commonParentPackage;

    private String mybatisParentPackage;


    private String superEntity;

    private String superController;

    private String superService;

    private String superServiceImpl;

    private String superQueryParam;

    private String[] superEntityCommonColumns;

    // 公共类包路径

    private String commonIdParam;

    private String commonApiResult;

    private String commonOrderEnum;

    private String commonOrderQueryParam;

    private String commonPaging;


    private boolean fileOverride;

    // 自定义需要填充的字段
    private  List tableFillList = new ArrayList<>();

    private String[] path;



    public void init() {
        this.commonParentPackage = this.parentPackage + ".common";
        this.mybatisParentPackage =this.parentPackage + ".mybatis";
        // 父类包路径
        this.superEntity = this.commonParentPackage + ".entity.baseEntity";
        this.superController = this.commonParentPackage + ".controller.baseController";
        this.superService = this.mybatisParentPackage + ".service.baseService";
        this.superServiceImpl = this.mybatisParentPackage + ".service.impl.baseServiceImpl";
        this.superQueryParam = this.mybatisParentPackage + ".param.QueryParam";
        this.superEntityCommonColumns = new String[]{};

        // 公共类包路径
        this.commonIdParam = this.commonParentPackage + ".param.IdParam";
        this.commonApiResult = this.commonParentPackage + ".api.ApiResult";
        this.commonOrderEnum = this.commonParentPackage + ".enums.OrderEnum";
        this.commonOrderQueryParam = this.mybatisParentPackage + ".param.OrderQueryParam";
        this.commonPaging = this.mybatisParentPackage+".vo.Paging";


        tableFillList.add(new TableFill("update_time",FieldFill.UPDATE));
        tableFillList.add(new TableFill("update_by",FieldFill.UPDATE));
        tableFillList.add(new TableFill("create_time",FieldFill.INSERT));
        tableFillList.add(new TableFill("create_by",FieldFill.INSERT));
    }


    public void generator() {
        // 代码生成器
        AutoGenerator mpg = new AutoGenerator();

        // 全局配置
        GlobalConfig gc = new GlobalConfig();
        String projectPath = System.getProperty("user.dir");
        gc.setOutputDir(projectPath + "/"+projectName+"/src/main/java");
        gc.setAuthor(author);
        gc.setOpen(false);                  // 是否打开输出目录
        gc.setSwagger2(true);               // 启用swagger注解
        gc.setIdType(IdType.ID_WORKER);     // 主键类型:ID_WORKER
        gc.setServiceName("%sService");     // 自定义文件命名，注意 %s 会自动填充表实体属性！
        gc.setFileOverride(fileOverride);   // 是否覆盖已有文件
        gc.setDateType(DateType.ONLY_DATE); // 设置日期类型为Date
        mpg.setGlobalConfig(gc);

        // 数据源配置
        DataSourceConfig dsc = new DataSourceConfig();
        dsc.setUrl(driverUrl);
        // dsc.setSchemaName("public");
        dsc.setDriverName(driverName);
        dsc.setUsername(userName);
        dsc.setPassword(password);
        // 设置自定义查询
        dsc.setDbQuery(new com.sinosoft.springbootplus.mybatis.generator.config.SpringBootPlusMySqlQuery());

        mpg.setDataSource(dsc);

        // 包配置
        PackageConfig pc = new PackageConfig();
        pc.setModuleName(moduleName);
        pc.setParent(parentPackage);
        pc.setController(packageController);
        pc.setService("application.service");
        pc.setServiceImpl("application.service.impl");
        pc.setMapper("domain.mapper");
        pc.setEntity("domain.entity");

        mpg.setPackageInfo(pc);

        // 自定义配置
        InjectionConfig cfg = new InjectionConfig() {
            @Override
            public void initMap() {

                String camelTableName = underlineToCamel(tableName);
                String pascalTableName = underlineToPascal(tableName);
                String colonTableName = underlineTocolon(tableName);

                Map map = new HashMap<>();
                map.put("customField", "Hello " + this.getConfig().getGlobalConfig().getAuthor());
                // 查询参数包路径
                String queryParamPackage = parentPackage + StringPool.DOT + pc.getModuleName() + ".param";
                map.put("queryParamPackage", queryParamPackage);
                // 查询参数类路径
                map.put("queryParamPath", queryParamPackage + StringPool.DOT + pascalTableName + "QueryParam");
                // 查询参数共公包路径
                map.put("queryParamCommonPath", superQueryParam);
                // 查询参数共公包路径
                map.put("idParamPath", commonIdParam);
                // 响应结果包路径
                String queryVoPackage = parentPackage + StringPool.DOT + pc.getModuleName() + ".vo";
                map.put("queryVoPackage", queryVoPackage);
                // 响应结果类路径
                map.put("queryVoPath", queryVoPackage + StringPool.DOT + pascalTableName + "QueryVo");
                // 实体对象名称
                map.put("entityObjectName", camelTableName);
                // service对象名称
                map.put("serviceObjectName", camelTableName + "Service");
                // mapper对象名称
                map.put("mapperObjectName", camelTableName + "Mapper");
                // 主键ID列名
                map.put("pkIdColumnName", pkIdColumnName);
                // 主键ID驼峰名称
                map.put("pkIdCamelName", underlineToCamel(pkIdColumnName));
                // 导入分页类
                map.put("paging", commonPaging);
                // 导入排序枚举
                map.put("orderEnum", commonOrderEnum);
                // ApiResult
                map.put("apiResult", commonApiResult);
                // 分页列表查询是否排序
                map.put("pageListOrder", pageListOrder);
                // 导入排序查询参数类
                map.put("orderQueryParamPath", commonOrderQueryParam);
                // 代码生成策略
                map.put("generatorStrategy", generatorStrategy);
                // 代码Validation校验
                map.put("paramValidation", paramValidation);
                // 冒号连接的表名称
                map.put("colonTableName", colonTableName);
                // 是否生成Shiro RequiresPermissions注解
                map.put("requiresPermissions", requiresPermissions);
                //================页面生成部分（开始）========
                if(generatorListHtml || generatorEditHtml){
                    map.put("baseLayFilter",StringUtils.join(path,"-")+"-"+camelTableName+"List");
                    map.put("baseEditPath",StringUtils.join(path,"/")+"/"+camelTableName+"Edit");
                }
                map.put("publishPackage","com.sinosoft.springbootplus."+moduleName+".application.event.publish");
                map.put("pubisherClass",pascalTableName+"Pubisher");
                map.put("subscriptionPackage","com.sinosoft.springbootplus."+moduleName+".application.event.subscription");
                map.put("subscriptionClass",pascalTableName+"Subscription");
                map.put("domainPackage","com.sinosoft.springbootplus."+moduleName+".domain.service");
                map.put("domainClass",pascalTableName+"Domain");
                map.put("domainClassName",camelTableName+"Domain");
                //================页面生成部分（结束）========
                this.setMap(map);
            }
        };
        List focList = new ArrayList<>();

        // 生成mapper xml
        if (generatorMapperXml) {
            focList.add(new FileOutConfig("/templates/mapper.xml.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    // 自定义输入文件名称
                    return projectPath + "/"+projectName+"/src/main/resources/mapper/" + pc.getModuleName()
                            + "/" + tableInfo.getEntityName() + "Mapper" + StringPool.DOT_XML;
                }
            });
        }

        // 自定义queryParam模板
        if (generatorQueryParam) {
            focList.add(new FileOutConfig("/templates/queryParam.java.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    return projectPath +"/"+projectName+ "/src/main/java/" + projectPackagePath + "/" + pc.getModuleName() + "/param/" + tableInfo.getEntityName() + "QueryParam" + StringPool.DOT_JAVA;
                }
            });
        }

        // 自定义queryVo模板
        if (generatorQueryVo) {
            focList.add(new FileOutConfig("/templates/queryVo.java.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    return projectPath + "/"+projectName+"/src/main/java/" + projectPackagePath + "/" + pc.getModuleName() + "/vo/" + tableInfo.getEntityName() + "QueryVo" + StringPool.DOT_JAVA;
                }
            });
        }
        if(generatiorEvent){
            focList.add(new FileOutConfig("/templates/pubisher.java.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    return projectPath + "/"+projectName+"/src/main/java/" + projectPackagePath + "/" + pc.getModuleName() + "/application/event/publish/" + tableInfo.getEntityName() + "Pubisher" + StringPool.DOT_JAVA;
                }
            });
            focList.add(new FileOutConfig("/templates/subscription.java.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    return projectPath + "/"+projectName+"/src/main/java/" + projectPackagePath + "/" + pc.getModuleName() + "/application/event/subscription/"+ tableInfo.getEntityName() + "Subscription" + StringPool.DOT_JAVA;
                }
            });
            focList.add(new FileOutConfig("/templates/domain.java.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    return projectPath + "/"+projectName+"/src/main/java/" + projectPackagePath + "/" + pc.getModuleName() + "/domain/service/" + tableInfo.getEntityName() + "Domain" + StringPool.DOT_JAVA;
                }
            });
        }
        // 自定义generatorListHtml模板
        if (generatorListHtml) {
            focList.add(new FileOutConfig("/templates/list.html.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    String camelTableName = underlineToCamel(tableInfo.getName());
                    return projectPath + "/"+projectName+"/src/main/webapp/src/views/" + StringUtils.join(path,"/") + "/" +camelTableName + "List.html";
                }
            });
        }
        // 自定义generatorListHtml模板
        if (generatorEditHtml) {
            focList.add(new FileOutConfig("/templates/edit.html.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    String camelTableName = underlineToCamel(tableInfo.getName());
                    return projectPath + "/"+projectName+"/src/main/webapp/src/views/" + StringUtils.join(path,"/") + "/" +camelTableName + "Edit.html";
                }
            });
        }
        if(generatorActivitiTable){
            focList.add(new FileOutConfig("/templates/activitiList.html.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    String camelTableName = underlineToCamel(tableInfo.getName());
                    return projectPath + "/"+projectName+"/src/main/webapp/src/views/" + StringUtils.join(path,"/") + "/" +camelTableName + "List.html";
                }
            });
            focList.add(new FileOutConfig("/templates/activitiList.js.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    String camelTableName = underlineToCamel(tableInfo.getName());
                    return projectPath + "/"+projectName+"/src/main/webapp/src/views/" + StringUtils.join(path,"/") + "/" +camelTableName + ".js";
                }
            });
            focList.add(new FileOutConfig("/templates/edit.html.vm") {
                @Override
                public String outputFile(TableInfo tableInfo) {
                    String camelTableName = underlineToCamel(tableInfo.getName());
                    return projectPath + "/"+projectName+"/src/main/webapp/src/views/" + StringUtils.join(path,"/") + "/" +camelTableName + "Edit.html";
                }
            });
        }
        cfg.setFileOutConfigList(focList);
        mpg.setCfg(cfg);

        // 模版生成配置，设置为空，表示不生成
        TemplateConfig templateConfig = new TemplateConfig();
        // xml使用自定义输出
        templateConfig.setXml(null);
        // 是否生成entity
        if (!generatorEntity) {
            templateConfig.setEntity(null);
        }
        // 是否生成controller
        if (!generatorController) {
            templateConfig.setController(null);
        }
        // 是否生成service
        if (!generatorService) {
            templateConfig.setService(null);
        }
        // 是否生成serviceImpl
        if (!generatorServiceImpl) {
            templateConfig.setServiceImpl(null);
        }
        // 是否生成mapper
        if (!generatorMapper) {
            templateConfig.setMapper(null);
        }
        mpg.setTemplate(templateConfig);

        // 策略配置
        StrategyConfig strategy = new StrategyConfig();
        strategy.setNaming(NamingStrategy.underline_to_camel);
        strategy.setColumnNaming(NamingStrategy.underline_to_camel);
        strategy.setSuperEntityClass(superEntity);
        strategy.setEntityLombokModel(true);
        strategy.setRestControllerStyle(true);
        strategy.setSuperControllerClass(superController);
        strategy.setSuperServiceClass(superService);
        strategy.setSuperServiceImplClass(superServiceImpl);
        strategy.setInclude(tableName);
        strategy.setSuperEntityColumns(superEntityCommonColumns);
        strategy.setControllerMappingHyphenStyle(true);

        //逻辑删除字段名称
        strategy.setLogicDeleteFieldName("deleted");
        //乐观锁
        strategy.setVersionFieldName("version");

        strategy.setTableFillList(tableFillList);


        //strategy.setTablePrefix(pc.getModuleName() + "_");
        mpg.setStrategy(strategy);
        mpg.execute();
    }


    public static String underlineToCamel(String underline) {
        if (StringUtils.isNotBlank(underline)) {
            return NamingStrategy.underlineToCamel(underline);
        }
        return null;
    }


    public static String underlineToPascal(String underline) {
        if (StringUtils.isNotBlank(underline)) {
            return NamingStrategy.capitalFirst(NamingStrategy.underlineToCamel(underline));
        }
        return null;
    }


    public static String underlineTocolon(String underline) {
        if (StringUtils.isNotBlank(underline)) {
            String string = underline.toLowerCase();
            return string.replaceAll("_", ":");
        }
        return null;
    }

    public static void main(String[] args) {
        System.out.println(underlineTocolon("sys_user"));
    }
}

---

SpringBootPlusGenerator类

public class SpringBootPlusGenerator {

        public static void main(String[] args) {
        CodeGenerator codeGenerator = new CodeGenerator();
        // 公共配置
        // 数据库配置
        codeGenerator
                .setUserName("root")
                .setPassword("123456")
                .setDriverName("com.mysql.cj.jdbc.Driver")
                .setDriverUrl("jdbc:mysql://localhost:3306/spring_boot_plus?useUnicode=true&characterEncoding=UTF-8&useSSL=false&serverTimezone=UTC");

        // 包信息
        codeGenerator
                .setProjectPackagePath("com/sinosoft/springbootplus")
                .setParentPackage("com.sinosoft.springbootplus");

        // 组件作者等配置
        codeGenerator
                .setProjectName("smartcampus")
                .setModuleName("system")
                .setAuthor("lh")
                .setPkIdColumnName("id");

        // 生成策略
        codeGenerator
                .setGeneratorStrategy(CodeGenerator.GeneratorStrategy.ALL)
                .setPageListOrder(true)
                .setParamValidation(true);

        // 生成实体映射相关代码,可用于数据库字段更新
        // 当数据库字段更新时，可自定义自动生成哪些那文件
        codeGenerator
                .setGeneratorEntity(true)
                .setGeneratorQueryParam(true)
                .setGeneratorQueryVo(true);

        // 生成业务相关代码
        codeGenerator
                .setGeneratorController(true)
                .setGeneratorService(true)
                .setGeneratorServiceImpl(true)
                .setGeneratorMapper(true)
                .setGeneratorMapperXml(true)
                .setGeneratorEditHtml(false)
                .setGeneratorListHtml(false);

        // 是否生成Shiro RequiresPermissions注解
        codeGenerator.setRequiresPermissions(true);

        // 是否覆盖已有文件
        codeGenerator.setFileOverride(true);

        // 初始化公共变量
        codeGenerator.init();

        // 需要生成的表数组
        // xxx,yyy,zzz为需要生成代码的表名称
        String[] tables = {
                "sys_file_manager"
        };
        //如果生成html则设置html目录，aa/bb/cc =》["aa","bb","cc"]
        codeGenerator.setPath(new String[]{"user","test"});
        // 循环生成
        for (String table : tables) {
            // 设置需要生成的表名称
            codeGenerator.setTableName(table);
            // 生成代码
            codeGenerator.generator();
        }

    }

---

还需要相应的工具磨板



提示:代码生成器是基于java代码进行生成的,填入相关信息运行SpringBootPlusGenerator类中的main方法代码就可以自动生成了

2.生成示例





 提示:1.生成的包 controller domain( entity mapper) param  vo xml

          2.在生成的包中必须有对应的类,如果包里有类说明你生成成功了,反之则没有成功.

---

---

总结

1.代码生成器在实际开发中有强大之处,节省了我们

2.代码生成器虽然好但是也有一些弊端,要适情况而使用,避免一些不必要的麻烦
