映射状态（MapState
- MapState.get(UK key)
- MapState.put(UK key, UV value)
- MapState.contains(UK key)
- MapState.remove(UK key)
在实际开发环境中，使用MapState的情况最多，下面我们将MapState结合 Window进行使用
①：KeyedState必须作用在RichFunction下
②：在RichFunction中 Open()方法，定义状态描述器（指明状态存储类型等）
③：状态变量定义
④：状态使用
（二）MapState验证我们前边讲过：
Keyed State基于KeyedStream（数据流使用keyBy()算子）基础上才可使用。
Keyed State由数据流中定义的每个具体的键(key) 来维护和访问，每个key维护一个状态实例，flink会将具有相同键的数据分区到同一个算子任务中，这个任务会维护和处理这个key对应的状态（会自动将状态的访问范围限定为当前数据的key，一个key只能访问它自己的状态，不同key之间也不能互相访问） 当任务处理一条数据时，它会自动将状态的访问范围限定为当前数据的key
键控状态Keyed State 数据结构：由于每个键属于 keyed operator 的一个并行实例，可将其简单地视为
上方，项目中设置并行度为4，那么job将会开启4个SpeedAlarmWindow窗口
窗口中的MapState使用姿势：
其中呢，window-apply-sink将会组成算子链，每一个算子链由一个具体的线程执行 （具体请查看：Flink窗口核心概念-有KEY窗口和无KEY窗口）
我们上边，再次强调flink会将具有相同键的数据分区到同一个算子任务中，
因此，如果程序逻辑正常
假如Key=1 被并行度1线程拿到，那么以后Key=1的数据将会一直被分配到并行度1线程执行；
假如Key=2 也被并行度1线程拿到，那么以后Key=2的数据也将会一直被分配到并行度1线程执行；
假如Key=3 被并行度4线程拿到，那么以后Key=3的数据将会一直被分配到并行度4线程执行
我们这里使用print来模拟flink的sink操作
从上图执行结果来看…
当前窗口打开了四个
线程号2处理了Key=12的数据，且对上一条定位进行了存储，从超速开始>>>超速持续中
Key=12具体的数据：
完全符合我们的预期！如此简洁的State操作，可以让我们从繁杂的状态管理中解放出来，更加侧重关注与我们的业务逻辑
（三）完整DEMOpackage com.leilei;
import cn.hutool.core.util.RandomUtil;
import com.alibaba.fastjson.JSON;
import org.apache.flink.api.common.RuntimeExecutionMode;
import org.apache.flink.api.common.state.MapState;
import org.apache.flink.api.common.state.MapStateDescriptor;
import org.apache.flink.api.common.typeinfo.TypeInformation;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.streaming.api.datastream.DataStream;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.datastream.WindowedStream;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.functions.sink.RichSinkFunction;
import org.apache.flink.streaming.api.functions.sink.SinkFunction;
import org.apache.flink.streaming.api.functions.source.SourceFunction;
import org.apache.flink.streaming.api.functions.windowing.RichWindowFunction;
import org.apache.flink.streaming.api.functions.windowing.WindowFunction;
import org.apache.flink.streaming.api.windowing.windows.GlobalWindow;
import org.apache.flink.util.Collector;
import java.sql.Connection;
import java.sql.DriverManager;
import java.sql.PreparedStatement;
import java.time.LocalDate;
import java.time.format.DateTimeFormatter;
import java.util.Iterator;
import java.util.Random;
import java.util.UUID;
public class Flink_State_2_MapState {
public static void main(String[] args) throws Exception {
final StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
env.setRuntimeMode(RuntimeExecutionMode.STREAMING);
env.setParallelism(4);
final DataStreamSource locationSource = env.addSource(new LocationSource());
final WindowedStream windowedStream = locationSource
.keyBy(Location::getVehicleId)
.countWindow(1);
DataStream result = windowedStream.apply(new SpeedAlarmWindow());
result.print();
//result.addSink(new MysqlSink());
env.execute("mapState-window");
}
public static class SpeedAlarmWindow extends RichWindowFunction {
MapState locationState;
String uuid;
@Override
public void apply(Integer integer, GlobalWindow window, Iterable locationList, Collector out) throws Exception {
for (Location location : locationList) {
final String key = location.getVehicleId().toString();
final Location preLocation = locationState.get(key);
if (preLocation == null) {
if (location.getGpsSpeed() > location.getLimitSpeed()) {
locationState.put(key, location);
out.collect(location.toString() + ">>超速开始");
break;
}
} else {
if (location.getGpsSpeed() > location.getLimitSpeed()) {
locationState.put(key, location);
out.collect(location.toString() + ">>持续超速中" + "n" +
"上一条超速数据为：" + "n" + preLocation.toString());
} else {
locationState.remove(key);
out.collect(location.toString() + ">>超速结束" + "n"+" 结束前定位:" + "n" + preLocation.toString());
}
}
}
}
@Override
public void open(Configuration parameters) throws Exception {
uuid = UUID.randomUUID().toString();
System.out.println(uuid + "窗口打开了");
super.open(parameters);
locationState = getRuntimeContext().getMapState(new MapStateDescriptor<>("locationState",
TypeInformation.of(String.class),
TypeInformation.of(Location.class)));
}
@Override
public void close() throws Exception {
super.close();
System.out.println(uuid + "窗口关闭了");
}
}
public static class LocationSource implements SourceFunction {
Boolean flag = true;
@Override
public void run(SourceContext ctx) throws Exception {
Random random = new Random();
while (flag) {
int vehicleId = random.nextInt(20) + 1;
Location location = Location.builder()
.vehicleId(vehicleId)
.plate("川A000" + vehicleId)
.color("绿")
.date(Integer.parseInt(LocalDate.now().format(DateTimeFormatter.BASIC_ISO_DATE)))
.gpsSpeed(RandomUtil.randomInt(88, 100))
.limitSpeed(RandomUtil.randomInt(88, 95))
.devTime(System.currentTimeMillis())
.build();
ctx.collect(location);
Thread.sleep(2000);
}
}
@Override
public void cancel() {
flag = false;
}
}
public static class MysqlSink extends RichSinkFunction {
Connection conn = null;
PreparedStatement ps = null;
String url = "jdbc:mysql://xx:3306/learn?useUnicode=true&characterEncoding=utf-8&useSSL=false";
String username = "root";
String password = "xx";
@Override
public void open(Configuration parameters) throws Exception {
conn = DriverManager.getConnection(url, username, password);
conn.setAutoCommit(false);
}
@Override
public void close() throws Exception {
if (conn != null) {
conn.close();
}
if (ps != null) {
ps.close();
}
}
@Override
public void invoke(String str, SinkFunction.Context context) throws Exception {
String sql = "insert into demo (`test_save_point`) " +
"values(?)";
ps = conn.prepareStatement(sql);
ps.setString(1, str);
ps.execute();
conn.commit();
}
}
}
