前面的文章已经把Mediapipe的环境配置好了,已经可以编译成apk文件了
接下来我们介绍下如何供android使用的aar文件
在编译aar之前我先介绍下mediapipe提供了哪些可以编译的aar工程
上面的这个截图对应的目录是rootfshometianmediapipemediapipeexamplesandroidsrcjavacomgooglemediapipeapps
basic:基础工程,下面的其他工程对它有依赖
具体什么含义,可以自己英文查询下
我用编译facedetectiongpu为例子
1、在rootfshometianmediapipemediapipeexamplesandroidsrcjavacomgooglemediapipeapps
下创建aar_example文件
然后在aar_example,这里面新建文件BUILD.txt,然后把txt去掉,把下面内容复制进去
load("//mediapipe/java/com/google/mediapipe:mediapipe_aar.bzl", "mediapipe_aar")
mediapipe_aar(
name = "mp_face_detection_aar",
calculators = ["//mediapipe/graphs/face_detection:mobile_calculators"],
) |
注意:
load("//mediapipe/java/com/google/mediapipe:mediapipe_aar.bzl", "mediapipe_aar")
是固定的,这个是编译aar的固定编译配置
name:这个是随意的,就是你编译完成后aar的名称
calculators :这个是具体编译aar用到的具体的graphs图资源,路径在/mediapipe/graphs/下面
需要什么,就配置什么,
我们打开看下face_detection中的BUILD看下
# Copyright 2019 The MediaPipe Authors.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR ConDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
licenses(["notice"])
package(default_visibility = ["//visibility:public"])
cc_library(
name = "mobile_calculators",
deps = [
"//mediapipe/calculators/core:flow_limiter_calculator",
"//mediapipe/calculators/util:annotation_overlay_calculator",
"//mediapipe/calculators/util:detections_to_render_data_calculator",
"//mediapipe/gpu:gpu_buffer_to_image_frame_calculator",
"//mediapipe/gpu:image_frame_to_gpu_buffer_calculator",
"//mediapipe/modules/face_detection:face_detection_front_cpu",
"//mediapipe/modules/face_detection:face_detection_front_gpu",
],
)
cc_library(
name = "desktop_live_calculators",
deps = [
"//mediapipe/calculators/core:flow_limiter_calculator",
"//mediapipe/calculators/util:annotation_overlay_calculator",
"//mediapipe/calculators/util:detections_to_render_data_calculator",
"//mediapipe/modules/face_detection:face_detection_front_cpu",
],
)
cc_library(
name = "desktop_live_gpu_calculators",
deps = [
"//mediapipe/calculators/core:flow_limiter_calculator",
"//mediapipe/calculators/util:annotation_overlay_calculator",
"//mediapipe/calculators/util:detections_to_render_data_calculator",
"//mediapipe/modules/face_detection:face_detection_front_gpu",
],
)
load(
"//mediapipe/framework/tool:mediapipe_graph.bzl",
"mediapipe_binary_graph",
)
mediapipe_binary_graph(
name = "face_detection_mobile_cpu_binary_graph",
graph = "face_detection_mobile_cpu.pbtxt",
output_name = "face_detection_mobile_cpu.binarypb",
deps = [":mobile_calculators"],
)
mediapipe_binary_graph(
name = "face_detection_mobile_gpu_binary_graph",
graph = "face_detection_mobile_gpu.pbtxt",
output_name = "face_detection_mobile_gpu.binarypb",
deps = [":mobile_calculators"],
)
|
看到这个我们怎么选择具体的什么name?
这个在官方文档上没有写,我是直接看官方的app里的build是怎么写看下
apps/facedetectiongpu/BUILD
# Copyright 2019 The MediaPipe Authors.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR ConDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
licenses(["notice"])
package(default_visibility = ["//visibility:private"])
cc_binary(
name = "libmediapipe_jni.so",
linkshared = 1,
linkstatic = 1,
deps = [
"//mediapipe/graphs/face_detection:mobile_calculators",
"//mediapipe/java/com/google/mediapipe/framework/jni:mediapipe_framework_jni",
],
)
cc_library(
name = "mediapipe_jni_lib",
srcs = [":libmediapipe_jni.so"],
alwayslink = 1,
)
android_binary(
name = "facedetectiongpu",
srcs = glob(["*.java"]),
assets = [
"//mediapipe/graphs/face_detection:face_detection_mobile_gpu.binarypb",
"//mediapipe/modules/face_detection:face_detection_front.tflite",
],
assets_dir = "",
manifest = "//mediapipe/examples/android/src/java/com/google/mediapipe/apps/basic:AndroidManifest.xml",
manifest_values = {
"applicationId": "com.google.mediapipe.apps.facedetectiongpu",
"appName": "Face Detection",
"mainActivity": "com.google.mediapipe.apps.basic.MainActivity",
"cameraFacingFront": "True",
"binaryGraphName": "face_detection_mobile_gpu.binarypb",
"inputVideoStreamName": "input_video",
"outputVideoStreamName": "output_video",
"flipframesVertically": "True",
"converterNumBuffers": "2",
},
multidex = "native",
deps = [
":mediapipe_jni_lib",
"//mediapipe/examples/android/src/java/com/google/mediapipe/apps/basic:basic_lib",
],
)
|
cc_binary( name = "libmediapipe_jni.so", linkshared = 1, linkstatic = 1, deps = [ "//mediapipe/graphs/face_detection:mobile_calculators", "//mediapipe/java/com/google/mediapipe/framework/jni:mediapipe_framework_jni", ], ) |
有上面那个mobile_calculators,这个是就要编译的具体的图配置,
接下来我们开始执行cmd命令
//给aar_example赋读写权限
1、sudo chmod -R 755 /mediapipe/examples/android/src/java/com/google/mediapipe/apps/aar_example //后面就是具体的aar_example 目录了,根据自己情况下
//下面这个指令就是编译aar文件了,会等很久,估计20分钟-40分钟,根据自己电脑配置决定
2、bazel build -c opt --fat_apk_cpu=arm64-v8a,armeabi-v7a //mediapipe/examples/android/src/java/com/google/mediapipe/apps/aar_example:mp_face_detection_aar
这个中间可能会出现很多的TimeOut的错误,因为编译过程会下载很多国外的资源,所以很慢或者超时了,这个就自己看有没有梯子或者切换个网络试试,我也是弄了很久,才好的
编译过程漫长,耐心等待,遇到问题仔细分析,一般都会编译成功
如果看到这个就代表成功了
去什么地方找这个aar呢,我之前用官方的方式没有找到
cp bazel-bin/mediapipe/examples/android/src/java/com/google/mediapipe/apps/aar_example/mp_face_detection_aar.aar /absolute/path/to/your/preferred/location 这个是官方介绍的,但是bazel-bin/mediapipe/examples/android/src/java/com/google/mediapipe/apps/aar_example/mp_face_detection_aar.aar 这个目录根本没有,执行这个命令会包,找不到文件的错误
最好我发现在这里
C:UsersMr.tianAppDataLocalPackagesCanonicalGroupLimited.Ubuntu18.04onWindows_79rhkp1fndgscLocalStaterootfshometian.cachebazel_bazel_tian7fe30ee7bfd1145e7a3fb5f9113d3a01execrootmediapipebazel-outk8-optbinmediapipeexamplesandroidsrcjavacomgooglemediapipeapps
这个根据自己的目录在找,或者直接在rootfshometian搜索你要的aar文件
祝你好运~
