HIVE自定义UDF函数-经纬度转换成省市地址

目录

1.需求背景

2.解决方案

3.代码pom引用

4.代码集成UDF

5.编译jar包

6.使用说明

7.将jar包放到hdfs

 8.创建持久化function

9.测试

 10.结语

用户行为埋点数据中存在经度、维度，需要通过hive分析数据所在地址信息。

2.解决方案

通过HIVE的自定义UDF函数，自己实现经纬度转换成地址信息集成百度接口查询。

3.代码pom引用

    4.0.0

    com.dd.xinwen.hive.udf
    dd-hiveudf
    1.0-SNAPSHOT

    dd-hiveudf


            cloudera
            https://repository.cloudera.com/artifactory/cloudera-repos/





        UTF-8
        1.8
        1.8
        2.3.3
        1.2.28

    jar



            org.apache.hive
            hive-exec
            ${hive.version}


            junit
            junit
            4.11
            test


            com.alibaba
            fastjson
            ${fastjson.version}






                org.apache.maven.plugins
                maven-compiler-plugin
                3.0

                    1.8
                    1.8
                    UTF-8



                org.apache.maven.plugins
                maven-shade-plugin
                2.2


                        package

                            shade




                                    *:*

                                        meta-INFRSA










4.代码集成UDF

package com.dd.xinwen.hive.udf;

import com.alibaba.fastjson.JSON;
import com.alibaba.fastjson.JSONArray;
import com.alibaba.fastjson.JSONObject;
import org.apache.hadoop.hive.ql.exec.UDF;
import org.apache.hadoop.io.Text;

import java.io.BufferedReader;
import java.io.InputStream;
import java.io.InputStreamReader;
import java.io.OutputStream;
import java.net.HttpURLConnection;
import java.net.URL;
import java.net.URLEncoder;

public class MapBaiduAddressUDF extends UDF {
    public Text evaluate (String lat, String lng){
        String s="";
        if (null==lat || null==lng){
            return null;
        }
        try {
            s=getLocationByBaiduMap(lng, lat);
        } catch (Exception e) {
            e.printStackTrace();
        }
        return new Text(s);
    }

    public static void main(String[] args) {
        String lat="31.931";
        String lng="120.961";
        Text evaluate = new MapBaiduAddressUDF().evaluate(lat,lng);

        System.out.println(evaluate.toString());
    }


    public static String getLocationByBaiduMap(String longitude,String latitude) throws Exception {
        String ak = "你的百度地图AK，申请一个吧";

        String locJson = geturl("http://api.map.baidu.com/geoconv/v1/?coords=" + longitude + "," +latitude + "&from=1&to=5&ak=" + ak);
        System.out.println(locJson);

        JSonObject jobject =  JSON.parseObject(locJson);
        JSonArray jsonArray = jobject.getJSonArray("result");
        String lat=jsonArray.getJSonObject(0).getString("y");
        String lng=jsonArray.getJSonObject(0).getString("x");
        //System.out.println(lat);

        String addrJson = geturl("http://api.map.baidu.com/reverse_geocoding/v3/?ak="+ ak +"&location=" + lat + "," + lng + "&output=json&pois=1");
        System.out.println(addrJson);

        JSonObject jobjectaddr =  JSON.parseObject(addrJson);
        JSonObject rJsonObject = jobjectaddr.getJSonObject("result");
        System.out.println(rJsonObject.getJSonObject("addressComponent").getString("city"));
System.out.println(rJsonObject.getJSonObject("addressComponent").getString("province"));

        String addr=jobjectaddr.getJSonObject("result").getString("formatted_address");
        return addr;
    }

    private static String geturl(String geturl) throws Exception {
        //请求的webservice的url
        URL url = new URL(geturl);
        //创建http链接,得到connection对象
        HttpURLConnection httpURLConnection = (HttpURLConnection) url.openConnection();
        //设置请求的方法类型
        httpURLConnection.setRequestMethod("POST");
        //设置请求的内容类型
        httpURLConnection.setRequestProperty("Content-type", "application/x-www-form-urlencoded");
        //设置发送数据
        httpURLConnection.setDoOutput(true);
        //设置接受数据
        httpURLConnection.setDoInput(true);
        //发送数据,使用输出流
        OutputStream outputStream = httpURLConnection.getOutputStream();
        //发送的soap协议的数据
        String content = "user_id="+ URLEncoder.encode("用户Id", "utf-8");
        //发送数据
        outputStream.write(content.getBytes());
        //接收数据
        InputStream inputStream = httpURLConnection.getInputStream();
        BufferedReader in = new BufferedReader(new InputStreamReader(inputStream, "UTF-8"));
        StringBuffer buffer = new StringBuffer();
        String line = "";
        while ((line = in.readLine()) != null){
            buffer.append(line);
        }
        String str = buffer.toString();
        return str;
    }
}

仿照实现另外2个java类即可MapBaiduCityUDF，MapBaiduProvinceUDF。

5.编译jar包

dd-hiveudf-1.0-SNAPSHOT.jar

大约85.5MB

6.使用说明

我们需要创建持久函数（Permanent Functions），并且使用hdfs上的jar。

生产环境建议此种方式，便于管理和使用。

7.将jar包放到hdfs

比较放到warehouse/dd/auxlib/dd-hiveudf-1.0-SNAPSHOT.jar

 8.创建持久化function

在hive中执行

create function gotBaiduAddr as 'com.dd.xinwen.hive.udf.MapBaiduAddressUDF' USING JAR 'hdfs://xxx:4007/warehouse/dd/auxlib/dd-hiveudf-1.0-SNAPSHOT.jar';
create function gotBaiduCity as 'com.dd.xinwen.hive.udf.MapBaiduCityUDF' USING JAR 'hdfs://xxx:4007/warehouse/dd/auxlib/dd-hiveudf-1.0-SNAPSHOT.jar';
create function gotBaiduProvince as 'com.dd.xinwen.hive.udf.MapBaiduProvinceUDF' USING JAR 'hdfs://xxx:4007/warehouse/dd/auxlib/dd-hiveudf-1.0-SNAPSHOT.jar';



9.测试

在hive中执行

select gotbaiduaddr('31.931','120.961');
select gotbaiducity('31.931','120.961');
select gotbaiduprovince('31.931','120.961');

 10.结语

创建临时函数（Temporary Functions）

官方参考：https://cwiki.apache.org/confluence/display/Hive/LanguageManual+DDL#LanguageManualDDL-CreateFunction

    缺点：Temporary Functions只对当前 session(窗口)有效

    示例：在Hive的Shell中执行

    ADD JAR /home/hadoop/lib/g6-hadoop-udf.jar;

    CREATE TEMPORARY FUNCTION sayHello AS 'com.ruozedata.hadoop.udf.HelloUDF';

11.遇到的问题

问题1：hive创建永久函数失败

参考CSDN贴主教程打jar包即可

hive创建永久函数失败，Failed to register youmeng.finderrorcount using class com.jinghang.hive.MyCoustom_lkm0522的博客-CSDN博客
