如何通过.NET访问ARP协议信息?

面试问答 更新时间: 发布时间: IT归档 最新发布 模块sitemap 名妆网 法律咨询 聚返吧 英语巴士网 伯小乐 网商动力

如何通过.NET访问ARP协议信息?

如果您知道那里有哪些设备,则可以使用Ping类。这样至少可以填充ARP表。您始终可以执行ARP
-a并根据需要解析输出。这也是一个链接,该链接显示了如何点选以调用GetIpNetTable。我在下面提供了Ping类的示例,以及如何使用GetIpNetTable访问ARP表的示例。

这是Ping类的一个示例

using System;using System.Net;using System.Net.NetworkInformation;using System.Text;namespace Examples.System.Net.NetworkInformation.PingTest{    public class PingExample    {        // args[0] can be an IPaddress or host name.        public static void Main (string[] args)        { Ping pingSender = new Ping (); PingOptions options = new PingOptions (); // Use the default Ttl value which is 128, // but change the fragmentation behavior. options.DontFragment = true; // Create a buffer of 32 bytes of data to be transmitted. string data = "aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa"; byte[] buffer = Encoding.ASCII.GetBytes (data); int timeout = 120; PingReply reply = pingSender.Send (args[0], timeout, buffer, options); if (reply.Status == IPStatus.Success) {     Console.WriteLine ("Address: {0}", reply.Address.ToString ());     Console.WriteLine ("RoundTrip time: {0}", reply.RoundtripTime);     Console.WriteLine ("Time to live: {0}", reply.Options.Ttl);     Console.WriteLine ("Don't fragment: {0}", reply.Options.DontFragment);     Console.WriteLine ("Buffer size: {0}", reply.Buffer.Length); }        }    }}

这是GetIpNetTable的示例。

using System;using System.Runtime.InteropServices;using System.ComponentModel; using System.Net;namespace GetIpNetTable{   class Program   {      // The max number of physical addresses.      const int MAXLEN_PHYSADDR = 8;      // Define the MIB_IPNETROW structure.      [StructLayout(LayoutKind.Sequential)]      struct MIB_IPNETROW      {         [MarshalAs(UnmanagedType.U4)]         public int dwIndex;         [MarshalAs(UnmanagedType.U4)]         public int dwPhysAddrLen;         [MarshalAs(UnmanagedType.U1)]         public byte mac0;         [MarshalAs(UnmanagedType.U1)]         public byte mac1;         [MarshalAs(UnmanagedType.U1)]         public byte mac2;         [MarshalAs(UnmanagedType.U1)]         public byte mac3;         [MarshalAs(UnmanagedType.U1)]         public byte mac4;         [MarshalAs(UnmanagedType.U1)]         public byte mac5;         [MarshalAs(UnmanagedType.U1)]         public byte mac6;         [MarshalAs(UnmanagedType.U1)]         public byte mac7;         [MarshalAs(UnmanagedType.U4)]         public int dwAddr;         [MarshalAs(UnmanagedType.U4)]         public int dwType;      }      // Declare the GetIpNetTable function.      [Dllimport("IpHlpApi.dll")]      [return: MarshalAs(UnmanagedType.U4)]      static extern int GetIpNetTable(         IntPtr pIpNetTable,         [MarshalAs(UnmanagedType.U4)]         ref int pdwSize,         bool bOrder);      [Dllimport("IpHlpApi.dll", SetLastError = true, CharSet = CharSet.Auto)]      internal static extern int FreeMibTable(IntPtr plpNetTable);      // The insufficient buffer error.      const int ERROR_INSUFFICIENT_BUFFER = 122;      static void Main(string[] args)      {         // The number of bytes needed.         int bytesNeeded = 0;         // The result from the API call.         int result = GetIpNetTable(IntPtr.Zero, ref bytesNeeded, false);         // Call the function, expecting an insufficient buffer.         if (result != ERROR_INSUFFICIENT_BUFFER)         { // Throw an exception. throw new Win32Exception(result);         }         // Allocate the memory, do it in a try/finally block, to ensure         // that it is released.         IntPtr buffer = IntPtr.Zero;         // Try/finally.         try         { // Allocate the memory. buffer = Marshal.AllocCoTaskMem(bytesNeeded); // Make the call again. If it did not succeed, then // raise an error. result = GetIpNetTable(buffer, ref bytesNeeded, false); // If the result is not 0 (no error), then throw an exception. if (result != 0) {    // Throw an exception.    throw new Win32Exception(result); } // Now we have the buffer, we have to marshal it. We can read // the first 4 bytes to get the length of the buffer. int entries = Marshal.ReadInt32(buffer); // Increment the memory pointer by the size of the int. IntPtr currentBuffer = new IntPtr(buffer.ToInt64() +    Marshal.SizeOf(typeof(int))); // Allocate an array of entries. MIB_IPNETROW[] table = new MIB_IPNETROW[entries]; // Cycle through the entries. for (int index = 0; index < entries; index++) {    // Call PtrToStructure, getting the structure information.    table[index] = (MIB_IPNETROW) Marshal.PtrToStructure(new       IntPtr(currentBuffer.ToInt64() + (index *       Marshal.SizeOf(typeof(MIB_IPNETROW)))), typeof(MIB_IPNETROW)); } for (int index = 0; index < entries; index++) {    MIB_IPNETROW row = table[index];    IPAddress ip=new IPAddress(BitConverter.GetBytes(row.dwAddr));    Console.Write("IP:"+ip.ToString()+"ttMAC:");    Console.Write( row.mac0.ToString("X2") + '-');    Console.Write( row.mac1.ToString("X2") + '-');    Console.Write( row.mac2.ToString("X2") + '-');    Console.Write( row.mac3.ToString("X2") + '-');    Console.Write( row.mac4.ToString("X2") + '-');    Console.WriteLine( row.mac5.ToString("X2")); }         }         finally         { // Release the memory. FreeMibTable(buffer);         }      }   }}
