docker-compose安装elk

docker pull elasticsearch:7.6.2
docker pull kibana:7.6.2
docker pull logstash:7.6.2

• 需要设置系统内核参数，否则会因为内存不足无法启动

# 改变设置
sysctl -w vm.max_map_count=262144
# 使之立即生效
sysctl -p

• 需要创建/mydata/elasticsearch/data目录并设置权限，否则会因为无权限访问而启动失败

# 创建目录
mkdir /mydata/elasticsearch/data/
# 创建并改变该目录权限
chmod 777 /mydata/elasticsearch/data

创建Logstash的配置文件logstash.conf中output节点下的Elasticsearch连接地址为es:9200。

input {
  tcp {
    mode => "server"
    host => "0.0.0.0"
    port => 4560
    codec => json_lines
    type => "debug"
  }
  tcp {
    mode => "server"
    host => "0.0.0.0"
    port => 4561
    codec => json_lines
    type => "error"
  }
  tcp {
    mode => "server"
    host => "0.0.0.0"
    port => 4562
    codec => json_lines
    type => "business"
  }
  tcp {
    mode => "server"
    host => "0.0.0.0"
    port => 4563
    codec => json_lines
    type => "record"
  }
}
filter{
  if [type] == "record" {
    mutate {
      remove_field => "port"
      remove_field => "host"
      remove_field => "@version"
    }
    json {
      source => "message"
      remove_field => ["message"]
    }
  }
}
output {
  elasticsearch {
    hosts => "es:9200"
    index => "mall-%{type}-%{+YYYY.MM.dd}"
  }
}

创建/mydata/logstash目录，并将Logstash的配置文件logstash.conf拷贝到该目录。

mkdir /mydata/logstash

文件上传的linux服务器上，执行docker-compose up

version: '3'
services:
  elasticsearch:
    image: elasticsearch:7.6.2
    container_name: elasticsearch
    environment:
      - "cluster.name=elasticsearch" #设置集群名称为elasticsearch
      - "discovery.type=single-node" #以单一节点模式启动
      - "ES_JAVA_OPTS=-Xms512m -Xmx512m" #设置使用jvm内存大小
    volumes:
      - /mydata/elasticsearch/plugins:/usr/share/elasticsearch/plugins #插件文件挂载
      - /mydata/elasticsearch/data:/usr/share/elasticsearch/data #数据文件挂载
    ports:
      - 9200:9200
      - 9300:9300
  logstash:
    image: logstash:7.6.2
    container_name: logstash
    environment:
      - TZ=Asia/Shanghai
    volumes:
      - /mydata/logstash/logstash.conf:/usr/share/logstash/pipeline/logstash.conf #挂载logstash的配置文件
    depends_on:
      - elasticsearch #kibana在elasticsearch启动之后再启动
    links:
      - elasticsearch:es #可以用es这个域名访问elasticsearch服务
    ports:
      - 4560:4560
      - 4561:4561
      - 4562:4562
      - 4563:4563
  kibana:
    image: kibana:7.6.2
    container_name: kibana
    links:
      - elasticsearch:es #可以用es这个域名访问elasticsearch服务
    depends_on:
      - elasticsearch #kibana在elasticsearch启动之后再启动
    environment:
      - "elasticsearch.hosts=http://es:9200" #设置访问elasticsearch的地址
    ports:
      - 5601:5601

指定yml文件名执行命令：

docker-compose -f docker-compose-env.yml up -d
