先展示集成效果:flowable有驳回功能，单单就这点我感觉就比activiti强。
这里我只列出与flowable有关的引用，我用的是6.5.0的版本
2、设置配置类4.0.0 org.jeecgframework.boot d-twins-parent 3.0.0 d-twins-workflow org.flowable flowable-spring-boot-starter 6.5.0 org.flowable flowable-ui-modeler-rest 6.5.0 org.springframework.boot spring-boot-starter-log4j2 org.flowable flowable-ui-modeler-conf 6.5.0 org.flowable flowable-rest 6.5.0 org.flowable flowable-ui-task-conf 6.5.0 org.flowable flowable-ui-admin-conf 6.5.0 org.flowable flowable-ui-idm-conf 6.5.0
package org.jeecg.workflow.core.configuartion;
import java.util.ArrayList;
import java.util.HashMap;
import java.util.List;
import java.util.Map;
import javax.sql.DataSource;
import org.flowable.common.engine.api.delegate.event.FlowableEngineEventType;
import org.flowable.common.engine.api.delegate.event.FlowableEventListener;
import org.flowable.rest.service.api.RestResponseFactory;
import org.flowable.spring.SpringProcessEngineConfiguration;
import org.flowable.spring.boot.EngineConfigurationConfigurer;
import org.flowable.spring.boot.FlowableSecurityAutoConfiguration;
import org.flowable.ui.common.service.exception.InternalServerErrorException;
import org.flowable.ui.common.service.idm.RemoteIdmService;
import org.flowable.ui.modeler.properties.FlowableModelerAppProperties;
import org.flowable.ui.modeler.rest.app.EditorGroupsResource;
import org.flowable.ui.modeler.rest.app.EditorUsersResource;
import org.flowable.ui.modeler.rest.app.ModelResource;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.boot.autoconfigure.condition.ConditionalOnMissingBean;
import org.springframework.boot.context.properties.EnableConfigurationProperties;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.ComponentScan;
import org.springframework.context.annotation.Configuration;
import org.springframework.context.annotation.FilterType;
import com.fasterxml.jackson.databind.ObjectMapper;
import liquibase.Liquibase;
import liquibase.database.Database;
import liquibase.database.DatabaseConnection;
import liquibase.database.DatabaseFactory;
import liquibase.database.jvm.JdbcConnection;
import liquibase.exception.DatabaseException;
import liquibase.resource.ClassLoaderResourceAccessor;
import lombok.extern.slf4j.Slf4j;
@Configuration
@EnableConfigurationProperties({ FlowableModelerAppProperties.class })
@ComponentScan(basePackages = { "org.flowable.ui.modeler.repository", "org.flowable.ui.modeler.service",
"org.flowable.ui.common.service", "org.flowable.ui.common.repository", "org.flowable.ui.common.tenant",
"org.flowable.ui.modeler.rest.app", "org.flowable.rest.service.api",
"org.flowable.ui.task.service.debugger" }, excludeFilters = {
@ComponentScan.Filter(type = FilterType.ASSIGNABLE_TYPE, value = RemoteIdmService.class),
@ComponentScan.Filter(type = FilterType.ASSIGNABLE_TYPE, value = ModelResource.class),
@ComponentScan.Filter(type = FilterType.ASSIGNABLE_TYPE, value = EditorUsersResource.class),
@ComponentScan.Filter(type = FilterType.ASSIGNABLE_TYPE, value = EditorGroupsResource.class),
@ComponentScan.Filter(type = FilterType.ASSIGNABLE_TYPE, value = FlowableSecurityAutoConfiguration.class) })
@Slf4j
public class FlowableConfiguration implements EngineConfigurationConfigurer {
@Value("${spring.datasource.dynamic.datasource.master.url}")
private String jdbcUrl;
@Value("${spring.datasource.dynamic.datasource.master.driver-class-name}")
private String jdbcDriverClassName;
@Value("${spring.datasource.dynamic.datasource.master.username}")
private String username;
@Value("${spring.datasource.dynamic.datasource.master.password}")
private String password;
@Override
public void configure(SpringProcessEngineConfiguration engineConfiguration) {
engineConfiguration.setJdbcUrl(jdbcUrl);
engineConfiguration.setJdbcDriver(jdbcDriverClassName);
engineConfiguration.setJdbcUsername(username);
engineConfiguration.setJdbcPassword(password);
}
@Autowired
protected ObjectMapper objectMapper;
@ConditionalOnMissingBean
@Bean
public RestResponseFactory restResponseFactory() {
return new RestResponseFactory(objectMapper);
}
@Bean
public Liquibase liquibase(DataSource dataSource) {
log.info("Configuring Liquibase");
Liquibase liquibase = null;
try {
DatabaseConnection connection = new JdbcConnection(dataSource.getConnection());
Database database = DatabaseFactory.getInstance().findCorrectDatabaseImplementation(connection);
database.setDatabaseChangeLogTableName("ACT_DE_" + database.getDatabaseChangeLogTableName());
database.setDatabaseChangeLogLockTableName("ACT_DE_" + database.getDatabaseChangeLogLockTableName());
liquibase = new Liquibase("meta-INF/liquibase/flowable-modeler-app-db-changelog.xml",
new ClassLoaderResourceAccessor(), database);
liquibase.update("flowable");
return liquibase;
} catch (Exception e) {
throw new InternalServerErrorException("Error creating liquibase database", e);
} finally {
closeDatabase(liquibase);
}
}
private void closeDatabase(Liquibase liquibase) {
if (liquibase != null) {
Database database = liquibase.getDatabase();
if (database != null) {
try {
database.close();
} catch (DatabaseException e) {
log.warn("Error closing database", e);
}
}
}
}
}
flowable配置还是很自由的, 实现接口EngineConfigurationConfigurer，可以注入数据库连接参数。
3、FlowbleSecurityConfiguration 放开springsecurity限制。package org.jeecg.workflow.core.configuartion;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.config.annotation.web.configuration.EnableWebSecurity;
import org.springframework.security.config.annotation.web.configuration.WebSecurityConfigurerAdapter;
import org.springframework.security.web.firewall.DefaultHttpFirewall;
import org.springframework.security.web.firewall.HttpFirewall;
@Configuration
@EnableWebSecurity
public class FlowbleSecurityConfiguration extends WebSecurityConfigurerAdapter {
@Override
protected void configure(HttpSecurity http) throws Exception {
http.csrf().disable().authorizeRequests().antMatchers("xml/*Mapper.xml, classpath:/meta-INF/modeler-mybatis-mappings/*.xml
configuration-properties:
blobType: BLOB
boolValue: true
prefix: ''
最后表应该有83张
前端待写。。
