账单管理项目，需要开发基于 resutful 的 webservice，搭建 Eureka Server，并把把账单服务注册到 Eureka Server

工具：IDEA

技术栈：

spring cloud；
- Eureka Server;
- ribbon;
- gateway;
- config;
- bus
mybatis;

其他工具使用：postman

步骤：

创建父工程

微服务中需要同时创建多个项目，先创建一个父工程，后续的工程都以这个工程为父，使用 Maven的聚合和继承。统一管理子工程的版本和配置。

[外链图片转存失败,源站可能有防盗链机制,建议将图片保存下来直接上传(img-L0sMk6qX-1634736764643)(C:UsershellnAppDataRoamingTyporatypora-user-imagesimage-20211020202352905.png)]



    4.0.0

    com.zym
    zym-springcloud
    pom
    1.0-SNAPSHOT

        eurekasever
        user-service
        consumer-demo
        zym-gateway
        config-server



        org.springframework.boot
        spring-boot-starter-parent
        2.1.5.RELEASE



        1.8
        Greenwich.SR1
        2.1.5
        5.1.46






                org.springframework.cloud
                spring-cloud-dependencies
                ${spring-cloud.version}
                pom
                import



                tk.mybatis
                mapper-spring-boot-starter
                ${mapper.starter.version}



                mysql
                mysql-connector-java
                ${mysql.version}





            org.projectlombok
            lombok





                org.springframework.boot
                spring-boot-maven-plugin

新建一个项目，对外提供查询用户的服务首先创建moudle:

[外链图片转存失败,源站可能有防盗链机制,建议将图片保存下来直接上传(img-iUamzhwa-1634736764648)(C:UsershellnAppDataRoamingTyporatypora-user-imagesimage-20211020202609317.png)]

pom.xml文件：




        zym-springcloud
        com.zym
        1.0-SNAPSHOT

    4.0.0

    user-service



            org.springframework.boot
            spring-boot-starter-web



            tk.mybatis
            mapper-spring-boot-starter



            mysql
            mysql-connector-java



            org.springframework.cloud
            spring-cloud-starter-netflix-eureka-client


            org.springframework.cloud
            spring-cloud-starter-netflix-hystrix


            org.springframework.cloud
            spring-cloud-starter-openfeign


            org.springframework.cloud
            spring-cloud-starter-config


            org.springframework.cloud
            spring-cloud-bus


            org.springframework.cloud
            spring-cloud-stream-binder-rabbit


            org.springframework.boot
            spring-boot-starter-actuator



            com.github.pagehelper
            pagehelper-spring-boot-starter
            1.2.3

项目结构：

[外链图片转存失败,源站可能有防盗链机制,建议将图片保存下来直接上传(img-tgtNSrGZ-1634736764650)(C:UsershellnAppDataRoamingTyporatypora-user-imagesimage-20211020202728495.png)]

配置文件：

spring:
  cloud:
    config:
      #git仓库中配置文件的application一致
      name: user
      #git仓库中配置文件的profile一致
      profile: dev
      #git仓库分支一致
      label: master
      discovery:
        # 使用配置中心
        enabled: true
        # 配置中心服务名
        service-id: config-server
  # 配置rabbitmq信息；如果是都与默认值一致则不需要配置
  rabbitmq:
    host: localhost
    port: 5672
    username: guest
    password: guest
eureka:
  client:
    service-url:
      defaultZone: http://127.0.0.1:10086/eureka

编写启动类：

package com.zym;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.circuitbreaker.EnableCircuitBreaker;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;
import tk.mybatis.spring.annotation.MapperScan;

@SpringBootApplication
@MapperScan("com.zym.mapper")
@EnableDiscoveryClient
@EnableCircuitBreaker
public class UserSeverApplication {
    public static void main(String[] args) {
        SpringApplication.run(UserSeverApplication.class, args);
    }
}

实体类：

package com.zym.pojo;

import javax.persistence.*;
import java.io.Serializable;
import java.util.Date;

@Table(name = "bill_")
public class Bill implements Serializable {
    public Long getId() {
        return id;
    }

    public void setId(Long id) {
        this.id = id;
    }

    public String getTitle() {
        return title;
    }

    public void setTitle(String title) {
        this.title = title;
    }

    public Date getBillTime() {
        return billTime;
    }

    public void setBillTime(Date billTime) {
        this.billTime = billTime;
    }

    public Long getTypeId() {
        return typeId;
    }

    public void setTypeId(Long typeId) {
        this.typeId = typeId;
    }

    public Double getPrice() {
        return price;
    }

    public void setPrice(Double price) {
        this.price = price;
    }

    public String getExplain() {
        return explain;
    }

    public void setExplain(String explain) {
        this.explain = explain;
    }

    public String getTypeName() {
        return typeName;
    }

    public void setTypeName(String typeName) {
        this.typeName = typeName;
    }

    public Date getDate1() {
        return date1;
    }

    public void setDate1(Date date1) {
        this.date1 = date1;
    }

    public Date getDate2() {
        return date2;
    }

    public void setDate2(Date date2) {
        this.date2 = date2;
    }

    @Id
    @GeneratedValue(strategy = GenerationType.IDENTITY)
    @Column(name = "id_")
    private Long id;
    @Column(name = "title_")
    private String title;
    @Column(name = "bill_time_")
    private Date billTime;
    @Column(name = "type_id_")
    private Long typeId;
    @Column(name = "price_")
    private Double price;
    @Column(name = "explain_")
    private String explain;

    @Transient
    private String typeName;

    @Transient
    private Date date1;

    @Transient
    private Date date2;
}

dao:

package com.zym.mapper;

import com.zym.pojo.Bill;
import tk.mybatis.mapper.common.Mapper;

import java.util.List;

public interface BillMapper extends Mapper {
}

service:

package com.zym.service;

import com.github.pagehelper.PageHelper;
import com.github.pagehelper.PageInfo;
import com.zym.mapper.BillMapper;
import com.zym.pojo.Bill;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

import java.util.List;

@Service
public class BillService {
    @Autowired
    private BillMapper billMapper;

    public List list() {
        return billMapper.selectAll();
    }

    public int add(Bill b) {
        return billMapper.insert(b);
    }

    public Bill get(Long id) {
        return billMapper.selectByPrimaryKey(id);
    }

    public int update(Bill b) {
        return billMapper.updateByPrimaryKeySelective(b);
    }

    public int delete(Long id) {
        return billMapper.deleteByPrimaryKey(id);
    }

    public PageInfo listPage(Bill b, int pageNum, int pageSize) {
        return PageHelper.startPage(pageNum, pageSize).doSelectPageInfo(() -> {
            billMapper.select(b);
        });
    }
}

控制类：

package com.zym.controller;

//import com.github.pagehelper.PageInfo;
import com.netflix.hystrix.contrib.javanica.annotation.DefaultProperties;
import com.netflix.hystrix.contrib.javanica.annotation.HystrixCommand;
import com.zym.pojo.Bill;
import com.zym.pojo.BillType;
import com.zym.service.BillService;
import com.zym.service.TypeService;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.cloud.context.config.annotation.RefreshScope;
import org.springframework.ui.Model;
import org.springframework.web.bind.annotation.*;

import javax.annotation.Resource;
import java.util.List;

@RestController
@RequestMapping("/bill")
@DefaultProperties(defaultFallback = "defaultFallback")
@RefreshScope
public class BillController {
    @Resource
    private TypeService typeService;
    @Resource
    private BillService billService;

    @Value("${test.name}")
    private String name;

    public String defaultFallback() { return "默认提示：对不起，网络太拥挤了！"; }

    @RequestMapping("/list")
    public List list() {
        System.out.println("配置中心配置的test.name = " + name);
        List list = billService.list();
        return list;
    }


    @RequestMapping("/toAdd")
    public String toAdd(Model model) {
        List types = typeService.list();
        model.addAttribute("types", types);
        return "/bill/add";
    }


    @ResponseBody
    @RequestMapping("/add")
    public Integer add(@RequestBody Bill b) {
        return billService.add(b);
    }


    @RequestMapping("/delete/{id}")
    public Integer delete(@PathVariable("id") Long id) {
        return billService.delete(id);
    }

    @RequestMapping("/{id}")
    public Bill queryById(@PathVariable("id") Long id) {
        return billService.get(id);
    }


    @ResponseBody
    @RequestMapping("/update/{id}")
    public Integer update(@PathVariable("id") Long id, @RequestBody Bill b) {
        b.setId(id);
        return billService.update(b);
    }
}

创建注册中心项目

Eureka负责管理、记录服务提供者的信息。服务调用者无需自己寻找服务，而是把自己的需求告诉 Eureka，然后Eureka会把符合你需求的服务告诉你。

同时，服务提供方与Eureka之间通过 “心跳” 机制进行监控，当某个服务提供方出现问题，Eureka自然会把它从服务列表中剔除。

这就实现了服务的自动注册、发现、状态监控。

项目结构

[外链图片转存失败,源站可能有防盗链机制,建议将图片保存下来直接上传(img-4KHhDYGd-1634736764654)(C:UsershellnAppDataRoamingTyporatypora-user-imagesimage-20211020210638176.png)]

pom.xml文件




        zym-springcloud
        com.zym
        1.0-SNAPSHOT

    4.0.0

    eurekasever



            org.springframework.cloud
            spring-cloud-starter-netflix-eureka-server

配置文件：

server:
  port:
    10086
spring:
  application:
    name: eureka-server
eureka:
  client:
      service-url: # eureka 服务地址，如果是集群的话；需要指定其它集群eureka地址
        defaultZone: HTTP://127.0.0.1:10086/eureka # 不注册自己
      register-with-eureka: false # 不拉取服务
      fetch-registry: false

启动类：

package com.zym;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.netflix.eureka.server.EnableEurekaServer;

@EnableEurekaServer
@SpringBootApplication
public class EurekaApplication {
    public static void main(String[] args) {
        SpringApplication.run(EurekaApplication.class, args);
    }
}

创建网关项目：

Spring Cloud Gateway组件的核心是一系列的过滤器，通过这些过滤器可以将客户端发送的请求转发（路由）到对应的微服务。 Spring Cloud Gateway是加在整个微服务最前沿的防火墙和代理器，隐藏微服务结点IP端口信息，从而加强安全保护。Spring Cloud Gateway本身也是一个微服务，需要注册到Eureka服务注册中心。

网关的核心功能是：过滤和路由

项目结构： [外链图片转存失败,源站可能有防盗链机制,建议将图片保存下来直接上传(img-J5cF0O6s-1634736764656)(C:UsershellnAppDataRoamingTyporatypora-user-imagesimage-20211020211551940.png)] pom.xml文件




        zym-springcloud
        com.zym
        1.0-SNAPSHOT

    4.0.0

    zym-gateway



            org.springframework.cloud
            spring-cloud-starter-gateway


            org.springframework.cloud
            spring-cloud-starter-netflix-eureka-client

配置文件：

server:
  port: 8086
spring:
  application:
    name: api-gateway
  cloud:
    gateway:
      routes:
        #路由的id，可以随意些
        - id: user-service-rote
          #代理的微服务地址
          #uri: http://127.0.0.1:9091
          uri: lb://user-service
          #路由断言：可以配置映射路径
          predicates:
            - Path=/api/bill/**
          filters:
            # 1：去除一个路径，2：去除2路径，以此类推
            - StripPrefix=1
#      default-filters:
#        - AddResponseHeader=X-Response-Foo, Bar
#        - AddResponseHeader=myname, lxs
      globalcors:
        corsConfigurations:
          '[/**]':
            #allowedOrigins: * # 这种写法或者下面的都可以，*表示全部
            allowedOrigins:
              - "http://docs.spring.io"
            allowedMethods:
              - GET
eureka:
  client:
    service-url:
      defaultZone: http://127.0.0.1:10086/eureka
  instance:
    prefer-ip-address: true

hystrix:
  command:
    default:
      execution:
        isolation:
          thread:
            timeoutInMilliseconds: 6000 #服务降级超时时间，默认1S
ribbon:
  ConnectTimeout: 1000 # 连接超时时长
  ReadTimeout: 2000 # 数据通信超时时长
  MaxAutoRetries: 1 # 当前服务器的重试次数
  MaxAutoRetriesNextServer: 1 # 重试多少次服务

启动类：

package com.zym;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;

@SpringBootApplication
@EnableDiscoveryClient
public class GateWayApplication {
    public static void main(String[] args) {
        SpringApplication.run(GateWayApplication.class, args);
    }
}

      thread:
        timeoutInMilliseconds: 6000 #服务降级超时时间，默认1S

ribbon:
ConnectTimeout: 1000 # 连接超时时长
ReadTimeout: 2000 # 数据通信超时时长
MaxAutoRetries: 1 # 当前服务器的重试次数
MaxAutoRetriesNextServer: 1 # 重试多少次服务

### 启动类：

```java
package com.zym;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;

@SpringBootApplication
@EnableDiscoveryClient
public class GateWayApplication {
    public static void main(String[] args) {
        SpringApplication.run(GateWayApplication.class, args);
    }
}

关于config配置中心与bus的内容下一章继续！
