AQS（AbstractQueuedSynchronizer）即 队列同步器，是用来构建锁或者其他同步组件的基础框架，它使用了一个int成员变量表示同步状态，通过内置的FIFO队列来完成资源获取线程的排队工作。
同步器的主要使用方式是继承。子类推荐被定义为自定义同步组件的静态内部类，同步器自身没有实现任何同步接口，它仅仅是定义了若干同步状态获取和释放的方法来供自定义同步组件使用，同步器既可以支持独占式地获取同步状态，也可以支持共享式地获取同步状态。 同步器的设计是基于模板方法模式的，也就是说，使用者需要继承同步器并重写指定的方法，随后将同步器组合在自定义同步组件的实现中，并调用同步器提供的模板方法，而这些模板方法将会调用使用者重写的方法。重写同步器指定的方法时，需要使用同步器提供的如下3个方法来访问或修改同步状态。
·getState()：获取当前同步状态。
·setState(int newState)：设置当前同步状态。
·compareAndSetState(int expect,int update)：使用CAS设置当前状态，该方法能够保证状态设置的原子性。
同步器提供的模板方法基本上分为3类：独占式获取与释放同步状态、共享式获取与释放同步状态和查询同步队列中的等待线程情况。自定义同步组件将使用同步器提供的模板方法来实现自己的同步语义。
2.实现的父类和接口public abstract class AbstractQueuedSynchronizer
extends AbstractOwnableSynchronizer
implements java.io.Serializable {……}
3.AQS的两个内部类
一个是表示单个节点的内部类，其定义了节点的状态、get()set()方法、和三个构造器等。
另外一个是自定义的链表ConditionObject，其节点由node构成。
1.链表提供了add、remove操作方法。
2.提供了返回链表长度、链表中等待线程的集合的方法。
3.提供了关键的节点的中断、唤醒操作。
3.1Node节点static final class Node {
//表示一个节点正在共享模式中等待
static final Node SHARED = new Node();
//表示节点处于排他等待模式
static final Node EXCLUSIVE = null;
//waitStatus值=1，表示线程已经取消
static final int CANCELLED = 1;
//表示成功的线程需要取出
static final int SIGNAL = -1;
//线程在等待
static final int ConDITION = -2;
//表示下一个获取的应该无条件传播
static final int PROPAGATE = -3;
//锁的状态，可能出现上面的几种值，默认0
volatile int waitStatus;
//链表前指针
volatile Node prev;
//后指针
volatile Node next;
//将线程放入节点中。初始化空
volatile Thread thread;
//下一个等待条件的节点
Node nextWaiter;
//返回下一个节点是否是共享模式
final boolean isShared() {
return nextWaiter == SHARED;
}
//返回前一个节点
final Node predecessor() throws NullPointerException {
Node p = prev;
if (p == null)
throw new NullPointerException();
else
return p;
}
//下面是三个构造器
Node() {
}
Node(Thread thread, Node mode) { // Used by addWaiter
this.nextWaiter = mode;
this.thread = thread;
}
Node(Thread thread, int waitStatus) { // Used by Condition
this.waitStatus = waitStatus;
this.thread = thread;
}
}
3.2条件对象ConditionObject
public class ConditionObject implements Condition, java.io.Serializable {
private static final long serialVersionUID = 1173984872572414699L;
//头节点//transient表示变量都是临时的
private transient Node firstWaiter;
//尾节点
private transient Node lastWaiter;
//构造器
public ConditionObject() { }
//链表ADD操作
private Node addConditionWaiter() {
Node t = lastWaiter;
// If lastWaiter is cancelled, clean out.
if (t != null && t.waitStatus != Node.CONDITION) {
unlinkCancelledWaiters();
t = lastWaiter;
}
Node node = new Node(Thread.currentThread(), Node.CONDITION);
if (t == null)
firstWaiter = node;
else
t.nextWaiter = node;
lastWaiter = node;
return node;
}
//删除和传输节点，直到命中或空。
//从信号方法中分离出来，为了方便编译器判断没有等待器的情况。
// @param first(非空)条件队列中的第一个节点
private void doSignal(Node first) {
do {
if ( (firstWaiter = first.nextWaiter) == null)
lastWaiter = null;
first.nextWaiter = null;
} while (!transferForSignal(first) &&
(first = firstWaiter) != null);
}
//传输和删除所有节点
private void doSignalAll(Node first) {
lastWaiter = firstWaiter = null;
do {
Node next = first.nextWaiter;
first.nextWaiter = null;
transferForSignal(first);
first = next;
} while (first != null);
}
//删除链表中的某一个节点
private void unlinkCancelledWaiters() {
Node t = firstWaiter;
Node trail = null;
while (t != null) {
Node next = t.nextWaiter;
if (t.waitStatus != Node.CONDITION) {
t.nextWaiter = null;
if (trail == null)
firstWaiter = next;
else
trail.nextWaiter = next;
if (next == null)
lastWaiter = trail;
}
else
trail = t;
t = next;
}
}
// public methods
//*将等待时间最长的线程(如果存在)从这个条件的等待队列移动到拥有锁。
public final void signal() {
if (!isHeldExclusively())
throw new IllegalMonitorStateException();
Node first = firstWaiter;
if (first != null)
doSignal(first);
}
//将所有线程从这个条件的等待队列移动到拥有锁的等待队列。
public final void signalAll() {
if (!isHeldExclusively())
throw new IllegalMonitorStateException();
Node first = firstWaiter;
if (first != null)
doSignalAll(first);
}
//中断唤醒等待
public final void awaitUninterruptibly() {
Node node = addConditionWaiter();
int savedState = fullyRelease(node);
boolean interrupted = false;
while (!isonSyncQueue(node)) {
LockSupport.park(this);
if (Thread.interrupted())
interrupted = true;
}
if (acquireQueued(node, savedState) || interrupted)
selfInterrupt();
}
//两种等待模式//1.退出wait重新中断2.抛异常
private static final int REINTERRUPT = 1;
private static final int THROW_IE = -1;
//节点在等待时候检查是否有中断产生
private int checkInterruptWhileWaiting(Node node) {
return Thread.interrupted() ?
(transferAfterCancelledWait(node) ? THROW_IE : REINTERRUPT) :
0;
}
//上面说的，抛异常
private void reportInterruptAfterWait(int interruptMode)
throws InterruptedException {
if (interruptMode == THROW_IE)
throw new InterruptedException();
else if (interruptMode == REINTERRUPT)
selfInterrupt();
}
//实现可被中断的等待
public final void await() throws InterruptedException {
if (Thread.interrupted())
throw new InterruptedException();
Node node = addConditionWaiter();
int savedState = fullyRelease(node);
int interruptMode = 0;
while (!isonSyncQueue(node)) {
LockSupport.park(this);
if ((interruptMode = checkInterruptWhileWaiting(node)) != 0)
break;
}
if (acquireQueued(node, savedState) && interruptMode != THROW_IE)
interruptMode = REINTERRUPT;
if (node.nextWaiter != null) // clean up if cancelled
unlinkCancelledWaiters();
if (interruptMode != 0)
reportInterruptAfterWait(interruptMode);
}
//实现定时等待
public final long awaitNanos(long nanosTimeout)
throws InterruptedException {
if (Thread.interrupted())
throw new InterruptedException();
Node node = addConditionWaiter();
int savedState = fullyRelease(node);
final long deadline = System.nanoTime() + nanosTimeout;
int interruptMode = 0;
while (!isonSyncQueue(node)) {
if (nanosTimeout <= 0L) {
transferAfterCancelledWait(node);
break;
}
if (nanosTimeout >= spinForTimeoutThreshold)
LockSupport.parkNanos(this, nanosTimeout);
if ((interruptMode = checkInterruptWhileWaiting(node)) != 0)
break;
nanosTimeout = deadline - System.nanoTime();
}
if (acquireQueued(node, savedState) && interruptMode != THROW_IE)
interruptMode = REINTERRUPT;
if (node.nextWaiter != null)
unlinkCancelledWaiters();
if (interruptMode != 0)
reportInterruptAfterWait(interruptMode);
return deadline - System.nanoTime();
}
//实现绝对即时等待
public final boolean awaitUntil(Date deadline)
throws InterruptedException {
long abstime = deadline.getTime();
if (Thread.interrupted())
throw new InterruptedException();
Node node = addConditionWaiter();
int savedState = fullyRelease(node);
boolean timedout = false;
int interruptMode = 0;
while (!isonSyncQueue(node)) {
if (System.currentTimeMillis() > abstime) {
timedout = transferAfterCancelledWait(node);
break;
}
LockSupport.parkUntil(this, abstime);
if ((interruptMode = checkInterruptWhileWaiting(node)) != 0)
break;
}
if (acquireQueued(node, savedState) && interruptMode != THROW_IE)
interruptMode = REINTERRUPT;
if (node.nextWaiter != null)
unlinkCancelledWaiters();
if (interruptMode != 0)
reportInterruptAfterWait(interruptMode);
return !timedout;
}
// Implements timed condition wait.
public final boolean await(long time, TimeUnit unit)
throws InterruptedException {
long nanosTimeout = unit.tonanos(time);
if (Thread.interrupted())
throw new InterruptedException();
Node node = addConditionWaiter();
int savedState = fullyRelease(node);
final long deadline = System.nanoTime() + nanosTimeout;
boolean timedout = false;
int interruptMode = 0;
while (!isonSyncQueue(node)) {
if (nanosTimeout <= 0L) {
timedout = transferAfterCancelledWait(node);
break;
}
if (nanosTimeout >= spinForTimeoutThreshold)
LockSupport.parkNanos(this, nanosTimeout);
if ((interruptMode = checkInterruptWhileWaiting(node)) != 0)
break;
nanosTimeout = deadline - System.nanoTime();
}
if (acquireQueued(node, savedState) && interruptMode != THROW_IE)
interruptMode = REINTERRUPT;
if (node.nextWaiter != null)
unlinkCancelledWaiters();
if (interruptMode != 0)
reportInterruptAfterWait(interruptMode);
return !timedout;
}
// support for instrumentation
//判断是否被当前AQS实例创建的
final boolean isOwnedBy(AbstractQueuedSynchronizer sync) {
return sync == AbstractQueuedSynchronizer.this;
}
//判断是否有线程在等待
protected final boolean hasWaiters() {
if (!isHeldExclusively())
throw new IllegalMonitorStateException();
for (Node w = firstWaiter; w != null; w = w.nextWaiter) {
if (w.waitStatus == Node.CONDITION)
return true;
}
return false;
}
//获取队列长度
protected final int getWaitQueueLength() {
if (!isHeldExclusively())
throw new IllegalMonitorStateException();
int n = 0;
for (Node w = firstWaiter; w != null; w = w.nextWaiter) {
if (w.waitStatus == Node.CONDITION)
++n;
}
return n;
}
//返回等待的线程的集合
protected final Collection getWaitingThreads() {
if (!isHeldExclusively())
throw new IllegalMonitorStateException();
ArrayList list = new ArrayList();
for (Node w = firstWaiter; w != null; w = w.nextWaiter) {
if (w.waitStatus == Node.CONDITION) {
Thread t = w.thread;
if (t != null)
list.add(t);
}
}
return list;
}
}
4.AQS的内部变量
state：表征可重入锁的状态。
head、tail头尾节点
spinForTimeoutThreshold：超时时限
参考资料：AQS实现原理_不行就改名-CSDN博客_aqs原理
