django+echart绘制曲线图的方法示例

声明：请事先到官网下载echarts，另外本文引用了adminlte模板构建前台页面

views：








网络趋势


























选择框 ：

 //表单提交
function submitForm_net(){
  var form_net = document.getElementById("net_range");
  form_net.submit();
}
ECAHRTS:

 // #################### 【网络流量趋势】图形 ####################
 var myChart_net_grow = echarts.init(document.getElementById('net-grow-chart'));
 option_net_grow = {
   title: {
     text: '网络流量',
     subtext: ''
   },
   tooltip: {
     trigger: 'axis',
     axisPointer: {
type: 'cross'
     }
   },
     legend: {
    data:['接收流量(kbps)','发送流量(kbps)']
  },
   toolbox: {
     show: true,
     feature: {
saveAsImage: {}
     }
   },
   xAxis: {
     type: 'category',
     boundaryGap: false,
     zlevel: 1,
     data: [{% for i in netgrow_list %}'{{ i.chk_time | date:"m-d H:i:s" }}',{% endfor %}]
   },
   yAxis: {
     type: 'value',
     axisLabel: {
formatter: '{value}'
     },
     axisPointer: {
snap: true
     },
     max:100,
     min:0
   },
   series: [
     {
name:'接收流量(kbps)',
type:'line',
smooth: true,
data: [{% for i in netgrow_list %}{{ i.recv_kbps }},{% endfor %}]
     },
 {
name:'发送流量(kbps)',
type:'line',
smooth: true,
data: [{% for i in netgrow_list %}{{ i.send_kbps }},{% endfor %}]
     }
   ]
 };
 myChart_net_grow.showLoading(); //显示loading
 setInterval(function () {
   myChart_net_grow.hideLoading(); //显示完成后不显示loading
   myChart_net_grow.setOption(option_net_grow, true);
 },500);

VIEWS:

@login_required(login_url='/login')
def linux_monitor(request):
  messageinfo_list = models.TabAlarmInfo.objects.all()
  tagsdefault = request.GET.get('tagsdefault')
  if not tagsdefault:
    tagsdefault = models.TabLinuxServers.objects.order_by('tags')[0].tags
  cpu_range_defualt =  request.GET.get('cpu_range_default')
  if not cpu_range_defualt:
    cpu_range_defualt = '1小时'.decode("utf-8")
  mem_range_default = request.GET.get('mem_range_default')
  if not mem_range_default:
    mem_range_default = '1小时'.decode("utf-8")
  net_range_default = request.GET.get('net_range_default')
  if not net_range_default:
    net_range_default = '1小时'.decode("utf-8")
  hostinfo = models.TabLinuxServers.objects.all().order_by('tags')

  net_begin_time = tools.range(net_range_default)
  cpu_begin_time = tools.range(cpu_range_defualt)
  mem_begin_time = tools.range(mem_range_default)
  end_time = datetime.datetime.now().strftime("%Y-%m-%d %H:%M:%S")

  netgrow = models.OsInfoHis.objects.filter(tags=tagsdefault, recv_kbps__isnull=False).filter(
    chk_time__gt=net_begin_time, chk_time__lt=end_time).order_by('-chk_time')
  netgrow_list = list(netgrow)
  netgrow_list.reverse()

  cpugrow = models.OsInfoHis.objects.filter(tags=tagsdefault, cpu_used__isnull=False).filter(
    chk_time__gt=cpu_begin_time, chk_time__lt=end_time).order_by('-chk_time')
  cpugrow_list = list(cpugrow)
  cpugrow_list.reverse()

  memgrow = models.OsInfoHis.objects.filter(tags=tagsdefault, mem_used__isnull=False).filter(
    chk_time__gt=mem_begin_time, chk_time__lt=end_time).order_by('-chk_time')
  memgrow_list = list(memgrow)
  memgrow_list.reverse()

  diskinfos = models.OsFilesystem.objects.filter(tags=tagsdefault)

  try:
    osinfo = models.OsInfo.objects.get(tags=tagsdefault)
  except models.OsInfo.DoesNotExist:
    osinfo = models.OsInfoHis.objects.filter(tags=tagsdefault,cpu_used__isnull=False).order_by('-chk_time')[0]

  if request.method == 'POST':
    if request.POST.has_key('select_tags') or request.POST.has_key('select_cpu')or request.POST.has_key('select_mem') or request.POST.has_key('select_net'):
      if request.POST.has_key('select_tags'):
 tagsdefault = request.POST.get('select_tags', None).encode("utf-8")
      elif request.POST.has_key('select_net'):
 net_range_defualt = request.POST.get('select_net',None)
      elif request.POST.has_key('select_cpu'):
 cpu_range_defualt = request.POST.get('select_cpu',None)
      elif request.POST.has_key('select_mem'):
 mem_range_default = request.POST.get('select_mem', None)
      return HttpResponseRedirect('/linux_monitor?tagsdefault=%s&net_range_default=%s&cpu_range_default=%s&mem_range_default=%s' %(tagsdefault,net_range_default,cpu_range_defualt,mem_range_default))

    else:
      logout(request)
      return HttpResponseRedirect('/login/')

  if messageinfo_list:
    msg_num = len(messageinfo_list)
    msg_last = models.TabAlarmInfo.objects.latest('id')
    msg_last_content = msg_last.alarm_content
    tim_last = (datetime.datetime.now() - msg_last.alarm_time).seconds / 60
    return render_to_response('linux_monitor.html', {'netgrow_list':netgrow_list,'cpugrow_list':cpugrow_list,'memgrow_list':memgrow_list, 'tagsdefault':tagsdefault, 'hostinfo':hostinfo, 'osinfo': osinfo,'net_range_default':net_range_default,'cpu_range_default':cpu_range_defualt,'mem_range_default':mem_range_default, 'messageinfo_list': messageinfo_list,
     'msg_num': msg_num,'msg_last_content': msg_last_content, 'tim_last': tim_last,'diskinfos':diskinfos})
  else:
    return render_to_response('linux_monitor.html', {'netgrow_list':netgrow_list,'cpugrow_list':cpugrow_list,'memgrow_list':memgrow_list, 'tagsdefault':tagsdefault, 'hostinfo':hostinfo, 'osinfo': osinfo,'net_range_default':net_range_default,'cpu_range_default':cpu_range_defualt,'mem_range_default':mem_range_default,'diskinfos':diskinfos})

效果图：
