【Java从0到架构师】Zookeeper 应用 - Java 客户端操作、服务器动态感知、分布式锁业务处理

分布式基石 Zookeeper 框架全面剖析

Java 客户端操作
- Java 客户端 API
服务器的动态感知
- 服务注册
- 服务发现
分布式锁业务处理
- 单机环境（一个虚拟机中）
- 分布式环境_同名节点
- 分布式环境_顺序节点

Java 从 0 到架构师目录：【Java从0到架构师】学习记录

Zookeeper 连接状态：

Java 客户端操作

Java 客户端操作：

自带的 zkclient


    org.apache.zookeeper
    zookeeper
    3.6.0

Apache 开源的 Curator


    org.apache.curator
    curator-framework
    4.3.0


    org.apache.curator
    curator-client
    4.3.0

Apache 开源的 ZkClient (com.101tec)


    com.101tec
    zkclient
    0.11

Java 客户端 API

我们使用 Zookeeper 自带的 zkclient 来操作：

创建会话：

@SpringBootApplication
public class ZookeeperApiDemoApplication {

    private  static  String ZK_SERVER_ADDR="192.168.48.100:2181,192.168.48.100:2182,192.168.48.100:2183";
    private static  int SESSION_TIMEOUT=30000;

    public static void main(String[] args) {
        SpringApplication.run(ZookeeperApiDemoApplication.class, args);
    }

    //创建一个zookeeper的连接
    @Bean
    public ZooKeeper zooKeeper() throws Exception{
        // 第一个参数: 连接地址和端口 第二个参数: 会话超时时间, 第三个参数: 事件监听程序
        ZooKeeper zooKeeper = new ZooKeeper(ZK_SERVER_ADDR, SESSION_TIMEOUT, new Watcher() {
            @Override
            public void process(WatchedEvent event) {
                System.out.println("event = " + event);
                if(event.getState()== Event.KeeperState.SyncConnected){
                    System.out.println("zookeeper客户端连接成功");
                }
            }
        });
        return zooKeeper;
    }

}

创建节点：

@RequestMapping("createNode")
public String createNode(String path, String data, String type) throws Exception{
    String result = zooKeeper.create(path,
    								 data.getBytes(),
    								 ZooDefs.Ids.OPEN_ACL_UNSAFE,
    								 CreateMode.valueOf(type));
    return result;
}

获取节点中的数据：

// 同步获取数据
@RequestMapping("getData")
public String getData(String path) throws Exception {
    // 1 先去查询版本信息  如果没有, 返回的是一个null
    Stat stat = zooKeeper.exists(path, false);
    // 同步获取数据
    byte[] data = zooKeeper.getData(path, new Watcher() {
        @Override
        public void process(WatchedEvent event) {
            System.out.println("event = " + event);
        }
    }, stat);
    System.out.println("new String(data) = " + new String(data));
    return new String(data);
}

// 异步数据处理
@RequestMapping("getDataAsync")
public String getDataAsync(String path) throws Exception{
    // 1 先去查询版本信息
    Stat stat = zooKeeper.exists(path, false);
    zooKeeper.getData(path, false, new AsyncCallback.DataCallback() {
        @Override
        public void processResult(int rc, String path, Object ctx, byte[] data, Stat stat) {
            System.out.println("异步处理回调数据");
            System.out.println("收到的数据:"+new String(data));
            System.out.println("ctx = " + ctx);
        }
    }, "测试数据");

    return "异步获取数据";
}


// 获取子节点列表
@RequestMapping("getChildren")
public List getChildren(String path) throws Exception{
    List children = zooKeeper.getChildren(path, false);
    return children;
}

判断节点是否存在：

@RequestMapping("exists")
public  boolean exists(String path) throws Exception{
    Stat stat = zooKeeper.exists(path, false);
    return stat != null ;
}

删除节点：

@RequestMapping("delete")
public boolean delete(String path) throws Exception{
    Stat stat = zooKeeper.exists(path, false);
    if (stat != null){
        zooKeeper.delete(path,stat.getVersion());
    }
    return true;
}

更新数据：

@RequestMapping("update")
public  boolean update(String path,String data) throws Exception{
    Stat stat = zooKeeper.exists(path, false);
    if (stat != null){
        zooKeeper.setData(path, data.getBytes(), stat.getVersion());
    }
    return true;
}

事件处理：

绑定一次事件：

@RequestMapping("addWatch1")
public String addWatch1(String path) throws Exception{
    Stat stat = zooKeeper.exists(path, false);
    // 定义一个监视器对象
    Watcher watcher = new Watcher() {
        @Override
        public void process(WatchedEvent event) { // 数据改变事件,而且还是一次性
            System.out.println("事件类型:" + event.getType());
            System.out.println("数据发生改变, 请及时更新");
            try {
                byte[] data = zooKeeper.getData(path, this, stat);
                System.out.println("更新后的数据:" + new String(data));
            } catch (Exception e) {
                e.printStackTrace();
            }
        }
    };
    zooKeeper.getData(path, watcher, stat);
    return "success";
}

绑定永久事件：

@RequestMapping("addWatch2")
public String addWatch2(String path) throws Exception{
    Stat stat = zooKeeper.exists(path, false);
    // 只是获取数据, 没有绑定事件
    byte[] data = zooKeeper.getData(path, null, stat);
    System.out.println("获取到数据:" + new String(data));
    // 绑定永久的事件  --> 1 数据变化事件  2  子节点改变事件
    zooKeeper.addWatch(path, new Watcher() {
        @Override
        public void process(WatchedEvent event) {
            System.out.println("event = " + event);
            // 数据改变事件
            if (event.getType() == Event.EventType.NodeDataChanged){
                try {
                    // 重新获取数据
                    Stat stat = zooKeeper.exists(path, false);
                    // 只是获取数据, 没有绑定事件
                    byte[] data = zooKeeper.getData(path, null, stat);
                    System.out.println("更新的数据:" + new String(data));
                } catch (Exception e) {
                    e.printStackTrace();
                }
            // 子节点改变事件
            } else if (event.getType() == Event.EventType.NodeChildrenChanged){
                // 重新获取子节点列表
                System.out.println("子节点数据发生改变");
            }
        }
    }, AddWatchMode.PERSISTENT);
    return "success";
}

递归绑定事件：对于创建的节点以及子节点都绑定事件

@RequestMapping("addWatch")
public List addWatch(String path) throws Exception{
    // 1 先获取所有的子节点
    List children = zooKeeper.getChildren(path, false);
    // 2 绑定一个监听事件
    zooKeeper.addWatch(path, new Watcher() {
        @Override
        public void process(WatchedEvent event) {
            if (event.getType() == Event.EventType.NodeChildrenChanged){
                System.out.println("子节点数据发送改变");
                System.out.println("重新获取子节点数据");
                try {
                    List children1 = zooKeeper.getChildren(path, false);
                    System.out.println("children1 = " + children1);
                    System.out.println("=========================");
                } catch (Exception e) {
                    e.printStackTrace();
                }
            } else if (event.getType() == Event.EventType.NodeDataChanged){
                System.out.println("节点数据发生改变");
                try {
                    byte[] data = zooKeeper.getData(path, false, new Stat());
                    System.out.println("获取到的数据是:" + new String(data));
                } catch (Exception e) {
                    e.printStackTrace();
                }
            }
        }
    }, AddWatchMode.PERSISTENT_RECURSIVE);
    return children;
}

服务器的动态感知

服务注册

创建一个 SpringBoot 项目

导入对应的依赖包


    org.apache.zookeeper
    zookeeper
    3.6.0

实例化一个 Zookeeper 的客户端连接
在连接成功以后，开始创建一个对应的临时顺序节点，注册自己的 ip 和端口

启动项目，连接zk，并且注册地址和端口信息

配置文件

server.port=8888
server.host=192.168.48.1

实现代码

// 注册服务
@SpringBootApplication
public class ZookeeperSeckillServerApplication{

    private static String ZK_SERVER_ADDR = "192.168.48.100:2181,192.168.48.100:2182,192.168.48.100:2183";
    private static int SESSION_TIMEOUT = 30000;
    private static String PATH = "/servers";
    private static String SUB_PATH = "/seckillServer";

    @Value("${server.host}")
    private String host;
    @Value("${server.port}")
    private String port;

    private ZooKeeper zooKeeper;

    public static void main(String[] args) {
        SpringApplication.run(ZookeeperSeckillServerApplication.class, args);
    }

    @Bean
    public ZooKeeper zooKeeper() throws  Exception {
    	  // 参数1: 连接地址和端口, 参数2: 会话超过事件, 参数3：事件监听程序
          zooKeeper = new ZooKeeper(SERVER_ADDR, SESSION_TIMEOUT, new Watcher() {
            @Override
            public void process(WatchedEvent event) {
                System.out.println("event = " + event);
                if(event.getState() == Event.KeeperState.SyncConnected){
                    System.out.println("zookeeper客户端连接成功");
                    //注册对应的信息
                    try {
                        zooKeeper.create(PATH + SUB_PATH, (host + ":" + port).getBytes(),
                                ZooDefs.Ids.OPEN_ACL_UNSAFE, CreateMode.EPHEMERAL_SEQUENTIAL);
                    } catch (Exception e) {
                        e.printStackTrace();
                    }
                }
            }
        });
        return zooKeeper;
    }
}

服务发现

创建一个 SpringBoot 项目

导入依赖


    org.apache.zookeeper
    zookeeper
    3.6.0

创建一个 Zookeeper 客户端连接
连接成功以后，获取地址列表
绑定子节点改变事件（每次改变获取最新的的服务地址）

启动项目，连接 zk，并且获取服务地址列表

注册永久的事件监听：

@SpringBootApplication
public class ZookeeperOrderServerApplication {

    private static String ZK_SERVER_ADDR = "192.168.48.100:2181,192.168.48.100:2182,192.168.48.100:2183";
    private static int SESSION_TIMEOUT = 30000;
    private static String PATH = "/servers";

    public static List addrList;

    // volatile: 保证在多线程之间的变量的可见性
    private volatile ZooKeeper zooKeeper;

    public static void main(String[] args) {
        SpringApplication.run(ZookeeperOrderServerApplication.class, args);
    }

    @Bean
    public ZooKeeper zooKeeper() throws Exception{
        // 第一个参数: 连接地址和端口 第二个参数: 会话超时时间, 第三个参数: 事件监听程序
        zooKeeper = new ZooKeeper(ZK_SERVER_ADDR, SESSION_TIMEOUT, new Watcher() {
            @Override
            public void process(WatchedEvent event) {
                System.out.println("event = " + event);
                if(event.getState()== Event.KeeperState.SyncConnected){
                    System.out.println("zookeeper客户端连接成功");
                    try {
                        //1 获取对应的地址列表
                        getData();
                        //2 绑定永久的事件监听
                        zooKeeper.addWatch(PATH, new Watcher() {
                            @Override
                            public void process(WatchedEvent event) {// 开启另外的线程处理
                                try {
                                    getData();
                                } catch (Exception e) {
                                    e.printStackTrace();
                                }
                            }
                        }, AddWatchMode.PERSISTENT);

                    } catch (Exception e) {
                        e.printStackTrace();
                    }
                }
            }
            //获取数据
            private void getData() throws KeeperException, InterruptedException {
                List serverAddr = zooKeeper.getChildren(PATH, null);
                List tempList = new ArrayList<>();
                for (String path : serverAddr) {
                    //获取节点路径数据
                    byte[] data = zooKeeper.getData(PATH + "/" + path, null, new Stat());
                    String addrInfo = new String(data);
                    // 把数据添加到临时列表
                    tempList.add(addrInfo);
                }
                addrList = tempList;
                System.out.println("获取到秒杀服务的最新地址n" + addrList);
            }
        });
        return zooKeeper;
    }
}

分布式锁业务处理

为什么程序中需要锁？

多任务环境：多个任务同时执行，可以是多线程，也可以是多进程
多个任务的资源共享操作：所有的任务都需要对同一资源进行写操作
对资源的访问是互斥的：对于资源的访问，多个任务同时执行，同一时间只能一个任务访问资源，其他的任务处于阻塞状态

锁的基本概念：

竞争锁：任务通过竞争获取锁才能对该资源进行操作
公平竞争：按照一定的顺序，先来先执行
非公平竞争：没有顺序，不管先后顺序执行
占有锁：当有一个任务在对资源进行更新时，其他任务都不可以对这个资源进行操作
任务阻塞
释放锁：直到该任务完成更新，释放资源

锁的应用场景：

单机环境（一个虚拟机中）
分布式环境_同名节点
分布式环境_顺序节点

单机环境（一个虚拟机中）

业务实现：

// 订单ID生成器
public class OrderIDGenerator {
    private int count = 0;
    public synchronized String getId(){
        SimpleDateFormat sdf = new SimpleDateFormat("yyyy-dd-mm");
        String format = sdf.format(new Date());
        try {
        	// 模拟网络延迟
            TimeUnit.MILLISECONDS.sleep(10);
        } catch (InterruptedException e) {
            e.printStackTrace();
        }
        return format + "-" + (++count);
    }
}

测试实现：

public class OrderService implements Runnable {
    private OrderIDGenerator orderIDGenerator = null;
    private static CountDownLatch countDownLatch = new CountDownLatch(50);
    private static Set result = new HashSet<>(50);

    public OrderService(OrderIDGenerator orderIDGenerator) {
        this.orderIDGenerator = orderIDGenerator;
    }

    public static void main(String[] args) throws Exception{
        OrderIDGenerator idGenerator = new OrderIDGenerator();

        System.out.println("开始模拟多线程生成订单号");
        for(int i = 0; i < 50; i++){
            new Thread(new OrderService(idGenerator)).start();
        }
        countDownLatch.await();
        System.out.println("生成的订单号个数:" + result.size());
        System.out.println("======================");
        for (String order : result) {
            System.out.println(order);
        }
    }

    @Override
    public void run() {
        result.add(orderIDGenerator.getId());
        countDownLatch.countDown();
    }
}

分布式环境_同名节点

分布式锁业务流程分析：

分布式锁流程图：

业务实现：

@RestController
public class OrderController {

    private  RestTemplate restTemplate = new RestTemplate();

    @Autowired
    private ZooKeeper zooKeeper;

    private String path = "/locks";
    private String node = "/orderIdLock";

    @RequestMapping("createOrder")
    public String createOrder() throws Exception{
        // 获取id
        if (tryLock()) {
            // 调用业务方法
            String id = restTemplate.getForObject("http://localhost:8080/getId", String.class);
            System.out.println("获取到的id:" + id);
            // 释放锁
            unlock();
        } else {
            waitLock();
        }
        return "success";
    }

    // 竞争锁资源: 尝试获取id, 如果获取到了, 返回true, 否则返回false
    public boolean tryLock(){
        try {
            // 因为不是顺序节点, 对于同一个路径, 只能创建一次
            String path = zooKeeper.create(this.path + this.node,
                    null, ZooDefs.Ids.OPEN_ACL_UNSAFE, CreateMode.EPHEMERAL);
            return true;
        } catch (Exception e) {
            e.printStackTrace();
            return false;
        }
    }

    // 释放锁资源
    public void unlock(){
        try {
            Stat stat = zooKeeper.exists(this.path + this.node, false);
            zooKeeper.delete(this.path + this.node, stat.getVersion());
        } catch (Exception e) {
            e.printStackTrace();
        }
    }

    // 阻塞状态
    public  void waitLock(){
        try {
            zooKeeper.getChildren(this.path, new Watcher() {
                @Override
                public void process(WatchedEvent event) {
                    try {
                        createOrder(); // 重新创建订单
                    } catch (Exception e) {
                        e.printStackTrace();
                    }
                }
            });
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

分布式环境_顺序节点

分布式锁流程：

@RestController
public class Order02Controller {

    private RestTemplate restTemplate = new RestTemplate();

    @Autowired
    private ZooKeeper zooKeeper;

    private String path = "/locks02";
    private String node = "/orderIdLock";

    @RequestMapping("createOrder02")
    public String createOrder() throws Exception {
        String currentPath = zooKeeper.create(this.path + this.node,
                null, ZooDefs.Ids.OPEN_ACL_UNSAFE, CreateMode.EPHEMERAL_SEQUENTIAL);
        currentPath = currentPath.substring(currentPath.lastIndexOf("/") + 1);
        //获取id
        if (tryLock(currentPath)) {
            // 调用业务方法
            String id = restTemplate.getForObject("http://localhost:8080/getId", String.class);
            System.out.println("获取到的id:" + id);
            // 释放锁
            unlock(currentPath);
        } else {
            waitLock(currentPath);
        }
        return "success";
    }

    //尝试获取id, 如果获取到了, 返回true, 否则返回false
    //竞争锁资源
    public boolean tryLock(String currentPath) {
        try {
            //获取到所有的节点
            List children = zooKeeper.getChildren(this.path, false);
            Collections.sort(children);
            if (StringUtils.pathEquals(currentPath, children.get(0))) {
                return true;
            } else {
                return false;
            }
        } catch (Exception e) {
            e.printStackTrace();
            return false;
        }
    }

    //释放锁资源
    public void unlock(String currentPath) {
        try {
            Stat stat = zooKeeper.exists(this.path + "/" + currentPath, false);
            zooKeeper.delete(this.path + "/" + currentPath, stat.getVersion());
        } catch (Exception e) {
            e.printStackTrace();
        }
    }

    //阻塞状态
    public void waitLock(String currentPath) {
        try {
            CountDownLatch count = new CountDownLatch(1);
            List children = zooKeeper.getChildren(this.path, false);
            //获取到前一个节点
            Collections.sort(children);
            int index = children.indexOf(currentPath);
            if (index > 0) {
                String preNode = children.get(index - 1);
                //前一个节点删除操作
                zooKeeper.getData(this.path + "/" + preNode, new Watcher() {
                    @Override
                    public void process(WatchedEvent event) {
                        if (event.getType() == Event.EventType.NodeDeleted) {
                            try {
                                String id = restTemplate.getForObject("http://localhost:8080/getId", String.class);
                                System.out.println("获取到的id:" + id);
                                //释放锁
                                unlock(currentPath);
                                count.countDown();
                            } catch (Exception e) {
                                e.printStackTrace();
                            }
                        }
                    }
                }, new Stat());
            }
            count.await();
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

【Java从0到架构师】Zookeeper 应用 - Java 客户端操作、服务器动态感知、分布式锁业务处理

Java相关栏目本月热门文章
