Linux Centos7 环境基于Docker部署Zookeeper服务搭建实战

配置Zookeeper安装目录

在宿主机配置zookeeper安装目录：/docker/develop/zookeeper
并且在文件夹创建 data 和logs 目录：
mkdir -p /docker/develop/zookeeper/data
mkdir -p /docker/develop/zookeeper/logs

[root@centos-knight ~]# cd /docker/develop/zookeeper
[root@centos-knight zookeeper]# mkdir -p /docker/develop/zookeeper/data
[root@centos-knight zookeeper]# mkdir -p /docker/develop/zookeeper/logs

授权文件目录：chmod -R 777 /docker/develop/zookeeper/

[root@centos-knight zookeeper]# chmod -R 777 /docker/develop/zookeeper/
[root@centos-knight zookeeper]#

安装和部署Zookeeper

拉取zookeeper镜像：docker pull zookeeper

[root@centos-knight zookeeper]# docker pull zookeeper
Using default tag: latest
latest: Pulling from library/zookeeper
Digest: sha256:6b6b5f7fb6a47d2b311df5af1718af5a425a679dbb844d77913fa68d1a8bf0fd
Status: Image is up to date for zookeeper:latest
docker.io/library/zookeeper:latest
[root@centos-knight zookeeper]#

临时安装Zookeeper服务：zookeeper-tmp-server

docker run -itd -p 2181:2181 --restart always --name=zookeeper-tmp-server  --privileged=true
-v /docker/develop/zookeeper/data:/data
-v /docker/develop/zookeeper/datalog:/datalog
-v /docker/develop/zookeeper/logs:/logs
-e "ZOO_STANDALONE_ENABLED=true"
-e "TZ=Asia/Shanghai"
-e "ZOO_4LW_COMMANDS_WHITELIST=*"
-e "ZOO_AUTOPURGE_SNAPRETAINCOUNT=5"
-e "ZOO_AUTOPURGE_PURGEINTERVAL=24"
-e "ZOO_MAX_CLIENT_CNXNS=64"
-e "ZOO_TICK_TIME=2000"
-e "ZOO_INIT_LIMIT=100"
-e "ZOO_SYNC_LIMIT=5"
zookeeper:latest

复制zookeeper-tmp-server的conf到/docker/develop/zookeeper：

[root@centos-knight ~]# docker ps
ConTAINER ID  IMAGE   COMMAND   CREATED      STATUS   PORTS   NAMES
12947bdadd84  zookeeper:latest "/docker-entrypoint.…"   36 hours ago  Up 36 hours  2888/tcp, 3888/tcp, 0.0.0.0:2181->2181/tcp, 8080/tcp   zookeeper-develop-server
[root@centos-knight ~]# docker cp 12947bdadd84:/conf /docker/develop/zookeeper/

编写zookeeper的zoo.cfg配置文件：

tickTime=2000
initLimit=100
syncLimit=5
dataDir=/data
dataLogDir=/datalog
clientPort=2181
quorumListenonAllIPs=true
preAllocSize=64M
globalOutstandingLimit=100000
snapCount=50000
maxClientCnxns=64
minSessionTimeout=4000
maxSessionTimeout=40000
4lw.commands.whitelist=*
standaloneEnabled=true
admin.enableServer=true
server.1=0.0.0.0:2888:3888
tcpKeepAlive=true
ipReachableTimeout=0
cnxTimeout=3
electionAlg=3
autopurge.snapRetainCount=5
autopurge.purgeInterval=24
#忽略ACL验证
skipACL=yes
forceSync=yes
fsync.warningthresholdms=50

编写正式安装Dcoekr命令：

docker run -itd -p 2181:2181 -p 2888:2888 -p 3888:3888 --restart always --name=zookeeper-develop-server  --privileged=true
-v /docker/develop/zookeeper/conf/zoo.cfg:/conf/zoo.cfg
-v /docker/develop/zookeeper/data:/data
-v /docker/develop/zookeeper/logs:/datalog
-e "TZ=Asia/Shanghai"
-e "JAVA_OPTS=-server -Xms512m -Xmx512m -Xmn256m -Duser.home=/opt -XX:metaspaceSize=128m -XX:MaxmetaspaceSize=320m -XX:+AlwaysPreTouch -XX:-UseBiasedLocking"
zookeeper:latest

部署Dubbo客户端

部署安装dubbo-admin：

docker run -itd --restart always --privileged=true  --name dubbo-devleop-ops -p 8083:8080  -e admin.registry.address="zookeeper://IP:2181" -e admin.config-center="zookeeper://IP:2181" -e admin.metadata-report.address="zookeeper://IP:2181" -e "JAVA_OPTS=-server -Xms512m -Xmx512m -Xmn256m -Duser.home=/opt -XX:metaspaceSize=128m -XX:MaxmetaspaceSize=320m -XX:+AlwaysPreTouch -XX:-UseBiasedLocking" -e TZ="Asia/Shanghai" apache/dubbo-admin:latest

基于Springboot整合和使用Dubbo+Zookeeper

创建工程：pivotal-cloud-dependencies [统一管理工程版本依赖资源]

一般都是使用Maven作为构建工具，这里便只需在pom.xml中添加如下依赖即可：
在标签定义依赖版本号：

2.7.3
2.7.3

3.5.6
4.2.0

在标签添加如下内容：



     org.apache.dubbo
     dubbo
     ${dubbo.version}



   org.springframework
   spring



   javax.servlet
   servlet-api



    log4j
    log4j



     io.netty
     netty-all




org.apache.dubbo
dubbo-spring-boot-starter
${spring-boot-dubbo.version}



org.apache.dubbo
 dubbo




     org.apache.dubbo
     dubbo-metadata-report-zookeeper
      ${dubbo.version}



    org.apache.dubbo
     dubbo-common



   org.apache.dubbo
   dubbo-remoting-zookeeper






  org.apache.zookeeper
  zookeeper
  ${zookeeper.version}



   log4j
   log4j



   org.slf4j
   slf4j-api



   org.slf4j
   slf4j-log4j12




  org.apache.curator
  curator-framework
  ${curator.version}



   org.apache.curator
   curator-client




  org.apache.curator
  curator-recipes
  ${curator.version}



   org.apache.curator
   curator-framework




  org.apache.curator
  curator-client
  ${curator.version}



   org.apache.curator
   curator-framework



   org.apache.zookeeper
   zookeeper



ps[注意事项]：

1.使用pivotal-cloud-dependencies的意义,可以排除多余和重复依赖，解决依赖冲突等具有指导和参考的作用

2.对于升级和改造可以灵活切换，统一管理版本号等

创建工程：pivotal-dubbo-integration


与Dubbo相关的依赖：



      org.apache.dubbo
      dubbo
      ${dubbo.version}


      org.apache.dubbo
      dubbo-spring-boot-starter
      ${spring-boot-dubbo.version}



与Zookeeper相关的依赖：


    org.apache.zookeeper
    zookeeper
    ${zookeeper.version}


  org.apache.curator
  curator-framework
  ${curator.version}


  org.apache.curator
  curator-recipes
  ${curator.version}


  org.apache.curator
  curator-client
  ${curator.version}



然后运行打包构建命令：mvn clean install 将工程打成一个jar，然后在工程需要使用Dubbo作为Provider和Consumer 的工程模块中依赖此内部整合工程：

 com.mark.apple
 pivotal-dubbo-integration
 version>${project.version}




ps[注意事项]：

1.使用pivotal-dubbo-integration的意义,可以自定义封装Dubbo相关特殊场景下的自定义模块[自定义Dubbo序列化等]，以及Dubbo性能调优等

2.可以整合以及其他框架，譬如[Dubbo网关以及Dubbo指标监控等]

最后在Provider和Consumer的工程配置相关属性：

Provider 相关属性配置：

#####################################################
#########Springboot Dubbo Provider Setting##########
#####################################################
pivotal.zookeeper.server-address=zookeeper://IP:2181
dubbo.metadata-report.address=${pivotal.zookeeper.server-address}
dubbo.application.id=${spring.application.name}-${spring.profiles.active}
dubbo.application.name=${spring.application.name}-${spring.profiles.active}
dubbo.application.registry=${spring.application.name}-${spring.profiles.active}
dubbo.application.organization=com.mark.apple
dubbo.application.architecture=${dubbo.application.name}
dubbo.application.environment=${spring.profiles.active}
dubbo.application.logger=slf4j
dubbo.config.override=true
dubbo.config.multiple=true
#dubbo file upload length
# ProtocolConfig Bean
dubbo.protocol.id=dubbo
dubbo.protocol.name=dubbo
#dubbo.protocol.status=client
dubbo.protocol.payload=2147483647
dubbo.protocol.buffer=8192
dubbo.protocol.register=true
dubbo.protocol.server=netty
dubbo.protocol.transporter=netty
dubbo.protocol.threadpool=cached
dubbo.protocol.threads=200
dubbo.protocol.iothreads=2
dubbo.protocol.dispatcher=all
#RegistryConfig Bean
dubbo.registry.address=${pivotal.zookeeper.server-address}
# ProtocolConfig Bean
dubbo.protocol.id=dubbo
dubbo.protocol.name=dubbo
dubbo.protocol.port=28080
dubbo.protocol.status=server
dubbo.protocol.payload=2147483647
dubbo.protocol.buffer=8192
dubbo.protocol.register=true
dubbo.protocol.server=netty
dubbo.protocol.transporter=netty
dubbo.protocol.threadpool=cached
dubbo.protocol.threads=200
dubbo.protocol.dispatcher=all
dubbo.protocol.accepts=1000
#Dubbo Provider setting
dubbo.provider.accepts=0
dubbo.protocol.iothreads=2
dubbo.provider.threads=200
dubbo.provider.threadpool=cached
dubbo.provider.executes=0
dubbo.provider.validation=true
dubbo.provider.connections=0
dubbo.provider.actives=0
dubbo.provider.buffer=8192
dubbo.provider.retries=3
dubbo.provider.delay=-1
dubbo.provider.timeout=360000
#Dubbo Consumer setting
dubbo.consumer.lazy=true
dubbo.consumer.connections=0
dubbo.consumer.actives=0
dubbo.consumer.retries=3
dubbo.consumer.timeout=360000
dubbo.consumer.validation=true
dubbo.consumer.check=true
dubbo.consumer.loadbalance=consistenthash
#base packages to scan Dubbo Components (e.g @Service , @Reference)
dubbo.scan.base-packages=com.pivotal.authority.server.impl


Consumer相关属性配置：

#####################################################
#########Springboot Dubbo Consumer Setting##########
#####################################################
pivotal.zookeeper.server-address=zookeeper://IP:2181
dubbo.metadata-report.address=${pivotal.zookeeper.server-address}
# Dubbo Config properties
dubbo.application.id=${spring.application.name}-${spring.profiles.active}
dubbo.application.name=${spring.application.name}-${spring.profiles.active}
dubbo.application.registry=${spring.application.name}-${spring.profiles.active}
dubbo.application.organization=com.mark.apple
dubbo.application.architecture=${dubbo.application.name}
dubbo.application.environment=${spring.profiles.active}
dubbo.application.logger=slf4j
dubbo.config.override=true
dubbo.config.multiple=true
# ProtocolConfig Bean
dubbo.protocol.id=dubbo
dubbo.protocol.name=dubbo
dubbo.protocol.status=client
dubbo.protocol.payload=2147483647
dubbo.protocol.buffer=8192
dubbo.protocol.register=true
dubbo.protocol.server=netty
dubbo.protocol.transporter=netty
dubbo.protocol.threadpool=cached
dubbo.protocol.threads=200
dubbo.protocol.iothreads=2
dubbo.protocol.dispatcher=all
#RegistryConfig Bean
dubbo.registry.id=${dubbo.application.name}
dubbo.registry.protocol=dubbo
dubbo.registry.check=true
dubbo.registry.address=${pivotal.zookeeper.server-address}
#Dubbo Consumer setting
dubbo.consumer.lazy=true
dubbo.consumer.connections=0
dubbo.consumer.actives=0
dubbo.consumer.retries=3
dubbo.consumer.validation=true
dubbo.consumer.check=true
dubbo.consumer.loadbalance=consistenthash


版权声明：本文为博主原创文章，遵循相关版权协议，如若转载或者分享请附上原文出处链接和链接来源。
