SpringBoot纯后台生成Echarts图片（一）
SpringBoot纯后台生成Echarts图片（二）
一、项目工程结构
二.项目依赖说明
项目的pom.xml配置，属性配置 见第一篇
三.项目代码说明
（1）echarts-pojo模块（数据模型）
package com.lhf.springboot.echarts.pojo;
import lombok.Data;
@Data
public class PieData {
private String[] types;
private String[] datas;
private String title;
}（2）controler模块(API接口)
package com.lhf.springboot.controller;
import com.alibaba.fastjson.JSON;
import com.alibaba.fastjson.JSONObject;
import com.lhf.springboot.common.JsonResult;
import com.lhf.springboot.echarts.pojo.BarData;
import com.lhf.springboot.echarts.pojo.LinesData;
import com.lhf.springboot.echarts.pojo.PieData;
import com.lhf.springboot.util.*;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiOperation;
import org.apache.commons.lang3.time.FastDateFormat;
import org.jboss.logging.Logger;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.bind.annotation.RestController;
import java.awt.*;
import java.io.File;
import java.io.FileOutputStream;
import java.text.DecimalFormat;
import java.util.*;
import java.util.List;
@Api(value = "Freemarker模板生成Echarts图表Api接口", tags = "模板生成图表Api-1")
@RequestMapping("/template")
@RestController
public class EchartsTemplateController {
private final static Logger logger = Logger.getLogger(EchartsController.class);
@Value("${img-url}")
private String imgUrl;
@Value("${img-url-path}")
private String imgUrlPath;
@Value("${request-url}")
private String requestUrl;
private static final String path = FreemarkerUtil.class.getClassLoader().getResource("").getPath();
private String temPath = path + "templates";
@ApiOperation("模板生成饼图, html文件格式")
@RequestMapping(value = "/pie", method = RequestMethod.POST)
public JsonResult createPieFtl(@RequestBody PieData pieData) {
String title = pieData.getTitle();
String[] types = pieData.getTypes();
String[] datas = pieData.getDatas();
if (title == null || types == null || datas == null) {
return new JsonResult(-1, "参数异常");
}
if(types.length != datas.length){
return new JsonResult(-1, "数据不对应");
}
//组装参数
Double data = null;
Double sum = 0.0;
DecimalFormat df = new DecimalFormat(".00");
List stringList = new ArrayList<>();
String bfb = null;
String typeParam = null;
List> listMap = new ArrayList<>();
for(int i = 0;i mapStr = new HashMap<>();
mapStr.put("name", typeParam);
mapStr.put("value", datas[i]);
listMap.add(mapStr);
}
System.out.println(stringList);
System.out.println(listMap);
try {
//组装参数
HashMap pieDatas = new HashMap<>();
pieDatas.put("title", title);
//pieDatas.put("types", JSON.toJSonString(types));
pieDatas.put("types", JSON.toJSonString(stringList));
pieDatas.put("datas", JSON.toJSonString(listMap));
String option = FreemarkerUtil.generateString("pieOption1.ftl", temPath, pieDatas);
System.out.println("option = " + option);
Map pieOption = new HashMap<>();
pieOption.put("option", option);
String htmlPie = FreemarkerUtil.generateString("pieOption.ftl", temPath, pieOption);
System.out.println("htmlPie = " + htmlPie);
//写入html
String nowStr = FastDateFormat.getInstance("yyyyMMddHHmmss").format(new Date());
String imageName = "pie"+nowStr;
File htmlFile = new File(imgUrl+imageName+".html");
if(!htmlFile.exists()){
htmlFile.createNewFile();
}
byte bytes[] = new byte[1024];
bytes = htmlPie.getBytes();
int b = bytes.length; //字节长度
FileOutputStream fos = new FileOutputStream(htmlFile);
fos.write(bytes, 0, b);
fos.write(bytes);
fos.close();
} catch (Exception e) {
logger.error("发生了异常，" + e.getMessage());
return new JsonResult(-1, "Fail");
}
return new JsonResult(1, "SUCCESS");
}
@ApiOperation("模板生成饼图")
@RequestMapping(value = "/pieImg", method = RequestMethod.POST)
public JsonResult createPieFtlImage(@RequestBody PieData pieData) {
String title = pieData.getTitle();
String[] types = pieData.getTypes();
String[] datas = pieData.getDatas();
if (title == null || types == null || datas == null) {
return new JsonResult(-1, "参数异常");
}
if(types.length != datas.length){
return new JsonResult(-1, "数据不对应");
}
//组装参数
Double data = null;
Double sum = 0.0;
DecimalFormat df = new DecimalFormat(".00");
List stringList = new ArrayList<>();
String bfb = null;
String typeParam = null;
List> listMap = new ArrayList<>();
for(int i = 0;i mapStr = new HashMap<>();
mapStr.put("name", typeParam);
mapStr.put("value", datas[i]);
listMap.add(mapStr);
}
System.out.println(stringList);
System.out.println(listMap);
String oldFilePath = null;
String newFilePath = null;
try {
//组装参数
HashMap pieDatas = new HashMap<>();
pieDatas.put("title", title);
//pieDatas.put("types", JSON.toJSonString(types));
pieDatas.put("types", JSON.toJSonString(stringList));
pieDatas.put("datas", JSON.toJSonString(listMap));
String option = FreemarkerUtil.generateString("pieOption1.ftl", temPath, pieDatas);
System.out.println("option = " + option);
long nowStr = Calendar.getInstance().getTimeInMillis();
String imageName = "pie"+nowStr+ RandomUtils.getRandomString(4)+".png";
Map opt = (Map) JSONObject.parse(option);
PhantomJS js = new PhantomJS();
js.setOpt(opt);
js.setReqMethod("echarts");
js.setFile(imgUrlPath+imageName);
PhantomJSUtil.phantomJS(requestUrl, JSON.parseObject(JSON.toJSonString(js)));
oldFilePath = imgUrlPath+imageName;
newFilePath = imgUrlPath+"new"+imageName;
logger.info("oldFilePath = " + oldFilePath);
logger.info("newFilePath = " + newFilePath);
String logoText = "霜花似雪";
//添加水印
ImageUtil.markImageByText(logoText, oldFilePath, newFilePath, -15, new Color(190,190,190), "png");
} catch (Exception e) {
logger.error("发生了异常，" + e.getMessage());
return new JsonResult(-1, "Fail");
}
return new JsonResult(1, "SUCCESS");
}
} 三、插件环境配置说明
插件环境说明见第一篇文章
其他重要说明：
生成饼图的命令：
D:>cd D:softpackechartsphantomjs-2.1.1-windowsbin D:softpackechartsphantomjs-2.1.1-windowsbin>phantomjs D:softpackechartsphantomjs-2.1.1-windowsbinecharts-util.js -s -p 6668 或者phantomjs D:softpackechartsphantomjs-2.1.1-windowsbinecharts-util-one.js -s -p 6668
关键文件说明：
echarts-util.js: 此文件用于生成状图、折线图、饼图, 只限于普通的option（option中没有js方法的）
echarts-util-one.js: 此文件用于生成状图、折线图、饼图，生成的柱状图具有颜色渐变的效果，option中含有js方法，实例可以参考bar.txt文件
echarts-util.js代码：
phantom.outputEncoding = "gbk";// 为防止输出中文时出现乱码，可设置输出编码格式,写在最顶部
var params = require('system');// 获取系统参数
var server = require('webserver').create(); // 服务端
var port = params.args[3];// 端口,与启动命令有关,不一定是3
var listen = server.listen(port, function(request, response) {// 监听端口
var args = serverGetArgs(request);// 得到网络请求参数
args.response = response;
methodDis(args);
});
var jslib = {
jquery : phantom.libraryPath + '/lib/jquery-3.2.1.min.js',
echarts : phantom.libraryPath + '/lib/echarts.min.js',
china : phantom.libraryPath + '/lib/china.js',
};
function methodDis(args) {
if (args.reqMethod == "table") {
table(args);
} else if (args.reqMethod == "echarts") {
echarts(args);
}
if (args.exit == "true") {
writeResponse(args.response, {
error_no : 0
});
phantom.exit();
}
}
function table(args) {
var page = require('webpage').create();// 打开页面
// 设置分辨率
page.viewportSize = {
width : 1000,
height : 1200
};
// 打开页面
page.open(args.url || 'http://127.0.0.1:8080/hello', function(status) {
if (status == "fail") {
writeResponse(args.response, {
error_no : -1
});
return;
}
page.injectJs(jslib.jquery);
var tableheight = page.evaluate(function() {
return $('body').height() + 20;
});
// 定义剪切范围
page.clipRect = {
top : 0,
left : 0,
width : 1000,
height : tableheight
};
page.render(args.file);// 将整个page保存为文件,可以是png，jpg, gif,pdf
page.close();
writeResponse(args.response, {
error_no : 0
});
});
page.onError = function(msg, trace) {
writeResponse(args.response, {
error_no : -1,
error_info : trace
});
};
}
function echarts(args) {
var page = require('webpage').create(); // 客户端
page.open("about:blank", function(status) {// 空白页
page.injectJs(jslib.jquery);
page.injectJs(jslib.echarts);
page.injectJs(jslib.china);
var pageBody = page.evaluate(function(args) {
// 动态加载js，获取options数据
$('
