Android编程中TextView宽度过大导致Drawable无法居中问题解决方法

本文实例讲述了Android编程中TextView宽度过大导致Drawable无法居中问题解决方法。分享给大家供大家参考，具体如下：

在做项目的时候，很多时候我们都要用到文字和图片一起显示，一般设置TextView的DrawableLeft、DrawableRight、DrawableTop、DrawableBottom就行了。但是有一种情况是当TextView的熟悉是fill_parent或者使用权重的时候并且设置了起Gravity的ceter的时候，Drawable图片是无法一起居中的，为了解决其，我们一般再套一层布局，然后设置TextView的熟悉是wrap_content，但是有时候嵌套过多的布局的时候，有可能发生StackOverFlow，所以必须要优化，下面说一下其中的一个解决方案。先上图

这个解决方案很粗糙，局限性很大，文字不能换行，换行之后就不准了，下面是源码：

package com.example.testandroid;
import java.lang.ref.WeakReference;
import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.graphics.Canvas;
import android.graphics.Color;
import android.graphics.Rect;
import android.util.AttributeSet;
import android.view.MotionEvent;
import android.widget.TextView;
public class DrawableTextView extends TextView {
 private WeakReference normalReference;
 private WeakReference pressReference;
 private WeakReference showReference;
 private int normalColor = Color.WHITE, pressColor = Color.WHITE;
 private String text;
 private int textWidth = 0;
 private int textHeight = 0;
 public DrawableTextView(Context context) {
  super(context);
 }
 public DrawableTextView(Context context, AttributeSet attrs) {
  super(context, attrs);
 }
 public DrawableTextView(Context context, AttributeSet attrs, int defStyle) {
  super(context, attrs, defStyle);
 }
 @Override
 protected void onFinishInflate() {
  super.onFinishInflate();
  initText();
 }
 private void initText() {
  text = super.getText().toString();
  initVariable();
 }

 private void initVariable() {
  textWidth = (int) (getPaint().measureText(text));
  final Rect rect = new Rect();
  getPaint().getTextBounds(text, 0, 1, rect);
  textHeight = rect.height();
 }

 public void setText(String text) {
  this.text = text;
  initVariable();
  invalidate();
 }

 public String getText() {
  return text;
 }

 public void setDrawableLeftId(final int normalDrawableId, final int pressDrawableId) {
  normalReference = new WeakReference(BitmapFactory.decodeResource(getResources(), normalDrawableId));
  if (pressDrawableId != -1) {
   pressReference = new WeakReference(BitmapFactory.decodeResource(getResources(), pressDrawableId));
  }
  showReference = normalReference;
  invalidate();
 }

 public void setTextColor(final int normalColor, final int pressColor) {
  this.normalColor = normalColor;
  this.pressColor = pressColor;
  getPaint().setColor(normalColor);
  initVariable();
 }
 @Override
 protected void onDraw(Canvas canvas) {
  if (showReference != null && showReference.get() != null) {
   final int bitmapWidth = showReference.get().getWidth();
   final int bitmapHeight = showReference.get().getHeight();
   final int viewHeight = getHeight();
   final int drawablePadding = getCompoundDrawablePadding();
   final int start = (getWidth() - (bitmapWidth + drawablePadding + textWidth)) >> 1;
   canvas.drawBitmap(showReference.get(), start, (viewHeight >> 1) - (bitmapHeight >> 1), getPaint());

   canvas.drawText(text, start + drawablePadding + bitmapWidth, (viewHeight >> 1) + (textHeight >> 1), getPaint());
  }
 }
 @Override
 public boolean onTouchEvent(MotionEvent event) {
  if (event.getAction() == MotionEvent.ACTION_DOWN) {
   if (pressReference != null && pressReference.get() != null) {
    showReference = pressReference;
   }
   getPaint().setColor(pressColor);
  } else if (event.getAction() == MotionEvent.ACTION_UP) {
   if (normalReference != null && normalReference.get() != null) {
    showReference = normalReference;
   }
   getPaint().setColor(normalColor);
  }
  invalidate();
  return super.onTouchEvent(event);
 }
}

xml布局：

调用代码：

DrawableTextView drawableTextView = (DrawableTextView) getView().findViewById(R.id.my_textview);
drawableTextView.setDrawableLeftId(R.drawable.bg_btn_delete_normal, R.drawable.bg_btn_delete_pressed);
drawableTextView.setTextColor(getResources().getColor(R.color.standard_orange), getResources().getColor(R.color.standard_white));
drawableTextView.setText("我在动态修改Text啦");

其实还有更加方便的方法，下面朋友借鉴某个网友的代码（地址我就不知道了）：

@Override
protected void onDraw(Canvas canvas) {
 Drawable[] drawables = getCompoundDrawables();
 if (drawables != null) {
  Drawable drawableLeft = drawables[0];
  if (drawableLeft != null) {
   final float textWidth = getPaint().measureText(getText().toString());
   final int drawablePadding = getCompoundDrawablePadding();
   final int drawableWidth = drawableLeft.getIntrinsicWidth();
   final float bodyWidth = textWidth + drawableWidth + drawablePadding;
   canvas.translate((getWidth() - bodyWidth) / 2, 0);
  }
 }
 super.onDraw(canvas);
}

xml布局：

嗯，自己写这个东西，也学到了一些东西，大家有什么更好的方法，大家可以讨论一下。

希望本文所述对大家Android程序设计有所帮助。
