基于Android实现百度地图定位过程详解

一、问题描述

LBS位置服务是android应用中重要的功能，应用越来越广泛，下面我们逐步学习和实现lbs相关的应用如定位、地图、导航等，首先我们看如何基于百度地图实现定位功能

二、配置环境

1、注册密钥：地址http://developer.baidu.com/map/

2、下载定位SDK，并导入SDK如图所示：

三、编写MyApplication类

编写MyApplication类，为了使用方便我们可以将实现定位的方法封装的Application组件中

封装下列方法

1、  获取定位信息——requestLocationInfo()

2、  通过广播发送位置信息——sendBroadCast()

3、  停止定位——stopLocationClient()

public class MyApplication extends Application{
  public LocationClient mLocationClient = null;
  public GeofenceClient mGeofenceClient;
  public MyLocationListenner myListener = new MyLocationListenner();
  public static String TAG = "MyApplication";
  private static MyApplication mInstance = null;
  @Override
  public void onCreate(){
    mInstance = this;
    mLocationClient = new LocationClient(this);

    mLocationClient.setAK("你的应用Key");
    mLocationClient.registerLocationListener(myListener);
    mGeofenceClient = new GeofenceClient(this);
    super.onCreate();
    Log.d(TAG, "... Application onCreate... pid=" + Process.myPid());
  }
  public static MyApplication getInstance(){
    return mInstance;
  }

  public void stopLocationClient(){
    if (mLocationClient != null && mLocationClient.isStarted()){
      mLocationClient.stop();
    }
  }

  public void requestLocationInfo(){
    setLocationOption();
    if (mLocationClient != null && !mLocationClient.isStarted()){
      mLocationClient.start();
    }
    if (mLocationClient != null && mLocationClient.isStarted()){
      mLocationClient.requestLocation();
    }
  }

  private void setLocationOption(){
    LocationClientOption option = new LocationClientOption();
    option.setOpenGps(true); // 打开gps
    option.setCoorType("bd09ll"); // 设置坐标类型
    option.setServiceName("com.baidu.location.service_v2.9");
    option.setPoiExtraInfo(true);
    option.setAddrType("all");
    option.setPoiNumber(10);
    option.disableCache(true);
    mLocationClient.setLocOption(option);
  }

  public class MyLocationListenner implements BDLocationListener
  {
    @Override
    public void onReceiveLocation(BDLocation location){
      if (location == null){
 sendBroadCast("定位失败!");
 return;
      }
      sendBroadCast(location.getAddrStr());
    }
    public void onReceivePoi(BDLocation poiLocation){
      if (poiLocation == null){
 sendBroadCast("定位失败!");
 return;
      }
      sendBroadCast(poiLocation.getAddrStr());
    }
  }

  public void sendBroadCast(String address){
 stopLocationClient();
    Intent intent = new Intent(MainActivity.LOCATION_BCR);
    intent.putExtra("address", address);
    sendBroadcast(intent);
  }
}

三、 主程序MainActivity

public class MainActivity extends Activity{
  public static String TAG = "LocTestDemo";
  private BroadcastReceiver broadcastReceiver;
  public static String LOCATION_BCR = "location_bcr";
  private Button locBtn;
  private TextView locInfo;
  private MyApplication application;
  @Override
  protected void onCreate(Bundle savedInstanceState){
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);
    application=(MyApplication)super.getApplication();
    initialize();
    initializeViews();
    initializeListeners();
  }
  private void initialize(){
    registerBroadCastReceiver();//注册广播
  }
  private void initializeViews()
  {
    locBtn = (Button) findViewById(R.id.location);
    locInfo = (TextView) findViewById(R.id.location_info);
  }
  private void initializeListeners()
  {
    locBtn.setonClickListener(new onClickListener(){
      @Override
      public void onClick(View v){
 locInfo.setText("定位中...");
      //调用请求定位信息
      application.requestLocationInfo();
      }
    });
  }

  private void registerBroadCastReceiver()
  {
    broadcastReceiver = new BroadcastReceiver(){
    public void onReceive(Context context, Intent intent){
      String address = intent.getStringExtra("address");
 locInfo.setText(address);
      }
    };
    IntentFilter intentToReceiveFilter = new IntentFilter();
    intentToReceiveFilter.addAction(LOCATION_BCR);
    registerReceiver(broadcastReceiver, intentToReceiveFilter);
  }
  @Override
  protected void onDestroy(){
    super.onDestroy();
    unregisterReceiver(broadcastReceiver);
  }
}

四、 AndroidManifest.xml配置信息
