Android应用中利用ViewPager实现多页面滑动切换效果示例

1、添加android support包
因为上面的几个类都是在android support包中才提供，我们先添加包。
在Eclipse->Window->Android SDK Manager，选择列表中Extras->Android Support Library进行安装。下载完后在android-sdkextrasandroidsupport目录下，这里我们选择v4版本，进入v4目录，拷贝其中的android-support-v4.jar文件到工程的libs目录(若没有新建)下即可，编译时ADT会自动将其导入项目中。

2、新建ViewPager的layout，内容如下

ViewPager用来管理layout并可以左右滑动显示各个页面数据，PagerTabStrip用来显示页面title，android:layout_gravity="top"表示title在顶部，可设置bottom等。

3、新建FragmentActivity页面
FragmentActivity页面含有ViewPager元素，可以用来显示Fragment，定义如下：

public class ViewPagerDemo extends FragmentActivity {


  List fragmentList = new ArrayList();

  List  titleList  = new ArrayList();

  @Override
  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.view_pager_demo);

    ViewPager vp = (ViewPager)findViewById(R.id.viewPager);
    fragmentList.add(new ViewPagerFragment1("页面1"));
    fragmentList.add(new ViewPagerFragment1("页面2"));
    fragmentList.add(new ViewPagerFragment1("页面3"));
    titleList.add("title 1 ");
    titleList.add("title 2 ");
    titleList.add("title 3 ");
    vp.setAdapter(new myPagerAdapter(getSupportFragmentManager(), fragmentList, titleList));
  }


  class myPagerAdapter extends FragmentPagerAdapter {

    private List fragmentList;
    private List  titleList;

    public myPagerAdapter(FragmentManager fm, List fragmentList, List titleList){
      super(fm);
      this.fragmentList = fragmentList;
      this.titleList = titleList;
    }


    @Override
    public Fragment getItem(int arg0) {
      return (fragmentList == null || fragmentList.size() == 0) ? null : fragmentList.get(arg0);
    }


    @Override
    public CharSequence getPageTitle(int position) {
      return (titleList.size() > position) ? titleList.get(position) : "";
    }


    @Override
    public int getCount() {
      return fragmentList == null ? 0 : fragmentList.size();
    }
  }
}

其中的myPagerAdapter集成自ragmentPagerAdapter，为ViewPager提供数据源。

onCreate函数得到ViewPager实例并设置数据源，getSupportFragmentManager表示得到Fragment管理器。ViewPagerFragment1表示具体的页面，见下面介绍。

4、新建Fragment页面
Fragment页面即为左右滑动需要显示的页面，新建类集成Fragment，并重写onCreateView函数即可。onCreateView函数相当于Activity的onCreate函数。如下：

public class ViewPagerFragment1 extends Fragment {

  private String  text;
  private TextView tv = null;

  public ViewPagerFragment1(String text){
    super();
    this.text = text;
  }


  @Override
  public View onCreateView(LayoutInflater inflater, ViewGroup container, Bundle savedInstanceState) {
    View v = inflater.inflate(R.layout.view_pager_fragment_demo1, container, false);
    tv = (TextView)v.findViewById(R.id.viewPagerText);
    tv.setText(text);
    return v;
  }
}

5、示例工程代码：

package cn.trinea.android.demo;

import java.util.ArrayList;
import java.util.List;

import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.support.v4.app.FragmentManager;
import android.support.v4.app.FragmentPagerAdapter;
import android.support.v4.view.ViewPager;

public class ViewPagerDemo extends baseFragmentActivity {

  private static int TOTAL_COUNT = 3;

  @Override
  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState, R.layout.view_pager_demo);

    ViewPager vp = (ViewPager)findViewById(R.id.view_pager);
    List fragmentList = new ArrayList();
    List titleList = new ArrayList();
    for (int i = 0; i < TOTAL_COUNT; i++) {
      ViewPagerFragment viewPagerFragment1 = new ViewPagerFragment();
      Bundle bundle = new Bundle();
      bundle.putInt("upImageId", 0);
      bundle.putString("text", "Page " + i);
      viewPagerFragment1.setArguments(bundle);
      titleList.add("title " + i);
      fragmentList.add(viewPagerFragment1);
    }

    vp.setAdapter(new myPagerAdapter(getSupportFragmentManager(), fragmentList, titleList));

  }

  class myPagerAdapter extends FragmentPagerAdapter {

    private List fragmentList;
    private List  titleList;

    public myPagerAdapter(FragmentManager fm, List fragmentList, List titleList) {
      super(fm);
      this.fragmentList = fragmentList;
      this.titleList = titleList;
    }

    @Override
    public Fragment getItem(int arg0) {
      return (fragmentList == null || fragmentList.size() == 0) ? null : fragmentList.get(arg0);
    }

    @Override
    public CharSequence getPageTitle(int position) {
      return (titleList.size() > position) ? titleList.get(position) : "";
    }

    @Override
    public int getCount() {
      return fragmentList == null ? 0 : fragmentList.size();
    }
  }
}

简单效果如下：
