Android App中ListView仿QQ实现滑动删除效果的要点解析

本来准备在ListView的每个Item的布局上设置一个隐藏的Button，当滑动的时候显示。但是因为每次只要存在一个Button，发现每个Item上的Button相互间不好控制。所以决定继承ListView然后结合PopupWindow。
首先是布局文件：
delete_btn.xml：这里只需要一个Button

主布局文件：activity_main.xml，ListView的每个Item的样式直接使用了系统的android.R.layout.simple_list_item_1

接下来看看QQListView的实现：

package com.example.listviewitemslidedeletebtnshow;

import android.content.Context;
import android.util.AttributeSet;
import android.view.Gravity;
import android.view.LayoutInflater;
import android.view.MotionEvent;
import android.view.View;
import android.view.ViewConfiguration;
import android.widget.Button;
import android.widget.LinearLayout;
import android.widget.ListView;
import android.widget.PopupWindow;

public class QQListView extends ListView
{

  private static final String TAG = "QQlistView";

  // private static final int VELOCITY_SANP = 200;
  // private VelocityTracker mVelocityTracker;

  private int touchSlop;


  private boolean isSliding;


  private int xDown;

  private int yDown;

  private int xMove;

  private int yMove;

  private LayoutInflater mInflater;

  private PopupWindow mPopupWindow;
  private int mPopupWindowHeight;
  private int mPopupWindowWidth;

  private Button mDelBtn;

  private DelButtonClickListener mListener;


  private View mCurrentView;


  private int mCurrentViewPos;


  public QQListView(Context context, AttributeSet attrs)
  {
    super(context, attrs);

    mInflater = LayoutInflater.from(context);
    touchSlop = ViewConfiguration.get(context).getScaledTouchSlop();

    View view = mInflater.inflate(R.layout.delete_btn, null);
    mDelBtn = (Button) view.findViewById(R.id.id_item_btn);
    mPopupWindow = new PopupWindow(view, LinearLayout.LayoutParams.WRAP_CONTENT,
 LinearLayout.LayoutParams.WRAP_CONTENT);

    mPopupWindow.getContentView().measure(0, 0);
    mPopupWindowHeight = mPopupWindow.getContentView().getMeasuredHeight();
    mPopupWindowWidth = mPopupWindow.getContentView().getMeasuredWidth();
  }

  @Override
  public boolean dispatchTouchEvent(MotionEvent ev)
  {
    int action = ev.getAction();
    int x = (int) ev.getX();
    int y = (int) ev.getY();
    switch (action)
    {

    case MotionEvent.ACTION_DOWN:
      xDown = x;
      yDown = y;

      if (mPopupWindow.isShowing())
      {
 dismissPopWindow();
 return false;
      }
      // 获得当前手指按下时的item的位置
      mCurrentViewPos = pointToPosition(xDown, yDown);
      // 获得当前手指按下时的item
      View view = getChildAt(mCurrentViewPos - getFirstVisiblePosition());
      mCurrentView = view;
      break;
    case MotionEvent.ACTION_MOVE:
      xMove = x;
      yMove = y;
      int dx = xMove - xDown;
      int dy = yMove - yDown;

      if (xMove < xDown && Math.abs(dx) > touchSlop && Math.abs(dy) < touchSlop)
      {
 // Log.e(TAG, "touchslop = " + touchSlop + " , dx = " + dx +
 // " , dy = " + dy);
 isSliding = true;
      }
      break;
    }
    return super.dispatchTouchEvent(ev);
  }

  @Override
  public boolean onTouchEvent(MotionEvent ev)
  {
    int action = ev.getAction();

    if (isSliding)
    {
      switch (action)
      {
      case MotionEvent.ACTION_MOVE:

 int[] location = new int[2];
 // 获得当前item的位置x与y
 mCurrentView.getLocationOnScreen(location);
 // 设置popupWindow的动画
 mPopupWindow.setAnimationStyle(R.style.popwindow_delete_btn_anim_style);
 mPopupWindow.update();
 mPopupWindow.showAtLocation(mCurrentView, Gravity.LEFT | Gravity.TOP,
     location[0] + mCurrentView.getWidth(), location[1] + mCurrentView.getHeight() / 2
  - mPopupWindowHeight / 2);
 // 设置删除按钮的回调
 mDelBtn.setonClickListener(new onClickListener()
 {
   @Override
   public void onClick(View v)
   {
     if (mListener != null)
     {
mListener.clickHappend(mCurrentViewPos);
mPopupWindow.dismiss();
     }
   }
 });
 // Log.e(TAG, "mPopupWindow.getHeight()=" + mPopupWindowHeight);

 break;
      case MotionEvent.ACTION_UP:
 isSliding = false;

      }
      // 相应滑动期间屏幕itemClick事件，避免发生冲突
      return true;
    }

    return super.onTouchEvent(ev);
  }


  private void dismissPopWindow()
  {
    if (mPopupWindow != null && mPopupWindow.isShowing())
    {
      mPopupWindow.dismiss();
    }
  }

  public void setDelButtonClickListener(DelButtonClickListener listener)
  {
    mListener = listener;
  }

  interface DelButtonClickListener
  {
    public void clickHappend(int position);
  }

}

代码注释写得很详细，简单说一下，在dispatchTouchEvent中设置当前是否响应用户滑动，然后在onTouchEvent中判断是否响应，如果响应则popupWindow以动画的形式展示出来。当然屏幕上如果存在PopupWindow则屏幕ListView的滚动与Item的点击，以及从右到左滑动时屏幕Item的click事件。
接下来是MainActivity.java，这里代码很简单不做介绍了。

package com.example.listviewitemslidedeletebtnshow;

import java.util.ArrayList;
import java.util.Arrays;
import java.util.List;

import android.app.Activity;
import android.os.Bundle;
import android.view.View;
import android.widget.AdapterView;
import android.widget.AdapterView.OnItemClickListener;
import android.widget.ArrayAdapter;
import android.widget.Toast;

import com.example.listviewitemslidedeletebtnshow.QQListView.DelButtonClickListener;

public class MainActivity extends Activity
{
  private QQListView mListView;
  private ArrayAdapter mAdapter;
  private List mDatas;

  @Override
  protected void onCreate(Bundle savedInstanceState)
  {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);

    mListView = (QQListView) findViewById(R.id.id_listview);
    // 不要直接Arrays.asList
    mDatas = new ArrayList(Arrays.asList("HelloWorld", "Welcome", "Java", "Android", "Servlet", "Struts",
 "Hibernate", "Spring", "HTML5", "Javascript", "Lucene"));
    mAdapter = new ArrayAdapter(this, android.R.layout.simple_list_item_1, mDatas);
    mListView.setAdapter(mAdapter);

    mListView.setDelButtonClickListener(new DelButtonClickListener()
    {
      @Override
      public void clickHappend(final int position)
      {
 Toast.makeText(MainActivity.this, position + " : " + mAdapter.getItem(position), 1).show();
 mAdapter.remove(mAdapter.getItem(position));
      }
    });

    mListView.setonItemClickListener(new onItemClickListener()
    {
      @Override
      public void onItemClick(AdapterView parent, View view, int position, long id)
      {
 Toast.makeText(MainActivity.this, position + " : " + mAdapter.getItem(position), 1).show();
      }
    });
  }
}

效果图如下：楼主使用asm.jar以及gifcamera截的gif，由于button的动画很短感觉截图效果很卡不流畅，大家有什么好的截图，还望推荐。有兴趣的还是下载源码看看效果i。
