Android自定义Chronometer实现短信验证码秒表倒计时功能

本文实例为大家分享了Chronometer实现倒计时功能，Android提供了实现按照秒计时的API，供大家参考，具体内容如下

一、自定义ChronometerView 继续自TextView

主要原理：先设置一个基准倒计时时间mbaseSeconds，内置handler 每隔1s发送一个空消息，mRemainSeconds--，同时刷新界面视图，回调给外部调用者，只到为零。外部调用者可通过start()/pause()/stop()来控制计时器的工作状态。
可以app中发送短信验证码的场景为例，做了一个很粗糙的界面，但功能都实现了。


public class ChronometerView extends TextView {


 public interface onTickChangeListener {


 public void onTickChanged(ChronometerView view, long remainSeconds);
 }

 private long mbase;
 private long mRemainSeconds;
 private boolean mStarted;
 private boolean mReStart;
 private boolean mVisible;
 private boolean mIsEnable;

 private onTickChangeListener mTickListener;

 public ChronometerView(Context context) {
 this(context, null);
 }

 public ChronometerView(Context context, AttributeSet attrs) {
 super(context, attrs, 0);
 }

 public ChronometerView(Context context, AttributeSet attrs, int defStyleAttr) {
 super(context, attrs, defStyleAttr);
 updateText(mRemainSeconds);
 }

 @Override
 protected void onWindowVisibilityChanged(int visibility) {
 super.onWindowVisibilityChanged(visibility);
 mVisible = visibility == VISIBLE;
 updateStatus();
 }

 @Override
 protected void onDetachedFromWindow() {
 super.onDetachedFromWindow();
 mVisible = false;
 updateStatus();
 }


 public void start() {
 if (mReStart && !mStarted) {
  mRemainSeconds = mbase;
 }
 mStarted = true;
 updateStatus();
 }


 public void pause() {
 if (mStarted) {
  mStarted = mReStart = false;
  updateStatus();
 }
 }


 public void stop() {
 mStarted = false;
 mReStart = true;
 updateStatus();
 updateText(mRemainSeconds = 0);
 dispatchTickListener();
 }


 private void updateStatus() {
 boolean isEnable = mVisible && mStarted;
 if (mIsEnable != isEnable) {
  if (isEnable) {
  mHandler.sendMessage(Message.obtain(mHandler, TICK_WHAT));
  } else {
  mHandler.removeMessages(TICK_WHAT);
  }
  mIsEnable = isEnable;
 }
 }

 private static final int TICK_WHAT = 1;

 private Handler mHandler = new Handler() {
 public void handleMessage(android.os.Message msg) {
  if (mRemainSeconds > 0) {
  updateText(--mRemainSeconds);
  dispatchTickListener();
  sendMessageDelayed(Message.obtain(this, TICK_WHAT), 1000);
  }
 }
 };

 private void updateText(long now) {
 String text = DateUtils.formatElapsedTime(now);
 setText(text);
 }


 public void setbaseSeconds(long baseSeconds) {
 if (baseSeconds > 0 && baseSeconds != mbase && !mStarted) {
  mbase = mRemainSeconds = baseSeconds;
  updateText(mRemainSeconds);
 }
 }


 public long getRemainSeconds() {
 return mRemainSeconds;
 }

 public void setonTickChangeListener(onTickChangeListener listener) {
 mTickListener = listener;
 }

 public onTickChangeListener getTickListener() {
 return mTickListener;
 }

 private void dispatchTickListener() {
 if (mTickListener != null) {
  mTickListener.onTickChanged(this, getRemainSeconds());
 }
 }

 @Override
 public void onInitializeAccessibilityEvent(AccessibilityEvent event) {
 super.onInitializeAccessibilityEvent(event);
 event.setClassName(ChronometerView.class.getName());
 }

 @Override
 public void onInitializeAccessibilityNodeInfo(AccessibilityNodeInfo info) {
 super.onInitializeAccessibilityNodeInfo(info);
 info.setClassName(Chronometer.class.getName());
 }
}

 二、xml 中没有加入自定义的控件属性，同TextView

三、在Activity中做一个简单的测试（可以发送短信验证码的实际应用场景为例）

public class ChronometerActivity extends Activity {

 private ChronometerView mChronometerView;

 @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.activity_clock);

 // 自定义计时器
 if (mChronometerView == null) {
  mChronometerView = (ChronometerView) findViewById(R.id.chronometer_view);
  mChronometerView.setbaseSeconds(60);
  mChronometerView.setonTickChangeListener(new onTickChangeListener() {
  @Override
  public void onTickChanged(ChronometerView view, long curTimeMills) {
   System.out.println(curTimeMills);
   view.setEnabled(curTimeMills == 0 || curTimeMills == 60);
   if (curTimeMills == 0) {
   mChronometerView.setText("重新发送");
   }
  }
  });
  mChronometerView.setText("点击发送验证码");
 }
 findViewById(R.id.start_chronometer_view_btn).setonClickListener(mClickListener);
 findViewById(R.id.pause_chronometer_view_btn).setonClickListener(mClickListener);
 findViewById(R.id.stop_chronometer_view_btn).setonClickListener(mClickListener);
 }

 private View.onClickListener mClickListener = new onClickListener() {

 @Override
 public void onClick(View v) {
  switch (v.getId()) {

  case R.id.start_chronometer_view_btn:
  if (mChronometerView != null) {
   mChronometerView.start();
  }
  break;

  case R.id.pause_chronometer_view_btn:
  if (mChronometerView != null) {
   mChronometerView.pause();
  }
  break;

  case R.id.stop_chronometer_view_btn:
  if (mChronometerView != null) {
   mChronometerView.stop();
  }
  break;
  }
 }
 };
}
