Android DrawerLayout实现侧拉菜单功能

效果图

activity_main.xml

注：DrawerLayout下有两个布局，DrawerLayout的第一个子元素是主要内容，即抽屉没有打开时显示的布局，DrawerLayout的第二个子元素是抽屉中的内容，即抽屉布局，layout_gravity为侧拉方向

因为用到Toolbar所以要把ActionBar替换了所以设置

values下设置styles.xml    为NoActionBar





    @color/colorPrimary
    @color/colorPrimaryDark
    @color/colorAccent


    false
    true





MainActivity

package com.example.lenovo.mydrawerlayout;
 import android.os.Bundle;
import android.support.design.widget.Snackbar;
import android.support.v4.view.GravityCompat;
import android.support.v4.widget.DrawerLayout;
import android.support.v7.app.ActionBarDrawerToggle;
import android.support.v7.app.AppCompatActivity;
import android.support.v7.widget.Toolbar;
import android.view.View;
import android.widget.TextView;
public class MainActivity extends AppCompatActivity {
  @Override
  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);
    //Toolbar代替ActionBar
    Toolbar toolbar = (Toolbar) findViewById(R.id.toolbar);
    setSupportActionBar(toolbar);
    // DrawerLayout
    DrawerLayout drawer = (DrawerLayout) findViewById(R.id.drawer_layout);
    //Toolbar上面最左边显示三杠图标监听DrawerLayout
    ActionBarDrawerToggle toggle = new ActionBarDrawerToggle(
 this, drawer, toolbar, R.string.navigation_drawer_open, R.string.navigation_drawer_close);
    drawer.setDrawerListener(toggle);
    toggle.syncState();
    //侧拉页面字体
    TextView t= (TextView) findViewById(R.id.t);
    t.setonClickListener(new View.onClickListener() {
      @Override
      public void onClick(View v) {
 Snackbar.make(v, "侧拉页面", Snackbar.LENGTH_LONG)
     .setAction("Action", null).show();
      }
    });
  }
  @Override
  public void onBackPressed() {
    DrawerLayout drawer = (DrawerLayout) findViewById(R.id.drawer_layout);
    if (drawer.isDrawerOpen(GravityCompat.START)) {
      drawer.closeDrawer(GravityCompat.START);
    } else {
      super.onBackPressed();
    }
  }
}
