android仿iphone滚轮控件显示效果，供大家参考，具体内容如下
在论坛里看到的，自己弄个效果：
这个滚动的WheelView
package kankan.wheel.widget;
import java.util.linkedList;
import java.util.List;
import android.content.Context;
import android.graphics.Canvas;
import android.graphics.Paint;
import android.graphics.Rect;
import android.graphics.drawable.Drawable;
import android.graphics.drawable.GradientDrawable;
import android.graphics.drawable.GradientDrawable.Orientation;
import android.os.Handler;
import android.os.Message;
import android.text.Layout;
import android.text.StaticLayout;
import android.text.TextPaint;
import android.util.AttributeSet;
import android.util.FloatMath;
import android.view.GestureDetector;
import android.view.GestureDetector.SimpleOnGestureListener;
import android.view.MotionEvent;
import android.view.View;
import android.view.animation.Interpolator;
import android.widget.Scroller;
import com.shao.pwd.R;
public class WheelView extends View {
private static final int SCROLLING_DURATION = 400;
private static final int MIN_DELTA_FOR_SCROLLING = 1;
private static final int VALUE_TEXT_COLOR = 0xF0000000;
private static final int ITEMS_TEXT_COLOR = 0xFF000000;
private static final int[] SHADOWS_COLORS = new int[] { 0xFF111111,
0x00AAAAAA, 0x00AAAAAA };
private static final int ADDITIONAL_ITEM_HEIGHT = 15;
private static final int TEXT_SIZE = 24;
private static final int ITEM_OFFSET = TEXT_SIZE / 5;
private static final int ADDITIONAL_ITEMS_SPACE = 10;
private static final int LABEL_OFFSET = 8;
private static final int PADDING = 10;
private static final int DEF_VISIBLE_ITEMS = 5;
// Wheel Values
private WheelAdapter adapter = null;
private int currentItem = 0;
// Widths
private int itemsWidth = 0;
private int labelWidth = 0;
// Count of visible items
private int visibleItems = DEF_VISIBLE_ITEMS;
// Item height
private int itemHeight = 0;
// Text paints
private TextPaint itemsPaint;
private TextPaint valuePaint;
// Layouts
private StaticLayout itemsLayout;
private StaticLayout labelLayout;
private StaticLayout valueLayout;
// Label & background
private String label;
private Drawable centerDrawable;
// Shadows drawables
private GradientDrawable topShadow;
private GradientDrawable bottomShadow;
// Scrolling
private boolean isScrollingPerformed;
private int scrollingOffset;
// Scrolling animation
private GestureDetector gestureDetector;
private Scroller scroller;
private int lastScrollY;
// Cyclic
boolean isCyclic = false;
// Listeners
private List changingListeners = new linkedList();
private List scrollingListeners = new linkedList();
public WheelView(Context context, AttributeSet attrs, int defStyle) {
super(context, attrs, defStyle);
initData(context);
}
public WheelView(Context context, AttributeSet attrs) {
super(context, attrs);
initData(context);
}
public WheelView(Context context) {
super(context);
initData(context);
}
private void initData(Context context) {
gestureDetector = new GestureDetector(context, gestureListener);
gestureDetector.setIsLongpressEnabled(false);
scroller = new Scroller(context);
}
public WheelAdapter getAdapter() {
return adapter;
}
public void setAdapter(WheelAdapter adapter) {
this.adapter = adapter;
invalidateLayouts();
invalidate();
}
public void setInterpolator(Interpolator interpolator) {
scroller.forceFinished(true);
scroller = new Scroller(getContext(), interpolator);
}
public int getVisibleItems() {
return visibleItems;
}
public void setVisibleItems(int count) {
visibleItems = count;
invalidate();
}
public String getLabel() {
return label;
}
public void setLabel(String newLabel) {
if (label == null || !label.equals(newLabel)) {
label = newLabel;
labelLayout = null;
invalidate();
}
}
public void addChangingListener(onWheelChangedListener listener) {
changingListeners.add(listener);
}
public void removeChangingListener(onWheelChangedListener listener) {
changingListeners.remove(listener);
}
protected void notifyChangingListeners(int oldValue, int newValue) {
for (onWheelChangedListener listener : changingListeners) {
listener.onChanged(this, oldValue, newValue);
}
}
public void addScrollingListener(onWheelScrollListener listener) {
scrollingListeners.add(listener);
}
public void removeScrollingListener(onWheelScrollListener listener) {
scrollingListeners.remove(listener);
}
protected void notifyScrollingListenersaboutStart() {
for (onWheelScrollListener listener : scrollingListeners) {
listener.onScrollingStarted(this);
}
}
protected void notifyScrollingListenersaboutEnd() {
for (onWheelScrollListener listener : scrollingListeners) {
listener.onScrollingFinished(this);
}
}
public int getCurrentItem() {
return currentItem;
}
public void setCurrentItem(int index, boolean animated) {
if (adapter == null || adapter.getItemsCount() == 0) {
return; // throw?
}
if (index < 0 || index >= adapter.getItemsCount()) {
if (isCyclic) {
while (index < 0) {
index += adapter.getItemsCount();
}
index %= adapter.getItemsCount();
} else{
return; // throw?
}
}
if (index != currentItem) {
if (animated) {
scroll(index - currentItem, SCROLLING_DURATION);
} else {
invalidateLayouts();
int old = currentItem;
currentItem = index;
notifyChangingListeners(old, currentItem);
invalidate();
}
}
}
public void setCurrentItem(int index) {
setCurrentItem(index, false);
}
public boolean isCyclic() {
return isCyclic;
}
public void setCyclic(boolean isCyclic) {
this.isCyclic = isCyclic;
invalidate();
invalidateLayouts();
}
private void invalidateLayouts() {
itemsLayout = null;
valueLayout = null;
scrollingOffset = 0;
}
private void initResourcesIfNecessary() {
if (itemsPaint == null) {
itemsPaint = new TextPaint(Paint.ANTI_ALIAS_FLAG
| Paint.FAKE_BOLD_TEXT_FLAG);
//itemsPaint.density = getResources().getDisplayMetrics().density;
itemsPaint.setTextSize(TEXT_SIZE);
}
if (valuePaint == null) {
valuePaint = new TextPaint(Paint.ANTI_ALIAS_FLAG
| Paint.FAKE_BOLD_TEXT_FLAG | Paint.DITHER_FLAG);
//valuePaint.density = getResources().getDisplayMetrics().density;
valuePaint.setTextSize(TEXT_SIZE);
valuePaint.setShadowLayer(0.1f, 0, 0.1f, 0xFFC0C0C0);
}
if (centerDrawable == null) {
centerDrawable = getContext().getResources().getDrawable(R.drawable.wheel_val);
}
if (topShadow == null) {
topShadow = new GradientDrawable(Orientation.TOP_BOTTOM, SHADOWS_COLORS);
}
if (bottomShadow == null) {
bottomShadow = new GradientDrawable(Orientation.BOTTOM_TOP, SHADOWS_COLORS);
}
setBackgroundResource(R.drawable.wheel_bg);
}
private int getDesiredHeight(Layout layout) {
if (layout == null) {
return 0;
}
int desired = getItemHeight() * visibleItems - ITEM_OFFSET * 2
- ADDITIONAL_ITEM_HEIGHT;
// Check against our minimum height
desired = Math.max(desired, getSuggestedMinimumHeight());
return desired;
}
private String getTextItem(int index) {
if (adapter == null || adapter.getItemsCount() == 0) {
return null;
}
int count = adapter.getItemsCount();
if ((index < 0 || index >= count) && !isCyclic) {
return null;
} else {
while (index < 0) {
index = count + index;
}
}
index %= count;
return adapter.getItem(index);
}
private String buildText(boolean useCurrentValue) {
StringBuilder itemsText = new StringBuilder();
int addItems = visibleItems / 2 + 1;
for (int i = currentItem - addItems; i <= currentItem + addItems; i++) {
if (useCurrentValue || i != currentItem) {
String text = getTextItem(i);
if (text != null) {
itemsText.append(text);
}
}
if (i < currentItem + addItems) {
itemsText.append("n");
}
}
return itemsText.toString();
}
private int getMaxTextLength() {
WheelAdapter adapter = getAdapter();
if (adapter == null) {
return 0;
}
int adapterLength = adapter.getMaximumLength();
if (adapterLength > 0) {
return adapterLength;
}
String maxText = null;
int addItems = visibleItems / 2;
for (int i = Math.max(currentItem - addItems, 0);
i < Math.min(currentItem + visibleItems, adapter.getItemsCount()); i++) {
String text = adapter.getItem(i);
if (text != null && (maxText == null || maxText.length() < text.length())) {
maxText = text;
}
}
return maxText != null ? maxText.length() : 0;
}
private int getItemHeight() {
if (itemHeight != 0) {
return itemHeight;
} else if (itemsLayout != null && itemsLayout.getLineCount() > 2) {
itemHeight = itemsLayout.getLineTop(2) - itemsLayout.getLineTop(1);
return itemHeight;
}
return getHeight() / visibleItems;
}
private int calculateLayoutWidth(int widthSize, int mode) {
initResourcesIfNecessary();
int width = widthSize;
int maxLength = getMaxTextLength();
if (maxLength > 0) {
float textWidth = FloatMath.ceil(Layout.getDesiredWidth("0", itemsPaint));
itemsWidth = (int) (maxLength * textWidth);
} else {
itemsWidth = 0;
}
itemsWidth += ADDITIONAL_ITEMS_SPACE; // make it some more
labelWidth = 0;
if (label != null && label.length() > 0) {
labelWidth = (int) FloatMath.ceil(Layout.getDesiredWidth(label, valuePaint));
}
boolean recalculate = false;
if (mode == MeasureSpec.EXACTLY) {
width = widthSize;
recalculate = true;
} else {
width = itemsWidth + labelWidth + 2 * PADDING;
if (labelWidth > 0) {
width += LABEL_OFFSET;
}
// Check against our minimum width
width = Math.max(width, getSuggestedMinimumWidth());
if (mode == MeasureSpec.AT_MOST && widthSize < width) {
width = widthSize;
recalculate = true;
}
}
if (recalculate) {
// recalculate width
int pureWidth = width - LABEL_OFFSET - 2 * PADDING;
if (pureWidth <= 0) {
itemsWidth = labelWidth = 0;
}
if (labelWidth > 0) {
double newWidthItems = (double) itemsWidth * pureWidth
/ (itemsWidth + labelWidth);
itemsWidth = (int) newWidthItems;
labelWidth = pureWidth - itemsWidth;
} else {
itemsWidth = pureWidth + LABEL_OFFSET; // no label
}
}
if (itemsWidth > 0) {
createLayouts(itemsWidth, labelWidth);
}
return width;
}
private void createLayouts(int widthItems, int widthLabel) {
if (itemsLayout == null || itemsLayout.getWidth() > widthItems) {
itemsLayout = new StaticLayout(buildText(isScrollingPerformed), itemsPaint, widthItems,
widthLabel > 0 ? Layout.Alignment.ALIGN_OPPOSITE : Layout.Alignment.ALIGN_CENTER,
1, ADDITIONAL_ITEM_HEIGHT, false);
} else {
itemsLayout.increaseWidthTo(widthItems);
}
if (!isScrollingPerformed && (valueLayout == null || valueLayout.getWidth() > widthItems)) {
String text = getAdapter() != null ? getAdapter().getItem(currentItem) : null;
valueLayout = new StaticLayout(text != null ? text : "",
valuePaint, widthItems, widthLabel > 0 ?
Layout.Alignment.ALIGN_OPPOSITE : Layout.Alignment.ALIGN_CENTER,
1, ADDITIONAL_ITEM_HEIGHT, false);
} else if (isScrollingPerformed) {
valueLayout = null;
} else {
valueLayout.increaseWidthTo(widthItems);
}
if (widthLabel > 0) {
if (labelLayout == null || labelLayout.getWidth() > widthLabel) {
labelLayout = new StaticLayout(label, valuePaint,
widthLabel, Layout.Alignment.ALIGN_NORMAL, 1,
ADDITIONAL_ITEM_HEIGHT, false);
} else {
labelLayout.increaseWidthTo(widthLabel);
}
}
}
@Override
protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
int widthMode = MeasureSpec.getMode(widthMeasureSpec);
int heightMode = MeasureSpec.getMode(heightMeasureSpec);
int widthSize = MeasureSpec.getSize(widthMeasureSpec);
int heightSize = MeasureSpec.getSize(heightMeasureSpec);
int width = calculateLayoutWidth(widthSize, widthMode);
int height;
if (heightMode == MeasureSpec.EXACTLY) {
height = heightSize;
} else {
height = getDesiredHeight(itemsLayout);
if (heightMode == MeasureSpec.AT_MOST) {
height = Math.min(height, heightSize);
}
}
setMeasuredDimension(width, height);
}
@Override
protected void onDraw(Canvas canvas) {
super.onDraw(canvas);
if (itemsLayout == null) {
if (itemsWidth == 0) {
calculateLayoutWidth(getWidth(), MeasureSpec.EXACTLY);
} else {
createLayouts(itemsWidth, labelWidth);
}
}
if (itemsWidth > 0) {
canvas.save();
// Skip padding space and hide a part of top and bottom items
canvas.translate(PADDING, -ITEM_OFFSET);
drawItems(canvas);
drawValue(canvas);
canvas.restore();
}
drawCenterRect(canvas);
drawShadows(canvas);
}
private void drawShadows(Canvas canvas) {
topShadow.setBounds(0, 0, getWidth(), getHeight() / visibleItems);
topShadow.draw(canvas);
bottomShadow.setBounds(0, getHeight() - getHeight() / visibleItems,
getWidth(), getHeight());
bottomShadow.draw(canvas);
}
private void drawValue(Canvas canvas) {
valuePaint.setColor(VALUE_TEXT_COLOR);
valuePaint.drawableState = getDrawableState();
Rect bounds = new Rect();
itemsLayout.getLineBounds(visibleItems / 2, bounds);
// draw label
if (labelLayout != null) {
canvas.save();
canvas.translate(itemsLayout.getWidth() + LABEL_OFFSET, bounds.top);
labelLayout.draw(canvas);
canvas.restore();
}
// draw current value
if (valueLayout != null) {
canvas.save();
canvas.translate(0, bounds.top + scrollingOffset);
valueLayout.draw(canvas);
canvas.restore();
}
}
private void drawItems(Canvas canvas) {
canvas.save();
int top = itemsLayout.getLineTop(1);
canvas.translate(0, - top + scrollingOffset);
itemsPaint.setColor(ITEMS_TEXT_COLOR);
itemsPaint.drawableState = getDrawableState();
itemsLayout.draw(canvas);
canvas.restore();
}
private void drawCenterRect(Canvas canvas) {
int center = getHeight() / 2;
int offset = getItemHeight() / 2;
centerDrawable.setBounds(0, center - offset, getWidth(), center + offset);
centerDrawable.draw(canvas);
}
@Override
public boolean onTouchEvent(MotionEvent event) {
WheelAdapter adapter = getAdapter();
if (adapter == null) {
return true;
}
if (!gestureDetector.onTouchEvent(event) && event.getAction() == MotionEvent.ACTION_UP) {
justify();
}
return true;
}
private void doScroll(int delta) {
scrollingOffset += delta;
int count = scrollingOffset / getItemHeight();
int pos = currentItem - count;
if (isCyclic && adapter.getItemsCount() > 0) {
// fix position by rotating
while (pos < 0) {
pos += adapter.getItemsCount();
}
pos %= adapter.getItemsCount();
} else if (isScrollingPerformed) {
//
if (pos < 0) {
count = currentItem;
pos = 0;
} else if (pos >= adapter.getItemsCount()) {
count = currentItem - adapter.getItemsCount() + 1;
pos = adapter.getItemsCount() - 1;
}
} else {
// fix position
pos = Math.max(pos, 0);
pos = Math.min(pos, adapter.getItemsCount() - 1);
}
int offset = scrollingOffset;
if (pos != currentItem) {
setCurrentItem(pos, false);
} else {
invalidate();
}
// update offset
scrollingOffset = offset - count * getItemHeight();
if (scrollingOffset > getHeight()) {
scrollingOffset = scrollingOffset % getHeight() + getHeight();
}
}
// gesture listener
private SimpleonGestureListener gestureListener = new SimpleonGestureListener() {
public boolean onDown(MotionEvent e) {
if (isScrollingPerformed) {
scroller.forceFinished(true);
clearMessages();
return true;
}
return false;
}
public boolean onScroll(MotionEvent e1, MotionEvent e2, float distanceX, float distanceY) {
startScrolling();
doScroll((int)-distanceY);
return true;
}
public boolean onFling(MotionEvent e1, MotionEvent e2, float velocityX, float velocityY) {
lastScrollY = currentItem * getItemHeight() + scrollingOffset;
int maxY = isCyclic ? 0x7FFFFFFF : adapter.getItemsCount() * getItemHeight();
int minY = isCyclic ? -maxY : 0;
scroller.fling(0, lastScrollY, 0, (int) -velocityY / 2, 0, 0, minY, maxY);
setNextMessage(MESSAGE_SCROLL);
return true;
}
};
// Messages
private final int MESSAGE_SCROLL = 0;
private final int MESSAGE_JUSTIFY = 1;
private void setNextMessage(int message) {
clearMessages();
animationHandler.sendEmptyMessage(message);
}
private void clearMessages() {
animationHandler.removeMessages(MESSAGE_SCROLL);
animationHandler.removeMessages(MESSAGE_JUSTIFY);
}
// animation handler
private Handler animationHandler = new Handler() {
public void handleMessage(Message msg) {
scroller.computeScrollOffset();
int currY = scroller.getCurrY();
int delta = lastScrollY - currY;
lastScrollY = currY;
if (delta != 0) {
doScroll(delta);
}
// scrolling is not finished when it comes to final Y
// so, finish it manually
if (Math.abs(currY - scroller.getFinalY()) < MIN_DELTA_FOR_SCROLLING) {
currY = scroller.getFinalY();
scroller.forceFinished(true);
}
if (!scroller.isFinished()) {
animationHandler.sendEmptyMessage(msg.what);
} else if (msg.what == MESSAGE_SCROLL) {
justify();
} else {
finishScrolling();
}
}
};
private void justify() {
if (adapter == null) {
return;
}
lastScrollY = 0;
int offset = scrollingOffset;
int itemHeight = getItemHeight();
boolean needToIncrease = offset > 0 ? currentItem < adapter.getItemsCount() : currentItem > 0;
if ((isCyclic || needToIncrease) && Math.abs((float) offset) > (float) itemHeight / 2) {
if (offset < 0)
offset += itemHeight + MIN_DELTA_FOR_SCROLLING;
else
offset -= itemHeight + MIN_DELTA_FOR_SCROLLING;
}
if (Math.abs(offset) > MIN_DELTA_FOR_SCROLLING) {
scroller.startScroll(0, 0, 0, offset, SCROLLING_DURATION);
setNextMessage(MESSAGE_JUSTIFY);
} else {
finishScrolling();
}
}
private void startScrolling() {
if (!isScrollingPerformed) {
isScrollingPerformed = true;
notifyScrollingListenersaboutStart();
}
}
void finishScrolling() {
if (isScrollingPerformed) {
notifyScrollingListenersaboutEnd();
isScrollingPerformed = false;
}
invalidateLayouts();
invalidate();
}
public void scroll(int itemsToScroll, int time) {
scroller.forceFinished(true);
lastScrollY = scrollingOffset;
int offset = itemsToScroll * getItemHeight();
scroller.startScroll(0, lastScrollY, 0, offset - lastScrollY, time);
setNextMessage(MESSAGE_SCROLL);
startScrolling();
}
}
主布局文件
适配器adapter
package kankan.wheel.widget;
public interface WheelAdapter {
public int getItemsCount();
public String getItem(int index);
public int getMaximumLength();
}
package kankan.wheel.widget;
public class NumericWheelAdapter implements WheelAdapter {
public static final int DEFAULT_MAX_VALUE = 9;
private static final int DEFAULT_MIN_VALUE = 0;
// Values
private int minValue;
private int maxValue;
// format
private String format;
public NumericWheelAdapter() {
this(DEFAULT_MIN_VALUE, DEFAULT_MAX_VALUE);
}
public NumericWheelAdapter(int minValue, int maxValue) {
this(minValue, maxValue, null);
}
public NumericWheelAdapter(int minValue, int maxValue, String format) {
this.minValue = minValue;
this.maxValue = maxValue;
this.format = format;
}
@Override
public String getItem(int index) {
if (index >= 0 && index < getItemsCount()) {
int value = minValue + index;
return format != null ? String.format(format, value) : Integer.toString(value);
}
return null;
}
@Override
public int getItemsCount() {
return maxValue - minValue + 1;
}
@Override
public int getMaximumLength() {
int max = Math.max(Math.abs(maxValue), Math.abs(minValue));
int maxLen = Integer.toString(max).length();
if (minValue < 0) {
maxLen++;
}
return maxLen;
}
}
监听器Listener文件：
package kankan.wheel.widget;
public interface onWheelScrollListener {
void onScrollingStarted(WheelView wheel);
void onScrollingFinished(WheelView wheel);
}
package kankan.wheel.widget;
public interface onWheelChangedListener {
void onChanged(WheelView wheel, int oldValue, int newValue);
}
以上就是本文的全部内容，希望对大家的学习有所帮助，也希望大家多多支持考高分网。
