最近研究了一下如何在Android上实现CoverFlow效果的控件，其实早在2010年，就有Neil Davies开发并开源出了这个控件，Neil大神的这篇博客地址。首先是阅读源码，弄明白核心思路后，自己重新写了一遍这个控件，并加入了详尽的注释以便日后查阅；而后在使用过程中，发现了有两点可以改进：
（1）初始图片位于中间，左边空了一半空间，比较难看，可以改为重复滚动地展示；
（2）由于图片一开始就需要加载出来，所以对内存开销较大，很容易OOM，需要对图片的内存空间进行压缩。
这个自定义控件包括4个部分，用于创建及提供图片对象的ImageAdapter，计算图片旋转角度等的自定义控件GalleryFlow，压缩采样率解析Bitmap的工具类BitmapScaleDownUtil，以及承载自定义控件的Gallery3DActivity。
首先是ImageAdapter，代码如下：
package pym.test.gallery3d.widget;
import pym.test.gallery3d.util.BitmapScaleDownUtil;
import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.Bitmap.Config;
import android.graphics.Canvas;
import android.graphics.LinearGradient;
import android.graphics.Matrix;
import android.graphics.Paint;
import android.graphics.PaintFlagsDrawFilter;
import android.graphics.PorterDuff.Mode;
import android.graphics.PorterDuffXfermode;
import android.graphics.Shader.TileMode;
import android.view.View;
import android.view.ViewGroup;
import android.widget.baseAdapter;
import android.widget.Gallery;
import android.widget.ImageView;
public class ImageAdapter extends baseAdapter
{
private final String TAG = "ImageAdapter";
private Context mContext;
//图片数组
private int[] mImageIds ;
//图片控件数组
private ImageView[] mImages;
//图片控件LayoutParams
private GalleryFlow.LayoutParams mImagesLayoutParams;
public ImageAdapter(Context context, int[] imageIds)
{
mContext = context;
mImageIds = imageIds;
mImages = new ImageView[mImageIds.length];
mImagesLayoutParams = new GalleryFlow.LayoutParams(Gallery.LayoutParams.WRAP_CONTENT, Gallery.LayoutParams.WRAP_CONTENT);
}
public void createImages(int imageWidth, int imageHeight)
{
// 原图与倒影的间距5px
final int gapHeight = 5;
int index = 0;
for (int imageId : mImageIds)
{
// 解析原图，生成原图Bitmap对象
// Bitmap originalImage = BitmapFactory.decodeResource(mContext.getResources(), imageId);
Bitmap originalImage = BitmapScaleDownUtil.decodeSampledBitmapFromResource(mContext.getResources(), imageId, imageWidth, imageHeight);
int width = originalImage.getWidth();
int height = originalImage.getHeight();
// Y轴方向反向，实质就是X轴翻转
Matrix matrix = new Matrix();
matrix.setScale(1, -1);
// 且仅取原图下半部分创建倒影Bitmap对象
Bitmap reflectionImage = Bitmap.createBitmap(originalImage, 0, height / 2, width, height / 2, matrix, false);
// 创建一个可包含原图+间距+倒影的新图Bitmap对象
Bitmap bitmapWithReflection = Bitmap.createBitmap(width, (height + gapHeight + height / 2), Config.ARGB_8888);
// 在新图Bitmap对象之上创建画布
Canvas canvas = new Canvas(bitmapWithReflection);
// 抗锯齿效果
canvas.setDrawFilter(new PaintFlagsDrawFilter(0, Paint.ANTI_ALIAS_FLAG));
// 绘制原图
canvas.drawBitmap(originalImage, 0, 0, null);
// 绘制间距
Paint gapPaint = new Paint();
gapPaint.setColor(0xFFCCCCCC);
canvas.drawRect(0, height, width, height + gapHeight, gapPaint);
// 绘制倒影
canvas.drawBitmap(reflectionImage, 0, height + gapHeight, null);
// 创建一个线性渐变的渲染器用于渲染倒影
Paint paint = new Paint();
LinearGradient shader = new LinearGradient(0, height, 0, (height + gapHeight + height / 2), 0x70ffffff, 0x00ffffff, TileMode.CLAMP);
// 设置画笔渲染器
paint.setShader(shader);
// 设置图片混合模式
paint.setXfermode(new PorterDuffXfermode(Mode.DST_IN));
// 渲染倒影+间距
canvas.drawRect(0, height, width, (height + gapHeight + height / 2), paint);
ImageView imageView = new ImageView(mContext);
imageView.setImageBitmap(bitmapWithReflection);
imageView.setLayoutParams(mImagesLayoutParams);
// 打log
imageView.setTag(index);
originalImage.recycle();
reflectionImage.recycle();
// bitmapWithReflection.recycle();
mImages[index++] = imageView;
}
}
@Override
public int getCount()
{
return Integer.MAX_VALUE;
}
@Override
public Object getItem(int position)
{
return mImages[position];
}
@Override
public long getItemId(int position)
{
return position;
}
@Override
public View getView(int position, View convertView, ViewGroup parent)
{
return mImages[position % mImages.length];
}
}
其次是GalleryFlow，代码如下：
package pym.test.gallery3d.widget;
import android.content.Context;
import android.graphics.Camera;
import android.graphics.Matrix;
import android.util.AttributeSet;
import android.util.Log;
import android.view.View;
import android.view.animation.Transformation;
import android.widget.Gallery;
public class GalleryFlow extends Gallery
{
private final String TAG = "GalleryFlow";
// 边缘图片最大旋转角度
private final float MAX_ROTATION_ANGLE = 75;
// 中心图片最大前置距离
private final float MAX_TRANSLATE_DISTANCE = -100;
// GalleryFlow中心X坐标
private int mGalleryFlowCenterX;
// 3D变换Camera
private Camera mCamera = new Camera();
public GalleryFlow(Context context, AttributeSet attrs)
{
super(context, attrs);
// 开启，在滑动过程中，回调getChildStaticTransformation()
this.setStaticTransformationsEnabled(true);
}
private int getCenterXOfCoverflow()
{
return (getWidth() - getPaddingLeft() - getPaddingRight()) / 2 + getPaddingLeft();
}
private int getCenterXOfView(View childView)
{
return childView.getLeft() + childView.getWidth() / 2;
}
@Override
protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec)
{
super.onMeasure(widthMeasureSpec, heightMeasureSpec);
mGalleryFlowCenterX = getCenterXOfCoverflow();
Log.d(TAG, "onMeasure, mGalleryFlowCenterX = " + mGalleryFlowCenterX);
}
@Override
protected void onLayout(boolean changed, int l, int t, int r, int b)
{
super.onLayout(changed, l, t, r, b);
mGalleryFlowCenterX = getCenterXOfCoverflow();
Log.d(TAG, "onLayout, mGalleryFlowCenterX = " + mGalleryFlowCenterX);
}
@Override
protected void onSizeChanged(int w, int h, int oldw, int oldh)
{
super.onSizeChanged(w, h, oldw, oldh);
mGalleryFlowCenterX = getCenterXOfCoverflow();
Log.d(TAG, "onSizeChanged, mGalleryFlowCenterX = " + mGalleryFlowCenterX);
}
@Override
protected boolean getChildStaticTransformation(View childView, Transformation t)
{
// 计算旋转角度
float rotationAngle = calculateRotationAngle(childView);
// 计算前置距离
float translateDistance = calculateTranslateDistance(childView);
// 开始3D变换
transformChildView(childView, t, rotationAngle, translateDistance);
return true;
}
private float calculateRotationAngle(View childView)
{
final int childCenterX = getCenterXOfView(childView);
float rotationAngle = 0;
rotationAngle = (mGalleryFlowCenterX - childCenterX) / (float) mGalleryFlowCenterX * MAX_ROTATION_ANGLE;
if (rotationAngle > MAX_ROTATION_ANGLE)
{
rotationAngle = MAX_ROTATION_ANGLE;
}
else if (rotationAngle < -MAX_ROTATION_ANGLE)
{
rotationAngle = -MAX_ROTATION_ANGLE;
}
return rotationAngle;
}
private float calculateTranslateDistance(View childView)
{
final int childCenterX = getCenterXOfView(childView);
float translateDistance = 0;
if (mGalleryFlowCenterX == childCenterX)
{
translateDistance = MAX_TRANSLATE_DISTANCE;
}
return translateDistance;
}
private void transformChildView(View childView, Transformation t, float rotationAngle, float translateDistance)
{
t.clear();
t.setTransformationType(Transformation.TYPE_MATRIX);
final Matrix imageMatrix = t.getMatrix();
final int imageWidth = childView.getWidth();
final int imageHeight = childView.getHeight();
mCamera.save();
// 在Y轴上旋转，位于中心的图片不旋转，中心两侧的图片竖向向里或向外翻转。
mCamera.rotateY(rotationAngle);
// 在Z轴上前置，位于中心的图片会有放大的效果
mCamera.translate(0, 0, translateDistance);
// 开始变换（我的理解是：移动Camera，在2D视图上产生3D效果）
mCamera.getMatrix(imageMatrix);
imageMatrix.preTranslate(-imageWidth / 2, -imageHeight / 2);
imageMatrix.postTranslate(imageWidth / 2, imageHeight / 2);
mCamera.restore();
}
}
Bitmap解析用具BitmapScaleDownUtil，代码如下：
package pym.test.gallery3d.util;
import android.content.res.Resources;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.view.Display;
public class BitmapScaleDownUtil
{
private final String TAG = "BitmapScaleDownUtil";
public static int[] getScreenDimension(Display display)
{
int[] dimension = new int[2];
dimension[0] = display.getWidth();
dimension[1] = display.getHeight();
return dimension;
}
public static Bitmap decodeSampledBitmapFromResource(Resources res, int resId, int reqWidth, int reqHeight)
{
// step1，将inJustDecodeBounds置为true，以解析Bitmap真实尺寸
final BitmapFactory.Options options = new BitmapFactory.Options();
options.inJustDecodeBounds = true;
BitmapFactory.decodeResource(res, resId, options);
// step2，计算Bitmap取样比例
options.inSampleSize = calculateInSampleSize(options, reqWidth, reqHeight);
// step3，将inJustDecodeBounds置为false，以取样比列解析Bitmap
options.inJustDecodeBounds = false;
return BitmapFactory.decodeResource(res, resId, options);
}
private static int calculateInSampleSize(BitmapFactory.Options options, int reqWidth, int reqHeight)
{
// 默认取样比例为1:1
int inSampleSize = 1;
// Bitmap原始尺寸
final int width = options.outWidth;
final int height = options.outHeight;
// 取最大取样比例
if (height > reqHeight || width > reqWidth)
{
final int widthRatio = Math.round((float) width / (float) reqWidth);
final int heightRatio = Math.round((float) height / (float) reqHeight);
// 取样比例为X:1，其中X>=1
inSampleSize = Math.max(widthRatio, heightRatio);
}
return inSampleSize;
}
}
测试控件的Gallery3DActivity，代码如下：
package pym.test.gallery3d.main;
import pym.test.gallery3d.R;
import pym.test.gallery3d.util.BitmapScaleDownUtil;
import pym.test.gallery3d.widget.GalleryFlow;
import pym.test.gallery3d.widget.ImageAdapter;
import android.app.Activity;
import android.content.Context;
import android.os.Bundle;
public class Gallery3DActivity extends Activity
{
private final String TAG = "Gallery3DActivity";
private Context mContext;
// 图片缩放倍率（相对屏幕尺寸的缩小倍率）
public static final int SCALE_FACTOR = 8;
// 图片间距（控制各图片之间的距离）
private final int GALLERY_SPACING = -10;
// 控件
private GalleryFlow mGalleryFlow;
@Override
protected void onCreate(Bundle savedInstanceState)
{
super.onCreate(savedInstanceState);
mContext = getApplicationContext();
setContentView(R.layout.gallery_3d_activity_layout);
initGallery();
}
private void initGallery()
{
// 图片ID
int[] images = {
R.drawable.picture_1,
R.drawable.picture_2,
R.drawable.picture_3,
R.drawable.picture_4,
R.drawable.picture_5,
R.drawable.picture_6,
R.drawable.picture_7 };
ImageAdapter adapter = new ImageAdapter(mContext, images);
// 计算图片的宽高
int[] dimension = BitmapScaleDownUtil.getScreenDimension(getWindowManager().getDefaultDisplay());
int imageWidth = dimension[0] / SCALE_FACTOR;
int imageHeight = dimension[1] / SCALE_FACTOR;
// 初始化图片
adapter.createImages(imageWidth, imageHeight);
// 设置Adapter，显示位置位于控件中间，这样使得左右均可"无限"滑动
mGalleryFlow = (GalleryFlow) findViewById(R.id.gallery_flow);
mGalleryFlow.setSpacing(GALLERY_SPACING);
mGalleryFlow.setAdapter(adapter);
mGalleryFlow.setSelection(Integer.MAX_VALUE / 2);
}
}
see效果图~~~
