项目中用到自定义尺子的样式：
原代码在github上找的，地址：https://github.com/QQabby/HorizontalRuler
原效果为
因为跟自己要使用的view稍有不同 所以做了一些修改，修改的注释都放在代码中了，特此记录一下。
首先是一个自定义View：
public class RuleView extends View {
private Paint paint;
private Context context;
private int maxValue = 500;
private float startX ;
private float startY ;
private float yLenght ;
// private float gap = 8f;
private float gap = 10;
private float textGap = 10f;
private float smallHeight = 10f;
private float largeHeight = 22f;
private DecimalFormat format;
private DisplayMetrics metrics = null;
private float mFontSize;
private Handler mScrollHandler = null;
private MyHorizontalScrollView horizontalScrollView;
private int mCurrentX = -999999999;
// private float unit = 10f;
private int unit = 10;//隔unit个刻度写一个数字
//每个大刻度代表值iValue
private int iValue = 10;
boolean isDraw = true;
public RuleView(Context context) {
super(context);
this.context = context;
init();
}
public void setHorizontalScrollView(
MyHorizontalScrollView horizontalScrollView) {
this.horizontalScrollView = horizontalScrollView;
this.horizontalScrollView.setonTouchListener(new onTouchListener() {
@Override
public boolean onTouch(View v, MotionEvent event) {
final int action = event.getAction();
switch (action) {
case MotionEvent.ACTION_DOWN:
break;
case MotionEvent.ACTION_MOVE:
mScrollHandler.removeCallbacks(mScrollRunnable);
break;
case MotionEvent.ACTION_UP:
mScrollHandler.post(mScrollRunnable);
break;
}
return false;
}
});
}
public RuleView(Context context, AttributeSet attrs) {
super(context, attrs);
this.context = context;
init();
}
public void init() {
// format = new DecimalFormat("0.0");
format = new DecimalFormat("0");//不使用浮点数格式
metrics = new DisplayMetrics();
WindowManager wmg = (WindowManager) context
.getSystemService(Context.WINDOW_SERVICE);
wmg.getDefaultDisplay().getMetrics(metrics);
paint = new Paint(Paint.ANTI_ALIAS_FLAG);
paint.setStyle(Paint.Style.FILL);
paint.setStrokeWidth(getResources().getDimension(R.dimen.ui_1_dip));
// paint.setStrokeWidth(2);
paint.setColor(Color.parseColor("#999999"));
mFontSize = ScreenUtil.dip2px(context, 16);
// startY = ScreenUtil.dip2px(context, 20f);
startY = ScreenUtil.dip2px(context, 0);//Y轴由0开始，即最顶端，不用设置适配布局文件RuleView的android:layout_marginTop="-20dp"
yLenght = ScreenUtil.dip2px(context, 10);
// gap = ScreenUtil.dip2px(context, 8f);
gap = ScreenUtil.dip2px(context, 10);
// startX = ScreenUtil.getScreenWidth(context)/ 2.0f- getResources().getDimension(R.dimen.ui_10_dip) ;
startX = ScreenUtil.getScreenWidth(context)/ 2.0f;//X轴不减去10dp，则三角形顶点可以刚好最准0位置
// + getResources().getDimension(R.dimen.text_h2)/2.0f
// Util.dip2px(context, 13f) +
mScrollHandler = new Handler(context.getMainLooper());
}
@Override
protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
float width = maxValue * gap + ScreenUtil.getScreenWidth(context) - getResources().getDimension(R.dimen.ui_10_dip)*2.0f ;
// int widthMode = MeasureSpec.getMode(heightMeasureSpec);
// if(widthMode == MeasureSpec.AT_MOST){
// Log.d("TAG", "mode::AT_MOST");
// }else if(widthMode == MeasureSpec.EXACTLY){
// Log.d("TAG", "mode::EXACTLY");
// }else if(widthMode == MeasureSpec.UNSPECIFIED){
// Log.d("TAG", "mode::UNSPECIFIED");
// }
setMeasuredDimension((int) width, heightMeasureSpec);
}
@Override
protected void onDraw(final Canvas canvas) {
super.onDraw(canvas);
// 画刻度线
paint.setColor(getResources().getColor(R.color.gray_bg_high));// 刻度颜色
for (int i = 0; i <= maxValue; i++) {
if (i % 5 == 0) {
yLenght = ScreenUtil.dip2px(context, largeHeight);
} else {
yLenght = ScreenUtil.dip2px(context, smallHeight);
}
canvas.drawLine(i * gap + startX, startY, i * gap + startX, yLenght
+ startY, paint);
}
paint.setTextSize(mFontSize);
// 每10个刻度写一个数字
textGap = gap * unit;
// 画刻度文字30
paint.setColor(getResources().getColor(R.color.textGray));// 文字颜色
for (int i = 0; i <= maxValue / unit; i++) {
// String text = format.format(i + 1) + "";//从0开始计数时不用加1
String text = format.format(i * iValue) + "";//乘以每刻度的值iValue
// 获取文本的宽度
float width = ScreenUtil.px2dip(context, calculateTextWidth(text)) / 2f;
canvas.drawText(
text,
startX - width + i * textGap,
(startY + ScreenUtil.dip2px(context, largeHeight))
+ ScreenUtil.dip2px(context, 24), paint);//字体大小
}
}
private float calculateTextWidth(String text) {
if (TextUtils.isEmpty(text)) {
return 0;
}
TextPaint textPaint = new TextPaint();
textPaint.setTextSize(mFontSize * metrics.scaledDensity);
final float textWidth = textPaint.measureText(text);
return textWidth;
}
DecimalFormat df = new DecimalFormat("0.0");
int scrollWidth = 0;
public void setScrollerChanaged(int l, int t, int oldl, int oldt) {
// 滑动的距离
scrollWidth = l;
float number = scrollWidth / gap;
float result = number / unit;
listener.onSlide(result);
}
public onChangedListener listener;
public interface onChangedListener {
void onSlide(float number);
}
public void onChangedListener(onChangedListener listener) {
this.listener = listener;
}
private Runnable mScrollRunnable = new Runnable() {
@Override
public void run() {
if (mCurrentX == horizontalScrollView.getScrollX()) {// 滚动停止了
try {
float x = horizontalScrollView.getScrollX();
float value = (x / (gap * unit));// 当前的值
String s = df.format(value);
// 滑动到11.0 ok
int scrollX = (int) (Double.parseDouble(s) * gap * unit);
horizontalScrollView.smoothScrollTo(scrollX, 0);
} catch (NumberFormatException numExp) {
numExp.printStackTrace();
}
mScrollHandler.removeCallbacks(this);
} else {
mCurrentX = horizontalScrollView.getScrollX();
mScrollHandler.postDelayed(this, 50);
}
}
};
public void setDefaultScalevalue(float scalevalue) {
// final int scrollX = (int) ((scalevalue - 1.0f) * gap * unit);//从0开始计数时不用减去1
final int scrollX = (int) (scalevalue * gap * unit / 10);//每个值在设置刻度时会乘以10，所以除去
new Handler().postDelayed(new Runnable() {
@Override
public void run() {
horizontalScrollView.smoothScrollTo(scrollX, 0);
}
}, 100);
}
public void setScalevalue(int iValue) {
this.iValue = iValue;
}
public void setMinScalevalue(Float minScalevalue) {
// this.minScalevalue = minScalevalue;
}
public Float getMaxScalevalue() {
// return maxScalevalue;
return 33.0f;
}
public void setMaxScalevalue(Float maxScalevalue) {
// this.maxScalevalue = maxScalevalue;
}
public void setScaleScroll(float scalevalue) {
int scrollX = (int) ((scalevalue - 1.0f) * gap * unit);
horizontalScrollView.smoothScrollTo(scrollX, 0);
}
}
另外用到一个自定义的scrollView：
public class MyHorizontalScrollView extends HorizontalScrollView {
private onScrollListener onScrollListener = null;
public MyHorizontalScrollView(Context context) {
this(context, null);
}
public MyHorizontalScrollView(Context context, AttributeSet attrs) {
this(context, attrs, 0);
}
public MyHorizontalScrollView(Context context, AttributeSet attrs,
int defStyleAttr) {
super(context, attrs, defStyleAttr);
}
@Override
protected void onScrollChanged(int l, int t, int oldl, int oldt) {
super.onScrollChanged(l, t, oldl, oldt);
if(onScrollListener != null){
onScrollListener.onScrollChanged(l, t, oldl, oldt);
}
}
public interface onScrollListener {
public void onScrollChanged(int l, int t, int oldl, int oldt);
}
public void setonScrollListener(onScrollListener onScrollListener) {
this.onScrollListener = onScrollListener;
}
}
直尺上的黄色三角标其实是嵌在布局上的，在drawble文件中实现
下面是布局文件,注意RuleView是嵌在ScrollView中的：
最后在界面中的使用：
ruleView = (RuleView) findViewById(R.id.rule_view);
horizontalScrollView = (MyHorizontalScrollView) findViewById(R.id.hor_scrollview);
horizontalScrollView.setOverScrollMode(View.OVER_SCROLL_NEVER);// 去掉超出滑动后出现的阴影效果
// 设置水平滑动
ruleView.setHorizontalScrollView(horizontalScrollView);
ruleView.setDefaultScalevalue(num);
// 当滑动尺子的时候
horizontalScrollView.setonScrollListener(new MyHorizontalScrollView.onScrollListener() {
@Override
public void onScrollChanged(int l, int t, int oldl, int oldt) {
ruleView.setScrollerChanaged(l, t, oldl, oldt);
}
});
ruleView.onChangedListener(new RuleView.onChangedListener() {
@Override
public void onSlide(float number) {
int num = (int) (number * 10);
tvNum.setText(num+"");
}
});
