介绍
小提示:上面一点有一个目录,可以快速定位到自己需要看的类。
今天对前面的代码有了小小的修改,让代码更加完善了一点。
至于用户唯一标识码uuid,会在以后修改成程序内部生成的,
现在的uuid还是由用户自己设置。
今天对这个程序,添加了用户界面的表现层的一部分,增加了公共类 枚举,
下面贴出目前我写的这个程序的全部代码:我会逐渐的写完这个程序的,请大家放心!(需要实现的功能在这个书店管理系统的系列一可以找到,我为这个系列的文章已经分类了,方便大家寻找)
这个系列的博客是不会断的。
现在的代码分层:
现在的程序运行后的图片:
我按照从目录上面到下面的顺序贴出代码:
请注意!这个代码顺序并不是我写代码的顺序!
如果你们要参考我的写,请不要按照我贴的代码的顺序。
应该先写公共类,工具类。
再次:数据层类—>逻辑层类—>表现层类
现在程序运行后的部分图片:
UserTypeEnum类:
cn.hncu.bookStore.common;
UserTypeEnum类:
package cn.hncu.bookStore.common;
public enum UserTypeEnum {
ADMIN(1,"超级管理员"),
BOOK(2,"图书管理员"),
IN(3,"进货管理员"),
OUT(4,"销售管理员"),
STOCK(5,"库存管理员");
private final int type;
private final String name;
private UserTypeEnum(int type, String name) {
this.type=type;
this.name=name;
}
public int getType() {
return type;
}
public String getName() {
return name;
}
public static String getNameByType(int type){
for(UserTypeEnum userType:UserTypeEnum.values()){
if(userType.getType()==type){
return userType.getName();
}
}
throw new IllegalArgumentException("枚举中没有对应的用户类型:"+type);
}
public static int getTypeByName(String name){
for(UserTypeEnum userType:UserTypeEnum.values()){
if(userType.getName().equals(name)){
return userType.getType();
}
}
throw new IllegalArgumentException("枚举中没有对应的用户类型:"+name);
}
}
UserEbi接口:
cn.hncu.bookStore.user.business.ebi;
UserEbi接口:
package cn.hncu.bookStore.user.business.ebi;
import java.util.List;
import cn.hncu.bookStore.user.vo.UserModel;
import cn.hncu.bookStore.user.vo.UserQueryModel;
public interface UserEbi {
public boolean create(UserModel user);
public boolean delete(String uuid);
public boolean update(UserModel user);
public List getAll();
public List getbyCondition(UserQueryModel uqm);
public UserModel getSingle(String uuid);
}
UserEbo类:
cn.hncu.bookStore.user.business.ebo;
UserEbo类:
package cn.hncu.bookStore.user.business.ebo;
import java.util.List;
import cn.hncu.bookStore.user.business.ebi.UserEbi;
import cn.hncu.bookStore.user.dao.dao.UserDao;
import cn.hncu.bookStore.user.dao.factory.UserDaoFactory;
import cn.hncu.bookStore.user.vo.UserModel;
import cn.hncu.bookStore.user.vo.UserQueryModel;
public class UserEbo implements UserEbi{
private UserDao dao = UserDaoFactory.getUserDao();
@Override
public boolean create(UserModel user) {
return dao.create(user);
}
@Override
public boolean delete(String uuid) {
return dao.delete(uuid);
}
@Override
public boolean update(UserModel user) {
return dao.update(user);
}
@Override
public List getAll() {
return dao.getAll();
}
@Override
public List getbyCondition(UserQueryModel uqm) {
// TODO Auto-generated method stub
return null;
}
@Override
public UserModel getSingle(String uuid) {
return dao.getSingle(uuid);
}
}
UserEbiFactory类:
cn.hncu.bookStore.user.business.factory;
UserEbiFactory类:
package cn.hncu.bookStore.user.business.factory;
import cn.hncu.bookStore.user.business.ebi.UserEbi;
import cn.hncu.bookStore.user.business.ebo.UserEbo;
public class UserEbiFactory {
public static UserEbi getUserEbi(){
return new UserEbo();
}
}
UserDao接口:
cn.hncu.bookStore.user.dao.dao;
UserDao接口:
package cn.hncu.bookStore.user.dao.dao;
import java.util.List;
import cn.hncu.bookStore.user.vo.UserModel;
import cn.hncu.bookStore.user.vo.UserQueryModel;
public interface UserDao {
public boolean create(UserModel user);
public boolean delete(String uuid);
public boolean update(UserModel user);
public List getAll();
public List getbyCondition(UserQueryModel uqm);
public UserModel getSingle(String uuid);
}
UserDaoFactory类:
cn.hncu.bookStore.user.dao.factory;
UserDaoFactory类:
package cn.hncu.bookStore.user.dao.factory;
import cn.hncu.bookStore.user.dao.dao.UserDao;
import cn.hncu.bookStore.user.dao.impl.UserDaoSerImpl;
public class UserDaoFactory {
public static UserDao getUserDao(){
return new UserDaoSerImpl();
}
}
UserDaoSerImpl类:
cn.hncu.bookStore.user.dao.impl;
UserDaoSerImpl类:
package cn.hncu.bookStore.user.dao.impl;
import java.util.ArrayList;
import java.util.List;
import cn.hncu.bookStore.user.dao.dao.UserDao;
import cn.hncu.bookStore.user.vo.UserModel;
import cn.hncu.bookStore.user.vo.UserQueryModel;
import cn.hncu.bookStore.util.FileIoUtil;
public class UserDaoSerImpl implements UserDao {
private static final String FILE_NAME = "User.txt";
@Override
public boolean create(UserModel user) {
// 1先把已有的数据反序列化(读)出来
List list = FileIoUtil.readFormFile(FILE_NAME);
// 2判断该用户是否已经存在,再决定是否创建
for (UserModel userModel : list) {
// 如果2个用户的uuid相等,用户就是相同的
if (userModel.getUuid().equals(user.getUuid())) {
return false;// 用户已经存在了,返回false
}
}
// 3如果用户不存在,就创建
list.add(user);
FileIoUtil.write2file(list, FILE_NAME);
return true;// 创建成功,返回true
}
@Override
public boolean delete(String uuid) {
// 1先把已有的数据反序列化(读)出来
List list = FileIoUtil.readFormFile(FILE_NAME);
// 2判断该用户是否已经存在,再决定是否删除
// for(int i=0;i list = FileIoUtil.readFormFile(FILE_NAME);
// 2判断该用户是否已经存在,再决定是否创建
for (int i = 0; i < list.size(); i++) {
// uuid是不能改的,通过uuid来找到那个用户数据,再修改就ok了
if (list.get(i).getUuid().equals(user.getUuid())) {
// 将找到的用户修改成user
list.set(i, user);
FileIoUtil.write2file(list, FILE_NAME);
// 找到用户,返回true
return true;
}
}
// 3若该用户不存在,则修改失败
return false;
}
@Override
public List getAll() {
return FileIoUtil.readFormFile(FILE_NAME);
}
@Override
public List getbyCondition(UserQueryModel uqm) {
// TODO Auto-generated method stub
return null;
}
@Override
public UserModel getSingle(String uuid) {
// 1先把已有的数据反序列化(读)出来
List list = FileIoUtil.readFormFile(FILE_NAME);
// 2判断该用户是否已经存在,存在就返回那个用户
for (int i = 0; i < list.size(); i++) {
if (list.get(i).getUuid().equals(uuid)) {
return list.get(i);
}
}
// 3若该用户不存在,返回null
return null;
}
}
AddPanel类:
cn.hncu.bookStore.user.ui;
AddPanel类:
package cn.hncu.bookStore.user.ui;
import javax.swing.Jframe;
import javax.swing.JOptionPane;
import cn.hncu.bookStore.common.UserTypeEnum;
import cn.hncu.bookStore.user.business.ebi.UserEbi;
import cn.hncu.bookStore.user.business.factory.UserEbiFactory;
import cn.hncu.bookStore.user.vo.UserModel;
import cn.hncu.bookStore.util.FileIoUtil;
public class AddPanel extends javax.swing.JPanel {
private Jframe mainframe = null;
public AddPanel(Jframe mainframe) {
this.mainframe = mainframe;
initComponents();
myInitData();
}
private void myInitData() {
for (UserTypeEnum type : UserTypeEnum.values()) {
combType.addItem(type.getName());
}
}
//GEN-BEGIN:initComponents
//
private void initComponents() {
jLabel1 = new javax.swing.JLabel();
jLabel2 = new javax.swing.JLabel();
tfdName = new javax.swing.JTextField();
jLabel3 = new javax.swing.JLabel();
tfdUuid = new javax.swing.JTextField();
jLabel4 = new javax.swing.JLabel();
tfdPwd2 = new javax.swing.JPasswordField();
jLabel5 = new javax.swing.JLabel();
jLabel6 = new javax.swing.JLabel();
combType = new javax.swing.JComboBox();
tfdPwd = new javax.swing.JPasswordField();
btnAdd = new javax.swing.JButton();
btnBack = new javax.swing.JButton();
setMinimumSize(new java.awt.Dimension(800, 600));
setLayout(null);
jLabel1.setFont(new java.awt.Font("微软雅黑", 1, 48));
jLabel1.setForeground(new java.awt.Color(204, 0, 0));
jLabel1.setText("u6dfbu52a0u7528u6237");
add(jLabel1);
jLabel1.setBounds(270, 30, 230, 80);
jLabel2.setFont(new java.awt.Font("微软雅黑", 0, 18));
jLabel2.setText("u7528u6237u7c7bu578b:");
add(jLabel2);
jLabel2.setBounds(40, 310, 90, 30);
tfdName.setFont(new java.awt.Font("Dialog", 1, 18));
tfdName.setAutoscrolls(false);
add(tfdName);
tfdName.setBounds(420, 160, 120, 30);
jLabel3.setFont(new java.awt.Font("微软雅黑", 0, 18));
jLabel3.setText("uuid:");
add(jLabel3);
jLabel3.setBounds(70, 160, 50, 30);
tfdUuid.setFont(new java.awt.Font("Dialog", 0, 11));
add(tfdUuid);
tfdUuid.setBounds(140, 160, 110, 30);
jLabel4.setFont(new java.awt.Font("微软雅黑", 0, 18));
jLabel4.setText("u59d3u540d:");
add(jLabel4);
jLabel4.setBounds(360, 160, 50, 30);
add(tfdPwd2);
tfdPwd2.setBounds(420, 240, 170, 30);
jLabel5.setFont(new java.awt.Font("微软雅黑", 0, 18));
jLabel5.setText("u5bc6u7801:");
add(jLabel5);
jLabel5.setBounds(70, 240, 50, 30);
jLabel6.setFont(new java.awt.Font("微软雅黑", 0, 18));
jLabel6.setText("u786eu8ba4u5bc6u7801:");
add(jLabel6);
jLabel6.setBounds(330, 240, 90, 30);
combType.setFont(new java.awt.Font("Dialog", 1, 18));
combType.setForeground(new java.awt.Color(51, 51, 255));
combType.setModel(new javax.swing.DefaultComboBoxModel(
new String[] { "请选择..." }));
add(combType);
combType.setBounds(140, 310, 160, 30);
tfdPwd.setFont(new java.awt.Font("宋体", 1, 18));
add(tfdPwd);
tfdPwd.setBounds(140, 240, 160, 30);
btnAdd.setFont(new java.awt.Font("Dialog", 1, 24));
btnAdd.setForeground(new java.awt.Color(0, 204, 204));
btnAdd.setText("u6dfbu52a0");
btnAdd.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
btnAddActionPerformed(evt);
}
});
add(btnAdd);
btnAdd.setBounds(140, 430, 120, 60);
btnBack.setFont(new java.awt.Font("Dialog", 1, 24));
btnBack.setForeground(new java.awt.Color(0, 204, 204));
btnBack.setText("u8fd4u56de");
btnBack.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
btnBackActionPerformed(evt);
}
});
add(btnBack);
btnBack.setBounds(470, 430, 120, 60);
}//
//GEN-END:initComponents
private void back() {
mainframe.setContentPane(new ListPanel(mainframe));
mainframe.validate();
}
private void btnBackActionPerformed(java.awt.event.ActionEvent evt) {
back();
}
private void btnAddActionPerformed(java.awt.event.ActionEvent evt) {
//1收集参数
String uuid = tfdUuid.getText();
String name = tfdName.getText();
String pwd = new String(tfdPwd.getPassword());
String pwd2 = new String(tfdPwd2.getPassword());
if (!pwd.equals(pwd2)) {
JOptionPane.showMessageDialog(null, "两次密码输入不一致,请重新输入!");
return;
}
int type = 0;
try {
type = UserTypeEnum.getTypeByName(combType.getSelectedItem()
.toString());
} catch (Exception e) {
JOptionPane.showMessageDialog(null, "请指定用户类型!");
return;
}
//2组织参数
UserModel user = new UserModel();
user.setName(name);
user.setPwd(pwd);
user.setType(type);
user.setUuid(uuid);
//3调用逻辑层
UserEbi ebi = UserEbiFactory.getUserEbi();
//4根据调用返回结果导向不同页面
if (ebi.create(user)) {
back();
} else {
JOptionPane.showMessageDialog(null, "该用户已经存在!");
}
}
//GEN-BEGIN:variables
// Variables declaration - do not modify
private javax.swing.JButton btnAdd;
private javax.swing.JButton btnBack;
private javax.swing.JComboBox combType;
private javax.swing.JLabel jLabel1;
private javax.swing.JLabel jLabel2;
private javax.swing.JLabel jLabel3;
private javax.swing.JLabel jLabel4;
private javax.swing.JLabel jLabel5;
private javax.swing.JLabel jLabel6;
private javax.swing.JTextField tfdName;
private javax.swing.JPasswordField tfdPwd;
private javax.swing.JPasswordField tfdPwd2;
private javax.swing.JTextField tfdUuid;
// End of variables declaration//GEN-END:variables
}
ListPanel类:
cn.hncu.bookStore.user.ui;
ListPanel类:
package cn.hncu.bookStore.user.ui;
import java.util.List;
import javax.swing.Jframe;
import cn.hncu.bookStore.user.business.ebi.UserEbi;
import cn.hncu.bookStore.user.business.factory.UserEbiFactory;
import cn.hncu.bookStore.user.vo.UserModel;
public class ListPanel extends javax.swing.JPanel {
private Jframe mainframe = null;
public ListPanel(Jframe mainframe) {
this.mainframe = mainframe;
initComponents();
myInitData();
}
private void myInitData() {
UserEbi user = UserEbiFactory.getUserEbi();
List list = user.getAll();
userLists.setListData(list.toArray());
}
//GEN-BEGIN:initComponents
//
private void initComponents() {
jScrollPane1 = new javax.swing.JScrollPane();
userLists = new javax.swing.JList();
jLabel1 = new javax.swing.JLabel();
btnToAdd = new javax.swing.JButton();
setMinimumSize(new java.awt.Dimension(800, 600));
setLayout(null);
userLists.setModel(new javax.swing.AbstractListModel() {
String[] strings = { "" };
public int getSize() {
return strings.length;
}
public Object getElementAt(int i) {
return strings[i];
}
});
jScrollPane1.setViewportView(userLists);
add(jScrollPane1);
jScrollPane1.setBounds(150, 150, 480, 230);
jLabel1.setFont(new java.awt.Font("Tahoma", 1, 48));
jLabel1.setForeground(new java.awt.Color(204, 0, 51));
jLabel1.setText("User List");
add(jLabel1);
jLabel1.setBounds(270, 30, 260, 80);
btnToAdd.setFont(new java.awt.Font("Dialog", 1, 18));
btnToAdd.setText("u6dfbu52a0u7528u6237");
btnToAdd.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
btnToAddActionPerformed(evt);
}
});
add(btnToAdd);
btnToAdd.setBounds(60, 420, 150, 50);
}//
//GEN-END:initComponents
private void btnToAddActionPerformed(java.awt.event.ActionEvent evt) {
mainframe.setContentPane(new AddPanel(mainframe));
mainframe.validate();
}
//GEN-BEGIN:variables
// Variables declaration - do not modify
private javax.swing.JButton btnToAdd;
private javax.swing.JLabel jLabel1;
private javax.swing.JScrollPane jScrollPane1;
private javax.swing.JList userLists;
// End of variables declaration//GEN-END:variables
}
UserModel类:
cn.hncu.bookStore.user.vo;
UserModel类:
用户值对象模块:
package cn.hncu.bookStore.user.vo;
import java.io.Serializable;
import cn.hncu.bookStore.common.UserTypeEnum;
public class UserModel implements Serializable{
private String uuid;//用户唯一标识码
private String name;//用户名
private int type;//用户类型
private String pwd;//用户密码
public UserModel() {
}
public String getUuid() {
return uuid;
}
public void setUuid(String uuid) {
this.uuid = uuid;
}
public String getName() {
return name;
}
public void setName(String name) {
this.name = name;
}
public int getType() {
return type;
}
public void setType(int type) {
this.type = type;
}
public String getPwd() {
return pwd;
}
public void setPwd(String pwd) {
this.pwd = pwd;
}
@Override
public int hashCode() {
final int prime = 31;
int result = 1;
result = prime * result + ((uuid == null) ? 0 : uuid.hashCode());
return result;
}
@Override
public boolean equals(Object obj) {
if (this == obj)
return true;
if (obj == null)
return false;
if (getClass() != obj.getClass())
return false;
UserModel other = (UserModel) obj;
if (uuid == null) {
if (other.uuid != null)
return false;
} else if (!uuid.equals(other.uuid))
return false;
return true;
}
@Override
public String toString() {
return uuid + "," + name + "," + UserTypeEnum.getNameByType(type);
}
}
UserQueryModel类:
cn.hncu.bookStore.user.vo;
UserQueryModel类:
虽然没有代码,但不能不写!这是查找用户时需要的。
原因我在系列一写了。
package cn.hncu.bookStore.user.vo;
public class UserQueryModel extends UserModel{
}
FileIoUtil类:
cn.hncu.bookStore.util;
FileIoUtil类:
package cn.hncu.bookStore.util;
import java.io.File;
import java.io.FileInputStream;
import java.io.FileNotFoundException;
import java.io.FileOutputStream;
import java.io.IOException;
import java.io.ObjectInputStream;
import java.io.ObjectOutputStream;
import java.util.ArrayList;
import java.util.List;
import javax.swing.JOptionPane;
public class FileIoUtil {
public FileIoUtil() {
}
@SuppressWarnings("unchecked")//压警告
public static List readFormFile(String fileName){
List list = new ArrayList();
final File file = new File(fileName);
ObjectInputStream in =null;
if(!file.exists()){
//JOptionPane.showMessageDialog(null, "数据表不存在!");
return list;
}
try {
in = new ObjectInputStream(new FileInputStream(fileName));
try {
list = (List) in.readObject();
} catch (ClassNotFoundException e) {
e.printStackTrace();
}
} catch (FileNotFoundException e) {
e.printStackTrace();
} catch (IOException e) {
e.printStackTrace();
}finally{
if(in!=null){
try {
in.close();
} catch (IOException e) {
throw new RuntimeException("数据库关闭失败");
}
}
}
return list;
}
public static void write2file(List list, String fileName){
ObjectOutputStream out = null;
try {
out = new ObjectOutputStream(new FileOutputStream(fileName));
out.writeObject(list);
} catch (FileNotFoundException e) {
e.printStackTrace();
} catch (IOException e) {
e.printStackTrace();
}finally{
if(out!=null){
try {
out.close();
} catch (IOException e) {
throw new RuntimeException("数据库关闭失败!");
}
}
}
}
}
BookStore类:(含main方法)
cn.hncu.bookStore;
BookStore类:
用户模块的main方法在这个类中:
package cn.hncu.bookStore;
import cn.hncu.bookStore.user.ui.ListPanel;
public class BookStore extends javax.swing.Jframe {
public BookStore() {
initComponents();
this.setContentPane(new ListPanel(this));
this.setResizable(false);//不能缩放
this.setDefaultCloseOperation(EXIT_ON_CLOSE);
}
//GEN-BEGIN:initComponents
//
private void initComponents() {
menuBar = new javax.swing.JMenuBar();
fileMenu = new javax.swing.JMenu();
openMenuItem = new javax.swing.JMenuItem();
saveMenuItem = new javax.swing.JMenuItem();
saveAsMenuItem = new javax.swing.JMenuItem();
exitMenuItem = new javax.swing.JMenuItem();
editMenu = new javax.swing.JMenu();
cutMenuItem = new javax.swing.JMenuItem();
copyMenuItem = new javax.swing.JMenuItem();
pasteMenuItem = new javax.swing.JMenuItem();
deleteMenuItem = new javax.swing.JMenuItem();
helpMenu = new javax.swing.JMenu();
contentsMenuItem = new javax.swing.JMenuItem();
aboutMenuItem = new javax.swing.JMenuItem();
setDefaultCloseOperation(javax.swing.WindowConstants.EXIT_ON_CLOSE);
setMinimumSize(new java.awt.Dimension(800, 600));
fileMenu.setText("File");
openMenuItem.setText("Open");
fileMenu.add(openMenuItem);
saveMenuItem.setText("Save");
fileMenu.add(saveMenuItem);
saveAsMenuItem.setText("Save As ...");
fileMenu.add(saveAsMenuItem);
exitMenuItem.setText("Exit");
exitMenuItem.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
exitMenuItemActionPerformed(evt);
}
});
fileMenu.add(exitMenuItem);
menuBar.add(fileMenu);
editMenu.setText("Edit");
cutMenuItem.setText("Cut");
editMenu.add(cutMenuItem);
copyMenuItem.setText("Copy");
editMenu.add(copyMenuItem);
pasteMenuItem.setText("Paste");
editMenu.add(pasteMenuItem);
deleteMenuItem.setText("Delete");
editMenu.add(deleteMenuItem);
menuBar.add(editMenu);
helpMenu.setText("Help");
contentsMenuItem.setText("Contents");
helpMenu.add(contentsMenuItem);
aboutMenuItem.setText("about");
helpMenu.add(aboutMenuItem);
menuBar.add(helpMenu);
setJMenuBar(menuBar);
javax.swing.GroupLayout layout = new javax.swing.GroupLayout(
getContentPane());
getContentPane().setLayout(layout);
layout.setHorizontalGroup(layout.createParallelGroup(
javax.swing.GroupLayout.Alignment.LEADING).addGap(0, 400,
Short.MAX_VALUE));
layout.setVerticalGroup(layout.createParallelGroup(
javax.swing.GroupLayout.Alignment.LEADING).addGap(0, 279,
Short.MAX_VALUE));
pack();
}//
//GEN-END:initComponents
private void exitMenuItemActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_exitMenuItemActionPerformed
System.exit(0);
}//GEN-LAST:event_exitMenuItemActionPerformed
public static void main(String args[]) {
java.awt.EventQueue.invokeLater(new Runnable() {
public void run() {
new BookStore().setVisible(true);
}
});
}
//GEN-BEGIN:variables
// Variables declaration - do not modify
private javax.swing.JMenuItem aboutMenuItem;
private javax.swing.JMenuItem contentsMenuItem;
private javax.swing.JMenuItem copyMenuItem;
private javax.swing.JMenuItem cutMenuItem;
private javax.swing.JMenuItem deleteMenuItem;
private javax.swing.JMenu editMenu;
private javax.swing.JMenuItem exitMenuItem;
private javax.swing.JMenu fileMenu;
private javax.swing.JMenu helpMenu;
private javax.swing.JMenuBar menuBar;
private javax.swing.JMenuItem openMenuItem;
private javax.swing.JMenuItem pasteMenuItem;
private javax.swing.JMenuItem saveAsMenuItem;
private javax.swing.JMenuItem saveMenuItem;
// End of variables declaration//GEN-END:variables
}
今天就写到这里的,未完待续。。。
目前的添加有一个小bug,就是添加用户时,什么都不输入,
只选择用户类型,也能创建!下次我会修复的。
以上就是本文的全部内容,希望对大家的学习有所帮助,也希望大家多多支持考高分网。
