此功能相当于给系统加了个令牌，只有输入对的一组数字才可以验证成功。类似于QQ令牌一样。
一丶创建最核心的一个类GoogleAuthenticator此类包含了生成密钥，验证，将绑定密钥转为二维码。
public class GoogleAuthenticator
{
private readonly static DateTime _epoch = new DateTime(1970, 1, 1, 0, 0, 0, DateTimeKind.Utc);
private TimeSpan DefaultClockDriftTolerance { get; set; }
public GoogleAuthenticator()
{
DefaultClockDriftTolerance = TimeSpan.FromMinutes(5);
}
///
/// Generate a setup code for a Google Authenticator user to scan
///
/// Issuer ID (the name of the system, i.e. 'MyApp'), can be omitted but not recommended https://github.com/google/google-authenticator/wiki/Key-Uri-Format
/// Account Title (no spaces)
/// Account Secret Key
/// Number of pixels per QR Module (2 pixels give ~ 100x100px QRCode)
/// SetupCode object
public SetupCode GenerateSetupCode(string issuer, string accountTitleNoSpaces, string accountSecretKey, int QRPixelsPerModule)
{
byte[] key = Encoding.UTF8.GetBytes(accountSecretKey);
return GenerateSetupCode(issuer, accountTitleNoSpaces, key, QRPixelsPerModule);
}
///
/// Generate a setup code for a Google Authenticator user to scan
///
/// Issuer ID (the name of the system, i.e. 'MyApp'), can be omitted but not recommended https://github.com/google/google-authenticator/wiki/Key-Uri-Format
/// Account Title (no spaces)
/// Account Secret Key as byte[]
/// Number of pixels per QR Module (2 = ~120x120px QRCode)
/// SetupCode object
public SetupCode GenerateSetupCode(string issuer, string accountTitleNoSpaces, byte[] accountSecretKey, int QRPixelsPerModule)
{
if (accountTitleNoSpaces == null) { throw new NullReferenceException("Account Title is null"); }
accountTitleNoSpaces = RemoveWhitespace(accountTitleNoSpaces);
string encodedSecretKey = base32Encoding.ToString(accountSecretKey);
string provisionUrl = null;
provisionUrl = String.Format("otpauth://totp/{2}:{0}?secret={1}&issuer={2}", accountTitleNoSpaces, encodedSecretKey.Replace("=",""), UrlEncode(issuer));
using (QRCodeGenerator qrGenerator = new QRCodeGenerator())
using (QRCodeData qrCodeData = qrGenerator.CreateQrCode(provisionUrl, QRCodeGenerator.ECCLevel.M))
using (QRCode qrCode = new QRCode(qrCodeData))
using (Bitmap qrCodeImage = qrCode.GetGraphic(QRPixelsPerModule))
using (MemoryStream ms = new MemoryStream())
{
qrCodeImage.Save(ms, System.Drawing.Imaging.ImageFormat.Png);
}
}
private static string RemoveWhitespace(string str)
{
return new string(str.Where(c => !Char.IsWhiteSpace(c)).ToArray());
}
private string UrlEncode(string value)
{
StringBuilder result = new StringBuilder();
string validChars = "abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789-_.~";
foreach (char symbol in value)
{
if (validChars.IndexOf(symbol) != -1)
{
result.Append(symbol);
}
else
{
result.Append('%' + String.Format("{0:X2}", (int)symbol));
}
}
return result.ToString().Replace(" ", "%20");
}
public string GeneratePINAtInterval(string accountSecretKey, long counter, int digits = 6)
{
return GenerateHashedCode(accountSecretKey, counter, digits);
}
internal string GenerateHashedCode(string secret, long iterationNumber, int digits = 6)
{
byte[] key = Encoding.UTF8.GetBytes(secret);
return GenerateHashedCode(key, iterationNumber, digits);
}
internal string GenerateHashedCode(byte[] key, long iterationNumber, int digits = 6)
{
byte[] counter = BitConverter.GetBytes(iterationNumber);
if (BitConverter.IsLittleEndian)
{
Array.Reverse(counter);
}
HMACSHA1 hmac = new HMACSHA1(key);
byte[] hash = hmac.ComputeHash(counter);
int offset = hash[hash.Length - 1] & 0xf;
// Convert the 4 bytes into an integer, ignoring the sign.
int binary =
((hash[offset] & 0x7f) << 24)
| (hash[offset + 1] << 16)
| (hash[offset + 2] << 8)
| (hash[offset + 3]);
int password = binary % (int)Math.Pow(10, digits);
return password.ToString(new string('0', digits));
}
private long GetCurrentCounter()
{
return GetCurrentCounter(DateTime.UtcNow, _epoch, 30);
}
private long GetCurrentCounter(DateTime now, DateTime epoch, int timeStep)
{
return (long)(now - epoch).TotalSeconds / timeStep;
}
public bool ValidateTwoFactorPIN(string accountSecretKey, string twoFactorCodeFromClient)
{
return ValidateTwoFactorPIN(accountSecretKey, twoFactorCodeFromClient, DefaultClockDriftTolerance);
}
public bool ValidateTwoFactorPIN(string accountSecretKey, string twoFactorCodeFromClient, TimeSpan timeTolerance)
{
var codes = GetCurrentPINs(accountSecretKey, timeTolerance);
return codes.Any(c => c == twoFactorCodeFromClient);
}
public string[] GetCurrentPINs(string accountSecretKey, TimeSpan timeTolerance)
{
List codes = new List();
long iterationCounter = GetCurrentCounter();
int iterationOffset = 0;
if (timeTolerance.TotalSeconds > 30)
{
iterationOffset = Convert.ToInt32(timeTolerance.TotalSeconds / 30.00);
}
long iterationStart = iterationCounter - iterationOffset;
long iterationEnd = iterationCounter + iterationOffset;
for (long counter = iterationStart; counter <= iterationEnd; counter++)
{
codes.Add(GeneratePINAtInterval(accountSecretKey, counter));
}
return codes.ToArray();
}
}
其中GenerateSetupCode 这个方法是用于把绑定的密钥直接转成二维码图片，然后再转成base64图片 输出再页面上，这样在APP上直接用扫一扫即可绑定。
二丶由于生成的密钥不可以直接使用，需要进行base32进行编码。下面是base32Encoding类
public class base32Encoding
{
///
/// base32 encoded string to byte[]
///
/// base32 encoded string
/// byte[]
public static byte[] ToBytes(string input)
{
if (string.IsNullOrEmpty(input))
{
throw new ArgumentNullException("input");
}
input = input.TrimEnd('='); //remove padding characters
int byteCount = input.Length * 5 / 8; //this must be TRUNCATED
byte[] returnArray = new byte[byteCount];
byte curByte = 0, bitsRemaining = 8;
int mask = 0, arrayIndex = 0;
foreach (char c in input)
{
int cValue = CharToValue(c);
if (bitsRemaining > 5)
{
mask = cValue << (bitsRemaining - 5);
curByte = (byte)(curByte | mask);
bitsRemaining -= 5;
}
else
{
mask = cValue >> (5 - bitsRemaining);
curByte = (byte)(curByte | mask);
returnArray[arrayIndex++] = curByte;
curByte = (byte)(cValue << (3 + bitsRemaining));
bitsRemaining += 3;
}
}
//if we didn't end with a full byte
if (arrayIndex != byteCount)
{
returnArray[arrayIndex] = curByte;
}
return returnArray;
}
///
/// byte[] to base32 string, if starting from an ordinary string use Encoding.UTF8.GetBytes() to convert it to a byte[]
///
/// byte[] of data to be base32 encoded
/// base32 String
public static string ToString(byte[] input)
{
if (input == null || input.Length == 0)
{
throw new ArgumentNullException("input");
}
int charCount = (int)Math.Ceiling(input.Length / 5d) * 8;
char[] returnArray = new char[charCount];
byte nextChar = 0, bitsRemaining = 5;
int arrayIndex = 0;
foreach (byte b in input)
{
nextChar = (byte)(nextChar | (b >> (8 - bitsRemaining)));
returnArray[arrayIndex++] = ValueToChar(nextChar);
if (bitsRemaining < 4)
{
nextChar = (byte)((b >> (3 - bitsRemaining)) & 31);
returnArray[arrayIndex++] = ValueToChar(nextChar);
bitsRemaining += 5;
}
bitsRemaining -= 3;
nextChar = (byte)((b << bitsRemaining) & 31);
}
//if we didn't end with a full char
if (arrayIndex != charCount)
{
returnArray[arrayIndex++] = ValueToChar(nextChar);
while (arrayIndex != charCount) returnArray[arrayIndex++] = '='; //padding
}
return new string(returnArray);
}
private static int CharToValue(char c)
{
int value = (int)c;
//65-90 == uppercase letters
if (value < 91 && value > 64)
{
return value - 65;
}
//50-55 == numbers 2-7
if (value < 56 && value > 49)
{
return value - 24;
}
//97-122 == lowercase letters
if (value < 123 && value > 96)
{
return value - 97;
}
throw new ArgumentException("Character is not a base32 character.", "c");
}
private static char ValueToChar(byte b)
{
if (b < 26)
{
return (char)(b + 65);
}
if (b < 32)
{
return (char)(b + 24);
}
throw new ArgumentException("Byte is not a value base32 value.", "b");
}
}
三丶主程序里面直接调用方法
private SetupCode Google(string key, string Guids)
{
GoogleAuthenticator gat = new GoogleAuthenticator();
return gat.GenerateSetupCode("Supported Giving", key, Guids, 5);
}
//key系统的账号，Guid是进行加密的字符串，要求唯一，不然密钥会重复，所以这里使用Guid. 2为二维码的大小约120x120px。
SetupCode结果类为
public class SetupCode
{
public string Account { get; internal set; }
public string AccountSecretKey { get; internal set; }
public string ManualEntryKey { get; internal set; }
///
/// base64-encoded PNG image
///
public string QrCodeSetupImageUrl { get; internal set; }
}
ManualEntryKey 是手机绑定的密钥。如果想手动输入密钥绑定就使用此字符串。
QrCodeSetupImageUrl 是将密钥转成的二维码图片
下载这个APP
进入APP后直接绑定，就会出现一下界面,即为绑定成功，然后我们就可以使用此令牌验证了。
验证方法
//Guids 之前生成密钥的字符，此时当做唯一键来查询，CheckCode为手机上动态的6位验证吗。校验成功会返回true
GoogleAuthenticator gat = new GoogleAuthenticator();
var result = gat.ValidateTwoFactorPIN(parameters["Guids"].ToString(), parameters["CheckCode"].ToString());
if (result)
{
return "True";
}
else
{
return "False";
}
这样功能就完成了。
